2A22O2000000Wireless Lighting Control System

AUTONOMY SENSOR DATASHEET Subject to change without notice VERSION 01 TABLE OF CONTENTS OVERVIEW 3 SPECIFICATIONS 4 ISED & FCC COMPLIANCE STATEMENT 20 Subject to change without notice VERSION 01 OVERVIEW AUTONOMY SENSOR 3 The JDRF Autonomy Sensor is a luminaire mounted ALC device that performs all sensing, control and configuration functions to provides a complete lighting control system. DECENTRALIZED SYSTEM Autonomy Sensors automatically build a secure Bluetooth Mesh network using multi-factor authentication and without any user involvement. Autonomy Sensors message each other without the use of intermediary of control hardware. Each Autonomy Sensor is an independent decision making entity that runs advanced lighting strategies using a built-in rules based engine. As a system, Autonomy Sensors coordinate the response to sev- eral simultaneous types of inputs, such as motion, daylight, user overrides and messages from 3rd party building automation systems. AUTONOMOUS GROUPING The Autonomy Sensor relies on temporal and spatial data generated by the motion patterns of the building occupants, natural daylight distribution patterns and the physical arrange- ment of light fixtures to automatically con- figure all groups. Machine learning and Near Infrared (NIR) localization technology under- pin the configuration of motion, daylight and wall switch groups. Each group configuration complies with ASHRAE regulations and does not require any programming before, during or after installation. Grouping is dynamic, auto- matically in adapting to changes in the layout of the space, and addition/removal of new devices. Autonomous Lighting Control (ALC) is the evolution of Smart Lighting (SL) for commercial buildings. ALC provides all of the advanced SL energy conservation, facility management and user access capabilities but is effortless to deploy, adapts to changes and continually improves its performance over time. ALC is built on three technology platforms: AI, edge-com- puting and data-fusion. These technologies work together to eliminate all design, setup and mainte- nance work, remove the need for physical control infrastructure, improve motion detection accuracy and lower energy consumption. Subject to change without notice VERSION 01 SPECIFICATIONS AUTONOMY SENSOR 4 FEATURES Daylight Groups are automatically defined based on the similarity of ambient lighting conditions among neighboring Autonomy Sensors. NIR localization en- sures that only devices that are in the same room are candidates for grouping. The grouping is dynamic, automatically adapting to changes in the layout of the space, and addition/removal of new devices. Motion Groups are automatically defined based on the similarity of motion patterns detected by neighboring Autonomy Sensors. NIR localization ensures that only devices that are in the same room are candidates for grouping. The grouping is dynamic, automatically adapting to changes in the layout of the space, and addition/removal of new devices. Wall Switch Groups are automatically defined based on the physical arrange- ment of light fixtures equipped with an Autonomy Sensor. NIR localization is used to determine the number of light fixtures within a room and their spatial arrangement to within 50 cm. Subject to change without notice VERSION 01 SPECIFICATIONS AUTONOMY SENSOR 5 FEATURES Motion Detection is performed with NIR that is reflected as an occupant passes through the field of view. The coverage area does not have blind-spots and there are no distance restrictions for placement near HVAC vents. The Autonomy Sensor leverages Machine Learning to reduce the number of false trips and improve detection accuracy. Decentralized System Architecture allows Autonomy Sensors to message each other directly and eliminate the design and installation effort associated with control hardware. Each Autonomy Sensor runs a local rules based engine to re- solve contention among several types of inputs (motion, daylight, wall switch- es, mobile devices, 3rd party systems). Network Build Automatically and securely builds and joins Bluetooth Mesh using multi-factor authentication that ensures only authorized devices join the network. Subject to change without notice VERSION 01 SPECIFICATIONS AUTONOMY SENSOR 6 AC Line Voltage Luminaire Compatible LED Driver LED Autonomy Sensor Notes Line voltage connects to LED driver. Lighting Groups are independant of power distribution. Linear and compact form factor luminaires are supported. LED Driver powers the Autonomy Sensor. See pg. 8 for a list of compatible LED drivers. Refer to LED driver datasheet for specifications of compatible LED illumination sources. Autonomy Sensor can be mounted to luminaire, electrical box or ceiling. Connect 0-10V LED drivers with Bridge. See pg. 8 for a list of compatible Bridge. Connect 0-10V LED drivers with Bridge. See pg. 8 for a list of compatible Bridge. JDRF Touch Screen (see pg. 15) JDRF Controlled Receptacle (see pg. 20) 0-10V Bridge 0-10V LED Driver JDRF Touch Screen JDRF Controlled Receptacle 1 1 2 3 4 5 6 7 8 9 2 3 4 5 6 7 8 9 SYSTEM Application Architecture is decentralized and eliminates the need for lighting control panels or distributed room controllers. The full system consists of the Autonomy Sensor, compatible LED driver or Bridge, wall switches and con- trolled receptacles. Subject to change without notice VERSION 01 SPECIFICATIONS AUTONOMY SENSOR 7 MOTION DETECTION & GROUPING Detection Technology Near Infrared (NIR) Number Detection Zones 900 (30 x 30) Accuracy F1-Score of 0.999 Coverage Area Top view illustrated below at rated heights below Major and Minor motion defined according to NEMA WD-7-2011 Hold Time 20 minute default, auto-adjusts down to 5 min Occupancy Level Default of 50% (as per ASHRAE 90.1 section 9.4) Vacancy Level Default of 0% (as per ASHRAE 90.1 section 9.4) Group Configuration Automatic and adaptive (no design or setup required) Height: Ɩ [ ņ Ƒ.ƕ m Coverage Area 324 ft2 / 30.1 …

Text truncated - open the document above for the full version.

August 17, 2022 Nemko North America, Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 REQUEST FOR CONFIDENTIALITY - FCC FCC ID: 2A22O2000000 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules and FCC Guidance document 726920, we hereby request confidential treatment of information accompanying this application as outlined below: PERMANENT LONG-TERM CONFIDENTIALITY: Schematics Bill of Materials/Parts List Block Diagrams Theory of Operation SHORT TERM CONFIDENTIALITY FOR A PERIOD OF 100 DAYS: Internal Photos External Photos User Manual Test Set-up Photographs When the device is marketed before the requested number of days listed above, the grantee will inform the TCB to release the Short-Term Confidentiality information withheld on the FCC equipment authorization website. The above information contains trade secrets and proprietary information not customarily released to the public. The public disclosure of this information might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Sincerely, Signed: Printed name: Elias Boukhers Title: Chief Technology Officer

Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent FCC On our behalf, I appoint Spencer Zhong of Nemko Canada, Inc. 303 River Road, Ottawa, Ontario, Canada K1V 1H2, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in FCC regulations will have affixed to it a label identical to that submitted for approval with this application. In signing this letter, Applicant certifies that neither the applicant nor any party to the application is not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides JDRF Electromag Engineering Inc., at 31 Lakeshore Road East, unit 302, Mississauga, Ontario, L5G4V5 Dated this 17th Day of August 20 22 Agency agreement expiration date: August 17, 2023 By: Elias Boukhers Signature Printed Title: Chief Technology Officer Telephone: 905 483 6761 On behalf of: JDRF Electromag Engineering Inc.

Autonomy Sensor Version 2000000 Input Voltage: Class 2 Input (12-24 VDC) Input Current: 55 mA (maximum) Temperature: 32ºF - 122º F / 0ºC - 50ºC Humidity: 0% - 90% (non-condensing) Environment: Dry indoor use only Patents & Wiring: Scan QR Code Part 351 D E520724 FCC ID: 2A22O2000000 ISED ID: 24973-2000000

Label placement diagram

AEC-Q200 Qualification Available New Global P/N 2450AT18D0100001 Legacy P/N 2450AT18D0100 Detail Specification: Page 1 of 7 Top Bottom ¹Efficiency measured on Johanson's evaluation board PN 2450AT18D0100001CE1 No. ±± 1 ±± 2 ±± 3 4 ±± Function 1: Antenna fed from left Function 2: Antenna fed from right https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver. 4.4 2021 Johanson Technology, Inc. All Rights Reserved Frequency (GHz) Peak Gain (dBi) Average Gain (dBi) Radiated Efficiency¹ 2.4 - 2.5 1.5 typ. (XZ-total) -1.0 typ. (XZ-total) 72% Humidity 45 - 75% RH 50 3 max. (CW) -40 to +125°C Recommended Storage Conditions and Period for unused Product on T&R 18 months max. +5 to +35°C Return Loss (dB) Impedance (Ω) Input Power (W) Operating Temperature 10 min. e.g. 2450AT18D0100001B e.g. 2450AT18D0100001E Packing Style T & R 3,000 Reel Quantity (pcs./reel) Bulk (loose pcs.) Part Number Explanation (See last page for more info on new and legacy part numbers) e.g. 2450AT18D0100001(B or S) Suffix = B Suffix = E 100% TinSuffix = None Terminal Configuration FEED GND GND GND GND GND GND FEED Function 1Function 2 b 0.0200.500.20.008 a 0.0120.30+0.1 / -0.2 +0.004 / -0.008 1.200.10.004 2450AT18D0100001CE1 mm Evaluation Board Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. P/N Suffix Mechanical Dimensions In L 0.1260.0083.200.2 W 0.0630.0081.600.2 T 0.047 High Frequency Ceramic Solutions 8/24/2022 Let us help you with the antenna design, optimization, and tuning! 2450AT18D0100001 2.45 GHz SMD Antenna, EIA 1206, Detuning resilient, Edge Mount Design https://www.johansontechnology.com/ask-a-question General Specifications New Global Part Number 1 2 4 3 b T L a w b New Global P/N 2450AT18D0100001 Legacy P/N 2450AT18D0100 Detail Specification:Page 2 of 7 https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver. 4.4 2021 Johanson Technology, Inc. All Rights Reserved High Frequency Ceramic Solutions 8/24/2022 Mounting Considerations 1: Evaluation Board (Standard Layout) Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. 2.45 GHz SMD Antenna, EIA 1206, Detuning resilient, Edge Mount Design To order a pre-tuned 50Ω EVB with a female SMA connector click here: https:// www.johansontechnology.com/request-a-sample Reference p/n: 2450AT18D0100001CE1 Units inmm Ground Vias Feeding Line Ground clearance 40mm 20mm Matching Circuits Measured radiated efficiency of 2450AT18D0100 on this evaluation board is 72% 1.02.01.0 0.6 0.7 0.6 4.1 4.0 0 Ohm Matching Circuits No ground, metal PCB layers, or other metallic components like batteries directly underneath antenna! Ground Ground Ground 6.0 Land Solder Resist 50Ω Trace (Grounded CPWG type is preferred) GND Vias New Global P/N 2450AT18D0100001 Legacy P/N 2450AT18D0100 Detail Specification:Page 3 of 7 https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver. 4.4 2021 Johanson Technology, Inc. All Rights Reserved High Frequency Ceramic Solutions 8/24/2022 Mounting Considerations 1: Electrical Performance @25°C Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. 2.45 GHz SMD Antenna, EIA 1206, Detuning resilient, Edge Mount Design MeasuredReturn Loss Would you like the antenna layout? Have antenna tuning issues? Please contact us if you have any questions regarding the implementation of this antenna in your PCB's layout. We'll be happy to guide you to maximize the antenna's performance. Contact our applications engineers at: https://www.johansontechnology.com/ask-a-question 2.22.42.62.82.03.0 -20 -10 -30 0 f req, GHz dB(S(1,1)) m1 m2 m3 m1 f req= dB(S(1,1))=-13.935 2.400GHz m2 f req= dB(S(1,1))=-14.774 2.500GHz m3 f req= dB(S(1,1))=-24.894 2.450GHz New Global P/N 2450AT18D0100001 Legacy P/N 2450AT18D0100 Detail Specification:Page 4 of 7 https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver. 4.4 2021 Johanson Technology, Inc. All Rights Reserved High Frequency Ceramic Solutions 8/24/2022 Mounting Considerations 1: Typical 2D radiation patterns @ 2.44GHz Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. 2.45 GHz SMD Antenna, EIA 1206, Detuning resilient, Edge Mount Design YZ-plane XZ-plane XY-plane θ +Z (θ= 0°) +Y (θ= 90°) -Y -Z θ +Z (θ= 0°) +X (θ= 90°) -X -Z φ +X (φ= 0°) -X +Y (φ= 90°) -Y +Z -Z +Y -Y +Z -Z +X -X +X -X +Y -Y New Global P/N 2450AT18D0100001 Legacy P/N 2450AT18D0100 Detail Specification:Page 5 of 7 https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver. 4.4 2021 Johanson Technology, Inc. All Rights Reserved Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. Mounting Considerations 2: Small Clearance or "Thin edge" Applications* 2.450.3 (XZ-plane) High Frequency Ceramic Solutions 2.45 GHz SMD Antenna, EIA 1206, Detuning resilient, Edge Mount Design 8/24/2022 Mounting Considerations 3: "Thind edge" application on circular PCB Frequency (GHz)Peak Gain (dBi)Average Gain (dBi)Radiated Efficiency (%) -3.6 (XZ-plane)66 Units inmm Land Solder Resist *Evaluationboard not available * 1.02.01.0 0.6 0.7 0.6 1.5 8.0 Matching Circuits Ground 0.6 2.8 0.6 3.4 3.4 GND clearance *Evaluationboard not available 50Ω Trace (Grounded CPWG type is preferred) No ground, metal PCB layers, or other metallic components like batteries and displays directly underneath antenna! Groun…

Text truncated - open the document above for the full version.

www.nemko.com Nemko Canada Inc., a testing laboratory, is accredited by the Standards Council of Canada. The tests included in this report are within the scope of this accreditation. The SCC Accreditation Symbol is an official symbol of the Standards Council of Canada, used under licence. SCC File Number: 15064 (Ottawa/Almonte); 151100 (Montreal); 151097 (Cambridge) FCC and RSS-102 Annex C – MPE Calculation; Date: May 2021 Choose Scandinavian trust RADIO TEST REPORT – 449009-2APFWL Type of assessment: MPE Calculation report Manufacturer: Product Description: JDRF Electromag Engineering Inc. Wireless Lighting Control System Product Marketing Name (PMN): Hardware Version Identification Number (HVIN): Autonomy Sensor 2000000 FCC ID: ISED certification number: 2A22O2000000 24973-2000000 Specification:  FCC 47 CFR Part 1 Subpart I, §§1.1307, 1.1310  FCC 47 CFR Part 2 Subpart J, §2.1091  FCC KDB 447498 D01 General RF Exposure Guidance v06  ISED Canada RSS-102 Issue 5 Amendment 1, (February 2021) RSS-102 Annex B - Declaration of RF Exposure Compliance ATTESTATION: I attest that the information provided in Annex A is correct; that the Technical Brief was prepared and the information contained therein is correct; that the device evaluation was performed or supervised by me; that applicable measurement methods and evaluation methodologies have been followed; and that the device meets the SAR and/or RF field strength limits of RSS-102. Date of issue: September 19, 2022 Ketav Jani, EMC/RF Test Specialist Prepared by Signature Section 1 MPE calculation Report reference ID: 449009-2APFWL Page 2 of 5 Lab locations Company name Nemko Canada Inc. Facilities Ottawa site: 303 River Road Ottawa, Ontario Canada K1V 1H2 Tel: +1 613 737 9680 Fax: +1 613 737 9691 Montréal site: 292 Labrosse Avenue Pointe-Claire, Québec Canada H9R 5L8 Tel: +1 514 694 2684 Fax: +1 514 694 3528 Cambridge site: 1-130 Saltsman Drive Cambridge, Ontario Canada N3E 0B2 Tel: +1 519 650 4811 Almonte site: 1500 Peter Robinson Road West Carleton, Ontario Canada K0A 1L0 Tel: +1 613 256-9117 Test site identifier Organization Ottawa/Almonte Montreal Cambridge FCC: CA2040 CA2041 CA0101 ISED: 2040A-4 2040G-5 24676 Website www.nemko.com Limits of responsibility Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. All results contained in this report are within Nemko Canada’s ISO/IEC 17025 accreditation. Copyright notification Nemko Canada Inc. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. © Nemko Canada Inc. Section 1 MPE calculation Report reference ID: 449009-2APFWL Page 3 of 5 Evaluation summary 1.1 MPE calculation for standalone transmission 1.1.1 References, definitions and limits FCC §2.1091(d) (2) (2) For operations within the frequency range of 300 kHz and 6 GHz (inclusive), the limits for maximum permissible exposure (MPE), derived from whole-body SAR limits and listed in Table 1 in paragraph (e)(1) of this section, may be used instead of whole-body SAR limits as set forth in paragraphs (a) through (c) of this section to evaluate the environmental impact of human exposure to RF radiation as specified in §1.1307(b) of this part, except for portable devices as defined in §2.1093 of this chapter as these evaluations shall be performed according to the SAR provisions in §2.1093. Table 1.1-1: Table 1 to §1.1310(e)(1)—Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (i) Limits for Occupational/Controlled Exposure 0.3–3.0 614 1.63 *(100) ≤6 3.0–30 1842 / f 4.89 / f *(900 / f 2 ) <6 30–300 61.4 0.163 1.0 <6 300–1500 f / 300 <6 1500–100000 5 <6 (ii) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) <30 1.34–30 824 / f 2.19 / f *(180 / f 2 ) <30 30–300 27.5 0.073 0.2 <30 300–1500 f / 1500 <30 1500–100000 1.0 <30 Notes: f = frequency in MHz. * = Plane-wave equivalent power density. RSS-102, Section 4 For the purpose of this standard, Industry Canada has adopted the SAR and RF field strength limits established in Health Canada’s RF exposure guideline, Safety Code 6: Table 1.1-2: Table 4 to RSS-102— RF Field Strength Limits Frequency range (MHz) Electric field strength (V/m rms) Magnetic field strength (A/m rms) Power density (W/m 2 ) Reference Period (minutes) Limits for Controlled Environment 10–20 61.4 0.163 10 6 20–48 129.8 / ƒ 0.25 0.3444 / ƒ 0.25 44.72 / ƒ 0.5 6 48–100 49.33 0.1309 6.455 6 100–6000 15.60 ƒ 0.25 0.04138 ƒ 0.25 0.6455 ƒ 0.5 6 6000–15000 137 0.364 50 6 Limits for Uncontrolled Environment 10–20 27.46 0.0728 2 6 20–48 58.07 / ƒ 0.25 0.1540 / ƒ 0.25 8.944 / ƒ 0.5 6 48–300 22.06 0.05852 1.291 6 300–6000 3.142 ƒ 0.3417 0.008335 ƒ 0.3417 0.02619 ƒ 0.6834 6 6000–15000 61.4 0.163 10 6 Notes: ƒ = frequency in MHz. Section 1 MPE calculation Report reference ID: 449009-2APFWL Page 4 of 5 References, definitions and limits, continued Equation from page 18 of OET Bulletin 65, Edition 97-01 푆= 푃퐺 4휋푅 2 where: S = power density (mW/cm 2 or W/m 2 ) P = power input to the antenna (mW or W) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (cm or m) 1.1.2 EUT technical information Prediction frequency 2479 MHz Antenna type Surface mount chip antenna Antenna gain 1.5 dBi Numbe…

Text truncated - open the document above for the full version.

www.nemko.com Nemko Canada Inc., a testing laboratory, is accredited by the Standards Council of Canada. The tests included in this report are within the scope of this accreditation. The SCC Accreditation Symbol is an official symbol of the Standards Council of Canada, used under licence. SCC File Number: 15064 (Ottawa/Almonte); 151100 (Montreal); 151097 (Cambridge) FCC 15.247 and RSS-247; Date: February 2021 C h o o s e S c a n d i n a v i a n t r u s t RADIO TEST REPORT – 449009-1TRFWL Type of assessment: Final product testing Type of radio equipment: Bluetooth Device Equipment class: DTS Applicant: Product description: JDRF Electromag Engineering Inc. Wireless Lighting Control System Model (HVIN): Product marketing name: 2000000 Autonomy Sensor FCC ID: IC Registration number: 2A22O2000000 24973-2000000 Specifications:  FCC 47 CFR Part 15 Subpart C, §15.247  RSS-247, Issue 2, Feb 2017, Section 5 Date of issue: September 19, 2022 Ketav Jani, EMC/RF Test Specialist Tested by Signature Fahar A Sukkoor, EMC/RF Specialist Reviewed by Signature Report reference ID: 449009-1TRFWL Page 2 of 39 Lab locations Company name Nemko Canada Inc. Facilities Ottawa site: 303 River Road Ottawa, Ontario Canada K1V 1H2 Tel: +1 613 737 9680 Fax: +1 613 737 9691 Montréal site: 292 Labrosse Avenue Pointe-Claire, Québec Canada H9R 5L8 Tel: +1 514 694 2684 Fax: +1 514 694 3528 Cambridge site: 1-130 Saltsman Drive Cambridge, Ontario Canada N3E 0B2 Tel: +1 519 650 4811 Almonte site: 1500 Peter Robinson Road West Carleton, Ontario Canada K0A 1L0 Tel: +1 613 256-9117 Test site identifier Organization Ottawa/Almonte Montreal Cambridge FCC: CA2040 CA2041 CA0101 ISED: 2040A-4 2040G-5 24676 Website www.nemko.com Limits of responsibility Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. All results contained in this report are within Nemko Canada’s ISO/IEC 17025 accreditation. Copyright notification Nemko Canada Inc. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. © Nemko Canada Inc. Report reference ID: 449009-1TRFWL Page 3 of 39 Table of Contents Table of Contents ......................................................................................................................................................................................................... 3 Report summary ................................................................................................................................................................................. 4 1.1 Test specifications .................................................................................................................................................................................................... 4 1.2 Test methods ............................................................................................................................................................................................................ 4 1.3 Exclusions ................................................................................................................................................................................................................. 4 1.4 Statement of compliance .......................................................................................................................................................................................... 4 1.5 Test report revision history ....................................................................................................................................................................................... 4 Engineering considerations ................................................................................................................................................................. 5 2.1 Modifications incorporated in the EUT for compliance ............................................................................................................................................ 5 2.2 Technical judgment .................................................................................................................................................................................................. 5 2.3 Model variant declaration ........................................................................................................................................................................................ 5 2.4 Deviations from laboratory tests procedures ........................................................................................................................................................... 5 Test conditions ................................................................................................................................................................................... 6 3.1 Atmospheric conditions ............................................................................................................................................................................................ 6 3.2 Power supply range .................................................................................................................................................................................................. 6 Measurement uncertainty .............................................................................................…

Text truncated - open the document above for the full version.

Model (HVIN): 2000000.0 Page 1 of 6 FCC ID: 2A22O2000000 IC: 24973-2000000 Section 1. Radiated emissions setup photos 1.1 Front view C h o o s e S c a n d i n a v i a n t r u s t Setup photos – NEX-449009 Model (HVIN): 2000000.0 Page 2 of 6 FCC ID: 2A22O2000000 IC: 24973-2000000 Front View, continued Model (HVIN): 2000000.0 Page 3 of 6 FCC ID: 2A22O2000000 IC: 24973-2000000 1.2 Rear view Model (HVIN): 2000000.0 Page 4 of 6 FCC ID: 2A22O2000000 IC: 24973-2000000 Rear View, continued Model (HVIN): 2000000.0 Page 5 of 6 FCC ID: 2A22O2000000 IC: 24973-2000000 Section 2. Conducted AC emissions setup photos 2.1 General setup Model (HVIN): 2000000.0 Page 6 of 6 FCC ID: 2A22O2000000 IC: 24973-2000000 2.2 General setup, alternative view END OF REPORT
