2A29I-SX2WPCNFCWireless Power Charger

Aptiv Confidential Wireless charging system 1. Description Wireless Power Charger System It is electromagnetic induction wireless charging system. Wireless power charger transmits 10W power to mobile. Qi (WPC) certified cell phone, which is a standard for wireless charging, or a case dedicated to wireless charging, can be used this system. ※ Reference • Qi : One of the wireless charging standards • WPC : Abbreviation of Wireless Power Consortium • Electromagnetic induction : When an electric current is sent through a coil (a wound-up cable), it creates a magnetic field whose action generates another electric current in a second coil 2. Product picture 3. Product organization 1) PAD 2) TOP COVER 3) COIL ASSEMBLY (MP-A13) 4) COIL SPACER 5) PCB ASSEMBLY 6) SCREW 7) FAN 8) HOUSING 9) LABEL 4. Product features 1) Wireless charging for automobile 2) Support high speed wireless charging (10W) 3) Apply coil cooling function by FAN 4) Apply FOD(Foreign object detection)function 5) Apply wireless charging system protection function (Over voltage, Over current, Over temperature prevention) 6) Apply Qi 1.2.4 ver Aptiv Confidential 5. Connector pin description PIN # Description 1 Ground 2 Ground 3 PWM LED AMBER OUT 4 PWM LED GREEN OUT 5 B-CAN LOW 6 B-CAN HIGH 7 Not connected 8 L-CAN LOW 9 L-CAN HIGH 10 Not connected 11 IGN + 12 BAT + 6. How to use 6-1 Charing 1) Input IGN+, BAT+ power to Wireless charger by #11, #12 pin on connector. 2) Put mobile which support wireless charging on the wireless charger 3) Check wireless charging connection. 6-2 NFC Mode 1) Input BAT+ power to Wireless charger by #12 pin on connector. 2) Put mobile which support wireless charging on the wireless charger 3) Check that user authentication is complete 4) Vehicle can be started 7. Matching parts Front console or Center console in automobile 8. Traceability information 1) Model name : SX2 WPC with NFC 2) Product name : Wireless Power Charger 3) Manufacturer : Aptiv Connection Systems Korea LLC 4) Address : 3, Hyundaikia-ro, Paltan-myeon, Hwaseong-si, Gyeonggi-do, Republic of Korea 9. Operating Frequency 1) Charging frequency : 128 kHz 2) NFC : 13.56 MHz WPC FCC warning statement: 15.19 λ. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 15.105 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. 15.21 - Any changes or modifications not expressly approved by the party responsible for compliance could void the authority to operate equipment. - This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. - End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. FCC/ IC RF Radiation Exposure Statement: This equipment complies with FCC/ISED radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 15cm between the radiator & your body. This device complies with FCC/ ISED radiation exposure limits set forth for an uncontrolled environment. IC warning statement: RSS-Gen Issue 4 8.4 This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Co-located This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter.

Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID : 2A29I-SX2WPCNFC Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block diagram (2A29I-SX2WPCNFC)_Block Diagram.pdf Parts List (2A29I-SX2WPCNFC)_Part List.pdf Schematics (2A29I-SX2WPCNFC)_Schematics.pdf (2A29I-SX2WPCNFC)_Schematics_PCB Layout.pdf Operational description (2A29I-SX2WPCNFC)_Operational Description.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, NAME: Maeng, MinKyung Applicant: Aptiv Connection Systems Korea LLC

Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date : December 29, 2022 SUBJECT: FCC Application for (FCC ID : 2A29I-SX2WPCNFC) To Whom It May Concern: We, the undersigned, hereby authorize Young-taek Lee at CTK on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by CTK on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, NAME: Maeng, MinKyung Applicant: Aptiv Connection Systems Korea LLC

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Model :SX2 WPC with NFC EUT External Photographs CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Model :SX2 WPC with NFC CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Model :SX2 WPC with NFC

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Model :SX2 WPC with NFC Label and Location

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Model :SX2 WPC with NFC EUT Internal Photographs CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Model :SX2 WPC with NFC CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Model :SX2 WPC with NFC CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Model :SX2 WPC with NFC Antenna [WPT] [NFC] 54 mm 46 mm 83 mm 83 mm

TEST REPORT CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2022-03390 Page (1) / (10) Pages [QF-QP15-07] Ver.01 R112 1. Applicant ◦ Name : Aptiv Connection Systems Korea LLC ◦ Address : 3, Hyundaikia-ro, Paltan-myeon, Hwaseong-si, Gyeonggi-do, Republic of Korea ◦ Date of Receipt : 2022-08-24 2. Manufacturer ◦ Name : Aptiv Connection Systems Korea LLC ◦ Address : 3, Hyundaikia-ro, Paltan-myeon, Hwaseong-si, Gyeonggi-do, Republic of Korea 3. Use of Report : For FCC Certification 4. Test Sample / Model : Wireless Power Charger / SX2 WPC with NFC 5. Date of Test : 2022-12-05 6. Test Standard(method) used : FCC 47 CFR part 2 subpart J 2.1091 7. Testing Environment: Temp.: (29 ± 1) °C, Humidity: (34 ± 3) % R.H 8. Test Results : Compliance 9. Location of Test : Permanent Testing Lab On Site Testing (Address : 5, Dongbu-ro 221beon-gil, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This report cannot be reproduced or copied without the written consent of CTK. Approval Tested by Bong-seok Kim: (Signature) Technical Manager Young-taek Lee: (Signature) Remark. This report is not related to KOLAS accreditation and relevant regulation. 2022-12-29 CTK Co., Ltd. CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2022-03390 Page (2) / (10) Pages [QF-QP15-07] Ver.01 R112 REPORT REVISION HISTORY Date Revision Page No 2022-12-29 Issued (CTK-2022-03390) all This report shall not be reproduced except in full, without the written approval of CTK Co., Ltd. This document may be altered or revised by CTK Co., Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by CTK Co., Ltd. will constitute fraud and shall nullify the document. CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2022-03390 Page (3) / (10) Pages [QF-QP15-07] Ver.01 R112 CONTENTS 1. General Product Description ........................................................................................ 4 1.1 Client Information .............................................................................................. 4 1.2 Product Information ............................................................................................ 4 2. Accreditations ........................................................................................................... 5 2.1 Laboratory Accreditations and Listings .................................................................. 5 2.2 Calibration Details of Equipment Used for Measurement .......................................... 5 3. RF Exposure Assessment ............................................................................................ 6 3.1 Maximum Permissible Exposure ............................................................................ 6 APPENDIX A – Test Equipment Used For Tests ................................................................... 9 APPENDIX B – Test Photos ............................................................................................ 10 CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2022-03390 Page (4) / (10) Pages [QF-QP15-07] Ver.01 R112 1. General Product Description 1.1 Client Information Company Aptiv Connection Systems Korea LLC Contact Point 3, Hyundaikia-ro, Paltan-myeon, Hwaseong-si, Gyeonggi-do, Republic of Korea Contact Person Name : Maeng, MinKyung E-mail : [email protected] Tel : +82-31-350-1799 1.2 Product Information FCC ID 2A29I-SX2WPCNFC Product Description Wireless Power Charger Model name SX2 WPC with NFC Variant Model name - Charging Frequency 128 kHz RF Output Power 95.0 dBuV/m @ 3m Power Transfer Method Magnetic induction and only single primary coil coupling secondary coil Output power from each primary coil < 15 W That may have multiple primary coils No Antenna Type Coil Charging Method Directly contact Power Source DC 12 V CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2022-03390 Page (5) / (10) Pages [QF-QP15-07] Ver.01 R112 2. Accreditations 2.1 Laboratory Accreditations and Listings Country Agency Registration Number USA FCC 805871 CANADA ISED 8737A KOREA NRRA KR0025 2.2 Calibration Details of Equipment Used for Measurement Test equipment and test accessories are calibrated on regular basis. The maximum time between calibrations is one year or what is recommended by the manufacturer, whichever is less. All test equipment calibrations are traceable to the Korea Research Institute of Standards and Science (KRISS), therefore, all test data recorded in this report is traceable to KRISS. CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2022-03390 Page (6) / (10) Pages [QF-QP15-07] Ver.01 R112 3. RF Exposure Assessment 3.1 Maximum Permissible Exposure Limit Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposure 0.3-3.0 614 1.63 *100 6 3.0-30 1842/f 4.89/f *900/f 2 6 30-300 61.4 0.163 1.0 6 300-1,500 - - f/300 6 1,500-100,000 - - 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *100 30 1.34-30 824/f 2.19/f *180/f 2 30 30-300 27.5 0.073 0.2 30 300-1,500 - - f/1500 30 1,500-100,000 - - 1.0 30 Note 1 : f = frequency in MHz; *Plane-wave equivalent power density Note 2 : For the applicable limit, see FCC 1.1310 Test method a) Performed aggregate both leakage E-field and H-field at s…

Text truncated - open the document above for the full version.

TEST REPORT CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2022-03389 Page (1) / (18) Pages [QF-QP15-07] Ver.01 R108 1. Applicant ◦ Name : Aptiv Connection Systems Korea LLC ◦ Address : 3, Hyundaikia-ro, Paltan-myeon, Hwaseong-si, Gyeonggi-do, Republic of Korea ◦ Date of Receipt : 2022-08-24 2. Manufacturer ◦ Name : Aptiv Connection Systems Korea LLC ◦ Address : 3, Hyundaikia-ro, Paltan-myeon, Hwaseong-si, Gyeonggi-do, Republic of Korea 3. Use of Report : For FCC Certification, For ISED Certification 4. Test Sample / Model : Wireless Power Charger / SX2 WPC with NFC 5. Date of Test : 2022-09-28 to 2022-11-14 6. Test Standard(method) used : FCC 47 CFR part 15 subpart C 15.209 RSS-Gen Issue 5, RSS-216 Issue 2 7. Testing Environment: refer to 11 pages to 17 pages 8. Test Results : Compliance 9. Location of Test : Permanent Testing Lab On Site Testing (Address : 5, Dongbu-ro 221beon-gil, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This report cannot be reproduced or copied without the written consent of CTK. Approval Tested by Bong-seok Kim: (Signature) Technical Manager Young-taek Lee: (Signature) Remark. This report is not related to KOLAS accreditation and relevant regulation. 2022-12-29 CTK Co., Ltd. CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2022-03389 Page (2) / (18) Pages [QF-QP15-07] Ver.01 R108 REPORT REVISION HISTORY Date Revision Page No 2022-12-29 Issued (CTK-2022-03389) all This report shall not be reproduced except in full, without the written approval of CTK Co., Ltd. This document may be altered or revised by CTK Co., Ltd. Personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by CTK Co., Ltd. Will constitute fraud and shall nullify the document. CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2022-03389 Page (3) / (18) Pages [QF-QP15-07] Ver.01 R108 CONTENTS 1. General Product Description ........................................................................................ 4 1.1 Client Information .............................................................................................. 4 1.2 Product Information ............................................................................................ 4 1.3 Antenna Information ........................................................................................... 4 2. Accreditations ........................................................................................................... 5 2.1 Laboratory Accreditations and Listings .................................................................. 5 2.2 Calibration Details of Equipment Used for Measurement .......................................... 5 3. Test Specifications ..................................................................................................... 6 3.1 Standards.......................................................................................................... 6 3.2 Mode of operation during the test ......................................................................... 7 3.3 Peripheral Devices .............................................................................................. 7 3.4 Maximum Measurement Uncertainty ..................................................................... 8 4. Technical Characteristic Test ........................................................................................ 9 4.1 Emission Bandwidth ............................................................................................ 9 4.2 Radiated emissions ........................................................................................... 11 APPENDIX A – Test Equipment Used For Tests ................................................................. 18 CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2022-03389 Page (4) / (18) Pages [QF-QP15-07] Ver.01 R108 1. General Product Description 1.1 Client Information Company Aptiv Connection Systems Korea LLC Contact Point 3, Hyundaikia-ro, Paltan-myeon, Hwaseong-si, Gyeonggi-do, Republic of Korea Contact Person Name : Maeng, MinKyung E-mail : [email protected] Tel : +82-31-350-1799 1.2 Product Information FCC ID 2A29I-SX2WPCNFC IC 29623-SX2WPCNFC Product Description Wireless Power Charger Model name SX2 WPC with NFC Variant Model name - FVIN N/A Classification of WPT devices Type 1 (Interference-causing Equipment) Type 2 (Category II Radio Apparatus) Type 3 (Category I Radio Apparatus) Charging Frequency 128 kHz RF Output Power 95.0 dBuV/m @ 3m Power Transfer Method Magnetic induction and only single primary coil coupling secondary coil Output power from each primary coil < 15 W That may have multiple primary coils No Antenna Type Coil Charging Method Directly contact Power Source DC 12 V 1.3 Antenna Information Integral antenna (antenna permanently attached) Temporary RF connector provided No temporary RF connector provided Transmit chains bypass antenna and soldered temporary RF connector provided for connected measurement. In case of conducted measurements the transmitter shall be connected to the measuring equipment via a suitable attenuator and correct for all losses in the RF path. External antenna (dedicated antennas) CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2022-03389 Page (5) / (18) Pages [QF-QP15-07] Ver.01 R108 2. Accreditations 2.1 Laboratory Accreditations and Listings Country Agency Registration Number USA FCC 805871 CANADA ISED 8737A …

Text truncated - open the document above for the full version.

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Model :SX2 WPC with NFC Test Setup Photographs and Configuration Radiated measurement [WPT] CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Model :SX2 WPC with NFC [NFC]
