2A2FA-TRISOLITE2lite2, linglong2

- 2 - LensSpeaker ON/ OFF KeyIndicator light Shoot button - 1 -- 3 -- 4 -- 5 -- 6 - Quick plug-in Product Description App Downloading QR code 1. Scan the QR code and install “Trisio360Camera” App. 2. Search and install the latest version of “Trisio360Camera” in your mobile application store such as “Google Play” and “App Store”. Quick Start 1. 2. 3. Fix the camera on the tripod with fasteners, and press the side switch to turn on the camera. Independent shooting: press the shoot button at the side to take panoramic photos. Remote shooting via App: connect Trisio360Camera to the camera's Wi-Fi for remote shooting. Specifications Indicator Parameter or description ApertureF2.3 Resolution of panoramic images 32 million pixels (8,000*4,000) Battery capacity 2,480mAh ( battery life about 200 min) Operating temperature 0°C~40°C Packing List Indicator Lights Camera state Indicator state Normal switch-on and running Blue light normally on Low battery Red light normally on Switch off to charge Green light flickering Switch on to charge Green light normally on Runtime exception Red light flickering 360° camera-------------------×1 Quick plug-in------------------×1 USB cable---------------------×1 Lens cleaner------------------×1 Instructions-------------------×1 Warranty card-----------------×1 Carry case---------------------×1 FAQ Wi-Fi connection failed Connect the Wi-Fi signal starting with “Trisio_******” from the list and the password is 12345678 by default, then connect the App to the camera. If your Android phone receives a prompt like "Wi-Fi Networking Failed," please stay connected. Android phone troubleshooting: check whether "Location" is on, as it must be, and delete the camera Wi-Fi for reconnection. Stay connected if the prompt of "Wi-Fi Networking Failed" appears. If the camera is still 1. disconnected, enter the mobile “Settings” to find an option similar to “WLAN Assistant”/ “WLAN Support”/ “WLAN+”, and turn off this function and data traffic (4G/5G), and then restart the App. iPhone troubleshooting: try manual connection to Wi-Fi first. If it fails, enter the Settings - “Trisio360Camera” to check the permissions for local network access (iOS14 and above) and location, which are necessary for proper functioning of App. If it doesn’t work, uninstall for reinstallation, and reboot the camera and mobile phone to check whether permissions are obtained. Both phone and camera should be be rebooted in case of connection failure under permission support. Why does the software flash back when it stitches pictures? Please free up the memory space for at least 2GB, and then reinstall the App. 2. Attentions 1. 2. 3. 4. 5. 6. 7. Check the stability of camera and tripod before shooting. Do not forcibly stop the camera from rotating, or damage will be caused. A windless environment is preferred. In the presences of strong winds, beware of tripod falling and camera damage. Please avoid outdoor use on rainy days and liquid splashing to prevent damage since the camera is not waterproof. A lithium battery is built in, please keep the camera away from fire or extremely high temperature (long-time direct sunlight or a sealed car), or fire or explosion may occur. Precision lens should be prevented from scratching when use and properly saved when idle. Do not position it face down, or scratches or damage may occur. Do not disassemble the camera without permission, or damage may occur. Do not use in an environment other than the specified operating temperature, or damage may occur. Service Terms 1. 2. 3. 4. 5. 6. This clause is only valid for Hong Kong, Macao, Taiwan and overseas areas of the People’s Republic of China. The user is entitled to a one-year warranty from the date of purchase with a warranty card and an official receipt with the correct product name. This card only serves as the warranty certificate of HZNOVI Trisio items, and door-to-door service is not supported. The user has access to other legal rights in addition to those stipulated in the warranty card. If the warranty card is lost, the user will not be able to get another one. Please keep it properly and present it when service is required. For malfunctions not caused by poor quality, the owner shall bear the joint expenses incurred during repair, such as insurance premium, handling fee, and transportation fee. HZNOVI shall not be liable for the product damage or loss in transit. All parts involved in replacement will be collected and disposed of by HZNOVI , rather than be returned to the owner. After the product is repaired, Instructions/ Warranty card Please safekeeping this card - 8 -- 9 -- 10 -- 11 -- 7 - Warranty Exclusions 1. 2. 3. 4. 5. 6. 7. 8. 9. Failing to present the valid receipt and the original warranty card at the same time. Altering the warranty card or having inconsistent product information. Damage caused by force majeures such as accidents, disasters, and wars. Damage caused by water or sand entry, dampness, leakage, or external forces. Damage caused by lightning strike or electrical system. Modification and repair without permission by HZNOVI, or demolition, modification, and repair by an unauthorized third party. Damage caused by pirated software or virus infection during operation. Damage caused by improper use, maintenance, and storage. The Company shall not be 10. 11. liable for any direct or indirect loss caused by malfunctions, deletion or alteration of image data during battery maintenance and replacement, as well as any claim not listed in the maintenance instructions. Out of warranty. Files, software or consumables (e.g. USB cable and lens cleaner) that are attached. User Profile Name Phone number Email Address Company Model Serial No. Purchasing date Purchasing channel Product Information * Please keep this card properly and present it to local dealers when you ask for after-sales service. Customer service: Trisio Camera (Facebook) or email Website: www.trisio.net Address: 2F & 5F, National Science and Te…

Text truncated - open the document above for the full version.

郔 SGS North America Inc 620 Old Peachtree Road SUITE 100 Applicant Declaration Suwanee, Georgia 30024 United States Applicant Legal Business Name Nanjing Hznovi Electronic Technology Co, Ltd Add「ess No.37, Jiangjun Avenue, Jiangning Economy and Technology development Zone, Nanjing City, Jiangsu Province, China Grantee Code 2A2FA FCC ID 2A2F A-TRISOLITE2 Authorized Contact Name xiushu yin Contact Ema仆 [email protected] Contact Phone 18606091052 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a ) in accordance wrth 47CFR2.911(d), all of the statemerrts herein and the exhibtts attached hereto are true and correct to the best of my knowledge and belief b ) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made 1n this application, the Applicant is responsible for (1) labeling the equipment wtth the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules , (3) compliance of the equipment wrth the applicable technical「ules , c ) if the Applicant is not the actual manufacture「of the equ叩ent,appropriate arrangements have been made wrth the manufacturer to ensu「e that production units of this equipment will continue to comply wrth the FCC's technical requirements d } in accordance wrth 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321 e ) in accordance wrth 1S017065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP - 100, the Applicant has 「ead, understood, accepts and agrees to abide by the post market surveillance requirements (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED (3) the Applicant shall, upon request by SGS, at the Applicant's expense, provide a production sample of the requested product to SGS , FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or softwa「e「equiredfor evaluation, review, certification and audit surveillance of products certified by SGS f ) neithe「the Applicant no「 any party to the application is subject to a denial of Federal benefrts, that includes FCC benefrts, pursuant to Section 5301 of the Anti - Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance See 47CFR 1.2002(b ) for the definition of a'party·for these purposes g } the Applicant has read, understood, accepts and agrees to abide by the SGS North America, lnc.(TCB ) terms and cond巾ons Link to CFRs: htt :t/www.fcc. ov/wi「eless/bureau-<:livisions/technoloies-s stems-and-innovation-div1s1on/「ules-reulations-title-47 LinK to KDBs·https. //apps fee qov/oetef/Kdb/index.efm LinK to RSP - 100·https //www ic qc ca/e1c/s1te艺兰兰巴/enq/sf01130.html Applicant Signatu「e Date202 I /06/24 Print Name Applicant Declaration Rev:0.0

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 5 External Photos Applicant: Nanjing Hznovi Electronic Technology Co. Ltd Address of Applicant: No.37, Jiangjun Avenue, Jiangning Economy and Technology development Zone, Nanjing City, Jiangsu Province, China Equipment Under Test (EUT): Product Name: lite2, linglong2 Model No.: S8II SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 5 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 5 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 5 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 5 of 5 End

Rem ark：It’s hard to put FCC statement on the product due to device’s irregular appearance. FCC statement will be placed in the user manual which the device is marketed.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 8 Internal Photos Applicant: Nanjing Hznovi Electronic Technology Co. Ltd Address of Applicant: No.37, Jiangjun Avenue, Jiangning Economy and Technology development Zone, Nanjing City, Jiangsu Province, China Equipment Under Test (EUT): Product Name: lite2, linglong2 Model No.: S8II SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 8 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 8 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 8 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 5 of 8 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 6 of 8 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 7 of 8 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 8 of 8 End

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210500426402 Page: 1 of 8 Parlam Zhan E&E Section Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. 1 Cover Page RF Exposure Evaluation Report Application No.: SHEM2105004264CR FCC ID: 2A2FA-TRISOLITE2 IC: 27409-TRISOLITE2 Applicant: Nanjing Hznovi Electronic Technology Co., Ltd Address of Applicant: No.37, Jiangjun Avenue, Jiangning Economy and Technology development Zone, Nanjing City, Jiangsu Province, China Manufacturer: Nanjing Hznovi Electronic Technology Co., Ltd Address of Manufacturer: No.37, Jiangjun Avenue, Jiangning Economy and Technology development Zone, Nanjing City, Jiangsu Province, China Equipment Under Test (EUT): EUT Name: lite2, linglong2 Model No.: S8II Trade mark: trisio, Xiao Hongwu Standard(s) : FCC Rules 47 CFR §2.1091 447498 D01 General RF Exposure Guidance v06 RSS-102 Issue 5 Amendment 1 (February 2, 2021) Date of Receipt: 2021-05-12 Date of Test: 2021-05-21 to 2021-06-08 Date of Issue: 2021-06-25 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services(Shanghai) Co., Ltd. Report No.: SHEM210500426402 Page: 2 of 8 Revision Record Version Description Date Remark 00 Original 2021-06-25 / Authorized for issue by: Micheal Niu / Project Engineer Parlam Zhan / Reviewer SGS-CSTC Standards Technical Services(Shanghai) Co., Ltd. Report No.: SHEM210500426402 Page: 3 of 8 2 Contents Page 1 COVER PAGE ................................................................................................................................................. 1 2 CONTENTS ..................................................................................................................................................... 3 3 GENERAL INFORMATION........................................................................................................................... 4 3.1 GENERAL DESCRIPTION OF E.U.T. ......................................................................................................... 4 3.2 TECHNICAL SPECIFICATIONS ................................................................................................................... 4 3.3 TEST LOCATION ....................................................................................................................................... 5 3.4 TEST FACILITY .......................................................................................................................................... 5 4 TEST STANDARDS AND LIMITS ............................................................................................................... 6 4.1 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS: ......................................................................... 6 4.2 IC RADIOFREQUENCY RADIATION EXPOSURE LIMITS: ............................................................................. 6 5 MEASUREMENT AND CALCULATION .................................................................................................... 7 5.1 MAXIMUM TRANSMIT POWER ................................................................................................................... 7 5.2 MPE CALCULATION ................................................................................................................................. 8 SGS-CSTC Standards Technical Services(Shanghai) Co., Ltd. Report No.: SHEM210500426402 Page: 4 of 8 3 General Information 3.1 General Description of E.U.T. Power Supply： 3.8V 2480mAh by lithium battery 3.2 Technical Specifications 2.4GHz Antenna Gain: Ant1: 3.2dBi (Provided by the manufacturer) Ant2: 3.1dBi (Provided by the manufacturer) Directional gain:6.16dBi Antenna Type: PIFA Channel Spacing: 5MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK) 802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) Data Rate: 802.11b:1/2/5.5./11Mbps 802.11g:6/9/12/18/24/36/48/54Mbps 802.11n:MCS0-MCS7 Number of Channels: 802.11b/g/n(HT20):11 802.11n(HT40):7 Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz 802.11n(HT40): 2422MHz to 2452MHz SGS-CSTC Standards Technical Services(Shanghai) Co., Ltd. Report No.: SHEM210500426402 Page: 5 of 8 3.3 Test Location All tests were performed at: Compliance Certification Services (Kunshan) Inc. No.10 Weiye Rd, Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China. Tel: +86 512 5735 5888 Fax: +86 512 5737 0818 No tests were sub-contracted. 3.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • CNAS (No. CNAS L4354) CNAS has accredited Compliance Certification Services (Kunshan) Inc. to ISO/IEC 17025:2017 General Requirements for the Competence of Testing and Calibration Laboratories (CNAS-CL01 Accreditation Criteria for the Competence of Testing and Calibration Laboratories) for the competence in the field of testing. • A2LA (Certificate No. 2541.01) Compliance Certification Services (Kunshan) Inc. is accredited by the American Association for Laboratory Accreditation (A2LA). Certificate No. 2541.01. • FCC (Designation Number: CN1172) Compliance Certification Services Inc. has been recognized as an accredited testing laboratory. Designation Number: CN1172. • ISED (CAB identifier: CN0072) Compliance Certification Services (Kunshan) Inc. has been recognized by Innovation, Science and Economic Development Canada (ISED) as an accredited testing l…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 96 Appendix A for SHEM210500426401 1. Duty Cycle 1.1 Test Result Test Mode Channel Frequency(M Hz) TX Type ANT No. T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) 802.11b 2412 SISO 1 12.420 12.570 98.81 0.05 2 12.420 12.550 98.96 0.05 2437 SISO 1 12.420 12.590 98.65 0.06 2 12.400 14.740 84.12 0.75 2462 SISO 1 12.420 12.590 98.65 0.06 2 12.420 14.720 84.38 0.74 802.11g 2412 SISO 1 2.063 2.234 92.35 0.35 2 2.064 2.235 92.35 0.35 2437 SISO 1 2.064 2.215 93.18 0.31 2 2.033 2.192 92.75 0.33 2462 SISO 1 2.064 2.217 93.10 0.31 2 2.064 2.227 92.68 0.33 802.11n(HT20) 2412 MIMO 1 1.888 2.012 93.84 0.28 2 1.896 2.058 92.13 0.36 2437 MIMO 1 1.890 2.047 92.33 0.35 2 1.890 2.048 92.29 0.35 2462 MIMO 1 1.921 2.090 91.91 0.37 2 1.891 2.059 91.84 0.37 802.11n(HT40) 2422 MIMO 1 0.916 1.072 85.45 0.68 2 0.916 1.073 85.37 0.69 2437 MIMO 1 0.917 1.073 85.46 0.68 2 0.917 1.104 83.06 0.81 2452 MIMO 1 0.916 1.064 86.09 0.65 2 0.917 1.082 84.75 0.72 1.2 Test Graph SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 5 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 6 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 7 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 8 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 9 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 10 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 11 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 12 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 13 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 14 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 15 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 16 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 17 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 18 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 19 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 20 of 96 2. Bandwidth 2.1 Test Result Test Mode Frequency (MHz) TX Type ANT No. 6dB Bandwidth Verdict Test Result (MHz) 802.11b 2412 SISO 1 10.082 PASS 2 10.101 PASS 2437 SISO 1 9.623 PASS 2 10.062 PASS 2462 SISO 1 10.048 PASS 2 10.095 PASS 802.11g 2412 SISO 1 16.395 PASS 2 16.408 PASS 2437 SISO 1 16.395 PASS 2 16.397 PASS 2462 SISO 1 16.389 PASS 2 16.377 PASS 802.11n(HT20) 2412 MIMO 1 17.598 PASS 2 17.600 PASS 2437 MIMO 1 17.581 PASS 2 17.594 PASS 2462 MIMO 1 17.589 PASS 2 17.580 PASS 802.11n(HT40) 2422 MIMO 1 36.120 PASS 2 36.100 PASS 2437 MIMO 1 35.999 PASS 2 35.831 PASS 2452 MIMO 1 36.123 PASS 2 36.333 PASS Test Mode Frequency (MHz) TX Type ANT No. 99% Occupied Bandwidth Test Result (MHz) 802.11b 2412 SISO 1 14.970 Only for Report Use 2 15.025 Only for Report Use 2437 SISO 1 14.990 Only for Report Use 2 14.972 Only for Report Use 2462 SISO 1 15.014 Only for Report Use 2 15.016 Only for Report Use 802.11g 2412 SISO 1 16.805 Only for Report Use 2 16.843 Only for Report Use 2437 SISO 1 16.775 Only for Report Use 2 16.788 Only for Report Use 2462 SISO 1 16.859 Only for Report Use 2 16.771 Only for Report Use 802.11n(HT20) 2412 MIMO 1 17.810 Only for Report Use 2 17.851 Only for Report Use 2437 MIMO 1 17.817 Only for Report Use 2 17.852 Only for Report Use 2462 MIMO 1 17.835 Only for Report Use 2 17.794 Only for Report Use 802.11n(HT40) 2422 MIMO 1 36.085 Only for Report Use 2 36.170 Only for Report Use 2437 MIMO 1 36.139 Only for Report Use 2 36.168 Only for Report Use SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 21 of 96 2452 MIMO 1 36.196 Only for Report Use 2 36.216 Only for Report Use 2.2 Test Graph - 6dB Bandwidth SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 22 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 23 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 24 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 25 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 26 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 27 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 28 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 29 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 30 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 31 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 32 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 33 of 96 2.3 Test Graph - 99% Occupied Bandwidth SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 34 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 35 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 36 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 37 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 38 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 39 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 40 of 96

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 41 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 42 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 43 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 44 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 45 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 46 of 96 3. Maximum Conducted Output Power 3.1 Test Result Test Mode Frequency (MHz) Tx Type Measured Peak Output Power (dBm) Limits (dBm) Verdict Ant 1 Ant 2 Total 802.11b 2412 SISO 17.74 16.25 / 30 PASS 2437 SISO 16.83 16.52 / 30 PASS 2462 SISO 16.45 16.10 / 30 PASS 802.11g 2412 SISO 17.67 17.19 / 30 PASS 2437 SISO 17.16 17.44 / 30 PASS 2462 SISO 16.73 17.10 / 30 PASS 802.11n(HT20) 2412 MIMO 15.23 14.29 17.80 29.84 PASS 2437 MIMO 15.10 14.46 17.80 29.84 PASS 2462 MIMO 14.82 14.37 17.61 29.84 PASS 802.11n(HT40) 2422 MIMO 15.02 14.40 17.73 29.84 PASS 2437 MIMO 14.83 14.40 17.63 29.84 PASS 2452 MIMO 14.59 14.47 17.54 29.84 PASS 3.2 Test Graph SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 47 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 48 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 49 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 50 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 51 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 52 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 53 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 54 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 55 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 56 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 57 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 58 of 96 4. Maximum Power Spectral Density (PSD) 4.1 Test Result Test Mode Frequency (MHz) Tx Type Maximum Power Spectral Density (dBm/3KHz) Limits (dBm/3kHz) Verdict Ant 1 Ant 2 Total 802.11b 2412 SISO -7.52 -9.22 / ≤8 PASS 2437 SISO -8.04 -9.38 / ≤8 PASS 2462 SISO -9.40 -9.64 / ≤8 PASS 802.11g 2412 SISO -15.19 -14.67 / ≤8 PASS 2437 SISO -16.14 -14.87 / ≤8 PASS 2462 SISO -15.86 -74.68 / ≤8 PASS 802.11n(HT20) 2412 MIMO -18.22 -18.21 -15.20 ≤7.84 PASS 2437 MIMO -17.93 -19.16 -15.73 ≤7.84 PASS 2462 MIMO -18.46 -19.36 -16.12 ≤7.84 PASS 802.11n(HT40) 2422 MIMO -21.45 -21.98 -18.77 ≤7.84 PASS 2437 MIMO -21.87 -21.42 -19.03 ≤7.84 PASS 2452 MIMO -20.67 -21.01 -19.24 ≤7.84 PASS 4.2 Test Graph SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 59 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 60 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 61 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 62 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 63 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 64 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 65 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 66 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 67 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 68 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 69 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 70 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 71 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 72 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 73 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 74 of 96 5. Unwanted Emissions in Non-restricted Frequency Bands 5.1 Test Result Test Mode Frequency (MHz) TX Type ANT No. Spurious Conducted Emission (dBm) Limits (dBm) Verdict 802.11b 2412 SISO 1 Refer to test graph -13.95 PASS 2 Refer to test graph -13.95 PASS 2437 SISO 1 Refer to test graph -13.95 PASS 2 Refer to test graph -13.95 PASS 2462 SISO 1 Refer to test graph -13.95 PASS 2 Refer to test graph -13.95 PASS 802.11g 2412 SISO 1 Refer to test graph -20.66 PASS 2 Refer to test graph -20.66 PASS 2437 SISO 1 Refer to test graph -20.66 PASS 2 Refer to test graph -20.66 PASS 2462 SISO 1 Refer to test graph -20.66 PASS 2 Refer to test graph -20.66 PASS 802.11n(HT20) 2412 MIMO 1 Refer to test graph -22.78 PASS 2 Refer to test graph -22.78 PASS 2437 MIMO 1 Refer to test graph -22.78 PASS 2 Refer to test graph -22.78 PASS 2462 MIMO 1 Refer to test graph -22.78 PASS 2 Refer to test graph -22.78 PASS 802.11n(HT40) 2422 MIMO 1 Refer to test graph -26.84 PASS 2 Refer to test graph -26.84 PASS 2437 MIMO 1 Refer to test graph -26.84 PASS 2 Refer to test graph -26.84 PASS 2452 MIMO 1 Refer to test graph -26.84 PASS 2 Refer to test graph -26.84 PASS 5.2 Test Graph SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 75 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 76 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 77 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 78 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 79 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 80 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 81 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 82 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 83 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 84 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 85 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 86 of 96 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 87 of 96 SGS-CSTC Standards Technical Ser…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210500426401 Page: 1 of 72 Parlam Zhan Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. TEST REPORT Application No.: SHEM2105004264CR FCC ID: 2A2FA-TRISOLITE2 IC: 27409-TRISOLITE2 Applicant: Nanjing Hznovi Electronic Technology Co., Ltd Address of Applicant: No.37, Jiangjun Avenue, Jiangning Economy and Technology development Zone, Nanjing City, Jiangsu Province, China Manufacturer: Nanjing Hznovi Electronic Technology Co., Ltd Address of Manufacturer: No.37, Jiangjun Avenue, Jiangning Economy and Technology development Zone, Nanjing City, Jiangsu Province, China Equipment Under Test (EUT): EUT Name: lite2, linglong2 Model No.: S8II Trade mark: trisio, Xiao Hongwu Standard(s) : 47 CFR Part 15, Subpart C 15.247 RSS-247 Issue 2, February 2017 RSS-Gen Issue 5, Amendment 2 (February 2021) Date of Receipt: 2021-05-12 Date of Test: 2021-05-21 to 2021-06-08 Date of Issue: 2021-06-25 Test Result: Pass* * In the configuration test…
