TurfPod v1.0 Instruction manual English – Original Instructions Stadium Grow Lighting B.V. Abr. Kroesweg 44 2742 KX Waddinxveen The Netherlands Preface Thank you for purchasing a TurfPod product from SGL. This manual contains all the necessary information for safe and correct installation, use and maintenance of a separate unit. Read this manual before you start using the product. Store this manual in an accessible place near the product for future reference. This manual is intended for groundsmen and greenkeepers of grass sports playing surfaces who must use the unit as part of their job. Read this manual carefully before using the unit and keep the manual at an accessible place close to the unit. Used symbols and signal words This manual includes warnings and notices on safe and effective handling of the product. These notes and warnings are accompanied by the following symbols and signal words. Read them attentively! DANGER Indicates a hazardous situation that, if not avoided, will result in death or serious injury. WARNING Indicates a hazardous situation that, if not avoided, could result in death or serious injury. CAUTION Indicates a hazardous situation that, if not avoided, could result in minor or moderate injury. NOTICE Indicates information considered important, but not hazard-related (e.g. messages relating to property damage). Warranty SGL warrants that any product delivered by and/or on behalf of SGL will function according to the specifications laid down by SGL for a period of twelve (12) months from the date of delivery. The warranty term shall not recommence in case of replacement and/or repair of the products concerned. The original warranty period shall in all cases remain intact. Limitation of liability SGL accepts no liability for damage by: • Failure to comply with these operating instructions • Unintended use • Unauthorised modifications • Technical changes • Use of spare parts not recommended by the manufacturer Copyright This document is protected by copyright. The unlawful dissemination of this manual to third parties, reproduction in any manner whatsoever, including extracts, as well as exploitation or communication of its contents, is not allowed, unless explicitly approved by the publisher. Violations will result in liability for damages. We reserve the right to further claims. Introduction Product description Intended use Safety General safety precautions Transport and storage Operation Product overview Main parts LED Indicators Included equipment Optional equipment Specifications Agronomical specifications Operation Installing the product User interface Indicator light colour explanations Resetting the product Charging Transport and Storage Transport Mode Maintenance Cleaning Troubleshooting Disposal Disclaimer Appendices? Introduction Product description The product requires a good signal to communicate with the SGL portal. The product uses 4GLTEm technology to communicate with SGL systems and does not require additional hardware or support. The product is compatible with the SGL customer portal products and requires a proper set up and configuration to operate correctly. Please read the entire manual before operating the product. Intended use The product is intended to be used by groundsmen and greenkeepers of grass sports playing surfaces. The product is NOT intended to be used by:  Persons aged under 18  Persons with reduced physical, sensory or mental capacity  Persons who are under the influence of alcohol or drugs The product was designed to be easy to use. A single button interface allows the user to cycle through the different states of reporting, and also reset the device if needed. The product is intended to be used in combination with other SGL products. There are no user serviceable parts in the product (including the battery). Use of the product and the tools provided with it for any purpose other than those described in this manual absolves SGL B.V. of all responsibility. Safety General safety precautions WARNING Never open the product to attempt to service. There are no user serviceable parts and doing so can damage the product, and will void the warranty. In case of questions or doubts contact SGL via phone +31 79 593 38 01 or email [email protected]. NOTICE Read this manual carefully before using the product. Keep the manual at an accessible place close to the product. In case of questions or doubts contact SGL via phone +31 79 593 38 01 or email [email protected]. Transport and storage NOTICE Make sure that the product is completely and correctly stored before transport. To ensure optimal battery life and performance, never leave the product for an extended period of time on a dead battery! Operation WARNING Soil pins are extremely sharp and should be handled with care. CAUTION Never use a tool, your foot or other device to press the product into the pitch, simply press with your hand. If you encounter resistance remove the TurfPod and move a small distance and retry. Do not force the product into overly hard pitch/ground, this may damage the sensor pins. Do not submerge the product into water, always ensure that the ventilation holes on the bottom are facing down towards the pitch when installed. NOTICE Always install the product in an upright position as level as possible to insure proper light readings. GPS signals take up to 60 minutes to reach optimal accuracy, we advise that once installed you do not move the product to frequently. This will cause less accurate location reporting and also impact battery life. Never leave the product in a fixed location for more than 24 hours, if outdoor temperatures are over 20 degrees they should be moved >10cm every 12 hours or so to maintain optimal pitch conditions and not damage the sample area. Do not tamper with the products SIM card for any reason. Make sure the flag pole is facing away from the sun to insure no shadows can impact the PAR readings. Product overview Main parts 1. LED indi…
