2A2IXBHF02Bluetooth Headset

BHF02 User Manual 1 / 4 Power on: In shut-dow n state, long press the Multi-Function Button ( MFB) about 3 seconds, the headphone is turned on with a prompt tone and blue light flashes 5 time quickly Pairing: Long press MFB around 5s to Power on with prompt tone, the blue light flashe s 5 times quickly then blue an d red light flash alternately, and the head phone enter the pairing mode w ith a prompt tone. Then operate the cellphone to pair with it. Re-connecting : 1) Long press MFB around 3s to power on and it will enter the re-connection mode with blue light flas h once every 5s, And re-connected with the paired device in priority. by double-clicking the MFB to skip to pairing mode if needed. But the paired device needs to be re-connected manually under pairing mode 2) The headphone will enter re-connection mode after back to ef fective working distance If disconnected because of over distance BHF02 User Manual 2 / 4 Power off: In powered on state, long press MFB about 3s with red light flash 5 times quickly and with a prompt tone Answer phone calls: In Bluetooth Connected state, there is in-coming call, short press the MFB to pick up the call with a prompt tone. End up phone calls: During calling state, short press MFB to end up the calls with a prompt tone Reject phone calls: for unwanted phone calling, long press MFB about 2 seconds to reject with a prompt tone. Volume Adjustment: In phone calling or music playing status, short press the button "+" for volume up; short press "-" for vol ume dow n .there is pro mpt tones when th e volume is at the maximum an d minimum. The Last Number Redial: In the standby state，double-click MFB to redial the last number that have called before with a prompt tone. Activating SIRI: In standby state , long press MFB about 1.5 seconds to start SIRI (if The cellphone Bluetooth support this function) with a prompt tone. Voice transfer: During phone calling, long press the button "+" about 3 seconds, there is a “Toot” sound, then the voice is transferred to cellphone. Same operation to transfer voice b ack to the headphone again with a prompt tone Phone Call Mute: During pho ne calling, press the mute button about 1s to turn o ff the MIC. Same operation to turn on the MIC, both with prompt tone. Music Play/Pause : Short press the MFB to play / pause music. Previous/Next song: Long press "-" button about 2 seconds to previous song, long press "+" button about 2 seconds to next song. Removing pairing: after power ed-on, long press the MFB firstly then lo ng press "-" button about 5 BHF02 User Manual 3 / 4 seconds immediately , there is a prompt tone. Then paired memories are removed and enter pairing mode automatically LED Indicator status: Power-on and Pairing: Blue light flashes 5 times Power off: Red light flashes 5 times Pairing status: Red and blue lights flash alternately Standby status: Blue light flashes once every 4 seconds Incoming call: Blue light flashes once every 2 seconds During phone calling: Blue light flashes once every 7 seconds Music playing status : Blue light flashes once every 8 seconds Charging process: Red light is always on Charging completed: Red light off Low battery reminder: Red light flashes twice every 12 seconds and there is a “Toot” sound every 60 seconds Reconnect mode: Blue light flashes once times every 5 seconds Charging Operation: 1. Charge at charging Dock: Connect the charging dock with 5V power source with its red light always on. And put the headp hone at the dock then charging starts with red lig ht of headp hone o n. Whe n fully-charged the red light of headphone will be off. the headphone is workable during charging process 2. Headphone can be charged directly by Type-c cord This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this devi ce must accept any inter ference received, including interfere nce that may cause unde sired operation 4 / 4 BHF02 User Manual This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not ins talled and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try correct the interference by one or more of the following measures: - Reorient the rec eiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into and outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment.

July 19, 2021 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2A2IXBHF02 Product Name: Bluetooth Headset Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature>： Name：Guo Gang Title：General Manager Company：Shenzhen JianYi KeJi Youxian Gongsi

July 19, 2021 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen Timeway Testing Laboratories/ 5/F,Block 4, Anhua Industrial Zone.,No.8 TaiRan Rd.CheGongMiao,FuTian District, Shenzhen,CHINA. (Name of Agent company name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Shenzhen JianYi KeJi Youxian Gongsi / Rm401, Unit 1, B1 Bulding, Bqu, Jinhuhuayuan, Jinhu Road, Qingshuihejiedao, Luohu District, Shenzhen 518023, China <Signature>： Name：Guo Gang Title：General Manager Company：Shenzhen JianYi KeJi Youxian Gongsi

Label Location

Earphone

RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/ 20) /10 6 d = measurement distance in meters (m)---3m So pt = (EXd) 2 /30 x gt Field strength = 96.29dBuV/m @3m Ant gain =2.28dBi ;so Ant numeric gain= 1.69 So pt={ [10 ( 96.29 /20) /10 6 x3] 2 /30x1.69 }x1000 mW =0.76mW So (0.76mW/5mm)x √2.402GHz = 0.24 <3 Then SAR evaluation is not required

Report No.: TW2107063E File reference No.: 2021-07-15 Applicant: Shenzhen JianYi KeJi Youxian Gongsi Product: Bluetooth Headset Model No.: BHF02 Brand Name: BESIGN Test Standards: FCC Part 15.249 Test result: It is herewith confirmed and found to comply with the requirements set up by ANSI C63.10 &FCC Part 15 Subpart C, Paragraph 15.249 regulations for the evaluation of electromagnetic compatibility Approved By Jack Chung Manager Dated: July 15, 2021 Results appearing herein relate only to the sample tested The technical reports is issued errors and omissions exempt and is subject to withdrawal at SHENZHEN TIMEWAY TESTING LABORATORIES Zone C, 1st Floor, Block B, Jun Xiang Da Building, Zhongshan Park Road West, Tong Le Village, Nanshan District, Shenzhen, China Tel (755) 83448688, Fax (755) 83442996, E-Mail:[email protected] Report No.: TW2107063E Page 2 of 48 Date: 2021-07-15 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Special Statement： The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19. The testing quality system of our laboratory meet with ISO/IEC-17025 requirements, which is approved by CNAS. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: CNAS-LAB Code: L2292 The EMC Laboratory has been assessed and in compliance with CNAS-CL01 accreditation criteria for testing Laboratories (identical to ISO/IEC 17025:2005 General Requirements) for the Competence of testing Laboratories. FCC-Registration No.: 744189 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. The acceptance letter from the FCC is maintained in our files. Registration No.: 744189. Industry Canada (IC) —Registration No.:5205A The EMC Laboratory has been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing with Registration No.: 5205A. A2LA (Certification Number:5013.01) The EMC Laboratory has been accredited by the American Association for Laboratory Accreditation (A2LA). Certification Number:5013.01 Report No.: TW2107063E Page 3 of 48 Date: 2021-07-15 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Test Report Conclusion Content 1.0 General Details ............................................................................................. 4 1.1 Test Lab Details............................................................................................. 4 1.2 Applicant Details.............................................................................................. 4 1.3 Description of EUT .......................................................................................... 4 1.4 Submitted Sample............................................................................................. 4 1.5 Test Duration................................................................................................... 5 1.6 Test Uncertainty................................................................................................ 5 1.7 Test By......................................................................................................... 5 2.0 List of Measurement Equipment......................................................................... 6 3.0 Technical Details............................................................................................ 7 3.1 Summary of Test Results.................................................................................... 7 3.2 Test Standards................................................................................................. 7 4.0 EUT Modification............................................................................................. 7 5.0 Power Line Conducted Emission Test..................................................................... 8 5.1 Schematics of the Test....................................................................................... 8 5.2 Test Method and Test Procedure............................................................................ 8 5.3 Configuration of the EUT................................................................................... 8 5.4 EUT Operating Conditio…
