Page 1 of 2 RF EXPOSURE EVALUATION FCC ID:2A2J3-SR09 Product Name : Smart Ring Model Name : SR09W US9, SR09W, SR06, SR06W, SR03, SR09N,SR09N US6,SR09N US7,SR09N US8,SR09N US9,SR09N US10,SR09N US11,SR09N US12,SR09N US13,SR09 US6, SR09 US7, SR09 US8, SR09 US9, SR09 US10, SR09 US11, SR09 US12, SR09 US13, SR09W US6, SR09W US7, SR09W US8, SR09W US9, SR09W US10, SR09W US11, SR09W US12, SR09W US13 Bluetooth Version : BT BLE Operating frequency : 2402-2480MHz Numbers of Channel : 40 channels For DTS Antenna Type : PCB Antenna Antenna Gain : 0.95 dBi Type of Modulation : GFSK Power supply : Input:5V,1A Hardware Version : N/A Software Version : V1.0.0 Page 2 of 2 Standard Requirement According to § 15.247(i) and § 1.1307b(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See KDB 447498 D01 General RF Exposure Guidance v06, section 4. 3. 1. The 1-g and 10-g SAR test exclusion thresholds for 100MHz to 6GHz at test separation distances ≤ 50mm are determined by: [ (max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]*[ √f(GHz)] ≤3.0 for 1-g SAR and ≤7.5 for 10-g SAR extremity SAR, where ⚫ f(GHz) is the RF channel transmit frequency in GHz ⚫ Power and distance are rounded to the nearest mW and mm before calculation ⚫ The result is rounded to one decimal place for comparison. The test exclusions are applicable only when the minimum test separation distance is ≤ 50mm and for transmission frequencies between 100MHz and 6GHz. When the minimum test separation distance is <5mm, a distance of 5mm is applied to determine SAR test exclusion. Routine SAR evaluation refers to that specifically required by § 2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to quality for TCB approval. Channel (MHz) Maximum output power (dBm) Tune up tolerance (dBm) Max Tune Up Power (mW) Distance (mm) Calculation results Limit Operating Mode 2480 1.34 1.34 ± 1 1.713957 5 0.539829 3 BLE According to KDB 447498, no stand-alone required for BT antenna, and no simultaneous SAR measurement is required. Signature Simon Pu Manager Date: 2023-09-07

PCB antenna specification 1. Product model PCB antenna 2. Features *Stable and reliable in performances *Low temperature coefficient of frequency *Low profile, compact size *RoHS compliance 3.Applications *Bluetooth earphone systems *Hand-held devices when Bluetooth functions are needed, e.g., Smart phone. 4. Description The antenna are specially designed for Bluetooth applications. Based on proprietary design and processes,this antenna has excellent stability and sensitivity to consistently provide high signal reception efficiency 5. Electrical Specifications 5-1 Characteristics Specifications Unit Outline Dimensions 5.6×8.5 mm Working Frequency 2442 MHz Bandwidth (under -10dB return loss) 100min MHz VSWR 2MAX. Impedance 50 Ω Polarization Linear Polarization Gain** Peak 0.95（typical） dBi Efficiency 84（typical） % Temperature Coefficient of Frequency 0±20max（@-40°C~85°C） ppm/°C ** Working frequency will be offset to another frequency according to the conditions of users ground plane and radome. **The data was measured by A Test Lab Techno Corp.(CTIA Authorized Test Lab). 5-2 6. Antenna Dimensions(unit:mm) a.AntennaDimensions 7.Radiation Pattern 7-1.3D Gain Pattern at（2442MHz） 7-2. Efficiency Table Frequency(MHz) 2400 2410 2420 2430 2442 2450 2460 2470 2480 2490 2500 Efficiency（dB） -1.38 -1.04 -0.85 -0.74 -0.73 -0.76 -0.86 -1.05 -1.18 -1.27 -1.40 Efficiency（%） 72.83 78.71 82.27 84.39 84.53 84.04 82.00 78.60 76.14 74.64 72.50 Gain（dBi） 0.55 0.6 0.71 0.82 0.95 0.95 0.8 0.69 0.65 0.63 0.59 7-3.Efficiency vs.Frequency 8. Matching circuit: 9. Fine tuning element vs. Center frequency System Matching Circuit Component Location Description Vendor 1 N/A - 2 2.2uH (0402) 3 0.7PF 0402 10.Storage Conditions: 1) Temperature:-25 to 85 (2) Relative Humidity:20% to 70%
