2A2JCEQBSU-U00Whipr Base Unit

Whipr, Inc.
Whipr Base Unit - FCC ID 2A2JCEQBSU-U00 - Whipr, Inc.
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Aug 10, 2021
Application Purpose
Original Equipment
Date of Application
Aug 10, 2021
Equipment Note
Whipr Base Unit
Frequency Range
2402.00000000 - 2480.00000000
Company
Whipr, Inc.
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

® Paddle. Ski. Row + THE WORLD'S ONLY PORTABLE MULTI-SPORT ERG MACHINE Whipr Base Unit Model: EQBSU-U00-BL1 or EQBSU-U00-BK1 Instruction Manual Includes: Base Unit, Stabilizing Bracket (for door), Strap Anchor, Ground Anchor, Webbing Strap, Carry Bag(Needs 3 AA Batteries - Not Included) 1)Install 3 AAA batteries. Batteries are located in the bottom of the unit. They can be installed by snapping off the plastic cover by pulling on both sides. 2)Turn power on by pushing and holding button on the far left (the one with the circle and vertical line in it). 3)After turning power on, you will need to select the desired sport mode. To select the mode, you will press the 2nd button on the left (the one with the 3 horizontal lines). You will then press the button in the middle (the one with the circle). The modes will be highlighted on the right. You will push the up or down button to select the desired mode. The options are: ROW, KAYAK, SWIM, OPEN, SUP, SKI. After selecting the mode, press the 2nd button again (the one with the 3 horizontal lines). 4)Resistance Mode – should now be selected from the wheel located at the back of the unit (1-10...1 being the easiest and 10 being the most difficult). 5)You are now ready to begin your exercise. 6)You can reset your workout any time by pressing the middle button (the one with the circle in it). The Display Stats include the following: Strokes/Minute, Distance, Time, 500 Meter Split Time, Projected Time, Calories, Average Watts Securing the Unit – some modalities require the Base Unit to be secured. There are 3 ways to secure the unit. Door - Securing the unit by using the attached inflatable anchor that goes under a door. The door should be a standard 3.5cm width door with up to a 2cm gap. 1)Stabilizing Bracket needs to be attached to the base unit – this easily can be done by locking the tabs on the bracket into 2 slots located on the bottom corners of Base Unit. 2)Slide the Bracket and Inflatable rubber anchor under the door. 3)Inflate the rubber anchor by pushing the larger of the 2 rubber balls on the Base Unit. You will need to keep pushing it until the anchor and bracket are fully secure and very tight under the door. When you are finished and would like to remove the Base Unit from the door crack, you can push the smaller rubber ball and the anchor will deflate. After removing from under the door, the Bracket can be taken off easily by pulling gently and removing from the grooves on the Base Unit. Strap Anchor – The strap holder can rotate to be horizontal or vertical 1)Before attaching the strap anchor, make sure the plastic panel that the bladder folds into is securely attached to the base unit. Also make sure the bladder is evenly placed in the square box (connects by magnets located within the top of the bladder). 2)The lug bolts on the strap anchor easily locks into place on the back of the Base Unit. 3)Take the loop end of the strap and place through anchor hole. 4)Wrap around object. 5)Place buckle through loop and tighten.. Ground Anchor – To use ground anchor, put in ground and wrap strap around anchor. See video links also: https://www.youtube.com/watch?v=7fCmaVLTanY https://whipr.com/collections/whipr-ecosystem/products/whipr-base-unit FCC DISCLAIMER Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC RulesThese limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Canada IC DISCLAIMER This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1) L’appareil ne doit pas produire de brouillage; 2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. 3. For WIFI product, it should be added: This equipment complies with FCC’s and IC’s RF radiation exposure limits set forth for an uncontrolled environment. The antenna(s) used for this transmitter must be installed and operated to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating…

Text truncated - open the document above for the full version.

External Photos

EQBSU-U00-BL1

ID Label/Location Info

Size:66X53 mm Material:silver polyster Affix location:The bottom of the base unit LABEL AREA

ID Label/Location Info

Size:66X53 mm Material:silver polyster Affix location:The bottom of the base unit base unit LABEL AREA

RF Exposure Info

Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Report No.: 210207077GZU FCC ID: 2A2JCEQBSU-U00 Version: 06 November 2020 Page 1 of 3 FCC simultaneously transmitter-Mobile (MPE) RF Exposure Compliance Requirement Model no.: EQBSU-U00-BL1, EQBSU-U00-BK1 1. Standard requirement Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2m normally can be maintained between the user and the device. (a) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S)(mW/cm 2 ) Averaging Times ׀E׀ 2 ׀, H׀ 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842/f 4.89/f (900/f 2 )* 6 30-300 61.4 0.163 1.0 6 300-1500 -- -- f/300 6 1500-100000 -- -- 5 6 (b) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S)(mW/cm 2 ) Averaging Times ׀E׀ 2 ׀, H׀ 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f 2 )* 30 30-300 27.5 0.073 0.2 30 300-1500 -- -- F/1500 30 1500-100000 -- -- 1.0 30 Note: f=frequency in MHz; *Plane-wave equivalent power density Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Report No.: 210207077GZU FCC ID: 2A2JCEQBSU-U00 Version: 06 November 2020 Page 2 of 3 FCC simultaneously transmitter-Mobile (MPE) 2. MPE Calculation Method E (V/m)=(30*P*G) 0.5 /d Power Density: Pd(W/m 2 )=E 2 /377 E=Electric Field (V/m) P=Peak RF output Power (W) G=EUT Antenna numeric gain (numeric) d= Separation distance between radiator and human body (m) The formula can be changed to Pd= (30*P*G)/(377*d 2 ) From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. 3. Calculated Result and Limit BLE: Peak Output Power = 1.6dBm (max. value provided by client), antenna gain = 3.4dBi as declared by applicant Frequency (MHz) Antenna Gain (Numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 2402 2.19 1.6 1.45 0.00063 1 Complies MPE ratio: 0.00063 (mW/cm2)/1(mW/cm2) = 0.00063 WIFI: Peak Output Power = 17.2dBm(max.value declared by client), antenna gain = 3.4dBi as declared by applicant Frequency (MHz) Antenna Gain (Numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 2412 2.19 17.2 52.48 0.02284 1 Complies MPE ratio: 0.02284 (mW/cm 2 )/1(mW/cm 2 ) = 0.02284 Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Report No.: 210207077GZU FCC ID: 2A2JCEQBSU-U00 Version: 06 November 2020 Page 3 of 3 FCC simultaneously transmitter-Mobile (MPE) Sum of the MPE ratio for all simultaneously transmitting antennas: 0.00063+0.02284= 0.02347 < 1 According to MPE test Exclusion condition in KDB 447498 (D01) General RF Exposure Guidance D01 v06, the MPE report is not required. Test Location: Intertek Testing Services Shenzhen Ltd. Guangzhou Branch All tests were performed at: Room102/104, No 203, KeZhu Road, Science City, GETDD Guangzhou, China

Test Report

WHIPR, INC. TEST REPORT SCOPE OF WORK EMC TESTING–EQBSU-U00-BL1, EQBSU-U00-BK1 REPORT NUMBER 210207077GZU-001 ISSUE DATE [REVISED DATE] 06- August -2021 [---------------------] PAGES 65 DOCUMENT CONTROL NUMBER FCC WIFI-d © 2017 INTERTEK TEST REPORT Room 02, & 101/E201/E301/ E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Telephone: +86 20 8213 9688 Facsimile: +86 20 3205 7538 www.intertek.com.cn This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Version: 10 June 2019 Page 2 of 65 FCC WIFI-d Applicant Name & Address : WHIPR, INC. 251 Little Falls Drive, Wilmington, Delaware, 19808,USA Manufacturing Site : Same as applicant Intertek Report No: FCC ID: : 210207077GZU-001 2A2JCEQBSU-U00 Test standards 47 CFR PART 15 Subpart C: 2019 section 15.247 Sample Description Product : Whipr Base Unit Model No. : EQBSU-U00-BL1, EQBSU-U00-BK1 Electrical Rating : DC 4.5V (3x1.5V “AA” battery) Serial No. : Not Labeled Date Received : 07 February 2021 Date Test Conducted : 01 March 2021-20 July 2021 Prepared and Checked By Elena Lei Engineer Approved By: Strong Yao Manager TEST REPORT Intertek Report No.: 210207077GZU-001 Version: 10 June 2019 Page 3 of 65 FCC WIFI-d CONTENT TEST REPORT ........................................................................................................................... 1 CONTENT ............................................................................................................................. 3 1.0 TEST RESULT SUMMARY ........................................................................................... 4 2.0 GENERAL DESCRIPTION ............................................................................................ 5 2.1 PRODUCT DESCRIPTION ...................................................................................................... 5 2.2 RELATED SUBMITTAL(S) GRANTS .......................................................................................... 5 2.3 TEST METHODOLOGY ......................................................................................................... 6 2.4 TEST FACILITY.................................................................................................................... 6 3.0 SYSTEM TEST CONFIGURATION ................................................................................ 6 3.1 JUSTIFICATION ................................................................................................................... 6 3.2 EUT EXERCISING SOFTWARE ............................................................................................... 7 3.3 SPECIAL ACCESSORIES ......................................................................................................... 8 3.4 MEASUREMENT UNCERTAINTY............................................................................................. 8 3.5 EQUIPMENT MODIFICATION ................................................................................................ 8 3.6 SUPPORT EQUIPMENT LIST AND DESCRIPTION ........................................................................ 9 4.0 MEASUREMENT RESULTS ....................................................................................... 10 4.1 ANTENNA REQUIREMENT .................................................................................................. 10 4.2 6 DB BANDWIDTH (DTS BANDWIDTH) ................................................................................ 11 4.3 DUTY CYCLE .................................................................................................................... 19 4.4 MAXIMUM AVERAGE CONDUCTED OUTPUT POWER ............................................................. 23 4.5 PEAK POWER SPECTRAL DENSITY ....................................................................................... 25 4.6 OUT OF BAND CONDUCTED EMISSIONS ............................................................................... 33 4.7 OUT OF BAND RADIATED EMISSIONS .................................................................................. 41 4.8 RADIATED EMISSIONS IN RESTRICTED BANDS........................................................................ 41 4.9 BAND EDGES REQUIREMENT ............................................................................................. 59 4.10 CONDUCTED EMISSION TEST ............................................................................................. 64 5.0 TEST EQUIPMENT LIST ............................................................................................ 65 TEST REPORT Intertek Report No.: 210207077GZU-001 Version: 10 June 2019 Page 4 of 65 FCC WIFI-d 1.0 TEST RESULT SUMMARY Test Item Test Requirement Test Method Result Antenna Requirement FCC PART 15 C section 15.247 (c) and Section 15.203 FCC PART 15 C section 15.247 (c) and Section 15.203 PASS 6 dB Bandwidth (DTS bandwidth) FCC PART 15 C secti…

Text truncated - open the document above for the full version.

Test Report

WHIPR, INC. TEST REPORT SCOPE OF WORK EMC TESTING–EQBSU-U00-BL1, EQBSU-U00-BK1 REPORT NUMBER 210207077GZU-002 ISSUE DATE [REVISED DATE] 06- August -2021 [---------------------] PAGES 35 DOCUMENT CONTROL NUMBER FCC BT 4.0-d © 2017 INTERTEK TEST REPORT Room 02, & 101/E201/E301/ E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Telephone: +86 20 8213 9688 Facsimile: +86 20 3205 7538 www.intertek.com.cn This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Version: 10 June 2019 Page 2 of 35 FCC BT 4.0-d Applicant Name & Address : WHIPR, INC. 251 Little Falls Drive, Wilmington, Delaware, 19808,USA Manufacturing Site : Same as applicant Intertek Report No: FCC ID: 210207077GZU-002 2A2JCEQBSU-U00 Test standards 47 CFR PART 15 Subpart C: 2019 section 15.247 Sample Description Product : Whipr Base Unit Model No. : EQBSU-U00-BL1, EQBSU-U00-BK1 Electrical Rating : DC 4.5V (3x1.5V “AA” battery) Serial No. : Not Labeled Date Received : 07 February 2021 Date Test Conducted : 01 March 2021-20 July 2021 Prepared and Checked By Elena Lei Engineer Approved By: Strong Yao Manager TEST REPORT Intertek Report No.: 210207077GZU-002 Version: 10 June 2019 Page 3 of 35 FCC BT 4.0-d CONTENT TEST REPORT ........................................................................................................................... 1 CONTENT ............................................................................................................................. 3 1.0 TEST RESULT SUMMARY ........................................................................................... 4 2.0 GENERAL DESCRIPTION ............................................................................................ 5 2.1 PRODUCT DESCRIPTION ...................................................................................................... 5 2.2 RELATED SUBMITTAL(S) GRANTS .......................................................................................... 6 2.3 TEST METHODOLOGY ......................................................................................................... 6 2.4 TEST FACILITY.................................................................................................................... 6 3.0 SYSTEM TEST CONFIGURATION ................................................................................ 6 3.1 JUSTIFICATION ................................................................................................................... 6 3.2 EUT EXERCISING SOFTWARE ............................................................................................... 7 3.3 SPECIAL ACCESSORIES ......................................................................................................... 7 3.4 MEASUREMENT UNCERTAINTY............................................................................................. 8 3.5 EQUIPMENT MODIFICATION ................................................................................................ 8 3.6 SUPPORT EQUIPMENT LIST AND DESCRIPTION ........................................................................ 9 4.0 MEASUREMENT RESULTS ....................................................................................... 10 4.1 ANTENNA REQUIREMENT .................................................................................................. 10 4.2 6 DB BANDWIDTH (DTS BANDWIDTH) ................................................................................ 11 4.3 MAXIMUM PEAK CONDUCTED OUTPUT POWER ................................................................... 14 4.4 PEAK POWER SPECTRAL DENSITY ....................................................................................... 17 4.5 OUT OF BAND CONDUCTED EMISSIONS ............................................................................... 20 4.6 OUT OF BAND RADIATED EMISSIONS .................................................................................. 23 4.7 RADIATED EMISSIONS IN RESTRICTED BANDS........................................................................ 23 4.8 BAND EDGES REQUIREMENT ............................................................................................. 32 4.9 CONDUCTED EMISSION TEST ............................................................................................. 34 5.0 TEST EQUIPMENT LIST ............................................................................................ 35 TEST REPORT Intertek Report No.: 210207077GZU-002 Version: 10 June 2019 Page 4 of 35 FCC BT 4.0-d 1.0 TEST RESULT SUMMARY Test Item Test Requirement Test Method Result Antenna Requirement FCC PART 15 C section 15.247 (c) and Section 15.203 FCC PART 15 C section 15.247 (c) and Section 15.203 PASS 6 dB Bandwidth (DTS bandwidth) FCC PART 15 C section 15.247 (a)(2) ANSI C63.10: Clause 11.8 PASS Maximum Peak Conducted Output Power FCC PART 15 C section 15.247(b)(3) ANSI C63.…

Text truncated - open the document above for the full version.

Test Setup Photos

Note:EUT is positioned at the center of the turntable to keep 3 m between the measurement antenna and EUT for the radiated emissions measurements Radiated Emission (Below 1GHz) Radiated Emission (Above 1GHz)

Contact Information

Applicant

Adrian Lee(Director of Global Supply Chain)
[email protected]3037258329Fax: n/a

Technical Contact

Intertek Testing Services Shenzhen Ltd.Guangzhou BElena Lei
[email protected]+86 20 82139616

lock E, No.7-2 Guang Dong Software Science Park, C · Guangzhou, Guangdong · China

Non-Technical Contact

Intertek Testing Services Shenzhen Ltd.Guangzhou BElena Lei
[email protected]+86 20 82139616

Test Firm

Intertek Testing Services Shenzhen LTD., GuangzhouEmily Huang
[email protected]+86 21 50319089-232

Technical Specifications

#Rule PartsFrequency RangePower Output
215C2.40 GHz - 2.48 GHz1.43 mW
Confidentiality
Long Term
Grant Notes
Output power listed is conducted. This device must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. End users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
