2A2JJ-YHW-6Infrared Thermometer

WARNING: The measurement result is only for reference, which is not a substitute for a physician's diagnosis. It is very dangerous to self-judge and treat only based on the measurement result. Please follow the doctor's instructions. WARNING: Please put the battery out of the reach of children, otherwise it is dangerous. WARNING: When the product is not used for a long time (more than 3 months), remove the battery from device to prevent the battery leakage. WARNING: If there is a temperature difference between the environment of the storage and that of the measurement, place the device in the measuring environment for more than 30 minutes, otherwise there may be errors in the measurement results. WARNING: It is forbidden to immerse the infrared thermometer in any liquid, and it is forbidden to use it for a long time under too high or low temperature condition. No collisions, drops and mixing with sharp objects. WARNING: Do not put the battery close to the fire or into the fire to avoid the battery explosion. Do not use the battery when it leaks or molds. When discarding batteries or this product, follow local regulations to avoid contamination. WARNING: This device contains sensitive electronic components and should not be used in environments with strong electromagnetic interference (e.g., mobile phones, microwave ovens, etc.) to prevent temporary impacts on its accuracy. WARNING: Do not modify the device without authoriza- tion from the manufacturer. If the device is damaged, return the device to the manufacturer or distributor for service. WARNING: If the situations cannot be solved or unexpected problem happens, please consult the local 01030402 2. Device Structure and Composition 050607 ●Device main structure and composition The thermometer consists of a housing, a sensor, a display and a circuit board. Detachable parts and materials for use: cover, 2 AAA alkaline batteries Battery Reminder Temperature Unit Sound Prompt Body Temperature Mode Result Display Object Temperature Mode Memory Mark Phenomenon of breakdown The operating environment temperature is lower than 10°C (50.0°F) When in body temperature mode, the measurement result is ＞43.0°C (109.4°F) or when in the object temperature mode, the measurement result is ＞60.0°C (140.0°F) The screen display " " The screen display " " Possible cause Trouble shooting methods In the body temperature mode, the measurement result is＜22.0°C (71.6°F) or in the object temperature mode, the measurement result is ＜0.0°C (32.0°F) The screen display " " The screen display " " The operating environment temperature is higher than 40°C(104.0°F) 0809 10 Power On/ Measure Button LCD Display Area Temperature Probe Battery Cover Mode Button Memory Button MODE MEMO distributor. WARNING: Do not immerse this device in medical alcohol or other liquids. WARNING: Avoid contact between liquid and the device’s metal parts. WARNING: Dispose of thermometer, accessories, and battery per local laws and regulations. WARNING: This device contains batteries and recyclable electronic components. To protect the environment, do not dispose of it with household waste. Dispose of used batteries at an appropriate collection location following national or local regulations. CAUTION: Do not try to measure when the device is wet, which may cause measurement results inaccurate. CAUTION: Before measurement, please make sure that there is no sweat, cosmetics or oil stains on the forehead of subject. Please make sure that the subject does not take a bath, exercise or have a meal within 30 minutes, and the body is measured at a steady state. CAUTION: During measurement, do not let the subject directly face sunlight, heater or the air outlet of air conditioner, which will change the temperature of the forehead. Please conduct measurement in a stable environment as far as possible. CAUTION: When the product gets wet due to contact with steam, do not use until it get dry or be gently wiped with a soft, dry cloth or cotton balls, otherwise it will cause measurement errors. CAUTION: For patients measuring their own tempera- ture, it is recommended to measure close to the forehead. CAUTION: Please read this instruction carefully before use and confirm that the battery is installed. CAUTION: Do not move while using. CAUTION: Under the combined effects of the environ- ment and the frequency of use, the product's housing temperature may exceed 41°C. Please use it carefully. CAUTION: Please pay attention to product storage to prevent damage caused by pets, pests or children. CAUTION: This product is a high-precision device, please do not drop the device! Avoid drastic collisions and jolts and other adverse possibilities for transport. CAUTION: Due to the limited size of the label, the font is too small, please put it in the appropriate position to watch. CAUTION: Do not store this thermometer in tempera- ture extremes below -20°C(-4°F) or over +55°C(131 °F) or in excessive humidity (below 15% or above 90% non-condensing relative humidity). CAUTION: Do not use this thermometer in temperature extremes below 10°C(50°F) or over 40°C(104°F) or in excessive humidity (below 15% or above 90% non-condensing relative humidity). ●Measurement environment: Temperature: 10°C (50 °F) to 40°C (104°F) Relative humidity: 15% to 90% (no condensation) Atmospheric pressure: 70kPa to 106kPa ●Transportation and storage environment: Temperature: -20°C(-4 °F) to +55°C (131°F) Relative humidity: 15% to 90%(no condensation) Atmospheric pressure: 70kPa to 106kPa When body temperature is 37.6 °C(99.7°F) or higher, the device will make sounds as "di-di-di" to prompt. ●Object temperature mode (Measure temperature of object) Short press the mode button in the power-on state, and the display icon flashes to switch between body temperature mode and object temperature mode. After selecting " "(object temperature mode), approach the object to be measured and press the Power On/ Measure Button " " to display the measurement resu…

Text truncated - open the document above for the full version.

Jiangsu Yuyue Medical Equipment & Supply Co., Ltd. Date: 3/4/2026 Federal Communications Commissions Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 RE: CFR 47 §2.911 (d)(5) Attestation FCC ID: 2A2JJ-YHW-6 Grantee FRN: 0031126220 1. Jiangsu Yuyue Medical Equipment&Supply Co., Ltd. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. 2. Jiangsu Yuyue Medical Equipment&Supply Co., Ltd. (“the applicant”) certifies that, the device does not have cybersecurity and / or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, identified on the Covered List installed on the device, nor will it be installed by the applicant anytime after certification. 3. Jiangsu Yuyue Medical Equipment&Supply Co., Ltd. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment and is not an affiliate or subsidiary of an entity identified on the Covered List. Sincerely yours, Name: Caixia Yang Job Title: RA Specialist Company Name: Jiangsu Yuyue Medical Equipment&Supply Co., Ltd.

Date: 3/4/2026 Federal Communications Commissions Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 RE: CFR 47 §2.911 (d)(7) FCC US Agent Letter of Attestation FCC ID: 2A2JJ-YHW-6 Grantee FRN: 0031126220 To whom it may concern: FCC US Agent Agent Company Name:Yuwell Medtech USA LLC FCC FRN: 0036838977 Agent Contact Name: Zac Xu Agent US Address: 5900 BALCONES DRIVE SUITE 100, Austin, TEXAS,78731 Agent Email Address: [email protected] This letter is to confirm that we have accepted the responsibility to act as US Agent on behalf of Jiangsu Yuyue Medical Equipment & Supply Co., Ltd. (“the applicant”) for the above referenced FCC ID. We are aware of the requirements and responsibilities of the applicant’s agent for service of process as outlined in the FCC section 2.911(d)(7) and Report and Order FCC 22-84 paragraph 63. Sincerely, Authorized Agent Contact Person Name: Zac Xu Agent contact Job Title: Strategy Manager Agent Company name: Yuwell Medtech USA LLC

Jiangsu Yuyue Medical Equipment&Supply Co., Ltd. Date: 3/4/2026 Federal Communications Commissions Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 RE: CFR 47 §2.911 (d)(7) Agent Designation Attestation FCC ID: 2A2JJ-YHW-6 Grantee FRN: 0031126220 Jiangsu Yuyue Medical Equipment&Supply Co., Ltd. as required by section 2.911(d)(7), designates the following agent, located in the United States, for purposes of acting as the applicant’s agent for service of process. The applicant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility under CFR 47 §2.929(c) to inform the FCC whenever the agent information changes. U.S. Agent Information: Contact Person: Zac Xu Company Name: Yuwell Medtech USA LLC Company Address: 5900 BALCONES DRIVE SUITE 100, Austin, TEXAS,78731 FCC FRN: 0036838977 Email: [email protected] Sincerely yours, Name: Caixia Yang Job Title: RA Specialist Company Name: Jiangsu Yuyue Medical Equipment&Supply Co., Ltd.

Jiangsu Yuyue Medical Equipment&Supply Co., Ltd. Date: 3/4/2026 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 To whom it may concern: I, the undersigned, hereby authorize UL Verification Services Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL Verification Services Inc. as our representative, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signed by: Company Name: Jiangsu Yuyue Medical Equipment&Supply Co., Ltd. Contact Name: Caixia Yang Title of Person: RA Specialist Address: No.1 Baisheng Road Development Zone, Danyang, Jiangsu 212300 China

Jiangsu Yuyue Medical Equipment&Supply Co., Ltd. Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: 2A2JJ-YHW-6 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Company Name: Jiangsu Yuyue Medical Equipment&Supply Co., Ltd. Contact Name: Caixia Yang Title of Person: RA Specialist Address: No.1 Baisheng Road Development Zone, Danyang, Jiangsu 212300 China Date:3/4/2026

External Photographs Page 2 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. External Page 3 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Page 4 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch.

A4 Power source: DC 3V (2×1.5V AAA alkaline batteries) JIANGSU YUYUE MEDICAL EQUIPMENT & SUPPLY CO.,LTD. No.1 Baisheng Road Development Zone, Danyang, Jiangsu 212300 CHINA Body temperature mode measuring site: forehead Serial number and Manufacture date: see product Infrared thermometer Service life: 5 years 10 Model: YHW-6 YHW-6001 FCC ID: 2A2JJ-YHW-6 Note: This label will be permanently attached on the product. label location

Internal Photographs Page 2 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal Page 3 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Page 4 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. PCB Antenna

FCC ID: 2A2JJ-YHW-6 According to 447498 D04 Interim General RF Exposure Guidance v01, 2.1.4 MPE-Based Exemption An alternative to the SAR-based exemption is provided in § 1.1307(b)(3)(i)(C), for a much wider frequency range, from 300 kHz to 100 GHz, applicable for separation distances greater or equal to λ/2π, where λ is the free-space operating wavelength in meters. The MPE-based test exemption condition is in terms of ERP, defined as the product of the maximum antenna gain and the delivered maximum time-averaged power.10 For this case, a RF source is an RF exempt device if its ERP (watts) is no more than a frequency-dependent value, as detailed tabular form in Appendix B. These limits have been derived based on the basic specifications on Maximum Permissible Exposure (MPE) considered for the FCC rules in § 1.1310(e)(1). B.4 SAR-based Exemption SAR-based thresholds are derived based on frequency, power, and separation distance of the RF source. The formula defines the thresholds in general for either available maximum time- averaged power or maximum time-averaged ERP, whichever is greater. If the ERP of a device is not easily determined, such as for a portable device with a small form factor, the applicant may use the available maximum time-averaged power exclusively if the device antenna or radiating structure does not exceed an electrical length of λ/4. As for devices with antennas of length greater than λ/4 where the gain is not well defined, but always less than that of a half-wave dipole (length λ/2), the available maximum time-averaged power generated by the device may be used in place of the maximum time-averaged ERP, where that value is not known. The separation distance is the smallest distance from any part of the antenna or radiating structure for all persons, during operation at the applicable ERP. In the case of mobile or portable devices, the separation distance is from the outer housing of the device where it is closest to the antenna. The SAR-based exemption formula of § 1.1307(b)(3)(i)(B), repeated here as Formula (B.2), applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power or effective radiated power (ERP), whichever is greater, of less than or equal to the threshold Pth (mW). This method shall only be used at separation distances from 0.5 cm to 40 cm and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by Formula (B.2). and f is in GHz, d is the separation distance (cm), and ERP 20cm is per Formula (B.1). The example values shown in Table B.2 are for illustration only. 1. SAR test exclusion threshold for 2.402GHz~2.480GHz is 3 mW. -The maximum tune-up power with tolerance is 4 dBm=2.512 mW, the antenna is -1.72 dBi, so the ERP = EIRP – 2.15 =0.13 dBm=1.030 mW. - When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. 2. Conclusion: No SAR is required.

The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report apply to the test sample(s) mentioned above at the time of the testing period only and are not to be used to indicate applicability to other similar products. FCC 47 CFR PART 15 SUBPART C TEST REPORT For Infrared Thermometer MODEL NUMBER: YHW-6 REPORT NUMBER: 4792105873-1-RF-1 ISSUE DATE: March 3, 2026 FCC ID: 2A2JJ-YHW-6 Prepared for JIANGSU YUYUE MEDICAL EQUIPMENT & SUPPLY CO.,LTD. No.1 Baisheng Road, Development Zone, Danyang, Jiangsu PR 212300 CHINA. Prepared by UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch Room 101, Building 2, No.4, Information Road, Songshan Lake, Dongguan, Guangdong, China Tel: +86 769 22038881 Fax: +86 769 33244054 Website: www.ul.com REPORT NO.: 4792105873-1-RF-1 Page 2 of 79 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Revision History Rev. Issue Date Revisions Revised By V0 March 3, 2026 Initial Issue REPORT NO.: 4792105873-1-RF-1 Page 3 of 79 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Summary of Test Results Test Item Clause Limit/Requirement Result Antenna Requirement N/A FCC Part 15.203/15.247 (c) Pass AC Power Line Conducted Emission ANSI C63.10-2020, Clause 6.2 FCC Part 15.207 N/A Conducted Output Power ANSI C63.10-2020, Clause 11.9.1.2 FCC Part 15.247 (b)(3) Pass 6dB Bandwidth and 99% Occupied Bandwidth ANSI C63.10-2020, Clause 11.8.1 FCC Part 15.247 (a)(2) Pass Power Spectral Density ANSI C63.10-2020, Clause 11.10.2 FCC Part 15.247 (e) Pass Conducted Band edge and spurious emission ANSI C63.10-2020, Clause 11.11 FCC Part 15.247(d) Pass Radiated Band edge and Spurious Emission ANSI C63.10-2020, Clause 11.12 FCC Part 15.247 (d) FCC Part 15.205/15.209 Pass Duty Cycle ANSI C63.10-2020, Clause 11.6 None; for reporting purposes only. Pass Note: 1. N/A: In this whole report not applicable. *This test report is only published to and used by the applicant, and it is not for evidence purpose in China. *The measurement result for the sample received is <Pass> according to <FCC 47 CFR PART 15 SUBPART C> when <Simple Acceptance> decision rule is applied. Decision rule for statement of conformity: The measurement uncertainty is not taken into account for statement of conformity. REPORT NO.: 4792105873-1-RF-1 Page 4 of 79 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. CONTENTS 1. ATTESTATION OF TEST RESULTS ..................................................................................... 6 2. TEST METHODOLOGY ......................................................................................................... 7 3. FACILITIES AND ACCREDITATION ..................................................................................... 7 4. CALIBRATION AND UNCERTAINTY ................................................................................... 8 4.1. MEASURING INSTRUMENT CALIBRATION ........................................................... 8 4.2. MEASUREMENT UNCERTAINTY ............................................................................ 8 5. EQUIPMENT UNDER TEST .................................................................................................. 9 5.1. DESCRIPTION OF EUT ........................................................................................... 9 5.2. CHANNEL LIST ........................................................................................................ 9 5.3. MAXIMUM POWER .................................................................................................. 9 5.4. TEST CHANNEL CONFIGURATION ...................................................................... 10 5.5. THE WORSE CASE POWER SETTING PARAMETER .......................................... 10 5.6. DESCRIPTION OF AVAILABLE ANTENNAS ......................................................... 10 5.7. SUPPORT UNITS FOR SYSTEM TEST ................................................................. 11 6. MEASURING EQUIPMENT AND SOFTWARE USED......................................................... 12 7. ANTENNA PORT TEST RESULTS ..................................................................................... 15 7.1. CONDUCTED OUTPUT POWER ........................................................................... 15 7.2. 6DB BANDWIDTH AND 99% OCCUPIED BANDWIDTH ........................................ 16 7.3. POWER SPECTRAL DENSITY .............................................................................. 18 7.4. CONDUCTED BAND EDGE AND SPURIOUS EMISSION ..................................... 19 7.5. DUTY CYCLE ......................................................................................................... 21 8. RADIATED TEST RESULTS ............................................................................................... 22 8.1. RESTRICTED BANDEDGE .................................................................................... 29 8.2. SPURIOUS EMISSIONS(1 GHZ~3 GHZ) ............................................................... 34 8.3. SPURIOUS EMISSIONS(3 GHZ~18 GHZ) ............................................................. 40 8.4. SPURIOUS EMISSIONS(9 KHZ~30 MHZ) ............................................................. 52 8.5. SPURIOUS EMISSIONS(18 GHZ~26 GHZ) ....…

Text truncated - open the document above for the full version.

Report No.: BTL-OTA-1-2502C238 Page 1 of 14 ANT Test Report Antenna Type: PCB Antenna EUT Photo Report No.: BTL-OTA-1-2502C238 Page 2 of 14 Project No. : 2502C238 Product Type : PCB Antenna Brand Name : yuwell Test Model : YUWELL_GC5BT_X01 Ant Date of Receipt : 2025-03-06 Date of Test : 2025-03-06 Issued Date : 2025-03-06 Report Version : R00 Standard(s) : NSI IEEE Std 149 Applicant : Jiangsu Yuyue Medical Equipment& Supply CO., LTD. Address : No.1 Baisheng Road Development Zone,Danyang,Jiangsu 212300 CHINA Manufacturer : Nanjing Lichao Electronic Technology Co.Ltd. Address : Room 1206, Huishang Building, No.2 Jinlan Road, Jiangning District, Nanjing, Jiangsu The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc.(Dongguan). Prepared by : Approved by : No.3, Jinshagang 1st Road, Dalang, Dongguan, Guangdong, China. Tel: +86-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-OTA-1-2502C238 Page 3 of 14 Table of Contents REPORT ISSUED HISTORY ........................................................................................... 4 1 . PHYSICAL LAYOUT AND SITE DESCRIPTION ....................................................... 6 1.1 WIRELESS MOBILE DEVICE TEST LABORATORY .......................................................................... 6 1.2 ANECHOIC CHAMBER ........................................................................................................................ 6 1.3 MULTI AXIS POSITIONING SYSTEM (MAPS™) ................................................................................ 6 1.4 QUIET ZONE ........................................................................................................................................ 7 1.5 EMCO MODEL 3165-01 ABSORBER NESTED DUAL-POLARIZED DUAL-VIVALDI ARRAY ANTENNA 7 1.6 EMCO-3102 CIRCULARLY POLARIZED COMMUNICATION ANTENNAS ....................................... 7 1.7 TEST EQUIPMENT .............................................................................................................................. 7 1.8 EMQUEST SOFTWARE ....................................................................................................................... 7 TEMPERATURE, HUMIDITY .......................................................................................... 7 2 . TEST EQUIPMENT LIST .......................................................................................... 12 2.1 TEST EQUIPMENT USED FOR MEASURING .................................................................................. 12 3 . PHOTOGRAPH ........................................................................................................ 14 3.1 EUT SETUP PHOTO .......................................................................................................................... 14 Report No.: BTL-OTA-1-2502C238 Page 4 of 14 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note BTL-OTA-1-2502C238 R00 Original Report. 2025-03-06 Valid Report No.: BTL-OTA-1-2502C238 Page 5 of 14 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL assumes no responsibility for the data provided by the customer, any statements, inferences or generalizations drawn by the customer or others from the reports issued by BTL. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025: 2017 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-OTA-1-2502C238 Page 6 of 14 1. PHYSICAL LAYOUT AND SITE DESCRIPTION 1.1 WIRELESS MOBILE DEVICE TEST LABORATORY All tests were performed in BTL Inc. state-of-the-art Wireless Mobile Device Test Laboratory consisting of a rectangular anechoic chamber equipped with a multi-axis positioning system (MAPS), a dual polarized quad- ridge waveguide horn, and two EMCO-3102 circularly polarized communication antennas. A base station simulator is used to establish communication with the EUT and place it in the proper mode, and a spectrum analyzer and RF switch combination is used for measuring the signal from the EUT at each position and polarization. BTL Inc.’s EMQuest EMQ-100 Pattern Measurement Software is used for data acquisition, post- processing, and generation of the required output. 1.2 ANECHOIC CHAMBER The anechoic chamber is a rectangular anechoic chamber designed and built by ETS-Lindgren with the following nominal dimensions。 Length: 5.1 m (200 in) Width:…
