2A2JW-HJ-6560Server

USER'S MANUAL HITACHI INDUSTRIAL COMPUTER HF-W7500 Model 65/60 INSTRUCTION MANUAL WIN-62-0075 USER'S MANUAL HITACHI INDUSTRIAL COMPUTER HF-W7500 Model 65/60 INSTRUCTION MANUAL WIN-62-0075 Read and keep this manual. • Read safety instructions carefully and understand them before starting your operation. • Keep this manual at hand for reference. First Edition, April 2022, WIN-62-0075 All Rights Reserved, Copyright © 2022, Hitachi, Ltd. The contents of this publication may be revised without prior notice. No part of this publication may be reproduced in any form or by any means without permission in writing from the publisher. Printed in Japan. TP<IC> (FL-MW2007) i PREFACE This manual is intended for operators of the HITACHI INDUSTRIAL COMPUTER HF-W7500 MODEL 65/60 (hereafter called as this equipment) contains information about the operation and maintenance of various devices necessary for their routine work. And also this manual describes the setup procedure of the OS installed in this equipment, namely the following pre-installed OS. ・Windows® 10 IoT Enterprise 2019 LTSC ・Windows Server® IoT 2019 Standard In the following pages, those marked as Windows® 10 indicate the above OS. SEPARATE VOLUME CONSTITUTION The manual of the HITACHI INDUSTRIAL COMPUTER HF-W7500 MODEL 65/60 consists of the following: ・SAFETY INSTRUMENTS ・INSTRUCTION MANUAL (This manual) ・RAS FEATURES MANUAL MANUAL CONSTITUTION This manual consists of the following: PREFACE IMPORTANT NOTIFICATIONS SAFETY INSTRUCTIONS PRECAUTIONS CHAPTER 1 GETTING STARTED CHAPTER 2 OPERATION CHAPTER 3 SET UP CHAPTER 4 PRECAUTIONS WHILE THE OS IS RUNNING CHAPTER 5 SPECIFICATIONS CHAPTER 6 CHECKUP AND MAINTENANCE CHAPTER 7 RESTORING THE FACTORY-SHIPPED CONDITION USING A RECOVERY DVD CHAPTER 8 MAINTENANCE OPERATIONS CHAPTER 9 TROUBLESHOOTING CHAPTER 10 RAID1 APPENDIX HANDLING REPLACEABLE COMPONENTS ii [Trademarks] • Microsoft®, Windows®, Internet Explorer®, Microsoft Edge® and Hyper-V® are registered trademarks of U.S. Microsoft Corporation in the United States and other countries. • Intel®, Intel® Xeon® are trademarks of Intel Corporation in the United States and other countries. • DisplayPort is a trademark or a registered trademark of Video Electronics Standards Association in the United States and other countries. • Magic Packet™ is a trademark or a registered trademark of Advanced Micro Devices, Inc. • All other product names (software and hardware) not from Hitachi described in this manual are the registered trademarks, the trademarks, or the products of their respective owners. • Zlib is used as a compression and decompression engine built in a part of the software of this product. Its copyright notice is as follows: Zlib ver 1.2.3 Copyright © 1995-2005 Jean-loup Gailly and Mark Adler iii IMPORTANT NOTIFICATIONS • The contents of this manual cannot be copy without permission. • The contents of this manual are subject to change without notice. NOTICE Depending on the type of failure, important files may be lost when you use this equipment. Files can be lost by power failure and human mistakes during operation in addition to the failure of the equipment. If such a situation occurs, the files cannot be recovered. In order to prevent data loss, make it a routine to save your files and establish a systematic schedule for backing up files. ● Harmonic Current Standards This equipment is compliant with the JIS C 61000-3-2 Harmonic Current Standard. ● VCCI Notice This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio noise disturbance may arise. When such trouble occurs, the user may be required to take corrective actions. [Note for storage capacity calculations] ● Memory capacities and requirements, file sizes and storage requirements, etc. must be calculated according to the formula 2 n . The following examples show the results of such calculations by 2 n (to the right of the equals signs). 1 KB (kilobyte) = 1,024 bytes 1 MB (megabyte) = 1,048,576 bytes 1 GB (gigabyte) = 1,073,741,824 bytes 1 TB (terabyte) = 1,099,511,627,776 bytes ● As for disc capacities, they must be calculated using the formula 10 n . Listed below are the results of calculating the above example capacities using 10 n in place of 2 n . 1 KB (kilobyte) = 1,000 bytes 1 MB (megabyte) = 1,000 2 bytes 1 GB (gigabyte) = 1,000 3 bytes 1 TB (terabyte) = 1,000 4 bytes iv ● This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. ● 이 기기는 업무용(A급) 전자파적합기기로서 판매자 또는 사용자는 이 점을 주의하시기 바라 며, 가정외의 지역에서 사용하는 것을 목적으로 합니다. This equipment conforms to the electromagnetic wave for Industrial use (Class A).Vender or user should take notice and use the purpose except for household use. v [Terms used in this manual] Terms used in this manual are defined as follows. ・Install: An operation of installing software programs in the computer’s HDD ・Setup: An operation of setting an environment so that the software can use in the computer ・Virtual machine: A virtual hardware environment provided by Virtual PC or Hyper-V® ・Host OS: A base operating system that operates the virtual machine ・Guest OS: An operating system that runs on the virtual machine [Rereading terms] This manual describes the Windows® operating procedure. Names of operations “sign in” and “sign out” are rep…

Text truncated - open the document above for the full version.

USER'S MANUAL HITACHI INDUSTRIAL COMPUTER HF-W6500 Model 60 INSTRUCTION MANUAL WIN-62-0074 USER'S MANUAL HITACHI INDUSTRIAL COMPUTER HF-W6500 Model 60 INSTRUCTION MANUAL WIN-62-0074 Read and keep this manual. • Read safety instructions carefully and understand them before starting your operation. • Keep this manual at hand for reference. First Edition, May 2021, WIN-62-0074 All Rights Reserved, Copyright © 2021, Hitachi, Ltd. The contents of this publication may be revised without prior notice. No part of this publication may be reproduced in any form or by any means without permission in writing from the publisher. Printed in Japan. TP<IC> (FL-MW2007) i PREFACE This manual is intended for operators of the HITACHI INDUSTRIAL COMPUTER HF-W6500 MODEL 60 (hereafter called as this equipment) contains information about the operation and maintenance of various devices necessary for their routine work. And also this manual describes the setup procedure of the OS installed in this equipment, namely the following pre-installed OS. ・Windows® 10 IoT Enterprise 2019 LTSB In the following pages, those marked as Windows® 10 indicate the above OS. SEPARATE VOLUME CONSTITUTION The manual of the HITACHI INDUSTRIAL COMPUTER HF-W6500 MODEL 60 consists of the following: ・SAFETY INSTRUMENTS ・INSTRUCTION MANUAL (This manual) ・RAS FEATURES MANUAL MANUAL CONSTITUTION This manual consists of the following: PREFACE IMPORTANT NOTIFICATIONS SAFETY INSTRUCTIONS PRECAUTIONS CHAPTER 1 GETTING STARTED CHAPTER 2 OPERATION CHAPTER 3 SET UP CHAPTER 4 PRECAUTIONS WHILE THE OS IS RUNNING CHAPTER 5 SPECIFICATIONS CHAPTER 6 CHECKUP AND MAINTENANCE CHAPTER 7 RESTORING THE FACTORY-SHIPPED CONDITION USING A RECOVERY DVD CHAPTER 8 MAINTENANCE OPERATIONS CHAPTER 9 TROUBLESHOOTING CHAPTER 10 Soft RAID APPENDIX HANDLING REPLACEABLE COMPONENTS ii [Trademarks] • Microsoft®, Windows®, Internet Explorer® and Hyper-V® are registered trademarks of U.S. Microsoft Corporation in the United States and other countries. • Intel®, Intel® Core TM i3 are trademarks of Intel Corporation in the United States and other countries. • DisplayPort is a trademark or a registered trademark of Video Electronics Standards Association in the United States and other countries. • Magic Packet™ is a trademark or a registered trademark of Advanced Micro Devices, Inc. • All other product names (software and hardware) not from Hitachi described in this manual are the registered trademarks, the trademarks, or the products of their respective owners. • Zlib is used as a compression and decompression engine built in a part of the software of this product. Its copyright notice is as follows: Zlib ver 1.2.3 Copyright © 1995-2005 Jean-loup Gailly and Mark Adler iii IMPORTANT NOTIFICATIONS • The contents of this manual cannot be copy without permission. • The contents of this manual are subject to change without notice. NOTICE Depending on the type of failure, important files may be lost when you use this equipment. Files can be lost by power failure and human mistakes during operation in addition to the failure of the equipment. If such a situation occurs, the files cannot be recovered. In order to prevent data loss, make it a routine to save your files and establish a systematic schedule for backing up files. ● Harmonic Current Standards This equipment is compliant with the JIS C 61000-3-2 Harmonic Current Standard. ● VCCI Notice This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio noise disturbance may arise. When such trouble occurs, the user may be required to take corrective actions. [Note for storage capacity calculations] ● Memory capacities and requirements, file sizes and storage requirements, etc. must be calculated according to the formula 2 n . The following examples show the results of such calculations by 2 n (to the right of the equals signs). 1 KB (kilobyte) = 1,024 bytes 1 MB (megabyte) = 1,048,576 bytes 1 GB (gigabyte) = 1,073,741,824 bytes 1 TB (terabyte) = 1,099,511,627,776 bytes ● As for disc capacities, they must be calculated using the formula 10 n . Listed below are the results of calculating the above example capacities using 10 n in place of 2 n . 1 KB (kilobyte) = 1,000 bytes 1 MB (megabyte) = 1,000 2 bytes 1 GB (gigabyte) = 1,000 3 bytes 1 TB (terabyte) = 1,000 4 bytes iv ● This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. ● 이 기기는 업무용(A급) 전자파적합기기로서 판매자 또는 사용자는 이 점을 주의하시기 바라 며, 가정외의 지역에서 사용하는 것을 목적으로 합니다. This equipment conforms to the electromagnetic wave for Industrial use (Class A).Vender or user should take notice and use the purpose except for household use. v [Terms used in this manual] Terms used in this manual are defined as follows. ・Install: An operation of installing software programs in the computer’s HDD／SSD ・Setup: An operation of setting an environment so that the software can use in the computer ・Virtual machine: A virtual hardware environment provided by Virtual PC or Hyper-V® ・Host OS: A base operating system that operates the virtual machine ・Guest OS: An operating system that runs on the virtual machine [Rereading terms] This manual describes the Windows® operating procedure. Names of operations “sign in” and “sign out” are replaced with “log on” and “log off” respectively depend…

Text truncated - open the document above for the full version.

CONFIDENTIALITY REQUEST Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. FCC ID: Product Title / Model 2A2JW-HJ-6560 Server / HJ-6560, HJ-7560, HJ-7565 The following exhibits contain trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our product. This material is not customarily available to the general public and we request that it be withheld from public inspection. We request that the following information submitted be held permanent confidential treatment. Permanent Confidential Request -. Schematics -. Block Diagram -. Operational Description (Theory of Operation) We also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give temporary confidentiality of commercially sensitive information prior to product release. Short-Term Confidential Request -. External Photos -. Internal Photos -. Test set-up photo -. User Manual If you have any questions, please feel free to contact me at the address shown below. Sincerely, (Type name of signer) Iori Kobayashi (Title of signer) Engineer (Applicant name) Hitachi, Ltd. (Date) January 10, 2023

Date: January 18, 2023 Dear Sir/Madam, Re: Letter of Similarity We, Hitachi, Ltd. declare the differences for between original model and variant models. -Product: Server -FCC ID: 2A2JW-HJ-6560 -Basic Model name: HJ-6560 -Variant Model name: HJ-7560, HJ-7565 ➔ There is a difference between CPU, HDD and RAM. ➔ Derivative model test completed. Sincerely Yours, (Type name of signer) Iori Kobayashi (Title of signer) Engineer (Applicant name) Hitachi, Ltd

External photos of EUT (Model: HJ-6560) External photos of EUT (Model: HJ-7560) External photos of EUT (Model: HJ-7565)

Label layout HF-W6500 规格 規格 RATING 100V-240V~;3.5A-1.5A 50Hz/60Hz 1 φ 型号 型號 MODEL HJ-6560 FCC ID:2A2JW-HJ-6560 株式会社日立制作所 Hitachi, Ltd. 2-1,Omika-cho 5-chome,Hi tachi-shi,Ibaraki,Japan 日本制造/日本製造 MADE IN JAPAN 服务器 伺服器 警告使用者：此為甲類資訊技術設備 ， 於居住環境中使用時 ， 可能會造 成射頻擾動 ， 在此種情況下 ， 使用者會被要求採取某些適當的對策 。 R35345 RoHS I.T.E. E142003 This device complies with part 15 of the FCC Rules. Operation is subject to the following two co nditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. HF-W7500 规格 規格 RATING 100V-240V~;3.5A-1.5A 50Hz/60Hz 1 φ 型号 型號 MODEL HJ-7565 FCC ID:2A2JW-HJ-6560 株式会社日立制作所 Hitachi, Ltd. 2-1,Omika-cho 5-chome,Hi tachi-shi,Ibaraki,Japan 日本制造/日本製造 MADE IN JAPAN 服务器 伺服器 警告使用者：此為甲類資訊技術設備 ， 於居住環境中使用時 ， 可能會造 成射頻擾動 ， 在此種情況下 ， 使用者會被要求採取某些適當的對策 。 R35345 RoHS I.T.E. E142003 This device complies with part 15 of the FCC Rules. Operation is subject to the following two co nditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. HF-W7500 规格 規格 RATING 100V-240V~;3.5A-1.5A 50Hz/60Hz 1 φ 型号 型號 MODEL HJ-7560 FCC ID:2A2JW-HJ-6560 株式会社日立制作所 Hitachi, Ltd. 2-1,Omika-cho 5-chome,Hi tachi-shi,Ibaraki,Japan 日本制造/日本製造 MADE IN JAPAN 服务器 伺服器 警告使用者：此為甲類資訊技術設備 ， 於居住環境中使用時 ， 可能會造 成射頻擾動 ， 在此種情況下 ， 使用者會被要求採取某些適當的對策 。 R35345 RoHS I.T.E. E142003 This device complies with part 15 of the FCC Rules. Operation is subject to the following two co nditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. HJ-6560 HJ-7560 HJ-7565

Internal photos of EUT (Model: HJ-6560) Internal photos of EUT (Model: HJ-7560) Internal photos of EUT (Model: HJ-7565)

verify No.324656537401 Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Tel: 82-31-285-0894 Fax: 82-505-299-8311 www.kctl.co.kr Report No.: KR23-SEF0014-A Page (2) of (31) KCTL-TIT004-006/6 KP22-07480 REPORT REVISION HISTORY Date Revision Page No 2023-01-17 Originally issued - 2023-01-25 Updated 19 p, 24 p This report shall not be reproduced except in full, without the written approval of Eurofins KCTL Co.,Ltd. This document may be altered or revised by Eurofins KCTL Co.,Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by Eurofins KCTL Co.,Ltd. will constitute fraud and shall nullify the document. This test report is a general report that does not use the KOLAS accreditation mark and is not related to KS Q ISO/IEC 17025 and KOLAS accreditation. Note. The report No. KR23-SEF0014 is superseded by the report No. KR23-SEF0014-A General remarks for test reports Statement concerning the uncertainty of the measurement systems used for the tests (may be required by the product standard or client) Internal procedure used for type testing through which traceability of the measuring uncertainty has been established: Procedure number, issue date and title: Calculations leading to the reported values are on file with the testing laboratory that conducted the testing. Statement not required by the standard or client used for type testing Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Tel: 82-31-285-0894 Fax: 82-505-299-8311 www.kctl.co.kr Report No.: KR23-SEF0014-A Page (3) of (31) KCTL-TIT004-006/6 KP22-07480 Contents 1. Applicant information ..................................................................................................................... 4 2. Laboratory information ................................................................................................................... 5 3. Test system configuration .............................................................................................................. 5 3.1 Operation environment ....................................................................................................... 6 3.2 Measurement Uncertainty .................................................................................................. 7 4. Description of EUT .......................................................................................................................... 9 4.1 General information ............................................................................................................ 9 4.2 Product description ........................................................................................................... 12 4.3 Auxiliary equipments ........................................................................................................ 13 4.4 Test configuration ............................................................................................................. 14 4.5 Operating conditions ........................................................................................................ 16 5. Summary of test results ............................................................................................................... 18 5.1 Summary of EMI emission test results ............................................................................. 18 6. Test results .................................................................................................................................... 19 6.1 Conducted Emissions....................................................................................................... 19 6.2 Radiated Emission ........................................................................................................... 24 Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Tel: 82-31-285-0894 Fax: 82-505-299-8311 www.kctl.co.kr Report No.: KR23-SEF0014-A Page (4) of (31) KCTL-TIT004-006/6 KP22-07480 1. Applicant information Applicant: Hitachi, Ltd. Address: 2-1, Omika-cho 5-chome Hitachi-shi Ibaraki-ken Japan Manufacturer: Hitachi, Ltd. Address: 2-1, Omika-cho 5-chome Hitachi-shi Ibaraki-ken Japan Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Tel: 82-31-285-0894 Fax: 82-505-299-8311 www.kctl.co.kr Report No.: KR23-SEF0014-A Page (5) of (31) KCTL-TIT004-006/6 KP22-07480 2. Laboratory information Address Eurofins KCTL Co.,Ltd. (Suwon Lab.) 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Telephone Number: 82 31 285 0894 Facsimile Number: 82 505 299 8311 FCC Site Designation No: KR0040 VCCI Registration No.: R-20080, G-20078, C-20059, T-20056 Industry Canada Registration No. : 8035A KOLAS NO.: KT231 SITE MAP Eurofins KCTL Co.,Ltd. Suwon city Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Tel: 82-31-285-0894 Fax: 82-505-299-8311 www.kctl.co.kr Report No.: KR23-SEF0014-A Page (6) of (31) KCTL-TIT004-006/6 KP22-07480 3. Test system configuration 3.1 Operation environment Temperature Humidity Pressure Chamber 10 m (RE) 21.4 °C / 21.2 °C 23.0 % R.H. / 22.7 % R.H. - Shielded room(CE) 21.2 °C 22.3 % R.H. - Test site These testing items were performed following locations; Test item Test site Conducted Emission Shielded Room Radiated Emission 10 m Chamber Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Tel: 82-31-285-0894 Fax: 82-505-299-8311 www.kctl.co.kr Report No.: KR23-SEF0014-A Page (7) of (31) KCTL-TIT004-006/6 KP22-07480 3.2 Measurement Uncertainty All measurements involve certain levels of uncertainties, especially in field of EMC. The factors contributing to uncertainties are test receiver, cable loss, antenna factor calibration, Antenna directivity, antenna factor variation with height, antenna phase center variation, antenna fre…

Text truncated - open the document above for the full version.

Test setup photos - Conducted Emission AC Main (Test #1) AC Main (Test #2, Test #3) - Radiated Emission 30 MHz ~ 1 GHz (Test #1) 1 GHz ~ 18 GHz (Test #1) 30 MHz ~ 1 GHz (Test #2, Test #3) 1 GHz ~ 18 GHz (Test #2, Test #3)
