2A2L9-CATCH2Multi-Device Wireless Charger

CAT CH: 2 CL ASSI CS QUICK S T A R T GUIDE Mu l t i -Dev ice Wi rele s s C harg e r Plug In. Use the USB-C cable and powerblock to power on your CATCH:2 Charge Up to Two Devices, Wirelessly. Place your Qi-compatible device(s) on the CATCH:2 The charger features a 5-coil arrangement allowing for multiple orientations, as illustrated below Note: Improper alignment may impact connection. SPECIFICATIONS — LIGHT — CATCH:2 CLASSICS Model: Catch2 Classics Input: DC 5V/3A DC9V/3A Wireless output (2): 5W / 7.5W / 10W Frequency: 1 12.82-146.47KHZ Efficiency: 7 5% Charging distance: 5 mm Supports all Qi-enabled devices Note: “Fast-charging” requires a QC 3.0 powerblock No Light Ready to charge White Light Your device is charging White Flashing Light Foreign object detected The lights on the back of t he CATCH:2 act as a charging indicator. Note: For certain devices, t he l ight i ndicator will t urn off despite being charged Instructions of the working mode of the coils: 1This product is a dual-charge wireless charging product with a total output power of 20W, 10W+10W respectively. The product total has 5 coils,coils 1, 2, and 3 compose group A.coils 4 and 5 compose group B. 2When the RX is placed on group A,only one of the three coils 1, 2, and 3 can transmit power,the other two coils will be automatically turned off. 3When the RX is placed on group B, only one of the coils 4 and 5 can transmit power, and the other coil will be automatically truned off. 4When both groups A and B are put RX on them, group A can only have one coil transmitting power, and group B can only have one coil transmitting power. Read all i nstructions and warnings prior to using the Courant CATCH:2 (“Product”). I mproper use of the Product may result in Product damage, overheating, toxic fumes, fire or explosion, for which damages you (“Purchaser”), and not Courant (“Manufacturer”) are responsible. • Wireless charging is temperature sensitive. Do not store the Product i n high- temperature environments, i ncluding intense sunlight or other f orms of heat. Do not place Product i n fire or other excessively hot environments. • Do not disassemble the Product or attempt to re-purpose or modify i n any manner. • Do not attempt to replace any par t of t he Product. • If t he Product i s i ntended by Purchaser t o be used by a minor, purchasing adult agrees to provide detailed instructions and warnings to any minor prior t o use. Failure to do so is sole responsibility of Purchaser, who agrees to indemnify Manufacturer f or any unintended use/misuse by a minor. • Do not place credit cards (with a chip or magnet) on the Product. • Product i s i ntended for hom e, office & general i ndoor use only . Please do not use near medical or i ndustrial equipment or on board an aircraft. • Keep away from liquids. • It i s recommended to unplug the Product i f i t i s not in use for an extended period of t ime. • All Products have gone through a thorough quality assurance inspection. I f you find the Product i s excessively hot, i s emitting odor, i s deformed, abraded, cut or is experiencing or demonstrating an abnormal phenomenon, i mmediately stop all Product use and contact Manufacturer. • For questions or i nstructions on the various ways to use the Product r efer t o the illustrations i n this manual. WARRANTY — At Courant we are dedicated to making the best quality products. Your CATCH:2 is under warranty for 1 year under normal use from the original date of purchase (the “Warranty Period”). The Purchaser must own the Product. This warranty does not affect any statutory rights that you may be entitled to. Keep a copy of your purchase receipt as proof of purchase. If a material or workmanship defect arises with regard to any Product, and a valid claim is received within the Warranty Period, we will at our option, eith er r epair t he Product using new or r efurbished par ts, r eplace the Product with a new or r efurbished unit, or r efund the purchase price of t he defective Product. For t he purpose of t his l imited warranty, “refurbished” means a Product or part that has been substantially returned to its original specifications. Except f or t he limited warranty expressly set f or th or t o the extent restricted or prohibited by applicable law, Courant expressly disclaims any and all other warranties (express or i mpl ied) i ncluding any warranty of quality, merchantability, or fitness for a par ticular purpose, and you specifically agree that Courant shall not be liable for any special, incidental, i ndirect, punitive, or consequential damages for breach of any warranty of any type on any Courant product. I n addition to and without l imiting the generality of t he foregoing disclaimers, t he limited warranty does not under any circumstances, cover t he replacement or cost of any electronic device or personal proper t y i nside or outside the Courant product. For t he avoidance of doubt, the limited warranty does not cover damages that arose from negligence, misuse, wear-and-tear or failure to follow the product i nstructions. Customer Service: [email protected] www.staycourant.com/warranty WARNINGS — LEGAL (CONT.) — Distributed by Very Great Inc. 52 Mercer Street, New York NY 10012. © 2021 Very Great Inc. All Rights Reserved. This equipment complies with FCC/IC RSS 102 radiation exposure limits set f or th for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. Cet équipement est conforme aux limites d’exposition aux radiations FCC/IC CNR 102 établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec une distance minimale de 20cm entre le radiateur et votre corps. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to par t 1 5 of t he FCC Rules. These limits are designed to provide reasonable protection against harmful i nterference in a resi…

Text truncated - open the document above for the full version.

VeryGreat,Incd/b/aCourant ModelDifference Productdescription:Multi-DeviceWirelessCharger Modelname:CATCH:2CLASSICS CR-C2-BK-BK,CR-C2-GR-GR,CR-C2-WH-SL,CR-C2-RS-RS, CR-C2-BL-SL,CR-C2-TN-PG TradeName:N/A FCCID: AllthemodelarethesamecircuitandRFmodule,onlyformodelname. Regards Sincerely Client’ssignature: Client’sname/title:NicoleLin(N/A) Contactinformation/address:52MercerStreet,#3,NewYork,NewYork,United States 2A2L9-CATCH2

C5266091_X8_Ed.1 1/1 Letter of Authorization < Very Great, Inc d/b/a Courant > Company:Very Great, Inc d/b/a Courant Address:52 Mercer Street, #3,New York,New York,United States Product Name:Multi-Device Wireless Charger Model Number:CATCH:2 CLASSICS CR-C2-BK-BK, CR-C2-GR-GR, CR-C2-WH-SL, CR-C2-RS-RS, CR-C2-BL-SL, CR-C2-TN-PG FCC Identifier: We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Nicole Lin Date: 2021-07-15 Title: N/A Signature of applicant: 2A2L9-CATCH2

C5266091_X10_Ed.1 1/1 < Very Great, Inc d/b/a Courant > Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2021-07-15 Subject: Request for Confidentiality FCC ID: To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name:Nicole Lin Title: N/A 2A2L9-CATCH2

EUT PHOTO(External Photos)

Label and label location Multi-Device Wireless Charger FCC ID:2A2L9- CATCH2

EUT PHOTO(Internal Photos) ※※※※※ ※※※※※ END OF REPORT

FCC ID:2A2L9-CATCH2 RF Exposure Evaluation 1 Measuring Standard KDB 680106 RF Exposure Wireless Charging Apps v03r01 2 Requirements According to the item 5 of KDB 680106 v03r01: Inductive wireless power transfer applications that meet all of the following requirements are excluded from submitting an RF exposure evaluation. (1) Power transfer frequency is less than 1MHz. (2) Output power from each primary coil is less than or equal to 15 watts. (3) The system may consist of more than one source primary coils, charging one or more clients. If more than one primary coil is present, the coil pairs may be powered on at the same time. (4) Client device is placed directly in contact with the transmitter. (5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). (6) The aggregate H-field strengths anywhere at or beyond 15 cm surrounding the device, and 20 cm away from the surface from all coils that by design can simultaneously transmit, and while those coils are simultaneously energized, are demonstrated to be less than 50% of the applicable MPE limit. Remark: Meet all the above requirements. Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) 3 Test Setup 4 Test Procedure 1) The RF exposure test was performed in anechoic chamber. 2) The measurement probe was placed at test distance (15 cm from all sides and 20 cm from the top) which is between the edge of the charger and the geometric center of probe. 3) The highest emission level was recorded and compared with limit as soon as measurement of each points (A, B, C, D, E) were completed. 4) The EUT was measured according to the dictates of KDB 680106 v03r01. Remark: The EUT’s test position A, B, C, D and E is valid for the E and H field measurements. 5) Test Mode1: Coil 1, Mode2: Coil 2, Mode3: Coil 3, Mode4: Coil 4, Mode5: Coil 5, Mode6: Coil 1+ Coil 4, Mode7: Coil 1+ Coil 5, Mode8: Coil 2+ Coil 4, Mode9: Coil 2+ Coil 5, Mode10: Coil 3+ Coil 4, Mode11: Coil 3+ Coil 5, the worst case mode are Mode 1 and Mode 6. This product is a dual-charge wireless charging product with a total output power of 20W, 10W+10W respectively. The product total has 5 coils, coils 1, 2, and 3 compose group A. coils 4 and 5 compose group B. When the RX is placed on group A, only one of the three coils 1, 2, and 3 can transmit power, the other two coils will be automatically turned off. When the RX is placed on group B, only one of the coils 4 and 5 can transmit power, and the other coil will be automatically truned off. When both groups A and B are put RX on them, group A can only have one coil transmitting power, and group B can only have one coil transmitting power.) 5 Test Instruments list Test Equipment Manufacturer Model No. SN. Cal.Date (mm-dd-yy) Cal.Due date (mm-dd-yy) Exposure Level Tester Narda ELT-400 N-0231 June. 26 2020 June. 25 2021 Magnetic field probe 100cm 2 Narda ELT probe 100cm 2 M0675 June. 26 2020 June. 25 2021 6 Test Result(Mode6: Coil 1+ Coil 4) E-Filed Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (V/m) 0.110-0.205 0.98 0.99 0.98 0.99 614 E-Filed Strength at 20 cm from the top of the EUT (V/m) Frequency Range (MHz) Test Position E Limits (V/m) 0.115-0.205 0.98 614 H-Filed Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (A/m) 0.115-0.205 0.16 0.15 0.15 0.16 1.63 H-Filed Strength at 20 cm from the top of the EUT (A/m) Frequency Range (MHz) Test Position E Limits (A/m) 0.115-0.205 0.16 1.63 Test Result(Mode1: Coil 1) E-Filed Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (V/m) 0.115-0.205 0.85 0.86 0.85 0.85 614 E-Filed Strength at 20 cm from the top of the EUT (V/m) Frequency Range (MHz) Test Position E Limits (V/m) 0.115-0.205 0.86 614 H-Filed Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (A/m) 0.115-0.205 0.12 0.11 0.12 0.11 1.63 H-Filed Strength at 20 cm from the top of the EUT (A/m) Frequency Range (MHz) Test Position E Limits (A/m) 0.115-0.205 0.12 1.63 Test Result(Mode3: Coil 5) E-Filed Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (V/m) 0.115-0.205 0.86 0.86 0.87 0.86 614 E-Filed Strength at 20 cm from the top of the EUT (V/m) Frequency Range (MHz) Test Position E Limits (V/m) 0.115-0.205 0.87 614 H-Filed Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (A/m) 0.115-0.205 0.11 0.10 0.11 0.11 1.63 H-Filed Strength at 20 cm from the top of the EUT (A/m) Frequency Range (MHz) Test Position E Limits (A/m) 0.115-0.205 0.11 1.63 7 Test Set-up Photo

Report N Date of T Date of is Total num Test Res Testing L Address . Applican Address . Manufac Address . Test spe Standar d Test proc Non-stan Test Rep Test Rep Master T This devi test (EUT identified This rep o be altered Product Tradema Model/Ty Ratings .. Number ........ Test ............... ssue ............. mber of page ult ................ Laboratory . .................... nt's name .... .................... cturer's nam .................... cification: d ................... cedure .......... ndard test me port Form No port Form(s) TRF ............... ce described T) is in com in the repor t ort shall not b d or revised name .......... rk ................ ype reference .................... FC FCC ...................... .................... ................... . es ................. .................... ...................... .................... ...................... .................... me ................... .................... .................... .................... ethod ........... o. .................. ) Originator . ...................... d above has pliance with t. be reproduce by ZKT, pers ...................... .................... e .................. .................... CC TE C ID:2 ........ ZKT-21 ...... Jun. 28 , .... : Jul. 02, ....... 21 ....... PASS ........ Shenzh ....... 1/F, No Avenu e ........ Very G r ....... 52 Mer c ........ Shenz h Yongfen ....... of feng h 518103 ....... FCC CF ....... / ....... N/A ........ TRF-E L ........ ZKT Tes ...... : Dated: 2 been tested the FCC re ed except in sonal only, a ........ Multi-D ....... COUR A ..... : CATCH CR-C2- CR-C2- ..... : Input: D Wireles EST R 2A2L9 06283040E , 2021 to Jul. 2021 hen ZKT Tec . 101, Buildin e, Fuhai Stree reat, Inc d/b cer Street, #3 hen Future C ngtian Indust huang, Fuyon FR Title 47 P L-107_V0 sting 2020-01-06 d by ZKT, an equirements. full, without nd shall be n Device Wirele ANT H:2 CLASSIC -BK-BK, CR- -BL-SL, CR-C DC 9V,3A ;DC s: 5W/7.5W/ REPO 9-CAT . 02, 2021 chnology Co ng B, No. 6, T et, Bao'an Di b/a Courant 3, New York Charger Tec trial Garden, ng, Town, Ba Part 15 Subpa d the test res . And it is a the written a noted in the r ess Charger CS C2-GR-GR, C2-TN-PG C 5V,3A /10W*2 Project RT TCH2 o., Ltd. Tangwei Com istrict, Shenz 10013 ch Co., Ltd the 3rd Ind u aoAn District art C sults show th applicable on approval of Z revision of th r CR-C2-WH- t No.: ZKT-21 P mmunity Indu zhen, China ustrial Park , Shenzhen, hat the equip nly to the tes ZKT, this doc e document. -SL, CR-C2- 106283040E Page 1 of 22 ustrial China pment under sted sample cument may . RS-RS, E 2 r y 1. VER 2. TES T M 3. GEN G T B T D E 4. CON C P D T E 4.6 T 5. RAD R A T D T 6. BAN 7. TES 8. EUT RSION ....... ST SUMMA TEST FACIL MEASUREM NERAL IN GENERAL D Test mode .. Block Diagra Test Conditio Description O EQUIPMENT NDUCTED CONDUCTE POWER LIN TEST PRO DEVIATION TEST SETU EUT OPERA Test Result . DIATED E Radiated Em Anechoic Ch Test Proced DEVIATION Test Result . NDWIDTH ST SETUP T CONSTR ................... ARY .......... LITY .......... MENT UNC FORMATI DESCRIPTI ................. am of EUT C ons ........... Of Support TS LIST FO D EMISSIO ED EMISSIO NE CONDU OCEDURE FROM TE S UP .............. ATING CON ................. MISSION mission Lim hamber Tes ure ............ FROM TE S ................. TEST ...... P PHOTO .. RUCTIONA TABL ................... ................... .................. ERTAINTY ION ........... ION OF EU .................. Configuratio .................. Units (Con d OR ALL TES ON TEST ... ON MEASU CTED EMIS .................. ST STANDA .................. NDITIONS . .................. MEASURE its .............. st Setup Dia .................. ST STANDA .................. ................... ................... AL DETAIL LE OF CONT ................... ................... .................. .................. ................... T ............... .................. on .............. .................. ducted Mod ST ITEMS .. ................... UREMENT .. SSION Lim ................. . ARD .......... .................. .................. .................. EMENT .... .................. agram ......... .................. ARD .......... .................. ................... ................... LS ............. TENTS ................... ................... .................. .................. ................... .................. .................. .................. .................. de) ............. .................. ................... .................. its .............. .................. .................. .................. .................. .................. ................... .................. .................. .................. .................. .................. ................... ................... ................... Project ................... ................... .................. .................. ................... .................. .................. .................. .................. .................. .................. ................... .................. .................. .................. .................. .................. .................. .................. ................... .................. .................. .................. .................. .................. ................... ................... ................... t No.: ZKT-21 P ................... ................... .................. .................. ................... .................. .................. .................. .................. .................. .................. ................... .................. .................. .................. .................. .................. .................. .................. ................... .................. .................. .................. .................. .................. ................... ................... ................... 106283040E Page 3 of 22 ................... ................... .....…

Text truncated - open the document above for the full version.

EUT TEST PHOTO
