User Manual USER MANUAL B.SHOW mini TW+ B.SHOW mini FC 2 User Manual CONTENT 1. Safety Informations 1.1. General Preventive Measures 4 1.2. Regulations for equipment that connects to power mains 5 1.3. Technical warnsigns and explanation 6 1.4. Battery Safety 7 2. Introduction 2.1. About us 8 2.2. B.SHOW mini TW+ / B.SHOW mini FC 8 3. General Product Information 3.1. Scope of delivery 9 3 .2. Control Functions 9 3.3. Features 9 4. Installation & Setup 4.1 Physical Installation and Rigging 10 4.2 Connections 11 4.2.1.1 AC Power 12 4.2.1.2 Charging the battery, operating and storage 12 4.2.2. DMX Connection 13 4.2.2.1. Cable Connection 13 4.2.2.2. Wireless Connection 13 5. Operation 5.1 Start up 16 5.2 Control Display 16 5.3 Display Short Cuts 16 5.4 Configuration 18 5.4.1 Battery Charge Status 18 5.4.2 Selecting DMX Mode 18 5.4.3 Stand Alone 19 5.4.4 Slave Mode 26 5.4.5 Settings 26 5.4.6 System Info 30 6. Accessories 6.1. Lenses 31 6 .2. More accessories 32 3 User Manual 7. Technical Data / Diagrams 7.1 Technical drawings and measurements 33 7.2 IP Rating 34 7.3 Technical Data - B.SHOW mini TW+ 35 7.4 Technical Data - B.SHOW mini FC 37 7.5 DMX-Charts / Color Macro Charts / CCT Chart 40 7.6 RDM Templates 70 7.7 Firmware Update 73 8. Troubleshooting 77 9. Manufacturer ́s Declaration 74 4 1. SAFETY INFORMATION 1.1. General Preventive Measures 1.1.1. Please read, understand and follow the instructions. 1.1.2. Store the instructions and information in a safe place. Best solution is the ring binder provided by ROXX ® . 1.1.3. Follow all safety warnings. Under no circumstances remove safety warnings or other information from the equipment. 1.1.4. Don’t use the equipment for any other intended purpose or manner. 1.1.5. Use only stable and compatible stands and/or brackets. Especially when fix installed. Make sure the wall brackets are properly installed and safe. Make sure the device is securely installed and cannot fall. 1.1.6. Check the safety regulations applying for your country before and during installation. 1.1.7. Keep the device away from heat! Don’t place/install near heaters, ovens or any source of heat. Make sure that the device always is efficiently cooled and cannot overheat. 1.1.8. Always guarantee that ventilation and cooling slots are clean and not blocked. 1.1.9. Item must be away minimum 20cm from anything around and above it. 1.1.10. Do not use this device close to water. 1.1.11. Do not expose this equipment to flammable materials. 1.1.12. Make sure that no objects can fall into the device. 1.1.13. Only use this device with the accessories recommended by the manufacturer. 1.1.14. Always check the equipment for housing damages, so that no water can enter the device. No containers containing liquids of any kind should be place on top of the unit. 1.1.15. Opening or modifying this device is only allowed by authorized and qualified persons. 1.1.16. All cables need to be checked after connecting the device in order to prevent damage or accidents. 1.1.17. Make sure that the device is transported safe and packed proper in order to prevent damage of any kind. 1.1.18. Once you notice improper function of your device due to damage, electric shock or anything similar, immediately unplug the unit from the mains outlet and contact our service department. 1.1.19. Clean the device with a dry cloth. User Manual 5 1.1.20. Observe all disposal laws applicable in your country. Especially for the packaging. 1.1.21. Plastic bags are not a toy! Keep away from children! 1.1.22. Please note that changes or modifications which are not approved by the party responsible for compliance will void the user’s authority to operate the device. 1.2 Regulations for equipment that connects to power mains 1.2.1. If an earthing contact is available in the used power cord, it must used in combination with an power outlet, providing a protective ground. In no circustances should the protective ground be deactivated. 1.2.2. Do not switch on the device immediately after it has been in strong different temperatures, especially after transport. Let the device acclimatize to the temparature in the room of usage first to prevent moisture and condensation. 1.2.3. Verify that the correct voltage and frequency are available in the area of operation, before connecting the unit to the mains outlet. 1.2.4. If the plug doesn‘t fit in your mains outlet, contact your electrician. 1.2.5. Make sure your power cord/adapter/connector does not show signs of kinks/warps or is being stepped on. 1.2.6. Allwas disconnect the unit when not in use or being cleaned. Don‘t pull on the cord to disconnect. Only touch power connections with dry hands! 1.2.7. Don‘t switch the unit on/off rapidly. This may cause damage. 1.2.8. If a fuse needs to be replaced, ALWAYS make sure that exact the same fuse will be used (type and rating). Repeatedly blown fuses need to be checked by an authorised service technician. 1.2.9. In the risk of lighting strike all units need to be unpluged from the mains in order to prevent damage. 1.2.10. During installation there must be a voltage free condition. 1.2.11. The device needs to be cleaned and serviced regularly and will credit this with a longer life cycle. Dust, dirt, moist, water, smoke, nicotine or anything similar inside the unit will cause damage/malfunction. 1.2.12. The unit needs to have at least 0,5m distance to anything flammable. 1.2.13. You have to make sure that any electrical installation applys to the laws of your country. Correct power cables and applying standards have to be used. User Manual 6 1.3. Technical warnsigns and explanation In order to prevent the risk of an electric shock, under no circumstances remove the cover/back or open the unit in any way! No user serviceable parts are inside. Service, maintenance and repairs should only be done by qualified service personnel or the manufacturer. Dangerous uninsulated voltage inside the device can cause an electrical shock when opened by unqualified…

Text truncated - open the document above for the full version.

ROXXGmbH Declarationonmodeldifference Wetheundersignedherebyconfirmthatthesemodelsareidentical,andsuchdevicesare electricallyidenticalandtheequipmentbearsanFCCIdentifiervalidatedbyagrantofcertification. Onlydifferentonmodel/typenumbers. Production name TrademarkFCCModelno. batterylight2A2LS-BSHOWMINI B.showminiFC ， B.showminiTW+ Confirmedby: DanielGarcia

2022.12.03 EurofinsElectricalandElectronicTestingNA,Inc. 914WestPatapscoAvenue Baltimore,MD21230 RE:CONFIDENTIALITYREQUESTFOR ( ProductName：batterylight ModelNumber：B.showminiFC，B.showminiTW+ FCCID：2A2LS-BSHOWMINI applicant:ROXXGmbH Address:HansestrasseNo.91|51149Cologne| Germany ) ToWhomItMayConcern: Thisletterservesasanofficialrequestforconfidentialityundersections0.457and0.459 ofCFR47.Wehaverequestedthatthe(BlockDiagram,Schematics,Operational Description)requiredtobesubmittedwiththisapplicationbepermanentlywithheld frompublicreview. SPECIFYREASONFORREQUEST(Theabovematerialscontaintradesecrets andproprietaryinformationnotcustomarilyreleasedtothepublic.Thepublic disclosureofthesematerialsmaybeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors.) Pleasecontactmeifthereisanyinformationyoumayneed. Sincerely, DanielGarcia

2022.12.03 ROXXGmbH HansestrasseNo.91|51149Cologne|Germany RE:LETTEROFAGENTAUTHORIZATION ToWhomItMayConcern: We,theundersigned,herebyauthorizeSamLvatEMTEK(DONGGUAN)CO.,LTD.toacton ourbehalfinallmattersrelatingtoapplicationforequipmentauthorization,includingthesigning ofalldocumentsrelatingtothesematters. Wealsoherebycertifythatnopartytotheapplicationauthorizedhereunderissubjecttothe denialofbenefits,includingFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseAct of1988,21U.S.C.853(a). Thisagreementexpiresoneyearfromthecurrentdate. Sincerely, DanielGarcia

FCCID:2A2LS-BSHOWMINI

Product Name: Product Key: Operating Voltαge: Power Consumption: Power Max. Out: Power Linking: Weight: Protection Class: Ta: B.SHO叭Imini FC 11401101 R。� ® 100V-240V AC, 50/60Hz 105W llA 11 units@ 120V I 23 units@ 230V 4, 9kg I 10,81bs IP65 40 。 Cl104 。 F This device complies with pa「t 15 of the FCC rules. Operation is sub­ ject to the following two conditions: 1- This device may NOT cause harmful interference. and 2- This device must accept any interference received, including interfe「ence that may cause undesi「ed operation. FCC ID: 2A2LS-BSHOWMINI C onforms to UL Std. 1573. Certified to CSA Std. C22.2N0.166 L ABEL

FCCID:2A2LS-BSHOWMINI ANT

ReportNo.EDG2207280043E03002RPage1of7Ver.1.0 TESTREPORT ProductName：batterylight ModelNumber：B.showminiFC，B.showminiTW+ FCCID：2A2LS-BSHOWMINI Preparedfor:ROXXGmbH Address:HansestrasseNo.91|51149Cologne|Germany Preparedby:EMTEK(DONGGUAN)CO.,LTD. Address:-1&2/F.,Building2,ZoneA,ZhongdaMarineBiotechnology ResearchandDevelopmentBase,No.9,XinchengAvenue, SongshanhuHigh-technologyIndustrialDevelopmentZone, Dongguan,Guangdong,China TEL:+86-0769-22807078 FAX:+86-0769-22807079 ReportNumber:EDG2207280043E03002R Date(s)ofTests:August10,2022toNovember21,2022 Dateofissue:November21,2022 $ 二维码 $ ReportNo.EDG2207280043E03002RPage2of7Ver.1.0 TableofContents 1.TESTRESULTCERTIFICATION...............................................................................................................................................3 2.EUTSPECIFICATION.................................................................................................................................................................5 3.TESTREQUIREMENT:...............................................................................................................................................................6 RFEXPOSUREEVALUATION...................................................................................................................................................6 4.MEASUREMENTRESULT.........................................................................................................................................................7 ReportNo.EDG2207280043E03002RPage3of7Ver.1.0 1.TESTRESULTCERTIFICATION Applicant:ROXXGmbH Address:HansestrasseNo.91|51149Cologne|Germany Manufacturer:ROXXGmbH Address:HansestrasseNo.91|51149Cologne|Germany EUT:batterylight ModelName: B.showminiFC ， B.showminiTW+ Trademark: MeasurementProcedureUsed: APPLICABLESTANDARDS STANDARDTESTRESULT §15.247(i),§2.1093PASS TheaboveequipmentwastestedbyEMTEK(DONGGUAN)CO.,LTD.Thetestdata,dataevaluation,test procedures,andequipmentconfigurationsshowninthisreportweremadeinaccordancewiththeprocedures giveninANSIC63.10(2013)andtheenergyemittedbythesampleEUTtestedasdescribedinthisreportisin compliancewiththerequirementsofFCCRules FCC§15.247(i),§2.1093 . Thetestresultsofthisreportrelateonlytothetestedsampleidentifiedinthisreport DateofTest:August10,2022toNovember21,2022 Preparedby: XiaYang/Editor Reviewer: TimDong/Supervisor Approve&AuthorizedSigner: SamLv/Manager ReportNo.EDG2207280043E03002RPage4of7Ver.1.0 ModifiedHistory VersionReportNo.RevisionDateSummary EDG2207280043E03002R/OriginalReport ReportNo.EDG2207280043E03002RPage5of7Ver.1.0 2. EUTSpecification CharacteristicsDescription Product:batterylight ModelNumber: B.showminiFC，B.showminiTW+ Allproductsarethesame,onlythemodelnumberandcolorofappearance aredifferent HereweselectedB.showminiFCforallthetest Sample:1# DeviceType: BluetoothV5.0 DataRate: 1MbpsforGFSKmodulation Modulation: GFSK OperatingFrequency Range(s): 2402-2480MHz NumberofChannels: 40Channels TransmitPowerMax: 2.79dBm(0.001901W) AntennaGain:-2.33dBi Powersupply: AC100-240V~50/60Hz Evaluationapplied:MPEEvaluation SAREvaluation ReportNo.EDG2207280043E03002RPage6of7Ver.1.0 3. TestRequirement: RFEXPOSUREEVALUATION Accordingto§15.247(i)and§1.1307(b)(1),systemsoperatingundertheprovisionsofthissectionshallbe operatedinamannerthatensuresthatthepublicisnotexposedtoradiofrequencyenergylevelinexcessof theCommission’sguidelines. RoutineSARevaluationreferstothatspecificallyrequiredby§2.1093,usingmeasurementsorcomputer simulation.WhenroutineSARevaluationisnotrequired,portabletransmitterswithoutputpowergreaterthan theapplicablelowthresholdrequireSARevaluationtoqualityforTCBapproval. OneantennaisavailablefortheEUT.Theminimumseparationdistanceis5mm. ReportNo.EDG2207280043E03002RPage7of7Ver.1.0 4. MeasurementResult Antennagain:-2.33dBi BLE_1M Transmit Frequency( MHz) Mode Measured Power (dBm) Tune upPower (dBm) Maxtuneup power(dBm) Calculation Result 1-g SAR 2402GFSK2.792±1 3 0.61846703 2441GFSK1.891±120.49513653 2480GFSK1.911±120.49917853 AccordingtoKDB447498,nostand-alonerequiredforBTantenna,andnosimultaneousSARmeasurementis required. ***EndofReport***

(A).Printed antenna pattern: Printed antenna testreport ITEMANTSPEC Model Name2.4GANT MAX. Gain-2.33 dBi Manufacturer ROXX GmbH Address Hansestrasse No. 91 | 51149 Cologne | Germany (B) Eut photo: (C) Test set photos Return loss Typical Free Space 3D Radiation Pattern at 2.45GHz: Gain Table(Unit :dBi): @2.4GH z Peak gain Avg.gain X-Y-H -2.33-5.76 X-Y-V-6.94-9.11 X-Z-H -3.62-6.43 X-Z-V -4.65-7.71 Y-Z-H -4.86-7.80 Y-Z-V -5.74-8.28 @2.45G Hz Peak gain Avg.gain X-Y-H -3.77-6.55 X-Y-V -8.04-9.68 X-Z-H -3.64-7.79 X-Z-V -5.84-8.93 Y-Z-H -5.30-7.96 Y-Z-V -6.38-8.30 @2.5GH z Peak gain Avg.gain X-Y-H -3.51-7.22 X-Y-V -7.35-10.61 X-Z-H -4.41-7.85 X-Z-V -5.38-9.17 Y-Z-H -5.89-8.74 Y-Z-V -6.65-9.58 X-Ycut @2.45GHz X-Zcut @2.45GHz Y-Zcut @2.45GHz -------------------------------------------------End------------------------------------------------

ReportNo.EDG2207280043E03001RPage1of49Ver.1.0 TESTREPORT ProductName：batterylight ModelNumber：B.showminiFC，B.showminiTW+ FCCID：2A2LS-BSHOWMINI Preparedfor:ROXXGmbH Address:HansestrasseNo.91|51149Cologne|Germany Preparedby:EMTEK(DONGGUAN)CO.,LTD. Address:-1&2/F.,Building2,ZoneA,ZhongdaMarineBiotechnology ResearchandDevelopmentBase,No.9,XinchengAvenue, SongshanhuHigh-technologyIndustrialDevelopmentZone, Dongguan,Guangdong,China TEL:+86-0769-22807078 FAX:+86-0769-22807079 ReportNumber:EDG2207280043E03001R Date(s)ofTests:August10,2022toNovember21,2022 Dateofissue:November21,2022 $二维码$ ReportNo.EDG2207280043E03001RPage2of49Ver.1.0 TableofContents 1TESTRESULTCERTIFICATION.......................................................................................................3 2EUTTECHNICALDESCRIPTION.....................................................................................................5 3SUMMARYOFTESTRESULT..........................................................................................................6 4TESTMETHODOLOGY.....................................................................................................................7 4.1GENERALDESCRIPTIONOFAPPLIEDSTANDARDS............................................................7 4.2MEASUREMENTEQUIPMENTUSED.......................................................................................7 4.3DESCRIPTIONOFTESTMODES.............................................................................................8 5FACILITIESANDACCREDITATIONS...............................................................................................9 5.1FACILITIES..................................................................................................................................9 5.2EQUIPMENT...............................................................................................................................9 5.3LABORATORYACCREDITATIONSANDLISTINGS..................................................................9 6TESTSYSTEMUNCERTAINTY......................................................................................................10 7SETUPOFEQUIPMENTUNDERTEST..........................................................................................11 7.1RADIOFREQUENCYTESTSETUP1.....................................................................................11 7.2RADIOFREQUENCYTESTSETUP2.....................................................................................11 7.3CONDUCTEDEMISSIONTESTSETUP.................................................................................14 7.4BLOCKDIAGRAMCONFIGURATIONOFTESTSYSTEM.....................................................15 7.5SUPPORTEQUIPMENT...........................................................................................................15 8TESTREQUIREMENTS...................................................................................................................16 8.1DTS6DBBANDWIDTH............................................................................................................16 8.2DTS99%BANDWIDTH............................................................................................................19 8.3MAXIMUMPEAKCONDUCTEDOUTPUTPOWER................................................................22 8.4MAXIMUMPOWERSPECTRALDENSITY..............................................................................25 8.5UNWANTEDEMISSIONSINNON-RESTRICTEDFREQUENCYBANDS.............................28 8.6RADIATEDSPURIOUSEMISSION..........................................................................................37 8.7CONDUCTEDEMISSIONSTEST............................................................................................45 8.8ANTENNAAPPLICATION.........................................................................................................48 ReportNo.EDG2207280043E03001RPage3of49Ver.1.0 1TESTRESULTCERTIFICATION Applicant:ROXXGmbH Address:HansestrasseNo.91|51149Cologne|Germany Manufacturer:ROXXGmbH Address:HansestrasseNo.91|51149Cologne|Germany EUT:batterylight ModelName: B.showminiFC，B.showminiTW+ Trademark: MeasurementProcedureUsed: APPLICABLESTANDARDS STANDARDTESTRESULT FCC47CFRPart2,SubpartJ FCC47CFRPart15,SubpartC PASS ICRSS-GEN,Issue5(04-2018)+A1(03-2019)+A2(02-2021) ICRSS-247Issue2(02-2017) PASS TheaboveequipmentwastestedbyEMTEK(DONGGUAN)CO.,LTD.Thetestdata,dataevaluation, testprocedures,andequipmentconfigurationsshowninthisreportweremadeinaccordancewiththe proceduresgiveninANSIC63.10(2013)andtheenergyemittedbythesampleEUTtestedasdescribed inthisreportisincompliancewiththerequirementsofFCCRulesPart2,Part15.247,ICRSS-247Issue 2andICRSS-GEN,Issue5. Thetestresultsofthisreportrelateonlytothetestedsampleidentifiedinthisreport. DateofTest:August10,2022toNovember21,2022 Preparedby: XiaYang/Editor Reviewer: TimDong/Supervisor Approve&AuthorizedSigner: SamLv/Manager ReportNo.EDG2207280043E03001RPage4of49Ver.1.0 ModifiedHistory VersionReportNo.RevisionDateSummary EDG2207280043E03001R/OriginalReport ReportNo.EDG2207280043E03001RPage5of49Ver.1.0 2EUTTECHNICALDESCRIPTION Characteristics Description Product: batterylight ModelNumber: B.showminiFC，B.showminiTW+ Allproductsarethesame,onlythemodelnumberandcolorof appearancearedifferent HereweselectedB.showminiFCforallthetest Samplenumber:1# DeviceType：BluetoothV5.0 DataRate:1Mbps Modulation:GFSK OperatingFrequencyRange:2402-2480MHz NumberofChannels:40Channels TransmitPowerMax:2.79dBm(0.001901W) AntennaType:Specialpurposeantenna AntennaGain:-2.33dBi PowerSupply:AC100-240V~50/60Hz TemperatureRange: 0°C~+40°C Note:formoredetails,pleaserefertotheUser’smanualoftheEUT. ReportNo.EDG2207280043E03001RPage6of49Ver.1.0 3SUMMARYOFTESTRESULT FCCPart Clause ICPart Clause TestParameterVerdictRemark 15.247(a)(2) RSS-2475.2(a) RSS-Gen6.7 EmissionBandwidthPASS 15.247(b)(3) RSS-2475.4(d) RSS-Gen6.12 MaximumPeakConductedOutput Power PASS 15.247(e) RSS-2475.2(b) RSS-Gen6.12 MaximumPowerSpe…

Text truncated - open the document above for the full version.
