2A2N5-A19Smart watches

Bonjour, merci d'avoir choisi notre montre de santé intelligente. Lors de la première utilisation de cet appareil, veuillez lire attentivement les instructions et suivre les étapes des instructions pour votre commodité. Instructions rapides sur la smartwatch Bouton (bouton d'alimenta tion/bouton de retour) Contacts de charge Écran tactile Capteur de fréquence cardiaque Note : appuyez longuement sur le bouton supérieur pour allumer la montre. À propos du chargement de la montre Avant d'utiliser la montre pour la première fois, elle doit être chargée pour l'activer. Veuillez utiliser le câble de charge magnétique équipé pour le fixer au point de contact métallique à l'arrière de la montre et connectez l'autre extrémité du câble de charge à l'adaptateur de charge USB ou au port USB de l'ordinateur. Installation de l'APP Scannez le code QR ci-dessous ou accédez au marché des applications pour télécharger et installer GloryFit Téléphones portables compatibles: iOS 8.0 et supérieur; Android 4.4 et supérieur. Bluetooth 4.0 est pris en charge. Ouvrez le client mobile pour définir vos informations personnelles Passez à la page « Appareil » et cliquez sur « Sélectionner un appareil » Cliquez sur votre appareil dans la liste des appareils scannés Connexion réussie Interface de fonction principale Interface principale/cadran Appuyez longuement sur l'interface principale pour balayer vers la gauche ou la droite pour changer de cadran, et choisissez l'un des 5 styles que vous aimez. Compteur de pas/distance/calories Vérifiez le nombre de pas, la distance parcourue et les calories brûlées à tout moment de la journée. Les données peuvent être synchronisées avec l'APP en temps réel pour afficher les données de mouvement. Interface pour la fréquence cardiaque La fréquence cardiaque peut être surveillée en temps réel à l'interface de mesure de la fréquence cardiaque. Les données de mesure peuvent être synchronisées avec l'application àtemps, avec un rapport de mesure. Interface pour l'oxygène sanguin Passez à l'interface d'oxygène sanguin pour effectuer une surveillance en temps réel de l'oxygène sanguin, et les résultats de mesure peuvent être affichés directement dans l'interface de montre. Interface pour le météo L'interface météo affichera la météo actuelle. La montre doit être connectée à l'application avant que les informations météorologiques puissent être consultées. Si la connexion est déconnectée pendant longtemps, les informations météorologiques ne seront pas mises à jour. Chronomètres Cliquez sur l'icô fonction chronomètre, faites glisser vers la droite pour quitter. Interface pour les notifications Faites glisser la page principale vers le haut pour accéder à l'interface de notification. Cliquez sur l'icône de message pour afficher le message, appuyez une fois pour tourner la page et balayez vers la droite pour quitter. Interface pour les paramètres des fonctions Faites glisser vers le bas sur l'écran principal pour accéder à l'interface de paramètres des fonctions, vous pouvez sélectionner des options telles que « Trouver le téléphone », « Réglage de luminosité », « À propos » et « Paramètres » et cliquez sur l'icône pour accéder au paramètre de fonction correspondant. Trouver le téléphone Lorsque la montre est connectée au téléphone portable, cliquez sur l'icône de « Trouver le téléphone », et le téléphone portable vibrera ou sonnera pour vous le rappeler. Réglage de luminosité Cliquez sur l'icône de réglage de luminosité pour choisir librement la luminosité de l'écran. À propos Cliquez sur l'icône « À propos » pour afficher le modèle de machine et les quatre derniers chiffres de l'adresse Bluetooth. Réinitialisation Cliquez sur l'icône de réinitialisation pour réinitialiser la montre. Éteindre la montre Cliquez sur « Éteindre » pour accéder à la page d'arrêt, où vous pouvez éteindre la montre. Fonctions de rappel La fonction de rappel doit être activée dans l'APP, et le téléphone mobile et la montre doivent être maintenus dans un état où la connexion Bluetooth est réussie. Le message entrant est un rappel par vibration. 1. Il est interdit d'utiliser un adaptateur dont la tension de charge est supérieure à 5V et le courant de charge est supérieur à 2A. La durée de charge est de 2-3 heures. 2. Il est interdit de recharger la montre en présence de taches d'eau. 3. Ce produit est un produit électronique et n'est pas destiné à servir de référence médicale, et les données de mesure sont fournies à titre indicatif uniquement. 4. Méthode de mesure de la pression artérielle Un repos calme d'au moins 5 minutes est nécessaire avant le test. Ne pas manger, fumer, prendre des médicaments et boire de la caféine deux heures avant le test. Prenez une position assise confortable et statique pendant le test, gardez un état d'esprit stable et interdites de parler. Assurez-vous que la montre est à la même hauteur que votre cœur 1. Pourquoi les tests de tension artérielle sont inexacts ? Le test de la pression artérielle est affecté par l'environnement extérieur et la couleur de la peau de l'individu, etc., la surveillance de la pression artérielle n'est utilisée que pour surveiller les changements de la pression artérielle. Il ne peut pas vraiment tester ou surveiller la pression artérielle chez l'hypertension. Il ne peut pas être utilisé comme un dispositif médical, les données de test ne peuvent pas être utilisées comme données médicales, juste pour la référence. 2. Pourquoi ne puis-je pas recevoir de notifications push pour les appels entrants, les SMS et les applications? 2.1. Acquisition d'autorisation de service de rappel d'application Android Lorsqu'un utilisateur Android active les commutateurs de rappel dans l'APP GloryFit pour la première fois, GloryFit demandera des autorisations correspondantes, veuillez confirmer toutes les autorisations afin que GloryFit puisse obtenir les autorisations correspondantes. 2.2. Lorsqu'un utilisateur iOS active le commutateur de rappel sur GloryFit pour la première …

Text truncated - open the document above for the full version.

Jiangsu Saibo Yuhua Technology Co.,Ltd U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Baihetian Innovative Solutions FRN: 0033401605 Contact Name: Kenneth Young Street Address: 6837 Chase Rd City/Province/Zip: Dearborn, MI 48126 Telephone No: 313-395-3113 Email: [email protected] This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: April 26, 2023 Signed by (Printed Name/Title): Kenneth Young/Manager The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: Jiangsu Saibo Yuhua Technology Co.,Ltd Grantee Code: 2A2N5 FCC ID: 2A2N5-A19 Contact Name: Shi WenWu Street Address: Building 8(D) of Yancheng High-Tech Zone Intelligent Terminal Industrial Park, City/Province/Zip: China Telephone No: 18681137213 Email: [email protected] Applicant Signature: Date: 2023-04-26 Signed by (Printed Name/Title): Shi WenWu / Manager

Jiangsu Saibo Yuhua Technology Co.,Ltd 2023.04.26 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for 2A2N5-A19 [Jiangsu Saibo Yuhua Technology Co.,Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Applicant printed name) Shi WenWu Jiangsu Saibo Yuhua Technology Co.,Ltd 2023.04.26 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for 2A2N5-A19 [Jiangsu Saibo Yuhua Technology Co.,Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Shi WenWu

Jiangsu Saibo Yuhua Technology Co.,Ltd 2023.04.26 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Smart watches Trademark: N/A MODEL : A19, DK01 FCC ID : 2A2N5-A19 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : Shi WenWu /Manager Contact information / address: Building 8(D) of Yancheng High-Tech Zone Intelligent Terminal Industrial Park, China

Jiangsu Saibo Yuhua Technology Co.,Ltd 2023.04.26 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen BCTC Testing Co., Ltd to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : Shi WenWu /Manager Contact information / address: Building 8(D) of Yancheng High-Tech Zone Intelligent Terminal Industrial Park, China

Jiangsu Saibo Yuhua Technology Co.,Ltd Model Difference 2023-04-26 EUT NAME: Smart watches FCC ID: 2A2N5-A19 MODEL : A19, DK01 All the model are the same circuit and RF module, except model names. Regards Sincerely Client’s signature: Client’s name / title : Anmy cheng / Manager Contact information / address: Building 8(D) of Yancheng High-Tech Zone Intelligent Terminal Industrial Park, China

External Photos

Size:10*5mm Smart watches FCC ID: 2A2N5-A19 Label location

Internal Photos Antenna

RF EXPOSURE EVALUATION METHOD FCC ID: 2A2N5-A19 Applicable standard： In accordance with FCC 47 CFR part 2 (2.1093) this device has been defined as a portable device which is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. Portable devices must be evaluated using the specified in FCC 47 CFR part 2 (2.1093) and ANSI/IEEEC95.1-1992. and had been tested in accordance with the measurement methods and procedures specified in IEEE 1528-2003. Per FCC KDB 447498 D01 v06, the 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances s 50 mm are determined by: SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Condition Mode Frequency (MHz) Conducted Power (dBm) Limit (dBm) Verdict NVNT 1-DH1 2402 1.44 21 Pass NVNT 1-DH1 2441 1.08 21 Pass NVNT 1-DH1 2480 0.30 21 Pass NVNT 2-DH1 2402 1.69 21 Pass NVNT 2-DH1 2441 1.48 21 Pass NVNT 2-DH1 2480 0.64 21 Pass NVNT 3-DH1 2402 2.27 21 Pass NVNT 3-DH1 2441 1.98 21 Pass NVNT 3-DH1 2480 1.25 21 Pass max possible output power (PK,conducted)：2±1dBm -0.91dBi logarithmic terms convert to numeric result is nearly 0.81 3dBm=2mW 2402MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 2/5*√2.402=0.62≤3.0 2441MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 2/5*√2.441=0.625≤3.0 2480MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 2/5*√2.48=0.63≤3.0 Conclusion: 1. [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] < 3.0. 2. SAR Test Exclusion Thresholds is 3.0 for separation distance 5mm. Therefore, SAR test is not required.

Report No.: BL-SZ2310466-AA 1 / 1 EUT PHOTO --BLANK BELOW -- Antenna

Report No.: BL-SZ2310466-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 1 / 14 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-09-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China TEST REPORT Applicant: Titan Company Limited Address: Integrity, #193, Veerasandra, Electronics City P.O., Off Hosur Main Road Bangalore, India, 560100 Equipment Type: Smart watch Model Name: 38082 Brand Name: N/A Test Standard: IEEE Std 149-2021 Sample Arrival Date: Jan. 12, 2023 Test Date: Jan. 13, 2023 Date of Issue: Jan. 31, 2023 ISSUED BY: Shenzhen BALUN Technology Co., Ltd. Tested by: Mai Jintian Checked by: Zou Liu Approved by: Tolan Tu (Testing Director) _______________ _______________ _______________ Report No.: BL-SZ2310466-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 2 / 14 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-09-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China Revision History Version Issue Date Revisions Rev. 01 Jan. 31, 2023 Initial Issue TABLE OF CONTENTS 1 GENERAL INFORMATION ......................................................................................................... 3 1.1 Test Laboratory ..................................................................................................................... 3 1.2 Test Location ......................................................................................................................... 3 2 PRODUCT INFORMATION ......................................................................................................... 4 2.1 Applicant Information ............................................................................................................ 4 2.2 Manufacturer Information ...................................................................................................... 4 2.3 General Description for Equipment under Test (EUT) .......................................................... 4 2.4 Ancillary Equipment .............................................................................................................. 4 2.5 Technical Information ............................................................................................................ 4 3 SUMMARY OF TEST RESULTS ................................................................................................. 5 3.1 Test Standards ...................................................................................................................... 5 3.2 Test Verdict ........................................................................................................................... 5 3.3 Test Uncertainty .................................................................................................................... 5 4 GENERAL TEST CONFIGURATIONS ........................................................................................ 6 4.1 Test Condition ....................................................................................................................... 6 4.2 Test Equipment List .............................................................................................................. 6 4.3 Test Setup ............................................................................................................................. 7 ANNEX A TEST RESULTS ............................................................................................................. 8 A.1 Gain and Efficiency ............................................................................................................... 8 A.2 VSWR ................................................................................................................................... 9 ANNEX B RADIATION PATTERN ................................................................................................ 10 ANNEX C TEST SETUP PHOTOS ............................................................................................... 13 ANNEX D EUT PHOTO ................................................................................................................ 13 Report No.: BL-SZ2310466-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 3 / 14 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-09-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 1 GENERAL INFORMATION 1.1 Test Laboratory Name Shenzhen BALUN Technology Co., Ltd. Address Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China Phone Number +86 755 6685 0100 1.2 Test Location Name Shenzhen BALUN Technology Co., Ltd. Location Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 1/F, Building B, Ganghongji High-tech Intelligent Industrial Park, No. 1008, Songbai Road, Yangguang Community, Xili Sub-district, Nanshan District, Shenzhen, Guangdong Province, P. R. China Report No.: BL-SZ2310466-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 4 / 14 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-09-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 2 PRODUCT INFORMATION 2.1 Applicant Information Applicant Titan Company Limited Address Integrity, #193, Veerasandra, Electronics City P.O., Off Hosur Main Road Bangalore, India, 560100 2.2 Manufacturer Information Manufacturer JIANGSU SOP TECHNOLOGY CO LTD Address D/F BLOCK 8 INTELLIGENT TERMINAL INDUSTRIAL PARK HI- TECH ZONE YANCHENG JIANGSU 2.3 General Description for Equipment under Test (EUT) EUT Name Smart watch Model Name Under Test 38082 Antenna Type Wire Antenna Dimensions 18 mm 2.4 Ancillary Equipment …

Text truncated - open the document above for the full version.

Report No.: BL-SZ2310466-AO 1 / 2 TEST SETUP PHOTOS Report No.: BL-SZ2310466-AO 2 / 2 --BLANK BELOW --

No.：BCTC/RF-EMC-007 Page: 1 of 80 Edition：A.5 TEST REPORT Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2303023330E Applicant: Jiangsu Saibo Yuhua Technology Co.,Ltd Product Name: Smart watches Model/Type reference: A19 Tested Date: 2023-03-09 to 2023-03-14 Issued Date: 2023-03-14 Report No.:BCTC2303023330E No.：BCTC/RF-EMC-007 Page: 2 of 80 Edition：A.5 FCC ID: 2A2N5-A19 The test report is effective only with both signature and specialized stamp.This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Testing Co., Ltd, this report can’t be reproduced except in full.The tested sample(s) and the sample information are provided by the client. Product Name: Smart watches Trademark: N/A Model/Type Reference: A19 DK01 Prepared For: Jiangsu Saibo Yuhua Technology Co.,Ltd Address: Building 8(D) of Yancheng High-Tech Zone Intelligent Terminal Industrial Park, China Manufacturer: Jiangsu Saibo Yuhua Technology Co.,Ltd Address: Building 8(D) of Yancheng High-Tech Zone Intelligent Terminal Industrial Park, China Prepared By: Shenzhen BCTC Testing Co., Ltd. Address: 1-2/F., Building B, Pengzhou Industrial Park, No.158, Fuyuan 1st Road, Zhancheng, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: 2023-03-09 Sample tested Date: 2023-03-09 to 2023-03-14 Issue Date: 2023-03-14 Report No.: BCTC2303023330E Test Standards: FCC Part15.247 ANSI C63.10-2013 Test Results: PASS Remark: This is Bluetooth Classic radio test report. Tested by: Approved by: Lei Chen/Project Handler Zero Zhou/Reviewer Report No.:BCTC2303023330E No.：BCTC/RF-EMC-007 Page: 3 of 80 Edition：A.5 Table Of Content Test Report Declaration Page 1. Version .................................................................................................................. 5 2. Test Summary ....................................................................................................... 6 3. Measurement Uncertainty ..................................................................................... 7 4. Product Information And Test Setup ..................................................................... 8 4.1 Product Information ............................................................................................... 8 4.2 Test Setup Configuration ...................................................................................... 8 4.3 Support Equipment ............................................................................................... 9 4.4 Channel List .......................................................................................................... 9 4.5 Test Mode ........................................................................................................... 10 4.6 Table Of Parameters Of Text Software Setting ................................................... 10 5. Test Facility And Test Instrument Used ............................................................... 11 5.1 Test Facility ......................................................................................................... 11 5.2 Test Instrument Used .......................................................................................... 11 6. Conducted Emissions .......................................................................................... 13 6.1 Block Diagram Of Test Setup .............................................................................. 13 6.2 Limit .................................................................................................................... 13 6.3 Test procedure .................................................................................................... 13 6.4 EUT operating Conditions ................................................................................... 13 6.5 Test Result .......................................................................................................... 14 7. Radiated emissions ............................................................................................. 16 7.1 Block Diagram Of Test Setup .............................................................................. 16 7.2 Limit .................................................................................................................... 17 7.3 Test procedure .................................................................................................... 18 7.4 EUT operating Conditions ................................................................................... 19 7.5 Test Result .......................................................................................................... 20 8. Radiated Band Emission Measurement And Restricted Bands Of Operation ..... 24 8.1 Block Diagram Of Test Setup .............................................................................. 24 8.2 Limit .................................................................................................................... 24 8.3 Test procedure .................................................................................................... 25 8.4 EUT operating Conditions ................................................................................... 25 8.5 Test Result .......................................................................................................... 26 9. Spurious RF Conducted Emissions ..................................................................... 27 9.1 Block Diagram Of Test Setup .............................................................................. 27 9.2 Limit .................................................................................................................... 27 9.3 Test procedure .................................................................................................... 27 9.4 Test Result .......................................................................................................... 28 1…

Text truncated - open the document above for the full version.

Report No.:BCTC2303023330E No.：BCTC/RF-EMC-007 Page: 53 of 80 Edition：A.5 -20dB Bandwidth NVNT 3-DH1 2402MHz -20dB Bandwidth NVNT 3-DH1 2441MHz Report No.:BCTC2303023330E No.：BCTC/RF-EMC-007 Page: 54 of 80 Edition：A.5 -20dB Bandwidth NVNT 3-DH1 2480MHz Report No.:BCTC2303023330E No.：BCTC/RF-EMC-007 Page: 55 of 80 Edition：A.5 11. Maximum Peak Output Power 11.1 Block Diagram Of Test Setup 11.2 Limit FCC Part15 (15.247) , Subpart C Section Test Item Limit Frequency Range (MHz) Result 15.247(b)(1) Peak Output Power 0.125 watt or 21dBm 2400-2483.5 PASS 11.3 Test procedure 1. Remove the antenna from the EUT and then connect a low RF cable from the antenna port to the spectrum. 2. Set the spectrum analyzer: RBW = 2MHz. VBW = 6MHz. Sweep = auto; Detector Function = Peak. 3. Keep the EUT in transmitting at lowest, medium and highest channel individually. Record the max value. 11.4 Test Result Condition Mode Frequency (MHz) Conducted Power (dBm) Limit (dBm) Verdict NVNT 1-DH1 2402 1.44 21 Pass NVNT 1-DH1 2441 1.08 21 Pass NVNT 1-DH1 2480 0.30 21 Pass NVNT 2-DH1 2402 1.69 21 Pass NVNT 2-DH1 2441 1.48 21 Pass NVNT 2-DH1 2480 0.64 21 Pass NVNT 3-DH1 2402 2.27 21 Pass NVNT 3-DH1 2441 1.98 21 Pass NVNT 3-DH1 2480 1.25 21 Pass Report No.:BCTC2303023330E No.：BCTC/RF-EMC-007 Page: 56 of 80 Edition：A.5 Test Graphs Power NVNT 1-DH1 2402MHz Power NVNT 1-DH1 2441MHz Report No.:BCTC2303023330E No.：BCTC/RF-EMC-007 Page: 57 of 80 Edition：A.5 Power NVNT 1-DH1 2480MHz Power NVNT 2-DH1 2402MHz Report No.:BCTC2303023330E No.：BCTC/RF-EMC-007 Page: 58 of 80 Edition：A.5 Power NVNT 2-DH1 2441MHz Power NVNT 2-DH1 2480MHz Report No.:BCTC2303023330E No.：BCTC/RF-EMC-007 Page: 59 of 80 Edition：A.5 Power NVNT 3-DH1 2402MHz Power NVNT 3-DH1 2441MHz Report No.:BCTC2303023330E No.：BCTC/RF-EMC-007 Page: 60 of 80 Edition：A.5 Power NVNT 3-DH1 2480MHz Report No.:BCTC2303023330E No.：BCTC/RF-EMC-007 Page: 61 of 80 Edition：A.5 12. Hopping Channel Separation 12.1 Block Diagram Of Test Setup 12.2 Limit Frequency hopping systems shall have hopping channel carrier frequencies separated by a minimum of 25 kHz or the 20 dB bandwidth of the hopping channel, whichever is greater. Alternatively, frequency hopping systems operating in the 2400-2483.5 MHz band may have hopping channel carrier frequencies that are separated by 25 kHz or two-thirds of the 20 dB bandwidth of the hopping channel, whichever is greater, provided the systems operate with an output power no greater than 0.125W. 12.3 Test procedure 1. Remove the antenna from the EUT and then connect a low RF cable from the antenna port to the spectrum. 2. Set the spectrum analyzer: RBW = 30kHz. VBW = 100kHz , Span = 2.0MHz. Sweep = auto; Detector Function = Peak. Trace = Max hold. 3. Allow the trace to stabilize. Use the marker-delta function to determine the separation between the peaks of the adjacent channels. The limit is specified in one of the subparagraphs of this Section Submit this plot. 12.4 Test Result Condition Mode Hopping Freq1 (MHz) Hopping Freq2 (MHz) HFS (MHz) Limit (MHz) Verdict NVNT 1-DH1 2401.972 2402.974 1.002 0.959 Pass NVNT 1-DH1 2440.974 2441.974 1.000 0.679 Pass NVNT 1-DH1 2478.976 2479.974 0.998 0.960 Pass NVNT 2-DH1 2402.140 2403.142 1.002 0.911 Pass NVNT 2-DH1 2441.142 2442.142 1.000 0.912 Pass NVNT 2-DH1 2479.144 2480.140 0.996 0.913 Pass NVNT 3-DH1 2401.916 2402.912 0.996 0.899 Pass NVNT 3-DH1 2440.912 2441.914 1.002 0.899 Pass NVNT 3-DH1 2478.916 2479.912 0.996 0.898 Pass Report No.:BCTC2303023330E No.：BCTC/RF-EMC-007 Page: 62 of 80 Edition：A.5 Test Graphs CFS NVNT 1-DH1 2402MHz CFS NVNT 1-DH1 2441MHz Report No.:BCTC2303023330E No.：BCTC/RF-EMC-007 Page: 63 of 80 Edition：A.5 CFS NVNT 1-DH1 2480MHz CFS NVNT 2-DH1 2402MHz Report No.:BCTC2303023330E No.：BCTC/RF-EMC-007 Page: 64 of 80 Edition：A.5 CFS NVNT 2-DH1 2441MHz CFS NVNT 2-DH1 2480MHz Report No.:BCTC2303023330E No.：BCTC/RF-EMC-007 Page: 65 of 80 Edition：A.5 CFS NVNT 3-DH1 2402MHz CFS NVNT 3-DH1 2441MHz Report No.:BCTC2303023330E No.：BCTC/R…

Text truncated - open the document above for the full version.
