MOD EL : BN801A INFURTURE H1 ANC BLUETOOTH HE ADPHONES Package List X1X1 X1 X1 X1 Diagram Power ON/OFF ④ ② ⑦ ⑥ ⑤ ① ⑤ ⑦⑥ ②③④ ③① ANC LED LED 2sON Pairing Mode 5sOFF 1. Power on: Press and hold MFB for 2 seconds, with blue light flashing for 1 second until you hear the voice "Power on". 2. Power of f: Press and hold MFB for 5 seconds, with red light flashing until yo u hear the voice "Power off ". EN < 1m (3.3ft) How to Pair Settings Bluetooth Bluetooth DEV ICES H1 Connected 1. Press and hold MFB for 5 seconds to enter the paring mode, with red and blue light taking turns to flash and the voice "Pairing" heard. 2. Turn on Bluetooth function on the cellphone, search "H1 " and click to pair. The voice "Connected" will be heard after the successful connection. EN 1. Drücken Sie bitte lange Zeit die Multifunktionentaste ca. 5 Sekunden, um in den Verbindung-Modus zu stellen. Das rote und blaue Licht wird blinken, und Sie "Pairing" hören. 2. Schalten Sie Bluetooth Funktion Ihres Handys ein, suchen "H1 " und klicken zu verbinden. Nach di e Verbindung erfolgen, werden Sie "Connected" hören. DE 1. Appuyez longuement sur MFB pendant 5 secondes pour passer en mode de couplage, les voyants rouge et bleu clignotant et la voix “Pairin g" entendue. 2. Activez la fonction Bluetooth sur le tél éphone, re cherchez "H1" et y cliquez pour vous connecter. L a voix "Connected" sera entendu e une fois la connexion établie. FR 1. Einschalten: Drücksen Sie bitte lange Zeit die Multifunktionentaste ca. 2 Sekunden, das blaue Licht wird 1 Sekunde blinken, bis Sie "Power on" hören. 2. Ausschalten: Drücken Sie bitte lange Zeit die Multifunktionentaste ca. 5 Sekunden, das rote Licht wird blinken, bis Sie "Power off " hören. DE 1. Allumer: Appuyez longuement sur MFB pendant 2 secondes, avec la lumière bleue clignotant pendant 1 seconde jusqu'à ce que vous entendiez la voix "Power on". 2. Éteindre: Appuyez longuement sur MFB pendant 5 secondes, le voyant rouge clignotant jusqu'à ce que vo us entendiez la voix "Power off ". FR 1. Encender: Mantenga presionado MFB durante 2 segundos, con la luz azul parpadeando durante 1 segundo hasta que escuche la voz "Power on". 2. Apagado: mantenga presionado MFB durante 5 segundos, con la luz roj a pa rpadeando hasta que escuche que la voz "Power off ". ES 1. Accensione: Premere a lungo MFB per 2 secondi, con luce blu lampeggiante per 1 secondo fino a sentire la voce " Power on ". 2. Spegnimento: Premere a lungo MFB per 5 secondi, con luce rossa lampeggiante fino a senti re la voce " Power off ". IT JP Volume Control/Music Control Clear Pairing Charge the Headphones DELautstärkesteuerung / Musiksteuerung FRContrôle du volume / Contrôle de l a musique ESControl de volumen / Control de música ITControllo Vo lume / Controllo Musica 1. Mantenga presionado MFB durante 5 segundos para ingresar al modo de emparejamiento, con la luz roja y azul parpadeando y se escuchará la voz "Pairing". 2. Active la función Bluetooth en el teléfono, busque "H1" y haga clic para conectarse. La voz "Connected" se escuchará después de la conexión exitosa. ES 1. Premere a lungo MFB per 5 secondi per entrare nella modalità di a ccoppiamento, co n luce rossa e blu accendono a lampeggiare alternativ amente e l a voce " Pairing " sentito. 2. Attivare la funzione Bluetooth sul telefono, cercare "H1" e fare clic per connettersi. La voce " Co nnected " verrà asc olt ata dopo la connessione riuscita. IT Hold on 1~2s Cli ck Once Hold on 1~2s Cli ck Once Play/ Pause/Answer a Call/ Hang up a Call/ Reject a Call DESp iel / Pause / Anruf annehmen / Anruf auflegen / Anruf ablehnen DEDie Verbindung Lösen FREffacer le Couplage ESCancelar Emparejamiento ITCancell are Accoppiamento JP FRJo uer/ Pause / Répondre à un appel / Raccrocher un ap pel / Rejet er un appel ESReproducir / Pausa / Responder una llamada / Colgar una lla mada / Rechazar una llamada ITRi produzione/ Pausa/ Risposta a Una Chiamata/ Ri attaccare Una Chiamata/ Rifiutare Una Chiamata Cl ick Once Hold on (1-2s) Hold on (5s) Double Click Siri Hold on (4-5s) Output : 5V 1A DEPairing-Modus FRMéthode d'appairage ESLas Funciones De Emparejamiento ITFunzione di Collegamento JP JP JP Step1: Step 2: JP Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. FCC Radiation Exposure Statement: FCC Statement FCC Caution： This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:…

Text truncated - open the document above for the full version.

Shenzhenshi Infurture Technology Co., Ltd 2023.04.24 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for FCC ID: 2A2OD-BN801A Shenzhenshi Infurture Technology Co., Ltd certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Applicant signature: Applicant printed name: Yuankang Ye / Manager Shenzhenshi Infurture Technology Co., Ltd 2023.04.24 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for FCC ID: 2A2OD-BN801A Shenzhenshi Infurture Technology Co., Ltd certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Applicant signature: Applicant printed name: Yuankang Ye / Manager

Shenzhenshi Infurture Technology Co., Ltd U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Baihetian Innovative Solutions FRN: 0033401605 Contact Name: Kenneth Young Street Address: 6837 Chase Rd City/Province/Zip: Dearborn, MI 48126 Telephone No: 313-395-3113 Email: [email protected] This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: Signed by (Printed Name/Title): The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: Shenzhenshi Infurture Technology Co., Ltd Grantee Code: 2A2OD FCC ID: 2A2OD-BN801A Contact Name: Yuankang Ye Street Address: 11-2, Lane 6, Hekan Village, Wuhe Community, Longgang District, Shenzhen, Guangdong, China Telephone No: 86-13286817960 Email: [email protected] Applicant Signature: Date: 2023.04.25 Signed by (Printed Name/Title): Yuankang Ye / Manager

Shenzhenshi Infurture Technology Co., Ltd 2023.04.24 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Wireless headphone MODEL : BN801A FCC ID: 2A2OD-BN801A To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : Yuankang Ye / Manager Contact information / address: 11-2, Lane 6, Hekan Village, Wuhe Community, Longgang District, Shenzhen, Guangdong, China

Shenzhenshi Infurture Technology Co., Ltd 2023.04.24 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen BCTC Testing Co., Ltd to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : Yuankang Ye / Manager Contact information / address: 11-2, Lane 6, Hekan Village, Wuhe Community, Longgang District, Shenzhen, Guangdong, China

External Photos

15*10mm Label Location Wireless headphone Model No: BN801A FCC ID: 2A2OD-BN801A IC: 29711-BN801A

Internal Photos Antenna

FCC ID: 2A2OD-BN801A Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion GFSK 2.402 -2.63 0.55 -2±1 -1.00 0.79 <5 0.24622 3.00 YES π/ 4 DQPSK 2.402 -1.76 0.67 -2±1 -1.00 0.79 <5 0.24622 3.00 YES Conclusion: For the max result : 0.24622＜3, the SAR testing is not required.

Type_2 Antenna Design Layout Guidelines & Pattern 1.Antenna Mechanical Dimensions(mm): (Figure.1) Top-Layer PCB picture 2. The PCB board is set as follows: This antenna type is suitable for A. PCB board thickness is _1.0 mm B. PCB sheet is _FR4 Manufacturer: Shenzhen InFurture Technology Co., Ltd. Address: 926, Building H, Bantian International Center, Huancheng South Road, Maantang Community, Bantian Street, Longgang District, Shenzhen, China 3. Antenna Radiation Patterns: Summary (Table.1) CenterFrequency_2400MHz DUT_ Horizontal ITEMSPEC. AntennaTypeType_2_SingleWiggleAntenna 2400MHz 2.48dBi CenterFrequency2450MHz 2.82dBi 2500MHz 3.7dBi Max.GAIN3.7dBi Mini.GAIN﹣48.85dBi AVGGAIN﹣4.62dBi DUTPolarizationHorizontal&Vertical TESTOutputPowerLevel10dBm Impedance50 Ω DUT_ Vertical CenterFrequency_2450MHz DUT_ Horizontal DUT_ Vertical CenterFrequency_2500MHz DUT_ Horizontal DUT_ Vertical 测试：林树盛 审核：黄龙 时间：2023/3/22
