产品名称:智能网关 产品型号: AT1556 品类: 网关 通讯方式: Wi‐Fi、蓝牙Mesh(SIG) 额定输入:5V‐1A 工作温度: ‐0°C~50°°C 工作湿度:0%‐95%RH，无冷凝 支持系统:Android 5.0 或iOS12.0及以上版本 Product name: Smart Bridge Product Model: AT1556 Category: Gateway Communication mode: Wi‐Fi, Bluetooth Mesh(SIG) Rated input :5V‐1A Operating temperature: ‐0°C~50° C Working humidity :0%‐95%RH, no condensation Supported operating system :Android 5.0 or iOS12.0 or above 连接方式/Connection mode:： 1. 第一步将网关接通电源 1. Step 1 ,Plug in the smart bridge 第二步打开涂鸦智能APP 点击右上角“+”添加涂鸦智能网关。2. Step 2 ,Open the Tuya APP and press "+" in the upper right corner to add the smart bridge. 2. 第三步:添加成功后，根据APP提示绑定其他智能设备。3. Step 3: Through the smart birdge, add the other smart devices as prompted by the APP. FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Note: The Grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. such modifications could void the user's authority to operate the equipment. The device has been evaluated to meet general RF exposure requirement. To maintain compliance with FCC's RF exposure guidelines, the distance must be at least 20 cm between the radiator and your body, and fully supported by the operating and installation
