2A2QO-MBZ228Smart white noise mechine

USER MANUAL Dreams Begin with Dreamegg Smart white noise mechine GETTING START Search and download the “Tuya Smart” app from the Apple App or Google Play store. Step 1 ：Plug it in Step 2 : Download the App Connect the provided power cable to Dreamegg Nite 1, then plug it into your power outlet. Always keep your Nite 1 plugged in. Make sure your phone is connected to a secure 2.4GHz Wifi network and the app is allowed to access your location, connect network, and use Bluetooth. Step 3 : Connect your Dreamegg Open App and tap “Add device” Long press the pairing button until the indicator light flashes white and the display flashes "P". This indicates that the device has entered pairing mode. Select 2.4GHz Wi-Fi network and enter the password to complete connection. Follow the on-screen steps to conect your Dreamegg Nite 1. Note: Make sure both your phone and device are connect to 2.4GHz Wi-Fi network, 5GHz will fail to pair. USING YOUR DREAMEGG Charing Port Dimmable Time Display Night light Alarm On : Alarm is enabled Off : Alarm is disabled Snooze Flashing : Snooze on Volume Down Previous Track Light Button Short press : Select light mode Long press : Turn off the light Pause Play Button Short press : Play / Pause Long press : Turn off the light and sound Multi-Fuction Button Short Press: Cycle through favorites / Snooze (When the alarm goes off ) Long Press: Adjust brightness / Turn off the alarm today (When the alarm goes off ) Child Lock Indicator Light Red : Child lock is enabled Wi-Fi Paring Button & Wi-Fi Pairing Indicator Long Press : Enter the pairing mode Flash White : Pairing mode Alarm disabled button & Alarm disable Indicator Long Press : Alarm disabled mode Light White : Alarm is disabled Volume Up Next Track CONTROL YOUR DREAMEGG VIA APP ①Alarm ②Routine ③Child Lock ④Settings ⑤Sound and Brightness Control ⑥Custom Favorite ⑦ 3 Light Modes ⑧ 4 Sound Options 11 Nature sounds / 7 Ambient Sounds / 6 Backgroud Noises / 10 Relaxing Melodies ❶❷❸❹ ❺ ❻ ❽ ❼ SAFETY INFORMATION IMPORTANT: Please read and comply with all of the instructions and warnings provided in this manual before using the product. Failure to cormply with the instructions and warnings provided herein may result in inaccurate results or damage to the product itself. ●Parents assume all responsibility for selecting volume and sound settings that are appropriate for their child. ●Never place against baby's ears or in a cribor bed. Always check with child's pediatrician prior to using any sound machine. ●Always keep at least three feet away from children as the cord can pose a strangulation hazard. ●Not a toy and not for teething. ●Put the unit away from heat source, dust or vibration. ●Avoid placing the unit in rain or humid place, keep it dry. ●Put the unit away from heat source, dust or vibration. ●Avoid dropping objects or spilling liquids onto the unit. ●Do not put any stuff on this product. ●Use provided power cord for the sake of safety. ●Do not operate the unit with a damaged cord or after malfunction occurs, or damaged in any manner. ●Do not remove the power plug with wet hands as it may cause electrical shock. ●The unit should be cleaned regularly with a soft, dry cloth. Do not use any liquids or sprays (including solvents, chemicals or alcohol) or abrasives to clean. FCC DISCLAIMER This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. PACKAGE CONTENTS Sound Machine Power Code User Manual THINGS Nite 1 CAN DO Change sound and volume Use the app or press the buttons to set the volume to a comfortable level and choose your preferred sound from a variety of white noises, nature sounds, and melodies. Dimmable clock Dim or turn off the clock in the app. Visit “Clock Display” under settings. Set an alarm Use the app to set an alarm with soothing sounds and your preferred color. Want to snooze? Press Multi-Fuction Button for another 9mins. Child lock Use the app to enable or disable the child lock function. Customize a routine Personalize a routine to fit your child’s schedule, choosing from the variety of colors and sounds in the app. Preset a favorite Use the app to preset the light and sound settings as favorites. Press the multi-function button to cycle through your favorites. Choose a custom color and brightness Use the app to choose your preferred color and brightness. Display not turning on.Q ①Check if the display is turned off in the app settings. Make sure to enable the display. ②Check that the display brightness is not set too low. Go to the app settings and increase the display brightness. A Cannot connect my Dreamegg to APP?Q ①Check if the device is in WI-FI pairing mode. When in WI-FI pairing mode, the indicator light should flash white, and the display should show a flashing "P." Press and hold the Wi-Fi pairing button on the bottom of the device to enter setup mode. ②Ensure the app is allowed to access your location, connect network, and use Bluetooth.Go to your phone's settings and enable these permissions. ③Confirm your phone is connected to a 2.4GHz Wi-Fi network. Both your phone and the device need to be on the same 2.4GHz Wi-Fi network for proper connectivity. A QUESTIONS & ANSWERS Fail to turn on after plugging in.Q ①Make sure you are using the provided power code and the power is not damaged. ②Check if the device is connected to an appropriate electrical outlet correctly. A Top button is not responsive.Q Check if a child lock is enabled. If so, the child lock indicator light at the bottom will be red. You’ll need to disable the child lock through the app. A Alarm set but not ringingQ ①Check if the device is in alarm disabled mode. When in this mode, the alarm icon on the display will be off, and the alarm disabled indicator light at the bottom will be on. Press and hold the alarm …
