DASH CAM User Manual Please read this manual before operating your device and keep it for future reference. DASH CAM User Manual Please read this manual before operating your device and keep it for future reference. DASH CAM User Manual Please read this manual before operating your device and keep it for future reference. Distractions can lead to accidents, and the risk of injury or death. Always keep your eyes on the road, and keep aware of your surroundings. 2 1 2 3 4 5 Camera Lens Power Button Status Indicator LED Speaker Vents Microphone 1 2 3 4 5 6 6 3 5 1 6 1 2 3 4 5 6 Power Port Vents Screen Album/Back Button Setting/Next Button Emergency Video (EMER Video)/Confirm Button 2 3 4 4 Installation 1. Install the electrostatic sticker Park your car in a safe area, and turn off the car engine. Take out the electrostatic sticker from the packing box and install it in the recommended area on the windshield, as shown in the figure below. Please clean the windshield, and remove the air bubbles between the electrostatic sticker and the windshield during the installation. 2. Connect the power supply Connec t the USB cable to the micro USB port of the Dash Cam. Run the cable along the edge of the windshield, tucking it away in the seams (With the Crowbar), and extend it all the way to the USB port of the  Car Charger. Be sure to keep it away from the airbag area. Insert the  Car Charger into your cigarette lighter, connect the  Dash Cam to the Car Charger. Note: Please DO NOT attached the dash cam with the sticker to the windshield before the camera calibration to ensure AI feature works properly. Note: The AI accuracy is dramatically effected by the position of installation. Please install carefully. 5 3. Camera Calibration You need to find a good position and angle to install the dash cam. Start the car engine (DO NOT install under driving) to power on and start from pressing the Setting Button in the middle on the right side, find System Settings g AI g Camera calibration. Align vertical line to the center, horizontal line to the vanishing point of the road in the preview LCD screen as shown below. Make sure the dash cam does not interfere with the driver’s view. Note: The AI accuracy is dramatically effected by the position of installation. Please install carefully. The vanishing point of the road is in the button of the image. The camera is tilted The engine cover occupy too much area in the image 6 4. Attach the Dash Cam Remove the protective sticker on the Dash Cam bracket and attach the Dash Cam to the center of the electrostatic sticker (the sweet spot in step 3), as shown in the figure below. Press the bracket mount by hand to ensure that the heat resistant adhesive is in close contact with the electrostatic sticker. Lock the bracket to the Dash Cam. You will hear a snap when it is in place. 5. Check and adjust the dash cam angle Ensure your dash cam is installed as the right angle in step 3. You may adjust the camera angle up or down against the preview screen to ensure that the camera is facing correctly. Note: In order to connect to Dash Cam Wi-Fi, please list the APP in your trust application list and make sure the Dash Cam Wi-Fi is on. 7 Miofive Dash Cam App Download Please scan the QR code below or search ‘Miofive’ in App Store or Google Play to download the App. Systems Supported: Android 5.0 and above / iOS 10.0 and above. Note: In order to connect to Dash Cam Wi-Fi, please list the APP in your trust application list and make sure the Dash Cam Wi-Fi is on. 8 Using Your Miofive APP Connect to the Dash Cam 1. Check the indicator status on the dash cam, make sure the power indicator slowly blinks green. 2. Make sure your phone and dash cam are in close range (within 2 meters). 3. Go to Phone Wi-Fi Setting and turn Wi-Fi on. 4. Launch the Miofive APP. (Recommend register account to unlock advanced features). 5. Press “Devices”, and press” Connect to the Dash Cam Wi-Fi”. 6. Choose your Miofive network name (SSID) from the Wi-Fi network list (ex. “Miofive_xxxx”, default password: 1234567890). Input the password to connect. 7. Return to Miofive app once the connection is complete. 9 Using Your Miofive Dash Cam LED Indicator Information LED IndicatorDash Cam Status Green LED light blinks (1 sec) Working, loop recording Green LED light blinks (250 ms) Emergency recording Green LED light solid onStop recording, user operating Red LED light blinksFirmware updating Red LED light blinks fast (0.5 sec) for 3 times Low battery Red LED light solid oneMMC abnormal Control Menu By pressing the button on the right side of the LCD panel, you could enter the control menu. By pressing this button, the current video clip will be locked and stored in EMER Video. Album Settings EMER Video 10 Features Parking Mode When your car is not running, i.e. the engine is turned off, the Dash Cam will automatically power off in 10 seconds and enter Parking Mode. When a shock or crash is detected, the G-Sensor will activate the Dash Cam and start recording a 16-second and a 60-second video. The Dash Cam will then re- enter the Parking Mode. Time Lapse Time Lapse recording is a technique whereby the frequency at which file frames are captured (frame rate) is lower than that used when playing back the recording. Time Lapse recording can be considered the opposite of slow motion, as when the recording is played back time appears to be moving faster. This feature operates for up to 24 hours after the ignition is turn off. Emergency Recordings A 16-second video and a 60-second video will be captured when the G-Sensor is activated in case of sharp turns or a sudden stop. When the capacity of these videos reaches 30% of the eMMC space, the oldest ones will be overwritten by the new ones. Travel Log Travel Log Record the driving path of your journey. Your video and photo will store the GPS information and shows the geographic in your album. Your journey could be store in your personal account in the cloud. Note: Not …

Text truncated - open the document above for the full version.

CruiseCloudTechnology(Shenzhen)CorporationLimited DeclarationonModelDifferences We, CruiseCloudTechnology(Shenzhen)CorporationLimited West3FBlock2,VisionBusinessPark,Tech.SouthRoad，High-techindustrialPark, Shenzhen,China Declarethatthefollowingproduct(s): FCCID:2A2Z5-MF02D-MF02 ProductName:DashCamDual ModelNo.:MF02D,MF02 Utilizetheidenticalcircuitdesign,PCBlayout,shieldingandinterfacewith(MF02D),onlythe modenamedifferent.Thereforethisapplicationcanberegardedasidenticalinperformance tothesubmittedtestsample. Themanufacturerwouldtakealltheresponsibilitiesfortheaboveproduct(s). Forandonbehalfof Authorizedperson Name:FranklinLo Position:GM Dateofissue:8/24/2022 *IherebydeclarethatIamentitledtosignonbehalfoftheapplicantandthattheinformationsuppliediscorrectandcomplete.

CruiseCloudTechnology(Shenzhen)CorporationLimited OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:2022-08-24 Subject;RequestforConfidentiality FCCID:2A2Z5-MF02D-MF02 ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthesedocuments mightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantageinthemarket. SchematicDiagram BlockDiagram OperationalDescription SWSECURITYDESCRIPTION PartsList Tuneup Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:FranklinLo Title:GM

CruiseCloudTechnology(Shenzhen)CorporationLimited LetterofAuthorization Company:CruiseCloudTechnology(Shenzhen)CorporationLimited Address:West3FBlock2,VisionBusinessPark,Tech.SouthRoad，High-tech industrialPark,Shenzhen,China ProductName:DashCamDual ModelNumber(s):MF02D,MF02 ProductDescription:DashCamDual WeauthorizeMiCOMLabsInc.,575BoulderCourt,Pleasanton,California94566,USA, toactonourbehalfonallmattersconcerningthecertificationofabovenamed equipment. WedeclarethatMiCOMLabsInc.isallowedtoforwardallinformationrelatedtothe approvalandcertificationofequipmenttotheregulatoryagenciesasrequiredandto discussanyissuesconcerningtheapprovalapplication.Anyandallactscarriedoutby MiCOMLabsonourbehalfshallhavethesameeffectasactsofourown. Signature:Date:2022-08-24 Name:FranklinLo Title:GM Company:CruiseCloudTechnology(Shenzhen)CorporationLimited

Code:AB-RF-05-b ExternalPhotograph Code:AB-RF-05-b Code:AB-RF-05-b Code:AB-RF-05-b

MF02Toviewanelectroniclabel 1.Clickthesettingsbutton 2.Checkaboutthismachine 3.SelectLegal&Regulatory Popupelectroniclabel

Code:AB-RF-05-b InternalPhotograph Code:AB-RF-05-b WIFIANT Code:AB-RF-05-b Code:AB-RF-05-b Code:AB-RF-05-b GPSRXANT

RFEXPOSUREEVALUATION AccordingtoFCC1.1310:Thecriterialistedinthefollowingtableshallbeusedto evaluatetheenvironmentimpactofhumanexposuretoradiofrequency(RF)Radiation asspecifiedin§1.1307(b) FCCID:2A2Z5-MF02D-MF02 EUTSpecification EUTWifiDigitalPhotoFrame Frequencyband(Operating)WLAN:2.412GHz~2.462GHz WLAN:5.18GHz~5.24GHz WLAN:5.745GHz~5.825GHz Others:Bluetooth:2402-2480MHz DevicecategoryPortable(<20cmseparation) Mobile(>20cmseparation) Others___ ExposureclassificationOccupational/Controlledexposure(S=5mW/cm2) GeneralPopulation/Uncontrolledexposure(S=1mW/cm2) AntennadiversitySingleantenna Multipleantennas Txdiversity Rxdiversity Tx/Rxdiversity Antennagain(Max) WiFi2.4G:0.81dBi WiFi5.2G/5.8G:2.76dBi EvaluationappliedMPEEvaluation SAREvaluation LimitsforMaximumPermissibleExposure(MPE) Frequency Range(MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) Power Density(mW/cm 2 ) Average Time (A)LimitsforOccupational/ControlExposures 300-1500----F/3006 1500-100000----56 (B)LimitsforGeneralPopulation/UncontrolExposures 300-1500----F/15006 1500-100000----130 Friistransmissionformula:Pd=(Pout*G)\(4*pi*R2) Where Pd=PowerdensityinmW/cm 2 Pout=outputpowertoantennainMw G=gainofantennainlinearscale Pi=3.1416 R=distancebetweenobservationpointandcenteroftheradiatorincm PdthelimitofMPE,1mW/cm2.Ifweknowthemaximumgainoftheantennaand totalpowerinputtotheantenna,throughthecalculation,wewillknowthedistance wheretheMPElimitisreached. MaxMeasurementResult Operating Mode Measured Power Tuneup tolerance Max.Tune upPower Antenna Gain Power densityat 20cm Power densityLimits (mW/cm2) (dBm)(dBm)(dBm)(dBi)(mW/cm2) 2.4GWIFI21.1821.18±122.180.810.0658 1 5GWIFI21.3121.31±122.312.760.0436 1
