2A33B-41824183wireless charger

1 UNIFIER wireless charger | user guide 2 WITH LOVE FROM COPENHAGEN At UMAGE, our designers take inspiration from the dis- tinct nature of the Nordic landscape to create unique designs related to the way we live in an urban setting. Influenced by the design language, colours and materials found around us in Scandinavia, we create a collection that is rooted in our home but designed for everyone. Versatile, flexible and multifunctional, our designs are created to enhance an urban lifestyle in smaller spaces! 4 ENGLISH TECHNICAL DATA Type: Unifier (4182 / 4183) Input: USB-C, 5V/2A, 9V/1.67A Indoor use only Output power: 10W MAX Wirelessly charges Qi-compatible devices LED RING INDICATOR Blue slow pulsing Fast blinking STATUS Charging Error, remove or readjust device INSTRUCTION FOR USE • Connect the USB cable to the power adapter and to Unifier. Plug it into the wall socket. • For wireless charging, place the device to be charged on top of the UMAGE logo on the charger. The device must be placed directly over and center of the logo on the charger for the charging function to work optimally. Note that some devices, you may have to activate wireless charging in settings. • If your battery is completely discharged, it may take a few minutes before it starts charging. This is entirely normal. You can see that the battery has begun charging when the battery symbol appears on your phone. GOOD TO KNOW • USB cable length and quality influences charging speed and performance. • Devices may get warm during charging; this is completely normal and they will gradually cool down again after they are fully charged. • Charging time may vary based on the device’s battery capacity, charge level, the age of the battery and the temperature in the surrounding area. • Charger storage temperature: -20°C to 25°C • Charger operating temperature: 0°C to 40°C Unplug the charger from the power source before cleaning and when it is not in use. To clean the charger, wipe with a moist cloth. Never submerge the charger in water. Save these instructions for future use. DEUTSCH TECHNISCHE DATEN Art: Unifier (4182 / 4183) Eingang: USB-C, 5V/2A, 9V/1.67A Nur Innenanwendung Ausgangsleistung: 10W MAX lädt Qi-kompatible Geräte drahtlos auf LED-INDIKATOR Blau langsam blinken Schnell blinken STATUS Laden Gerät fehlerhaft, entfernen oder erneut einstellen BENUTZERINFORMATION • Das USB-Kabel an das Netzteil und LIVBOJ anschließen und das Kabel in die Steckdose stecken. • Zum kabellosen Laden das zu ladende Gerät auf das Pluszeichen (+) des Ladegeräts legen. Für optimales Laden muss das Gerät akkurat auf dem Pluszeichen (+) des Ladegeräts liegen. Bitte beachten, dass bei manchen Geräten kabelloses Aufladen erst unter "Einstellungen" aktiviert werden muss. • Bei vollständig entladenem Akku kann es bis zum Ladebeginn einige Minuten dauern. Sobald der Ladevorgang beginnt, erscheint das Batteriesymbol im Telefondisplay. GUT ZU WISSEN • USB-Kabellänge und -qualität wirken sich auf die Ladegeschwindigkeit und -leistung aus. • Während des Ladevorgangs können sich die Komponenten erwärmen. Das ist normal und sie kühlen nach dem Aufladen langsam ab. • Die Ladezeit kann je nach Akkukapazität, Restenergie, dem Alter des Akkus bzw. abhängig von der Umgebungstemperatur unterschiedlich lang sein. • Aufbewahrungstemperatur für das Ladegerät: -20 bis +25 °C. • Temperatur für Einsatz des Ladegeräts: 0 bis +40 °C. Zum Reinigen des Ladegeräts oder bei Nichtbenutzung den Netzstecker herausziehen. Das Gerät mit einem feuchten Tuch reinigen. Darf nicht in Wasser getaucht werden. Diese Anleitung für spätere Benutzung aufbewahren. FRANÇAIS CARACTÉRISTIQUE TECHNIQUES Type: Unifier (4182 / 4183) Entrée: USB-C, 5V/2A, 9V/1.67A Utilisation en intérieur uniquement Puissance de sortie : 10W MAX Compatible avec les appareils de recharge sans-fil Qi TÉMOIN LED Clignote en bleu lentement Clignote rapidement STATUT En charge Erreur, enlevez ou réajustez l’appareil INSTRUCTIONS D'UTILISATION • Raccorder le câble USB à l’adaptateur et à LIVBOJ, puis brancher à une prise de courant. • Pour le chargement sans fil, placer le téléphone sur le signe (+) du chargeur. L'appareil doit être placé précisément sur le signe (+) du chargeur pour un chargement optimal. Sur certains appareils, il est nécessaire d’activer la fonction de chargement sans fil dans les paramètres pour que le chargement fonctionne. • Si la batterie est complètement déchargée, elle peut mettre quelques minutes avant de commencer à se recharger. Cela est tout à fait normal. Lorsque le symbole de la batterie apparaît sur le téléphone cela indique le début du chargement. BON À SAVOIR • La longueur et la qualité du câble USB influent sur la vitesse et la performance du chargement. • Il est tout à fait normal que les appareils chauffent au cours du chargement ; ils refroidiront progressivement une fois qu’ils seront entièrement chargés. • La durée du chargement peut varier en fonction de la capacité de la batterie de l’appareil, du niveau de charge, de l’âge de la batterie et de la température ambiante. • Température de stockage du chargeur : -20°C à 25°C. • Température de fonctionnement du chargeur : 0°C à 40°C. Débranchez le chargeur de la source d’alimentation avant de procéder à son nettoyage et lorsqu’il n’est pas utilisé. Pour nettoyer le chargeur, essuyez-le avec un chiffon humide. Ne jamais plonger le chargeur dans l’eau. Conserver ces instructions en vue d’une utilisation ultérieure. NEDERLANDS TECHNICSCHE GEGEVENS Type: Unifier (4182 / 4183) Ingang: USB-C, 5V/2A, 9V/1.67A Alleen voor gebruik binnenshuis Uitgangsvermogen: 10W MAX Laad Qi-compatibele apparaten draadloos op LED-INDICATOR Blauw knippert langzaam Snel knippert STATUS Aan het opladen Foutmelding, verwijder of herstel apparaat GEBRUIKERSINSTRUCTIES • Sluit de USB-kabel aan op de lichtnetadapter en op LIVBOJ. Steek de stekker in het stopcontact. • Voor draadloos opladen plaats je het op te laden apparaat bovenop het plusteken (+) van de lader…

Text truncated - open the document above for the full version.

Form: RFT-AMER-TCB-OP-19o Revision: 1 Page 1 of 1 Date: 1/25/2023 Attention: Application Examiner Re: Certification designating a U.S. agent for service of process pursuant to 47 CFR part §2.911(d)(7) of the FCC rules To whom it may concern, This letter is to certify that Umage Inc (“Applicant”) accepts responsibilities to act as its own agent pursuant to 47 CFR part §2.911(d)(7) of the FCC rules for service of process. I consent to the obligation to accept service of process on behalf of the Applicant for all certification applications to the FCC. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant. I further acknowledge the requirement to maintain an agent extends for no less than one year after the termination of all marketing and importation or the conclusion of and commission-related proceeding involving the equipment and agree to immediately notify the FCC and Intertek if there is any change in the status identified above. Applicant Company Name : Umage Inc Contact Name : Riyad Ahmed Address : 185 Wythe Ave 2 FL, Brooklyn, NY 11249 USA Telephone No : +1 646 790 7171 Email : [email protected] Applicant FRN : 0031760598 Signature: Date: 07/11/2023

Form: RFT-AMER-TCB-OP-19n Revision: 1 Page 1 of 1 Date: 1/25/2023 Attention: Application Examiner Re: Covered List, located at https://www.fcc.gov/supplychain/coveredlist and 47 CFR parts §2.903 and §2.911(d)(5)(ii) of the FCC rules Applicant: UMAGE Inc. FCC ID: 2A33B-41824183 To whom it may concern, UMAGE Inc. (“Applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to 47 CFR part §2.903 of the FCC rules and does not originate directly or indirectly from any company named on the covered list located in the link above or any subsidiary or affiliate thereof. Applicant further certifies that, as of the date of the filing of the application, the Applicant is not identified on the Covered List as an entity producing “covered” equipment and is not a subsidiary or affiliate of any such entity pursuant to 47 CFR part §1.50002 and required by 47 CFR part §2.911(d)(5)(ii) of the FCC rules. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant and agree to immediately notify Intertek if there is any change in the status identified above. ______________________________ [Signature of authorized Proprietor, Partner or Authorized Officer] Kasper Roed Wehage Global Product Compliance Manager UMAGE Inc. 10-07-2023

05 July. 2023 Federal Communications Commission 445 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement UMAGE Inc. FCC ID: 2A33B-41824183 To Whom It May Concern: We, UMAGE Inc., hereby authorized Intertek Testing Services Shenzhen Ltd. Guangzhou Branch to act as our Agent for the purpose of preparing application for FCC ID number (2A33B- 41824183) under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is 05 July. 2023. The Limited Agency Agreement expires on 05 January. 2024, unless sooner terminated or extended by written notice to Intertek Testing Services Shenzhen Ltd. Guangzhou Branch and the Federal Communications Commission. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, Kasper Roed Wehage Global Product Compliance Manager

1(1) UMAGE Inc. 10-07-2023 Attention: Application Examiner RE: Request for Confidentiality Applicant: UMAGE Inc. FCC ID: 2A33B-41824183 To Whom It May Concern: Permanent Confidentiality [Complete this section if permanent confidentiality is requested] Request is hereby submitted by UMAGE Inc. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: [Select one or more of items below, as appropriate] • Schematics • Detailed Block Diagrams • Detailed Operational/Functional Description Rationale for request for confidentiality: UMAGE Inc. has invested considerable time and materials in research and development to produce the referenced product. [Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us.] If you have questions or need further information, please contact the undersigned. Sincerely, [Signature] [Printed Name]Kasper Roed Wehage [Type Title]Global Product Compliance Manager [Company name]UMAGE Inc.

On black Unifier underside of base: On white Unifier underside of base: Location

UMAGE Inc. TEST REPORT SCOPE OF WORK EMC TESTING–4182, 4183 REPORT NUMBER 230608076GZU-002 ISSUE DATE [REVISED DATE] 01-July-2023 [--------------------] PAGES 8 DOCUMENT CONTROL NUMBER © 2017 INTERTEK TEST REPORT Room 02, & 101/E201/E301/ E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Telephone: +86 20 8213 9688 Facsimile: +86 20 3205 7538 www.intertek.com.cn This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Version: 21 August 2017 Page 2 of 8 Applicant Name & Address : UMAGE Inc. 185 Wythe Ave. 2.fl. Brooklyn, NY 11249 Manufacturing Site : Same as applicant Intertek Report No: FCC ID: 230608076GZU-002 2A33B-41824183 Test standards 47 CFR PART 1, Subpart I, Section 1.1310 KDB 680106 D01 RF Exposure Wireless Charging App v03r01 Sample Description Product : wireless charger Model No. : 4182, 4183 Electrical Rating : Input: 5V-9V DC 1.67-2A Output: 10W MAX Serial No. : Not Labeled Date Received : 08 June 2023 Date Test Conducted : 28 June 2023-01 July 2023 Prepared and Checked By Richard Liu Engineer Approved By: Dean Liu Project Engineer TEST REPORT Intertek Report: No: 230608076GZU-002 Version: 21 August 2017 Page 3 of 8 FCC Part 15.225-a CONTENT TEST REPORT ........................................................................................................................... 1 CONTENT ............................................................................................................................. 3 1.0 TEST RESULT SUMMARY ............................................................................................ 4 2.0 GENERAL DESCRIPTION .............................................................................................. 5 2.1 PRODUCT DESCRIPTION ........................................................................................................ 5 2.2 TEST FACILITY ...................................................................................................................... 5 2.3 EUT EXERCISING SOFTWARE.................................................................................................. 5 2.4 SPECIAL ACCESSORIES ........................................................................................................... 5 2.5 EQUIPMENT MODIFICATION .................................................................................................. 5 2.6 SUPPORT EQUIPMENT LIST AND DESCRIPTION .......................................................................... 5 3.0 EMF TEST.................................................................................................................. 7 3.1 STANDARD REQUIREMENT .......................................................................................................... 7 3.2 TEST DATA ............................................................................................................................... 8 4.0 TEST EQUIPMENT LIST ............................................................................................... 8 TEST REPORT Intertek Report: No: 230608076GZU-002 Version: 21 August 2017 Page 4 of 8 FCC Part 15.225-a 1.0 TEST RESULT SUMMARY Classification of EUT: Class B Test Item Standard Result EMF 47 CFR PART 1, Subpart I, Section 1.1310 PASS Remark: When determining the test results, measurement uncertainty of tests has been considered. Model 4182 and Model 4183 are just different colors. Select model 4182 as full test. TEST REPORT Intertek Report: No: 230608076GZU-002 Version: 21 August 2017 Page 5 of 8 FCC Part 15.225-a 2.0 General Description 2.1 Product Description Operating Frequency 112-149.1KHz Type of Modulation: ASK Antenna Type Inductive loop coil antenna Power Supply: Input: 5V-9V DC 1.67-2A Output: 10W MAX Power cord: 1m USB wires unscreened cable 2.2 Test Facility Room102/104, No 203, KeZhu Road, Science City, GETDD Guangzhou, China A2LA Certificate Number 0078.10 Intertek Testing Services Shenzhen Ltd. Guangzhou Branch is accredited by A2LA and Listed in FCC website. FCC accredited test labs may perform both Certification testing under Parts 15 and 18 and Declaration of Conformity testing. 2.3 EUT Exercising Software N/A 2.4 Special Accessories N/A 2.5 Equipment Modification Any modifications installed previous to testing by UMAGE Inc. will be incorporated in each production model sold / leased in the United States. No modifications were installed by Intertek Testing Services Shenzhen Ltd. Guangzhou Branch. 2.6 Support Equipment List and Description TEST REPORT Intertek Report: No: 230608076GZU-002 Version: 21 August 2017 Page 6 of 8 FCC Part 15.225-a This product was tested with corresponding support equipment as below: Support Equipment: Equipment Model No. Rating Supplier WPT client Tx-test2 DC 12V/0.83A,DC 7.5V/1.06A,DC 5V/1A Intertek Adaptor HW-200325CP0 100-240V,50/60Hz,1.8A Intertek Cable: Description Model No. Connector type Cable length/type…

Text truncated - open the document above for the full version.

UMAGE Inc. TEST REPORT SCOPE OF WORK EMC TESTING–4182, 4183 REPORT NUMBER 230608076GZU-001 ISSUE DATE [REVISED DATE] 01-July-2023 [---------------------] PAGES 23 DOCUMENT CONTROL NUMBER FCC Part 15C -d © 2017 INTERTEK TEST REPORT Room 02, & 101/E201/E301/ E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Telephone: +86 20 8213 9688 Facsimile: +86 20 3205 7538 www.intertek.com.cn This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Version: 14 December 2022 Page 2 of 23 FCC Part 15C-d Applicant Name & Address : UMAGE Inc. 185 Wythe Ave. 2.fl. Brooklyn, NY 11249 Manufacturing Site : Same as applicant Intertek Report No: FCC ID: 230608076GZU-001 2A33B-41824183 Test standards 47 CFR PART 15 Subpart C:2021 Sample Description Product : wireless charger Model No. : 4182, 4183 Electrical Rating : Input: 5V-9V DC 1.67-2A Output: 10W MAX Serial No. : Not Labeled Date Received : 08 June 2023 Date Test Conducted : 28 June 2023-01 July 2023 Prepared and Checked By Richard Liu Engineer Approved By: Dean Liu Project Engineer TEST REPORT Intertek Report No.: 230608076GZU-001 Version: 14 December 2022 Page 3 of 23 FCC Part 15C-d CONTENT TEST REPORT ........................................................................................................................... 1 CONTENT ............................................................................................................................. 3 1.0 TEST RESULT SUMMARY ............................................................................................ 4 2.0 GENERAL DESCRIPTION .............................................................................................. 5 2.1 PRODUCT DESCRIPTION ........................................................................................................ 5 2.2 RELATED SUBMITTAL(S) GRANTS ............................................................................................ 5 2.3 TEST METHODOLOGY ........................................................................................................... 5 2.4 TEST FACILITY ...................................................................................................................... 5 3.0 SYSTEM TEST CONFIGURATION .................................................................................. 6 3.1 JUSTIFICATION ..................................................................................................................... 6 3.2 EUT EXERCISING SOFTWARE.................................................................................................. 7 3.3 SPECIAL ACCESSORIES ........................................................................................................... 7 3.4 MEASUREMENT UNCERTAINTY ............................................................................................... 7 3.5 EQUIPMENT MODIFICATION .................................................................................................. 8 3.6 SUPPORT EQUIPMENT LIST AND DESCRIPTION .......................................................................... 8 4.0 RADIATED EMISSION ................................................................................................. 9 5.0 OCCUPIED BANDWIDTH ........................................................................................... 18 6.0 CONDUCTED EMISSION TEST ................................................................................... 20 7.0 TEST EQUIPMENT LIST ............................................................................................. 23 TEST REPORT Intertek Report No.: 230608076GZU-001 Version: 14 December 2022 Page 4 of 23 FCC Part 15C-d 1.0 TEST RESULT SUMMARY Test Item Test Requirement Test Method Result Conducted disturbance voltage at mains ports FCC PART 15 C section 15.207 ANSI C63.10: Clause 6.2 PASS Radiated Emission FCC PART 15 C section 15.209 ANSI C63.10: Clause 6.4 & 6.5 PASS 20dB Bandwidth FCC PART 15 C section 15.215 FCC PART 15 C section 15.215 PASS Remark: When determining the test results, measurement uncertainty of tests has been considered. Model 4182 and Model 4183 are just different colors. Select model 4182 as full test. TEST REPORT Intertek Report No.: 230608076GZU-001 Version: 14 December 2022 Page 5 of 23 FCC Part 15C-d 2.0 General Description 2.1 Product Description Operating Frequency 112-149.1KHz Type of Modulation: ASK Antenna Type Inductive loop coil antenna Power Supply: Input: 5V-9V DC 1.67-2A Output: 10W MAX Power cord: 1m USB wires unscreened cable 2.2 Related Submittal(s) Grants This is an application for certification of: DCD-Part 15 Low Power Transmitter below 1705kHz 2.3 Test Methodology Both AC mains line-conducted and radiated emission measurements were performed according to the procedures in ANSI C63.10. Radiated emission measurement was performed in semi-anechoic chamber and conducted emission measuremen…

Text truncated - open the document above for the full version.

43mm 21mm

Conducted Emission Test Radiated Emissions(9kHz to 30MHz) Radiated Emissions(30MHz to 1GHz) Remark: The EUT is center on the turntable, due to the edge of desk placed on the diameter of the turntable. EMF Side 1: Side 2: Side 3: Side 4: TOP
