2A33Q-EWC1W001Apple Watch Wireless Charger

Apple Watch Wireless Charger-Quick Guide Model No.：EWC1W001 Input Power (V/A): 5V/1A Output Power (W): 2.5W Compatible with: Apple Watch S1-8; Net Weight: 15g Size: 43*35*9mm No-load power consumption : 25~100 mW working frequency: 300KHz-350KHz 01/Operation manual 1. Plug the charging cable into the wireless charger. 2. Attach the watch to the wireless charger，and when the charging icon is displayed on the watch pane， The watch starts charging wirelessly. 3. Remove the watch from the wireless charger when charging is completed. 02/ Notes It is recommended that the charging ambient temperature be lower than 28 degrees Celsius, as higher temperatures can lead to a decrease in charging efficiency. 03/Safety tips 1. Do not put foreign metal objects in the charging area between the phone and wireless charger, which will lead to latent danger. 2.Do not put magnetic stripe cards (such as credit cards, telephone cards, bank cards, etc.) or some medical equipment (such as pacemakers or hearing aids) together with this product, which may cause damage to the magnetic stripe or abnormal operation of the equipment. 3.Do not apply heavy pressure and place it out of reach of children or animals. 4.Do not disassemble, refit and repair the wireless charger by oneself, otherwise it will not be able to carry out normal after-sale service. 04/Warranty The warranty of this product is twelve months. Failure or damage not caused by human factors, please contact the purchasing channel or manufacture for after-sales service under warranty. The warranty does not apply to the following: 1.Damage caused by force majeure. 2.Failure or damage of the product caused by human factors. 3.Warranty expired. FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC RF exposure statement: The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance between 20cm the radiator your body.

OasisCompliance,Inc.FCCID:2A33Q-EWC1W001 CFR47§2.911(d)(7)FCCUSAgentLetterofAttestation Date:04-08-2023 FCCID:2A33Q-EWC1W001 To:FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 ToWhomItMayConcern, ThisletteristoconfirmthatwehaveacceptedtheresponsibilitytoactasUSAgentonbehalf. ShenzhenEnPassionTechnologyLtd.(“theapplicant”)fortheabovereferencedFCCID. Weareawareoftherequirementsandresponsibilitiesoftheapplicant’sagentforserviceof processasoutlinedintheFCCsection2.911(d)(7)andReportandOrderFCC22-84paragraph 63. U.S.AgentInformation: OasisCompliance,Inc. FRN:0033464157 JamesHe 3313VerdiDr,SanJose,CA95111 Cell:202-602-8330 Sincerelyyours, JamesHe GlobalMarketAccessManager OasisCompliance,Inc. Email:[email protected]

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Shenzhen EnPassion Technology Ltd. Grantee code: 2A33Q FCC ID: 2A33Q-EWC1W001 Contact Name: Li Zhong Address: 828-1, 8F, Building12, BlockB, Shenzhen Bay Science and Technology Eco- Park, Science & Technology South Road, District Nanshan, Shenzhen, Province Guangdong, China Telephone No: 0755-86970520 Fax No: 0755-86970520 Email: [email protected] i. [Shenzhen EnPassion Technology Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [ Shenzhen EnPassion Technology Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. Shenzhen EnPassion Technology Ltd. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Date: 06.2 8.2023 Applicant’s Name: Li Zhong Title: GM Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Shenzhen EnPassion Technology Ltd. Product Similarity Declaration Product name: Apple Watch Wireless Charger Model name: EWC1W001, EWC1W001-C, EWC1W001-L, EWC1W001-HC, EWC1W001-HL, EWC1W001-1C, EWC1W001-1L, EWC1W001-2C, EWC1W001-2L, EWC1W001-3C, EWC1W001-3L, EWC1W001-1HC, EWC1W001-1HL, EWC1W001-2HC, EWC1W001- 2HL, EWC1W002 FCC ID: 2A33Q-EWC1W001 We (Shenzhen EnPassion Technology Ltd.) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the only difference is the model name and color. Demonstrate the detail(descriptions and pictures) as to the difference list above. Signature: Name: Li Zhong Title: GM Date: 4.24.2023

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Shenzhen EnPassion Technology Ltd. Address: 828-1, 8F, Building12, BlockB, Shenzhen Bay Science and Technology Eco-Park, Science & Technology South Road, District Nanshan, Shenzhen, Province Guangdong, China. Product Name: Apple Watch Wireless Charger Model Number: EWC1W001, EWC1W001-C, EWC1W001-L, EWC1W001-HC, EWC1W001-HL, EWC1W001-1C, EWC1W001-1L, EWC1W001-2C, EWC1W001-2L, EWC1W001-3C, EWC1W001-3L, EWC1W001-1HC, EWC1W001-1HL, EWC1W001-2HC, EWC1W001-2HL, EWC1W002 FCC Identifier: 2A33Q-EWC1W001 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Li Zhong Date: 4/24/2023 Title: GM Signature of applicant:

C5266091_X10_Ed.1 1/1 Shenzhen EnPassion Technology Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 4/24/2023 Subject: Request for Confidentiality FCC ID: 2A33Q-EWC1W001 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Li Zhong Date: 4/24/2023 Title: GM

Page 1 of 3 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Appendix - EUT Photos Model: EWC1W001 Page 2 of 3 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 3 of 3 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] ----End of Report----

Size:43*35*9mm 43mm 35mm MadeinChina AppleWatchWirelessCharger Model:EWC1W001 Input:5V1AOutput:2.5W(Max) Manufacturer: ShenzhenEnPassionTechnologyLtd. FCCID:2A33Q-EWC1W001

Page 1 of 2 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Appendix - EUT Photos Model: EWC1W001 Page 2 of 2 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] ----End of Report---- Coli

Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel : (8 6-755)88850135 Fax: (86-755) 88850136 We b : www.mtitest.com E-mail: [email protected] Test Report Report No.: MTi230314004-05E2 Date of issue: 2023-03-23 Applicant: Shenzhen EnPassion Technology Ltd. Product: Apple Watch Wireless Charger Model(s): EWC1W001, EWC1W001-C, EWC1W001-L, EWC1W001-HC, EWC1W001-HL, EWC1W001-1C, EWC1W001-1L, EWC1W001-2C, EWC1W001-2L, EWC1W001-3C, EWC1W001-3L, EWC1W001-1HC, EWC1W001-1HL, EWC1W001-2HC, EWC1W001-2HL, EWC1W002 FCC ID: 2A33Q-EWC1W001 Shenzhen Microtest Co., Ltd. http://www.mtitest.com Page 2 of 13 Report No.: MTi230314004-05E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Instructions 1. This test report shall not be partially reproduced without the written consent of the laboratory. 2. The test results in this test report are only responsible for the samples submitted 3. This test report is invalid without the seal and signature of the laboratory. 4. This test report is invalid if transferred, altered, or tampered with in any form without authorization. 5. Any objection to this test report shall be submitted to the laboratory within 15 days from the date of receipt of the report. Page 3 of 13 Report No.: MTi230314004-05E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Contents 1 General Description ........................................................................................................................ 5 1.1 Description of the EUT ....................................................................................................................................... 5 1.2 Description of test modes ................................................................................................................................... 5 1.3 Description of support units ................................................................................................................................ 6 2 Measurement uncertainty ............................................................................................................... 6 3 Test facilities and accreditations .................................................................................................... 7 3.1 Test laboratory .................................................................................................................................................... 7 4 List of test equipment ..................................................................................................................... 8 5 Test result ........................................................................................................................................ 9 5.2 Test setup ......................................................................................................................................................... 10 5.3 Test Procedures ................................................................................................................................................ 10 5.4 Equipment Approval Considerations item 5 b) of KDB 680106 D01 v03r01 .................................................... 11 5.5 Test results ....................................................................................................................................................... 12 Photographs of the Test Setup ............................................................................................................ 13 Photographs of the EUT....................................................................................................................... 13 Page 4 of 13 Report No.: MTi230314004-05E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Test Result Certification Applicant: Shenzhen EnPassion Technology Ltd. Address: 828-1, 8F, Building12, BlockB, Shenzhen Bay Science and Technology Eco-Park, Science & Technology South Road, District Nanshan, Shenzhen, Province Guangdong, China Manufacturer: Shenzhen EnPassion Technology Ltd. Address: 828-1, 8F, Building12, BlockB, Shenzhen Bay Science and Technology Eco-Park, Science & Technology South Road, District Nanshan, Shenzhen, Province Guangdong, China Factory: Shenzhen EnPassion Technology Ltd. Address: 828-1, 8F, Building12, BlockB, Shenzhen Bay Science and Technology Eco-Park, Science & Technology South Road, District Nanshan, Shenzhen, Province Guangdong, China Product description Product name: Apple Watch Wireless Charger Trademark: N/A Model name: EWC1W001 Series Model: EWC1W001-C, EWC1W001-L, EWC1W001-HC, EWC1W001-HL, EWC1W001-1C, EWC1W001-1L, EWC1W001-2C, EWC1W001-2L, EWC1W001-3C, EWC1W001-3L, EWC1W001-1HC, EWC1W001-1HL, EWC1W001-2HC, EWC1W001-2HL, EWC1W002 Standards: FCC CFR 47 PART 1, § 1.1310 Test method: KDB 680106 v03r01 Date of Test Date of test: 2023-03-16 ~ 2023-03-23 Te s t result: Pass Test Engineer : (Letter Lan) Reviewed By: : (Leon Chen) Approved By: : (Tom Xue) Page 5 of 13 Report No.: MTi230314004-05E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] 1 General Description 1.1 Description of the EUT Product name: Apple Watch Wireless Charger Model name: EWC1W001 Series Model: EWC1W001-C, EWC1W001-L, EWC1W001-HC, EW…

Text truncated - open the document above for the full version.

Name: Coil KEFEITE NO: 15.4x0.8x24px12Tx6.6uH-引线5mm-W15355 No: W15355 Date: 2022.12.01 Ver. A0 1.Size: （mm） 背胶 1.12±0.1 2.8MAX 磁铁 7.8±0.5 14±0.5 21MAX 25±1 5±1.5 3±1.5 2.Ele ctrical performance（L）： Item Standard Test conditon Test instruments Notes Inductance 4.0uH±5% 100KHZ,1V TH2817B+ Aircored coil test Inductance1 6.5uH±5% 100KHZ,1V TH2817B+ Test with Magnet SPECIFICATION FOR APPROVA Adhesive backing Magnet manufacturer：Guangdong Jinsheng Intelligent Co., Ltd turns per coil：12 S 3、Appearance requirements: 1) The shape and size of the product should be strictly controlled. 2) The product surface shall be free of oil stains, impurities, burrs, etc. 3) Materials cannot be changed without customer confirmation 4) The product must comply with ROSH requirements 4、B ill of materials n umber Material name Description Material Code 1 Wire stock 0.08* 24P Hot air stranded wire 2 Soft magnetic sheet G25*7.8*2.6H 3 Magnet Strong magnetN52 7.5* 2.0H ;Galvanization (2900-3100 Gauss) 4 Adhesive backing 19*0. 15H (No holes）
