2A348SPARKPEDALWireless Foot Controller

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 1 of 5 Appendix External Photos for GZCR2603000625AT Test Model No.: Spark PEDAL SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 2 of 5 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 3 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 4 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 5 of 5 - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 1 of 10 Appendix Internal Photos for GZCR2603000625AT Test Model No.: Spark PEDAL SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 2 of 10 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 3 of 10 BT ANT BLE/ Wi-Fi ANT SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 4 of 10 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 5 of 10 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 6 of 10 USB port isolator IC option 1: ISOUSB111 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 7 of 10 USB port isolator IC option 2: ADuM3160 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 8 of 10 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 9 of 10 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 10 of 10 - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 2.0 Report No.:GZCR260300062505 Page: 1 of 9 FCC ID: 2A348SPARKPEDAL RF EXPOSURE EVALUATION REPORT Application No.: GZCR2603000625AT Applicant:Positive LLC Address of Applicant:2820 S Alma School Rd Suite 18 PMB 2011, Chandler, Arizona 85286, United States Manufacturer:Jia Ge Digital Technology Co. Ltd Address of Manufacturer:11F, No. 176, Changchun Rd., Zhongshan Dist., Taipei City 104082, Taiwan Product Name:Wireless Foot Controller Model No.: Spark PEDAL Trade Mark:Positive Grid Standard(s) : KDB 447498 D01 V06 47 CFR Part 1.1310 Date of Receipt: 2026-04-03 Date of Evaluation: 2026-05-14 Date of Issue: 2026-06-12 Evaluation Result: Pass* * In the configuration evaluated, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 2.0 Report No.:GZCR260300062505 Page: 2 of 9 Revision Record VersionReport No.DateRemark 01GZCR2603000625052026-06-12Original Authorized for issue by: Luke Lin/Project Engineer Approved By Vico Cui/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 2.0 Report No.:GZCR260300062505 Page: 3 of 9 2Evaluation Summary ItemStandardMethodRequirementResult RF Exposure KDB 447498 D01 V06 KDB 447498 D01 V0647 CFR Part 1.1310Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. Remark: For model Spark PEDAL optional USB port isolator IC ISOUSB111 or AduM3160. And all RF modules selected for use are the same. So only the EUT with optional IC ISOUSB111 was evaluated in this report. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 2.0 Report No.:GZCR260300062505 Page: 4 of 9 3Contents Page 1Cover Page...............................................................................................................................................1 2Evaluation Summary................................................................................................................................3 3Contents....................................................................................................................................................4 4General Information.................................................................................................................................5 4.1Details of E.U.T.................................................................................................................................5 4.2Evaluating Location...........................................................................................................................5 4.3Facility...............................................................................................................................................6 4.4Deviation from Standards..................................................................................................................6 4.5Abnormalities from Standard Conditions...........................................................................................6 5Technical Requirements Specification..................................................................................................7 5.1General Description of Applied Standards........................................................................................7 5.2RF Exposure Evaluation....................................................................................................................7 5.2.1Limit & Test Method......................................................................................................................7 5.2.2Conclusion....................................................................................................................................8 6EUT Constructional Details (EUT Photos).............................................................................................9 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 2.0 Report No.:GZCR260300062505 Page: 5 of 9 4General Information 4.1Details of E.U.T. Power supply:Powered by built in rechargeable battery as below: Model: GSP872693 Rated: DC 3.7V, 3000mAh DC 5V 2A for charging Cable(s):AUX-IN output *1pcs Audio OUTPUT port L & R *1pcs EXP port *1pcs USB-C port *1pcs (charge and transmit data) MIDI IN/OUT port Earphone port RF characters: Refer to test report GZCR260300062502 for BLE detail. Refer to test report GZCR260300062503 for BT classic detail. Refer to test report GZCR260300062504 for 2.4GHz Wi-Fi detail. Remark: The information in this section is provided by the applicant or manufacturer, SGS is not liable to the accuracy, suitability, reliability or/and integrity of the information. 4.2Evaluating Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd., Guangzhou Branch EMC Laboratory, No.198, Kezhu Road, Science City, Economic & Technological Development Area, Guangzhou, Guangdong, China 510663 Tel: +86 20 82155555 No tests were sub-contracted. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 2.0 Report No.:GZCR260300062505 Page: 6 of 9 4.3Facility The facility is recognized, certified, or accredited by the following organizations: ● ACMA SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory can also perform testing for the Australian/New Zealand Regulatory Compliance Mark (RCM). ● SGS UK(Certificate No.: 32), SGS-TUV SAARLAND and SGS-FIMKO Have approved SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory as a supplier of EMC TESTING SERVICES and SAFETY TESTING SERVICES. ● FCC Recognized Accredited Test Firm(Registration No.: 486818) SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory has been accredited and fully described in a report filed with the (FCC) Federal Communications C…

Text truncated - open the document above for the full version.

表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 1 页共 13 页 开发案号Project：Y2508151413 日期Date.：2026.03.12 版本Ver.：A1 承认书 AntennaSPEC 客户名称 Customername ：国光电器 调试项目Customerproject：PGSparkPedal 客户料号CustomerP/N：EAN0053303 博安通料号 B&TP/N ： 74220712 规格描述Spec.:内置天线-2.4G-黑色1.13锡锡线-1代端子 -L=142mm-FPC-30.4×13mm Spec. ： Built-inAntenna-2.4G-Black1.13TinWire-1stGenerationTerminal- L=142mm-FPC-30.4×13mm 出厂签章Sealedbycorporation： 编写 compilation 审核 verify 批准 approval 许张金 Xuzhangjin 张光伟 ZhangGuangwei 刘立华 Liulihua 客户承认签章Sealedbycustomer： 检查 check 审核 verify 批准 approval 博安通联系方式ContactinformationofB&T: 业务联系人：龙明国 Contactpersonforsales ： Longmingguo 手机 MB ：18576042661邮箱 E-mail ：[email protected] 技术联系人：张光伟 Contactpersonfortechnical: ZhangGuangwei 手机 MB ：18060818565邮箱 E-mail ：[email protected] 品质联系人：谭杰鑫 ContactpersonforQuality: Tanjiexin 手机 MB ：18181766292邮箱 E-mail ：[email protected] 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 2 页共 13 页 博安通生产地址：四川省绵阳市经开区塘汛街道文武中路218号8幢5层2、3号 Address:RoomNo.2and3,5F,Building8,No.218,WenwuMiddleRoad,TangxunStreet,Economic DevelopmentZone,MianyangCity,SichuanProvince 文件制定 / 修订 / 废止履历表 Documentmaking/revising/abolishingresume 版本 Version 日期 Date 制定/修订内容 Develop/revisecontent 制定 Formulate 核准 approval A02025.10.13 首次制定 Firstformulation 许张金 Xuzhangjin 张光伟/刘立华 ZhangGuangwei/Liulihua A0-11202025.11.20 更新FPC UpdateFPC 许张金 Xuzhangjin 张光伟/刘立华 ZhangGuangwei/Liulihua A12026.03.12 更新线长 UpdateLineLength 许张金 Xuzhangjin 张光伟/刘立华 ZhangGuangwei/Liulihua 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 3 页共 13 页 目录 Contents 1 、封面Cover ································································1 2 、目录 Directory·····························································3 3 、产品图面 Productdrawing··············································4~5 4 、性能参数表 PerformanceparametersTable··························6 5 、电气性能测试报告 Electricalperformancetestreport··············7~8 6 、材料成份及有害物质表 ListofMaterialCompositionandHazardous Substance·······································································9 7 、包装规范 packagingspecification······································10 8 、天线安装位置示意图 AntennainstallationpositionDiagram·····11 9 、天线测试暗室摆放位置 Locationofantennatestdarkroom·······11 10 、可靠性测试要求 Reliabilitytestrequirements······················12~13 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 4 页共 13 页 3 、产品图面 Productdrawing 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 5 页共 13 页 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 6 页共 13 页 4 、性能参数 Properties&parameter 电气参数Electricalparameter 频率范围 FreqRange 2400~2500MHz 输入阻抗 CharacteristicImpedance 50Ω 驻波比 VSWR ＜2 增益 Gain 2.63dBi 功率容量 TheMaxinputpower <10w 极化方式 Polarizationmode 线极化 Linearpolarization 辐射方向 Radiationdirection 全向 omnidirectional 接头型号 Jointtype 端子 IPEXconnector 机械参数Mechanicalparameter 线长 Length 142±3mm 端子维持力 Maintaintheforce ≥ 0.8kgf 同轴电缆 Coaxialcable 黑色1.13锡锡线 Black1.13tinwire 盐雾测试 Saltspraytest 24H 环境参数Environmentparameter 工作温度 OperatingTemp -30 °C ~65 °C 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 7 页共 13 页 6、电气性能测试报告Electricaltestreport（整机测试Wholemachinetesting） 天线S11参数图AntennaS11parameterdiagram 驻波比数据Standingwaveratiodata Freq/MHz240024502500 VSWR1.491.061.31 天线暗室测试数据 Antennadarkroomtestdata Frequency (MHz) Gain(dBi)Efficiency(%) 2400.02.5644.41 2410.02.5745.27 2420.02.5446.55 2430.02.6147.42 2440.02.6347.98 2450.02.5648.21 2460.02.3849.73 2470.02.2247.88 2480.02.0946.63 2490.02.1445.26 2500.02.2045.46 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 8 页共 13 页 天线方向图 2400MHz 2450MHz 2500MHz 有源数据 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 9 页共 13 页 6、材料成分及有害物质表ListofMaterialCompositionandHazardous Substances 项次 Item 规格 Specific ation 材质 Texture of material RoHS检验结果（PPM） ROHSTestResults（PPM）ICP检测编号 ICPtestnumber 检测时间 Testtime CdPbHgCr+6PBBPBDE 1线wire FEPNDNDNDNDNDNDNGBPC260000158152026/1/19 镀锡铜线 Tinned wire NDNDNDNDNDNDA22504164681010012025/6/20 2 端子 Terminal PBTND2.99NDNDNDNDETR257035192025/7/27 磷青铜 Phosphor Bronze ND4NDNDNDNDCANEC250273630052025/11/13 3FPC PINDNDNDNDNDNDSHAEC250318409012025/12/8 背胶TapeNDNDNDNDNDNDSZXEC250030680382025/8/28 4 海绵 Sponge PU泡棉 PUSponge NDNDNDNDNDNDA22506684241010012025/9/18 背胶TapeNDNDNDNDNDNDCANEC250168042372025/7/22 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 10 页共 13 页 产品包装规范 PACKINGCRITERION 产品料号 P/N ：74220712 产品规格:内置天线-2.4G-黑色1.13锡锡线-1代端子-L=142mm-FPC-30.4×13mm Spec：Built-inAntenna-2.4G-Black1.13TinWire-1stGenerationTerminal-L=142mm-FPC-30.4 ×13mm 一、标签要求（根据客户名称参考对应的成品标签制作要求，无要求即按普通标签要求） contentsoflabel(accordingtothecustomer'sname,refertothecorrespondingfinishedproductlabelproduction requirements.Ifthereisnorequirement,itwillfollowtheordinarylabelrequirements.) 内外标签长10cm宽6cm左右 Theinnerandouterlabelsareabout10cmlongand6cmwid 需方 buyer ************* 供方 vender 四川博安通通信技术有限公司 SichuanB&TTechnologyCo.,Ltd. 物料编码 PurchaseNo ************* 生产单号 MaterialNo. ***************** 品名规格 Namespecification ******** 检验员 QC ** 数量/单位 Q’ty/Unit ***** 日期 Manufacturedate ****.**.* 追溯码 Tracecode ******** 流水号 Serialnumber ** 二、装箱要求 Packingrequirement 作业说明 Operatingdescription ： 1．内包装 innerpacking ： 产品50PCS/小袋 /smallbag 200PCS/大袋 bigbag 2．外包装 outerpacking ： 根据实际包装定数量 Quantityaccordingtoactualpacking/ 箱 carton 注意事项 Notice ： 1．是否要增设隔板、珍珠棉Whethertoaddpartitions,pearlcotton； 2．标签的贴附，如ROHS等Labeling,suchasROHS； 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 11 页共 13 页 8 、天线整机安装示意图 AntennainstallationpositionDiagram 9 、天线测试暗室摆放位置 Locationofantennatestdarkroom 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 12 页共 13 页 10 、可靠性测试要求 Reliabilitytestrequirements 序号 Serial Number 可靠性试验名称 ReliabilityTestName 试验条件 Experimentalconditions 判定标准 Judgmentcriteria 1 恒温恒湿试验 Constanttemperature andhumiditytest 高温:70°C，湿度:80%RH24H;低温 -40°C24H;共持续48H； Hightemperature:70°C,humidity:80% RHfor24hours;Lowtemperature-40°C for24hours;continuousfor48hoursin total; 试验前后外观要求：金属表面 镀层应无剥落，裂痕起皱，分 离等。非金属部分不应变色， 发生开裂，变形，脱胶等不良； 电气性能测试符合标准要求； Appearancerequirementsbefore andaftertheexperiment:The metalsurfacecoatingshouldbe freeofpeeling,cracks,wrinkles, separation,etc.Nonmetallic partsshouldnotdiscolor,crack, deform,orpeeloff;T…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.:GZCR260300062502 Page: 1 of 71 FCC ID: 2A348SPARKPEDAL TEST REPORT Application No.: GZCR2603000625AT Applicant: Positive LLC Address of Applicant: 2820 S Alma School Rd Suite 18 PMB 2011, Chandler, Arizona 85286, United States Manufacturer: Jia Ge Digital Technology Co. Ltd Address of Manufacturer: 11F, No. 176, Changchun Rd., Zhongshan Dist., Taipei City 104082, Taiwan Product Name: Wireless Foot Controller Model No.: Spark PEDAL Trade Mark: Positive Grid Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2026-04-03 Date of Test: 2026-04-20 to 2026-06-06 Date of Issue: 2026-06-12 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.:GZCR260300062502 Page: 2 of 71 Revision Record Version Report No. Date Remark 01 GZCR260300062502 2026-06-12 Original Authorized for issue by: Luke Lin/Project Engineer Approved By Vico Cui/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.:GZCR260300062502 Page: 3 of 71 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2020) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2020) Section 6.10.5 & 11.12 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2020) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2020) Section 6.6 & 11.12 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Maximum Conducted Output Power ANSI C63.10 (2020) Section 11.9.1 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2020) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectral Density ANSI C63.10 (2020) Section 11.10.3 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2020) Section 6.10.4 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2020) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. N/A means Not applicable, please find the detailed decision rule in the report relative section. Remark: For model Spark PEDAL with optional USB port isolator IC ISOUSB111 or AduM3160. And all RF modules selected for use are the same. So the EUT with optional IC AduM3160 was tested Conducted Emissions at AC Power Line (150kHz-30MHz) & Radiated Spurious Emissions Below 1GHz for verification, and the EUT with optional IC ISOUSB111 was full tested in this report. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.:GZCR260300062502 Page: 4 of 71 3 Contents Page 1 Cover Page ................................................................................................................................................. 1 2 Test Summary ............................................................................................................................................ 3 3 Contents ..................................................................................................................................................... 4 4 General Information ................................................................................................................................... 6 4.1 Details of E.U.T. .................................................................................................................................. 6 4.2 Description of Support Units ............................................................................................................... 6 4.3 Measurement Uncertainty ................................................................................................................... 7 4.4 Test Location ....................................................................................................................................... 7 4.5 Test Facility ......................................................................................................................................... 8 4.6 Deviation from Standards .................................................................................................................... 8 4.7 Abnormalities from Standard Conditions ............................................................................................ 8 5 Equipment List ........................................................................................................................................... 9 6 Radio Spectrum Technical Requirement .............................................................................................. 12 6.1 Antenna Requirement ....................................................................................................................... 12 6.1.1 Test Requirement: ........................................................................................................................ 12 6.1.2 Conclusion .................................................................................................................................... 12 7 Radio Spectrum Matter Test Results ..................................................................................................... 13 7.1 Conducted Emissions at AC Power Line (150kHz-30MHz) ....................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.:GZCR260300062504 Page: 1 of 104 FCC ID: 2A348SPARKPEDAL TEST REPORT Application No.: GZCR2603000625AT Applicant: Positive LLC Address of Applicant: 2820 S Alma School Rd Suite 18 PMB 2011, Chandler, Arizona 85286, United States Manufacturer: Jia Ge Digital Technology Co. Ltd Address of Manufacturer: 11F, No. 176, Changchun Rd., Zhongshan Dist., Taipei City 104082, Taiwan Product Name: Wireless Foot Controller Model No.: Spark PEDAL Trade Mark: Positive Grid Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2026-04-03 Date of Test: 2026-04-20 to 2026-06-06 Date of Issue: 2026-06-12 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.:GZCR260300062504 Page: 2 of 104 Revision Record Version Report No. Date Remark 01 GZCR260300062504 2026-06-12 Original Authorized for issue by: Luke Lin/Project Engineer Approved By Vico Cui/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.:GZCR260300062504 Page: 3 of 104 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2020) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2020) Section 6.10.5 & 11.12 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2020) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2020) Section 6.6 & 11.12 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Maximum Conducted Output Power ANSI C63.10 (2020) Section 11.9.2 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2020) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectral Density ANSI C63.10 (2020) Section 11.10.3 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2020) Section 6.10.4 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2020) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. N/A means Not applicable, please find the detailed decision rule in the report relative section. Remark: For model Spark PEDAL with optional USB port isolator IC ISOUSB111 or AduM3160. And all RF modules selected for use are the same. So the EUT with optional IC AduM3160 was tested Conducted Emissions at AC Power Line (150kHz-30MHz) & Radiated Spurious Emissions Below 1GHz for verification, and the EUT with optional IC ISOUSB111 was full tested in this report. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.:GZCR260300062504 Page: 4 of 104 3 Contents Page 1 Cover Page ................................................................................................................................................. 1 2 Test Summary ............................................................................................................................................ 3 3 Contents ..................................................................................................................................................... 4 4 General Information ................................................................................................................................... 6 4.1 Details of E.U.T. .................................................................................................................................. 6 4.2 Description of Support Units ............................................................................................................... 6 4.3 Measurement Uncertainty ................................................................................................................... 7 4.4 Test Location ....................................................................................................................................... 7 4.5 Test Facility ......................................................................................................................................... 8 4.6 Deviation from Standards .................................................................................................................... 8 4.7 Abnormalities from Standard Conditions ............................................................................................ 8 5 Equipment List ........................................................................................................................................... 9 6 Radio Spectrum Technical Requirement .............................................................................................. 12 6.1 Antenna Requirement ....................................................................................................................... 12 6.1.1 Test Requirement: ........................................................................................................................ 12 6.1.2 Conclusion .................................................................................................................................... 12 7 Radio Spectrum Matter Test Results ..................................................................................................... 13 7.1 Conducted Emissions at AC Power Line (150kHz-30MHz) ................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.:GZCR260300062504 Page: 83 of 104 802.11n(HT40)_LCH_2422MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_MCH_2437MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.:GZCR260300062504 Page: 84 of 104 802.11n(HT40)_HCH_2452MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.:GZCR260300062504 Page: 85 of 104 3. Maximum Conducted Output Power 3.1 Test Result 3.1.1 Power Mode TX Type Frequency (MHz) Maximum Peak Conducted Output Power (dBm) Verdict ANT1 Limit 802.11b SISO 2412 11.52 <=30 Pass 2437 8.08 <=30 Pass 2462 7.79 <=30 Pass 802.11n (HT20) SISO 2412 15.04 <=30 Pass 2437 11.59 <=30 Pass 2462 11.30 <=30 Pass 802.11n (HT40) SISO 2422 13.33 <=30 Pass 2437 11.24 <=30 Pass 2452 10.78 <=30 Pass SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.:GZCR260300062504 Page: 86 of 104 4. Maximum Power Spectral Density 4.1 Test Result 4.1.1 PSD Mode TX Type Frequency (MHz) Maximum PSD (dBm) Verdict ANT1 Limit(dBm/3kHz) 802.11b SISO 2412 0.21dBm/100kHz <=8 Pass 2437 -3.41dBm/100kHz <=8 Pass 2462 -3.65dBm/100kHz <=8 Pass 802.11n (HT20) SISO 2412 -3.21dBm/100kHz <=8 Pass 2437 -6.62dBm/100kHz <=8 Pass 2462 -6.91dBm/100kHz <=8 Pass 802.11n (HT40) SISO 2422 -8.05dBm/100kHz <=8 Pass 2437 -10.07dBm/100kHz <=8 Pass 2452 -10.45dBm/100kHz <=8 Pass 4.2 Test Graph 4.2.1 PSD 802.11b_LCH_2412MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.:GZCR260300062504 Page: 87 of 104 802.11b_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11b_HCH_2462MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.:GZCR260300062504 Page: 88 of 104 802.11n(HT20)_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_MCH_2437MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.:GZCR260300062504 Page: 89 of 104 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_LCH_2422MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.:GZCR260300062504 Page: 90 of 104 802.11n(HT40)_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_HCH_2452MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.:GZCR260300062504 Page: 91 of 104 5. Unwanted Emissions In Non-restricted Frequency Bands 5.1 Test Result 5.1.1 Ref Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) 802.11b SISO 2412 1 0.31 2437 1 -3.74 2462 1 -3.61 802.11n (HT20) SISO 2412 1 -3.21 2437 1 -6.61 2462 1 -7.06 802.11n (HT40) SISO 2422 1 -8.12 2437 1 -10.14 2452 1 -10.45 5.1.2 CSE and Band Edge Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) Limit (dBm) Verdict 802.11b SISO 2412 1 0.31 -19.69 Pass 2437 1 0.31 -19.69 Pass 2462 1 0.31 -19.69 Pass 802.11n (HT20) SISO 2412 1 -3.21 -23.21 Pass 2437 1 -3.21 -23.21 Pass 2462 1 -3.21 -23.21 Pass 802.11n (HT40) SISO 2422 1 -8.12 -28.12 Pass 2437 1 -8.12 -28.12 Pass 2452 1 -8.12 -28.12 Pass SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.:GZCR260300062504 Page: 92 of 104 5.2 Test Graph 5.2.1 Ref 802.11b_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11b_MCH_2437MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.:GZCR260300062504 Page: 93 of 104 802.11b_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_LCH_2412MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.:GZCR260300062504 Page: 94 of 104 802.11n(HT20)_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.1 Report No.:GZCR260300062504 Page: 95 of 104 802.11n(HT40)_LCH_2422MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_MCH_2437MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev…

Text truncated - open the document above for the full version.
