  3. 2A35D-DWM3001

2A35D-DWM3001UWB Transceiver module

Qorvo International Pte. Ltd.
UWB Transceiver module - FCC ID 2A35D-DWM3001 - Qorvo International Pte. Ltd.
Click to zoom

Application Details

Equipment Class
UWB - Ultra Wideband Transmitter
Date of Grant
Jun 04, 2022
Application Purpose
Original Equipment
Date of Application
Apr 28, 2022
Equipment Note
UWB Transceiver module
Frequency Range
7987.20000000 - 7987.20000000
Company
Qorvo International Pte. Ltd.
Country
Singapore

Documents & Files

Select a file to view

Users Manual

↗
↗

Cover Letter(s)

↗
↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

DWM3001C Fully Integrated UWB Transceiver Module DWM3001C Data Sheet Rev B.2, Apr 2022 Subject to change without notice | All rights reserved 1 of 22 www.qorvo.com ® Product Overview The Qorvo® DWM3001C is a fully integrated UWB transceiver module based on the Qorvo DW3110 IC. Integration of the DW3110 IC, nRF52833 MCU, planar UWB antenna, accelerometer, power management and crystal simplifies the design cycle. The RF design is fully validated, tested, and calibrated. Low power consumption allows powering from batteries for extended periods, providing cost-effective implementation of UWB solutions. The DWM3001C can be used in two-way ranging and TDoA applications. The DWM3001C is designed to be compliant to the FiRa™ PHY and MAC specifications enabling interoperability with other FiRa™ compliant devices. Functional Block Diagram 48 Pin 27 x 19.13 mm side castellated package Key Features • IEEE 802.15.4-2015 and IEEE 802.15.4z BPRF compliant • Fully aligned with FiRa™ PHY, MAC and certification development • Supports Channels 5 (6.5 GHz) and 9 (8 GHz) • FCC, SRRC and ETSI certification (planned) • Nordic nRF52833 SoC with BLE transceiver • Supply voltage VCC: 2.5 V - 3.6 V • Bluetooth chip antenna • AES 128/256 Security block • Fully coherent receiver for maximum range and accuracy • Power consumption optimized for battery applications • Data rates of 850 kbps, 6.8 Mbps • Maximum packet length of 1023 bytes for high data throughput applications • Integrated MAC support features • Backward compatible with the DWM3001C module • Temperature range -40°C to +85°C Applications • Precision real time location systems (RTLS) using two-way ranging or TDoA schemes in a variety of markets. • Location aware wireless sensor networks (WSNs) Ordering Information PART NUMBER DESCRIPTION DWM3001CSQ Module - 25 pcs bag DWM3001CTR13 Module – 500 pcs on a 13” reel DWM3001CDKE1.0 Engineering Design kit DCDC Converter BLE Antenna UWB Antenna RESET Nordic nRF52833 MCU / BLE TRx 64 MHz ARM Cortex M4 DW3110 UWB TRx BT_WAKE_UP READ Y UAR T[1:0] SPI[3:0] USB[1:0] I2C[1:0] GPIOSWD[1:0] GPIO SPI 12 4 1.6 V IMU VCC GND DWM3001C Fully Integrated UWB Transceiver Module DWM3001C Data Sheet Rev B.2, Apr 2022 Subject to change without notice | All rights reserved 2 of 22 www.qorvo.com ® Table of Contents 1. Overview ..............................................................3 1.1 DWM3001C UWB Transceiver .......................................... 3 1.2 Nordic nRF52833 Processor ............................................. 3 1.3 ST LIS12DH Accelerometer .............................................. 3 1.4 Torex XC9282 DCDC Converter ........................................ 3 2. DWM3001C Calibration .........................................4 2.1 Crystal Oscillator Trim ....................................................... 4 2.2 Transmitter Calibration ...................................................... 4 2.3 Antenna Delay Calibration ................................................. 4 3. DWM3001C Pin Connections ................................5 3.1 Pin Numbering .................................................................. 5 3.2 Pin Descriptions ................................................................ 6 4. Electrical Specifications .......................................8 4.1 Nominal Operating Conditions ........................................... 8 4.2 DC Characteristics ............................................................ 8 4.3 Receiver AC Characteristics.............................................. 9 4.4 Reference Clock AC Characteristics .................................. 9 4.4.1 Reference Frequency ................................................. 9 4.5 Transmitter AC Characteristics .......................................... 9 4.6 Absolute Maximum Ratings ..............................................10 5. OTP Memory Map ............................................... 11 6. Package Information .......................................... 13 6.1 Module Drawings .............................................................13 6.2 Module Land Pattern ........................................................14 7. Regulatory Information....................................... 15 7.1 European Union requirements ..........................................15 7.1.1 Radio Equipment Directive ....................................... 15 7.1.2 ETSI harmonised standards ..................................... 16 7.2 United States (FCC).........................................................17 7.2.1 Radio and Television Interference ............................ 17 7.3 Innovation, Science and Economic Development Canada (ISED) .............................................................................18 7.4 Regulatory Module Integration Instructions .......................18 7.5 Device Classifications ......................................................19 7.6 FCC Definitions ...............................................................19 7.7 Simultaneous Transmission Evaluation ............................19 7.8 Operating Requirements and Conditions ..........................19 7.9 Miscellaneous ..................................................................19 8. Glossary ............................................................. 20 9. Revision History ................................................. 21 10. Further Information ............................................ 21 List of Figures Figure 1: DWM3001C Pin Diagram ................................5 Figure 2: Module Package Size (mm) ......................... 13 Figure 3: Module Land Pattern (mm) .......................... 14 List of Tables Table 1: DWM3001C Calibrated Items ..................................... 4 Table 2: DWM3001C Pin Functions ......................................... 6 Table 3: Explanation of Abbreviations ...................................... 7 Table 4: DWM3001C Operating Conditions ............................. 8 Table 5: …

Text truncated - open the document above for the full version.

Users Manual

DWM3001C Fully Integrated UWB Transceiver Module DWM3001C Data Sheet Rev B, May 2022 Subject to change without notice | All rights reserved 1 of 27 www.qorvo.com ® Product Overview The Qorvo® DWM3001C is a fully integrated UWB transceiver module based on the Qorvo DW3110 IC. Integration of the DW3110 IC, nRF52833 MCU, planar UWB antenna, accelerometer, power management and crystal simplify the design cycle. The RF design is fully validated, tested, and calibrated. Low power consumption allows powering from batteries for extended periods, providing cost-effective implementation of UWB solutions. The DWM3001C can be used in two-way ranging and TDoA applications. The DWM3001C is designed to be compliant to the FiRa™ PHY and MAC specifications enabling interoperability with other FiRa™ compliant devices. Functional Block Diagram 48 Pin 27.1 x 19.13 mm side castellated package Key Features • IEEE 802.15.4-2015 and IEEE 802.15.4z BPRF compliant • Fully aligned with FiRa™ PHY, MAC and certification development • Supports Channels 5 (6.5 GHz) and 9 (8 GHz) • FCC, SRRC and ETSI certification (planned) • Nordic nRF52833 SoC with BLE transceiver • Supply voltage VCC: 2.5 V - 3.6 V • Bluetooth chip antenna • AES 128/256 Security block • Fully coherent receiver for maximum range and accuracy • Power consumption optimized for battery applications • Data rates of 850 kbps, 6.8 Mbps • Maximum packet length of 1023 bytes for high data throughput applications • Integrated MAC support features • Backward compatible with the DWM1001C module • Temperature range -40°C to +85°C Applications • Precision real time location systems (RTLS) using two-way ranging or TDoA schemes in a variety of markets. • Location aware wireless sensor networks (WSNs) Ordering Information PART NUMBER DESCRIPTION DWM3001CSR Module – 100 pcs reel DWM3001CTR13 Module – 500 pcs on 13” reel DWM3001CDKE1.0 Engineering Development kit DCDC Converter BLE Antenna UWB Antenna RESET Nordic nRF52833 MCU / BLE TRx 64 MHz ARM Cortex M4 DW3110 UWB TRx BT_WAKE_UP READ Y UAR T[1:0] SPI[3:0] USB[1:0] I2C[1:0] GPIOSWD[1:0] GPIO SPI 12 4 1.6 V IMU VCC GND DWM3001C Fully Integrated UWB Transceiver Module DWM3001C Data Sheet Rev B, May 2022 Subject to change without notice | All rights reserved 2 of 27 www.qorvo.com ® Table of Contents 1. Overview ..............................................................3 1.1 DWM3001C UWB Transceiver .......................................... 3 1.2 Nordic nRF52833 Processor ............................................. 3 1.3 ST LIS12DH Accelerometer .............................................. 3 1.4 Torex XC9282 DCDC Converter ........................................ 3 2. DWM3001C Calibration .........................................4 2.1 Crystal Oscillator Trim ....................................................... 4 2.2 Transmitter Calibration ...................................................... 4 2.3 Antenna Delay Calibration ................................................. 4 3. DWM3001C Pin Connections ................................5 3.1 Pin Numbering .................................................................. 5 3.2 Pin Descriptions ................................................................ 6 4. Electrical Specifications .......................................8 4.1 Nominal Operating Conditions ........................................... 8 4.2 DC Characteristics ............................................................ 8 4.3 Receiver AC Characteristics.............................................. 9 4.4 Reference Clock AC Characteristics .................................. 9 4.4.1 Reference Frequency ................................................. 9 4.5 Transmitter AC Characteristics .......................................... 9 4.6 Absolute Maximum Ratings ..............................................10 5. OTP Memory Map ............................................... 11 6. Antenna Performance ......................................... 13 7. Application Information ...................................... 16 7.1 Application Board Layout Guidelines ................................16 7.2 Note on Ranging Performance in Harsh Multipath Environments ..................................................................16 8. Package Information .......................................... 17 8.1 Module Drawings .............................................................17 8.2 Module Land Pattern ........................................................17 8.3 Module Marking Information .............................................18 8.4 Module Solder Profile .......................................................18 9. Tape and Reel Information ................................. 19 10. Regulatory Information....................................... 20 10.1 European Union requirements ..........................................20 10.1.1 Radio Equipment Directive ....................................... 20 10.1.2 ETSI harmonised standards ..................................... 21 10.2 United States (FCC).........................................................22 10.2.1 Radio and Television Interference ............................ 22 10.3 Innovation, Science and Economic Development Canada (ISED) .............................................................................23 10.4 Regulatory Host Integration Instructions ...........................23 10.5 Device Classifications ......................................................24 10.6 FCC Definitions ...............................................................24 10.7 Simultaneous Transmission Evaluation ............................24 10.8 Operating Requirements and Conditions ..........................24 10.9 Miscellaneous ..................................................................24 11. Glossary ............................................................. 25 12. Revision History ................................................. 26 13. Further Inf…

Text truncated - open the document above for the full version.

Cover Letter(s)

Qorvo International Pte. Ltd. Authority letter FCC Date: 20-Jan-2022 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2A35D-DWM3001 To whom it may concern: We, the undersigned, hereby authorize SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Guangzhou branch and Kobe Jian in SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Guangzhou branch to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with applicant company FCC. This authorization is valid until further written notice from the applicant. Name (Printed): Jason Keane Givens Title: General Counsel Signature: On behalf of Company: Qorvo International Pte. Ltd. Tel: +001-336-678-7119 E-mail: [email protected]

Cover Letter(s)

Qorvo International Pte. Ltd. TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: Confidentiality Request regarding application for FCC ID: 2A35D-DWM3001 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY(Remark:The following information needs short-term confidentiality. Please select 0, 45, 90 or 180 days. During the short-term confidentiality period, the products cannot be sold in the U.S. market.) Additionally, the applicant requests the following documents be held confidential until the device is marketed or 0 days from the grant date, whichever is less. If the device is marketed within 0 days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. External Photos Internal Photos Test Setup Photos Datasheet/user manual(s) Sincerely, Name (Printed): Jason Keane Givens Title: General Counsel Signature: On behalf of Company: Qorvo International Pte. Ltd. Tel: +001-336-678-7119 E-mail: [email protected]

Cover Letter(s)

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Qorvo International Pte. Ltd. Address 1 Changi Business Park Avenue 1, # 04-01,Singapore,486058 Grantee Code 2A35D FCC ID 2A35D-DWM3001 Authorized Contact Name Jason Keane Givens Contact Email [email protected] Contact Phone +001-336-678-7119 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date: Print Name: Jason Keane Givens Title: General Counsel *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

Cover Letter(s)

Qorvo International Pte. Ltd. Cover Letter-Modular Approval FCC ID: 2A35D-DWM3001 Date: 20-Jan-2022 To whom it may concern: The specific product as below, multipurpose UWB module with its designed features and specified description, meets special requirements for Full modular approval on FCC KDB996369 as per the table below. Company Qorvo International Pte. Ltd. Model Name multipurpose UWB module Model Number DWM3001C FCC ID 2A35D-DWM3001 Requirement of FCC KDB996369 Comply(Y/N) 1. The modular transmitter must have its own RF shielding. Y The EUT provides the RF shielding. See EUT photo which shows the metal shield soldered onto the module. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. Y The EUT has its buffered modulation. Please see the Schematic Diagram. 3. The modular transmitter must have its own power supply regulation. Y The EUT has its own power supply regulation, please see the Schematic Diagram. 4. The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Y The EUT meets the FCC antenna requirements. It has two on-chip antennas- the BLE antenna is soldered onto the module and the UWB antenna is a PCB antenna, as shown in the test report. 5. The modular transmitter must be tested in a stand‐alone configuration, i.e., the module must not be inside another device during testing. Y The EUT was tested with a test board, please see test report and setup photo Qorvo International Pte. Ltd. 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: 2A35D-DWM3001” or “Contains FCC ID: 2A35D-DWM3001” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. Y Please see exhibition label sample for the FCC ID of this module, which is om a label on the RF shield. Also, in the exhibition Datasheet, there are instructions given to the OEM on how to label the end product. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequat e instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Y The EUT is compliant with all applicable FCC rules. Details instructions for maintaining compliance are give in the User Manual. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter w ave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Y The EUT complies with RF exposure requirement. Qorvo International Pte. Ltd. Thank you. Sincerely, Name (Printed): Jason Keane Givens Title: General Counsel Signature: On behalf of Company: Qorvo International Pte. Ltd. Tel: +001-336-678-7119 E-mail: [email protected]

External Photos

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.0 Page: 1 of 2 Appendix External Photos for GZCR2111021379AT SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 2 of 2 EUT Constructional Details (EUT Photos)

ID Label/Location Info

1 Doc #: DWM3001C-220 Rev 3 Template: FOR-001227 Rev C •On PCB: •“Qorvo” logo and PCL298338” •On Label (15mm x 15mm on metal shield can): •“DWM3001C” (Note: “Model” is not required but will be accepted.) •“FCC ID: 2A35D-DWM3001” •“IC ID: 23794-DWM3001” •“CE” Marking •Serial number # (or SN:) YYWW4SSSSS •“YY” is year, “WW” is calendar week per ISO-8601, “4” is DWM3001C, SSSSS is serial number, starting from 00001,00002,.... •2D Barcode: Serial number as per text •Exterior label wording: FCC ID: 2A35D-DWM3001 IC: 23794-DWM3001 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Module Marking –Mass Production 15.0 mm DWM3001C FCC ID: 2A35D-DWM3001 IC: 23794-DWM3001 SN: YYWW4SSSSS 15.0 mm ©2021QorvoUS,Inc. QorvoConfidential&ProprietaryInformation

Internal Photos

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.0 Page: 1 of 2 Appendix Internal Photos for GZCR2111021379AT SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 2 of 2 EUT Constructional Details (EUT Photos) UWB antenna BLE antenna

RF Exposure Info

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.0 Report No.: GZCR211102137903 Page: 1 of 8 FCC ID: 2A35D-DWM3001 Kobe Jian EMC Laboratory Manager 1 Cover page RF Exposure Evaluation Report Application No.: GZCR2111021379AT Applicant: Qorvo International Pte. Ltd. Address of Applicant: 1 Changi Business Park Avenue 1, # 04-01, Singapore Manufacturer: Qorvo International Pte. Ltd. Address of Manufacturer: 1 Changi Business Park Avenue 1, # 04-01, Singapore Factory: Victory Concept Address of Factory: Building A, No 18 Shuiyuan Industrial District, Ruhu Town, Huizhou City, 516021, Guangdong Equipment Under Test (EUT): EUT Name: UWB Transceiver module Model No.: DWM3001C Trade Mark: Qorvo Standards: 47 CFR PART 1.1307 47 CFR PART 1.1310 47 CFR PART 2.1093 447498 D04 Interim General RF Exposure Guidance v01 Date of Receipt: 2021-11-15 Date of Test: 2021-11-15 to 2021-11-19 Date of Issue: 2021-12-02 Test Result : PASS* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.0 Report No.: GZCR211102137903 Page: 2 of 8 2 Version Revision Record Version Chapter Date Modifier Remark 01 2021-12-02 Original Authorized for issue by: Curry Wu/Project Engineer Ricky Liu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.0 Report No.: GZCR211102137903 Page: 3 of 8 3 Contents Page 1 COVER PAGE .............................................................................................................................................. 1 2 VERSION ...................................................................................................................................................... 2 3 CONTENTS .................................................................................................................................................. 3 4 GENERAL INFORMATION .......................................................................................................................... 4 4.1 GENERAL DESCRIPTION OF EUT ................................................................................................................. 4 4.2 TEST LOCATION .......................................................................................................................................... 5 4.3 TEST FACILITY ............................................................................................................................................ 5 4.4 DEVIATION FROM STANDARDS ..................................................................................................................... 6 4.5 ABNORMALITIES FROM STANDARD CONDITIONS ............................................................................................ 6 4.6 OTHER INFORMATION REQUESTED BY THE CUSTOMER ................................................................................. 6 5 RF EXPOSURE EVALUATION .................................................................................................................... 7 5.1 RF EXPOSURE COMPLIANCE REQUIREMENT ................................................................................................ 7 5.1.1 Limits ................................................................................................................................................ 7 5.1.2 Test Procedure ................................................................................................................................ 7 4.1.3 EUT RF EXPOSURE EVALUATION ............................................................................................................... 8 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.0 Report No.: GZCR211102137903 Page: 4 of 8 4 General Information 4.1 General Description of EUT Power supply: For RF Module: DC3.3V from debug board For Debug Board: DC5V from PC USB port Firmware Version: 0.6.5+211103 Hardware Version: DWM3001_D1 SN: 2123400141(Conducted), 2123400073(Radiated) For BLE: Operation Frequency: 2402MHz to 2480MHz Bluetooth Version: V5.0 LE Data Rate: 1Mbps, 2Mbps Modulation Type: GFSK Number of Channels: 40 Channel Spacing: 2MHz Antenna Type: Chip Antenna Antenna Gain: 0.5dBi Testing Software: J-Flash Lite V7.58 Power Setting: 0dBm as default, can't be changed by end user. For UWB Operating Frequency: 6489.6MHz;7987.2MHz Modulation Type: PM Number of Channels: 2 Sample Type: Hand Held Use Antenna Type: PCB Antenna Antenna Gain: 0.3dBi for 6489.6MHz, 0.8dBi for 7987.2MHz Testing Software: J-Flash Lite V7.58 Power Setting: -41.3dBm(EIRP) as default, can't be changed by end user. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.0 Report No.: GZCR211102137903 Page: 5 of 8 4.2 Test Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd., Guangzhou Branch EMC Laboratory, 198 Kezhu Road, Scientech Park, Guangzhou Economic & Technology Development District, Guangzhou, China 510663 Tel: +86 20 82155555 Fax: +86 20 82075059 4.3 Test Facility The test facility is recognized, certified, or accredited by the following organizations: ● NVLAP (Lab Code: 200611-0) SGS-CSTC Standards Technical Services Co., Ltd., Guangzhou EMC Laboratory is accredited by the National Voluntary Laboratory Accreditation Program (NVLAP/NIST). NVLAP Code: 200611-0. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. ● ACMA SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory can also perform testing for the Australian/New Zealand Regulatory Compliance Mark (RCM). ● SGS UK(Certificate No.: 32), SGS-TUV SAARLAND and SGS-FIMKO Have approved SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory as a supplier o…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Jason Keane Givens(General Counsel)
[email protected]001-336-678-7119Fax: N/A

Technical Contact

SGS-CSTC Standards Technical Services Co., Ltd.Kobe Jian
[email protected]+862082155314

No.198 Kezhu Road, Science City · Guangzhou, Guangdong · China

Test Firm

SGS-CSTC Standards Technical Services Co., Ltd.Bonnie Liao
[email protected]020-8215-5379

Technical Specifications

#Rule PartsFrequency RangePower Output
215F7.99 GHz - 7.99 GHz-
Modular Type
Single Modular Approval
Confidentiality
Long Term
Grant Notes
Antennas mounted on outdoor structures such, as antennas mounted on the outside of a building or on a telephone pole, or any fixed outdoors infrastructure are prohibited for use with this device.
