2A3CX-MT0716XLMimiq Track XL

Mimiq Track XL Datasheet v1.2 MT - 0716 - XL Tracker Device Installation Guide Product Overview Welcome to the installation guide for Mimiq Track XL. This guide will walk you through the installation process step by step to ensure a successful setup of the device. Before You Begin Before installing the tracker device, please ensure you have the following: ●A wet wipe to clean the surface where the device will be installed. ●The primer which is provided with Mimiq Track XL that enhances sticking power. ●A mobile phone assists in matching the device ID with the container number or plate number on the dashboard or API. (No mobile application is required) Installation Steps Step 1: Pre-Installation Preparation ●Clean the area where the device will be adhered using a wet wipe to remove any dirt. ●After removing the cap of the primer, apply it to the surface to be adhered. Ensure that it spreads evenly. ●Peel off the protective cover of the double-sided tape on the back of the device. Step 2: Mounting the Tracker Device ●Press the device firmly towards the surface where the primer is applied in the direction where the arrows on the device are pointing to the sky. (container applications) Step 3: Provisioning ●Scan the QR code on the device with your phone's camera and log in to the Mimiq Dashboard page. ●The information of the device scanned via QR code will automatically appear on the screen. On this page, enter the license plate number or container number to pair it with the device. ●You are all set! Featured Highlights LoRa Chipset : Semtech LR1110 Core : ARM 32-bit MCU Flash memory / RAM size (bytes) : 1 M / 256 K LoRa® Frequency band support* : US915, AU915, EU868 Network Connectivity : LoRaWAN® Network Server Providers Device Connectivity : Bluetooth 5.2 Specifications Hardware and Mechanical Design The outer dimensions of Mimiq Track XL are: 4.2 x 2.55 x 1.6 in (115mm x 65mm x 40 mm) Property Specification Material ABS Sticker and Film High temp resistant PP Color Matte Grey Operating Temperature-20 C - 60 C Property Specification Embedded Sensors3-axis accelerometer Battery TypeLi-SOCl2 Operating Voltage1.8V to 3V Electronic Design FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: The grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. Such modifications could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help. This equipment complies with the FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and all persons. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. © Copyright 2024 Mimiq, Inc. All rights reserved. Mimiq and its respective logos are registered trademarks of Mimiq, Inc. 555 Bryant St, #819 Palo Alto, CA 94301 USA Contact https://mimiq.io/contact-us/

Mimiq, Inc. 555 Bryant St. #819 Palo Alto, CA 94301 Date: 05/08/24 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2A3CX-MT0716XL Attestation Statements Part 2.911(d)(5)(i) Filing To whom it may concern, Mimiq, Inc.,certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to the section 2.903 of the FCC rules. Sincerely, Signature: Serdar Serttop Chief Technology Office

Mimiq, Inc. 555 Bryant St. #819 Palo Alto, CA 94301 Date: 05/08/24 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2A3CX-MT0716XL Attestation Statements Part 2.911(d)(5)(ii) Filing To whom it may concern, Mimiq, Inc. certifies that, as of the date of the filing of the application, Mimiq, Inc. is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Signature: Serdar Serttop Chief Technology Office

Mimiq, Inc. 555 Bryant St. #819 Palo Alto, CA 94301 Date: 05/08/24 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2A3CX-MT0716XL FRN: 0031477565 US Agent – Attestation Statement / Part 2.911(d)(7) To whom it may concern, 911Cellularcertifies that, as of the date of the filing of the application, we designate ourselves as the U.S. agent for service of process. Designated U.S. Agent Information: Name: Mimiq, Inc. FRN: 0031477565 Address: 555 Bryant St. #819, Palo Alto, CA 94301, United States Contact Person: Serdar Serttop Tel.:(408) 412-9651 Email: [email protected] Sincerely, Signature: Serdar Serttop Chief Technology Office

Mimiq, Inc. 555 Bryant St. #819 Palo Alto, CA 94301 Date: 05/08/24 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2A3CX-MT0716XL Confidentiality Request To whom it may concern, Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of the information accompanying this application as outlined below: ☒Block Diagram ☐Tune-Up Information ☒Operational Description ☐Security Information ☒Schematics ☐Software Defined Radio (SDR) Information ☒Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature: Serdar Serttop Chief Technology Office

Mimiq, Inc. 555 Bryant St. #819 Palo Alto, CA 94301 Date: 05/08/24 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2A3CX-MT0716XL Declaration of Authorization To whom it may concern, I, the undersigned, hereby authorize, Jandy So, of Waltek Testing Group (Shenzhen) Co., Ltd., (WALTEK) to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Jandy So, of Waltek Testing Group (Shenzhen) Co., Ltd., (WALTEK) on our behalf shall have the same effects as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C 853(a). This authorization is valid until further written notice from the applicant. Sincerely, Signature: Serdar Serttop Chief Technology Office

Reference No.: WTX24X01022692W Page 2 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Reference No.: WTX24X01022692W Page 3 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTX24X01022692W Page 4 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6

Reference No.: WTX24X01022692W Page 1 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn ANNEX EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format Proposed Label Location on EUT FCC ID Label Location

Reference No.: WTX24X01022692W Page 5 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 Solder Board-Component View 1 Reference No.: WTX24X01022692W Page 6 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 2 Antenna View 900MHz Antenna BLE Antenna

1. RF Exposure Requirements 1.1 General Information Client Information Applicant: Mimiq, Inc. Address of applicant: 555 Bryant St. #819, Palo Alto, CA 94301 Manufacturer: The same as Applicant Address of manufacturer: The same as Applicant General Description of EUT: Product Name: Mimiq Track XL Trade Name / Model No.: MT-0716-XL Adding Model(s): / Rated Voltage: Battery:DC3.6V Power Adapter: / FCC ID: 2A3CX-MT0716XL Equipment Type: Mobile device Technical Characteristics of EUT: Bluetooth Bluetooth Version: V5.2 (BLE mode) Frequency Range: 2402-2480MHz RF Output Power: 1Mbps: 3.97dBm (Conducted) 2Mbps: 3.98dBm (Conducted) Data Rate: 1Mbps, 2Mbps Modulation: GFSK Quantity of Channels: 40 Channel Separation: 2MHz Type of Antenna: PCB antenna Antenna Gain: 2.11dBi LoRa Non-hopping Frequency Range: 903MHz-914.2MHz RF Output Power: 24.98dBm (Conducted) Modulation: Lora Quantity of Channels: 8 Channel Separation: 600kHz Type of Antenna: PCB antenna Antenna Gain: 1.14dBi LoRa Hopping Frequency Range: 902.3-914.9MHz RF Output Power: 21.38dBm (Conducted) Modulation: Lora Quantity of Channels: 64 Channel Separation: 200kHz Type of Antenna: PCB antenna Antenna Gain: 1.14dBi 1.2 RF Exposure Exemption According to §1.1307(b)(3) and KDB 447498 D04 Interim General RF Exposure Guidance v01, system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. Option A: FCC Rule Part 1.1307 (b)(3)(i)(A):The available maximum time-averaged power is no more than 1mW, regardless of separation distance. Option B: FCC Rule Part 1.1307 (b)(3)(i)(B): The available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold P th (mW) described in the following formula. P th is given by: Option C: FCC Rule Part 1.1307 (b)(3)(i)(C): The minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. R must be at least λ/2π, where λ is the free-space operating wavelength in meters. Single RF Sources Subject to Routine Environmental Evaluation RF Source frequency (MHz) Threshold ERP (watts) 0.3-1.34 1,920 R 2 1.34-30 3,450 R 2 /f 2 30-300 3.83 R 2 300-1,500 0.0128 R 2 f 1,500-100,000 19.2R 2 For Multiple RF sources: FCC Rule Part 1.1307(b)(3)(ii): (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). (B) In the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation. 1.3 Calculated Result Radio Access Technology Prediction Frequency Output Power Antenna Gain Duty Cycle Tune-Up Time-Averaged Power ERP (MHz) (dBm) (dBi) (%) (dBm) (dBm) Bluetooth 2402 3.98 2.11 100 4.00 3.96 LoRa Non-hopping 903 24.98 1.14 100 25.00 23.99 LoRa Hopping 902.3 21.38 1.14 100 22.00 20.99 Frequency Option Min. Distance Max. Power Exposure Limit Ratio Result (MHz) (cm) (dBm) (mW) (mW) Pass/Fail 2402 C 20.00 3.96 2.49 768.00 0.01 Pass 903 C 20.00 23.99 250.61 462.34 0.54 Pass 902.3 C 20.00 20.99 125.60 461.98 0.27 Pass Note: 1. Time-Averaged Power=Output Power * Duty Cycle; ERP= Time-Averaged Power+ Antenna gain-2.15dB 2. Option A, B and C refers as clause 1.2. 3. For option B, Max (time-averaged power, effective radiated power (ERP)) converts to Max. Power. For option C, ERP converts to Max. Power; 4. For option B, P th (mW) converts to Exposure Limit (mW); For option C, ERP (W) converts to Exposure Limit (mW). 5. Ratio= Tune-Up ERP (mW)/ Exposure Limit (mW) Mode for Simultaneous Multi-band Transmission: Radio Access Technology Ratio 1 Ratio 2 Simultaneous Ratio Limit Result Pass/Fail / / / / / / Note: Mimiq Track XL FW does not support simultaneous LoRa and BLE TX. Result: Pass

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 11 TEST REPORT Reference No. .................... : WTX24X01022709W Applicant ........................... : Mimiq, Inc. Address.............................. : 555 Bryant St. #819, Palo Alto, CA 94301 Manufacturer ..................... : Mimiq, Inc. Address.............................. : 555 Bryant St. #819, Palo Alto, CA 94301 Product Name ................... : Mimiq Track XL LoRa Antenna Model No... ......................... : MT-0716-XL LoRa Antenna Standards .......................... : ANSI/ IEEE 149-2021 Date of Receipt sample .... : 2024-01-31 Date of Test........................ : 2024-01-31 to 2024-02-02 Date of Issue ..................... : 2024-02-18 Test Report Form No. ....... : WTX_IEEE 149 Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Email: [email protected] Tested by: Approved by: Mike Shi Silin Chen Reference No.: WTX24X01022709W Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 2 of 11 TABLE OF CONTENTS 1.GENERAL INFORMATION ....................................................................................................................................4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ...............................................................................4 2. SUMMARY OF TEST RESULTS ...........................................................................................................................5 3. ANTENNA TEST CONFIGURATIONS ................................................................................................................6 3.1 TEST LOCATION .....................................................................................................................................................6 3.1 TEST ENVIRONMENTS.............................................................................................................................................6 3.2 TEST EQUIPMENT LIST ...........................................................................................................................................6 3.3 MEASUREMENT UNCERTAINTY ..............................................................................................................................6 3.4 TEST SETUP ............................................................................................................................................................6 4. ANTENNA TEST RESULT .....................................................................................................................................7 4.1 GAIN AND EFFICIENCY ...........................................................................................................................................7 4.2 RADIATION PATTERN 2D VIEW ...............................................................................................................................8 4.3 RADIATION PATTERN 3D VIEW ...............................................................................................................................9 EXHIBIT 1 - EUT PHOTOGRAPHS ........................................................................................................................ 10 EXHIBIT 2 - TEST SETUP PHOTOGRAPHS ........................................................................................................ 11 Reference No.: WTX24X01022709W Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 3 of 11 Report version Version No. Date of issue Description Rev.00 2024-02-18 Original / / / Reference No.: WTX24X01022709W Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 4 of 11 1.GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) General Description of EUT Product Name: Mimiq Track XL LoRa Antenna Trade Name: / Model No.: MT-0716-XL LoRa Antenna Adding Model(s): / Note: The test data is gathered from a production sample, provided by the manufacturer. Technical Characteristics of EUT Frequency Range: 900-930MHz Gain of Antenna: 1.36dBi (Max.) Type of Antenna: PCB Antenna Size: 51.5*8.5mm Dimension: Reference No.: WTX24X01022709W Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 5 of 11 2. SUMMARY OF TEST RESULTS Standards Description of Test Item Result ANSI/ IEEE 149-2021 IEEE Recommended Practice for Antenna Measurements Compliant N/A: not applicable Reference No.: WTX24X01022709W Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 6 of 11 3. Antenna Test Configurations 3.1 Test Location Name: Shenzhen Morlab Communications Technology Co.,Ltd. Address: FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen, GuangDong Province, P.R. China 3.1 Test Environments Environments Parameter Temperature Voltage Humidit NTNV 25 C -- 50% 3.2 Test Equipment List Description Manufacturer Model Serial Number Cal. Date Due. Date Network Analyzer Agilent E5071C MY46110140 2023-06-21 2024-06-20 OTA Chamber ETS AMS-8923-150 TJ2235-Q1793 2022-11-30 2025-11-29 Antenna Measurement System ETS EMQuest EMQ-100 V1.13 Build 21267 1685 N/A N/A 3.3 Measurement Uncertainty The uncertainty is calculated using the methods suggested in the“Guide to the Expression of Uncertainty in Measurement" (GUM) published by ISO. When the test result is a critical value,we will use the measurement uncertainty give the judgment result based on the 95%Confidence int…

Text truncated - open the document above for the full version.

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 53 TEST REPORT Reference No. .................... : WTX24X01022692W003 FCC ID ................................ : 2A3CX-MT0716XL Applicant ........................... : Mimiq, Inc. Address.............................. : 555 Bryant St. #819, Palo Alto, CA 94301 Manufacturer ..................... : The same as Applicant Address.............................. : The same as Applicant Product Name ................... : Mimiq Track XL Model No... ......................... : MT-0716-XL Standards .......................... : FCC Part 15.247 Date of Receipt sample .... : 2024-01-29 Date of Test........................ : 2024-01-29 to 2024-02-23; 2024-02-29 to 2024-03-31 Date of Issue ..................... : 2024-03-31 Test Report Form No. ....... : WTX_Part 15_247W Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Email: [email protected] Tested by: Approved by: Mike Shi Jason Su Reference No.: WTX24X01022692W003 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 2 of 53 TABLE OF CONTENTS 1. GENERAL INFORMATION ....................................................................................................................................5 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) .........................................................................5 1.2 TEST STANDARDS .................................................................................................................................................6 1.3 TEST METHODOLOGY ...........................................................................................................................................6 1.4 TEST FACILITY ......................................................................................................................................................6 1.5 EUT SETUP AND TEST MODE ..............................................................................................................................7 1.6 MEASUREMENT UNCERTAINTY .............................................................................................................................8 1.7 TEST EQUIPMENT LIST AND DETAILS ...................................................................................................................9 2. SUMMARY OF TEST RESULTS ......................................................................................................................... 14 3. ANTENNA REQUIREMENT ................................................................................................................................. 15 3.1 STANDARD APPLICABLE ..................................................................................................................................... 15 3.2 EVALUATION INFORMATION ................................................................................................................................ 15 4. FREQUENCY HOPPING SYSTEM REQUIREMENTS .................................................................................... 16 5. QUANTITY OF HOPPING CHANNELS AND CHANNEL SEPARATION .................................................... 18 5.1 STANDARD APPLICABLE ..................................................................................................................................... 18 5.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................................... 18 5.3 TEST PROCEDURE .............................................................................................................................................. 18 5.4 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 19 6. DWELL TIME OF HOPPING CHANNEL ........................................................................................................... 20 6.1 STANDARD APPLICABLE ..................................................................................................................................... 20 6.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................................... 20 6.3 TEST PROCEDURE .............................................................................................................................................. 20 6.4 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 21 7. 20DB BANDWIDTH ............................................................................................................................................... 22 7.1 STANDARD APPLICABLE ..................................................................................................................................... 22 7.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................................... 22 7.3 TEST PROCEDURE .............................................................................................................................................. 22 7.4 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 23 8. RF OUTPUT POWER ...............................................…

Text truncated - open the document above for the full version.

Reference No.: WTX24X01022692W Page 7 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 4 - TEST SETUP PHOTOGRAPHS Radiation Emission Test Setup (Below 30MHz) Radiation Emission Test Setup (30MHz to 1GHz) Reference No.: WTX24X01022692W Page 8 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Radiation Emission Test Setup (1GHz to 18GHz) Radiation Emission Test Setup (Above 18GHz) Reference No.: WTX24X01022692W Page 9 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn ***** END OF REPORT *****
