Seguro 150 Temperature Data Logger Quick Start Guide For more detailed information on using the app, go to: sensified.io/150qs Getting the App The Seguro app is available free of charge in the Google Play Store and the Apple App Store. Scan the barcode with your phone to start: This device complies with Part 15 of the FCC Rules (FCC ID: 2A3LI-PM06). The full FCC compliance statement can be found under “Regulatory” in the Seguro app. Setting Up an Account 1. Tap the “Cloud Account” button on the home screen, which will display a browser window with the Seguro authentication site. 2. Tap the “Sign up” link (under the Continue button). 3. On the signup page, you can choose between using your Google or Apple ID to log in, or creating a sensified.io account with a new email and password. If you choose to use a third-party identity provider (Apple or Google), only your basic profile information (name, email, language preference and picture) are used. Note: A cloud account is not needed to use the Seguro 150 temperature data logger. Connecting to the Device For Android Devices: Once the Seguro app is installed, simply touch the Seguro device to the back of the phone (usually near the top of the phone) and the app will open automatically, then the device screen will open. For Apple (iOS) Devices: Open the Seguro app, and tap the Connect to Device button on the home screen. A “Ready to Scan” window will appear at the bottom of the screen. Hold the Seguro device next to the back of the phone until the phone beeps and/or vibrates. The exact location of the NFC reader in the phone may vary somewhat, but it is usually near the top of the phone. Once the app recognizes the device, the Device screen will open. 5 6 7 8 Starting a Recording Once you have connected to a Seguro device, you can start a recording by tapping the Start Recording button. The Start Recording screen is displayed, and you can adjust the high and low thresholds, start delay, and sampling interval before starting the recording. Cloud account users can also add a photo of the item being monitored, and Premium users can add shipment tracking information. When all of the options have been selected, tap the Start button to start the recording. Ending a Recording Stopping a recording that is already in progress is straightforward. After connecting to the device, the current recording will be displayed on the device screen. Tap the Stop Recording button, and the Stop Recording screen will appear. Users who have a cloud account will have the option to add a photo to the recording, and premium cloud account holders will have the option to add tracking information, if it isn’t already attached. Tap the Stop button to stop the recording, and the device screen will reappear, with a summary of the recording. If you are not the person who started the recording, that person will get a notification on their mobile device that the recording is complete. Reviewing Your Recordings To review your past recordings, tap the Recent Recordings button on the home screen. A list of recordings will appear, most recent first. Completed recordings are colored green, red, or blue (for in-range, too high, or too low, respectively) and incomplete recordings are gray. Tapping on an individual recording displays the recording detail screen, which includes a chart of the trip as well as various statistics and datapoints. If the start or stop location is provided, you can see a detailed map of the location by tapping on the address. Also, if your account allows, you can display any photos included, as well as the detailed tracking information. Extras Location The mechanism for setting the location is also slightly different between Android and Apple. For Apple devices, the Seguro app will request location permission the first time a recording is started or stopped on a device. For Android devices, the app requires location permission just to connect to a Seguro device, but will also ask to attach location information to the recording the first time a recording is started or stopped. Photos You can add photos for both the start and end of a recording. The Seguro app requires Camera permission to add photos to a recording. Shipping Information For Premium account users, tracking information for popular carriers can be added when a recording is started or stopped. The app can scan the barcode on a waybill, or the user can type in the tracking number manually. The app requires Camera permission to scan barcodes.
Il•llsensified.io Date: 06/19/23 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2A3Ll-PM06 Sensified LLC 958 Austin Ave Atlanta, GA 30307 Attestation Statements Part 2.911(d)(5)(i) Filing To whom it may concern, Sensified LLC, certifies that the equipment is seeking authorization is not on the "List of Equipment and Services Covered by Section 2 of the Secure Networks Act," which it is prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Sign re: Christopher B ar President, Fo n er
Il•llsensified.io Date: 06/19/23 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2A3Ll-PM06 Sensified LLC 958 Austin Ave Atlanta, GA 30307 Attestation Statements Part 2.911 (d)(5)(ii) Filing To whom it may concern, Sensified LLC certifies that, as of the date of the filing of the application, Sensified LLC is not identified on the "List of Equipment and Services Covered by Section 2 of the Secure Networks Act," as an entity producing "covered" equipment. Sincerely, Signa re: ristopher B President, Fou
sensified.io Date: 06/19/23 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2A3Ll-PM06 Sensified LLC 958 Austin Ave Atlanta, GA 30307 US Agent — Attestation Statement / Part 2.911 (d)(7) To whom it may concern, Sensified LLC certifies that, as of the date of the filing of the application, we designate ourselves as the U.S. agent for service of process. Designated U.S. Agent Information: Name: Sensified LLC FRN: 0031591159 Address: 958 Austin Ave, Atlanta, GA 30307 Contact Person: Christopher Bear Tel.: 678-2944270 Email: [email protected] Sincerely, Signat e: Christopher B ar President, nder
11 0 11 sensified.io Date: 06/19/23 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2A3Ll-PM06 Sensified LLC 958 Austin Ave Atlanta, GA 30307 Confidentiality Request To whom it may concern, Pursuant to Sections 0.457 and 0.459 of the Commission's Rules, we hereby request confidential treatment of the information accompanying this application as outlined below: @Block Diagram EOperational Description @Schematics EParts List O Tune-Up Information DSecurity Information DSoftware Defined Radio (SDR) Information The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signa re: Christ ph President, F der
11 0 11 sensified.io Date: 06/19/23 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2A3Ll-PM06 Sensified LLC 958 Austin Ave Atlanta, GA 30307 E-label Declaration We, Sensified, LLC, hereby declare that the E-label meets the following FCC requirements: 1. The FCC ID can be found in the APP through the following steps: a) Once the APP is opened, tab on the Regulatory button. b) Once the Regulatory tab is opened, the FCC ID and the FCC required statement are on the same page. 2. The product does not require the use of special access codes or accessories (e.g. SIM/USIM cards) to access the FCC ID. 3. The user manual shows the FCC ID and directs the user where to find the FCC ID information and the FCC ID is displayed electronically in manner that is clearly legible without the aid of magnification. 4. Both regulatory information and dedicatedexclusive application(s) or script(s) aresecured and implemented in a factory-set unalterable format. The regulatory informationis capable of being retrieved anddisplayed locally, and under the control of theend user in possession of the product. Themethod is secure, such that theapplication or scripensures that the regulatoryinformation correctly displayed. The FCC regulatory information will not change for any reasons, like system upgrade, etc, also that the end user cannot modify it. 5. There is a physical label on the product packaging box of the product, as show below: This:devié€eomplies wth Part 15 of the FCC RJIes. is subject to two condtions: (1) This device may not cause hamful interference, and (2) this device must æcept ary interference received, including interferenco that may caug undesirable operatbn. FCC ID: 2A3U-PM06 Sincerely, Signa re: (4 Christopher a President, under
11 0 11 sensified.io Date: 06/19/23 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2A3Ll-PM06 Sensified LLC 958 Austin Ave Atlanta, GA 30307 Declaration of Authorization To whom it may concern, l, the undersigned, hereby authorize, Jandy So, of Waltek Testing Group (Shenzhen) Co., Ltd., (WALTEK) to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Jandy So, of Waltek Testing Group (Shenzhen) Co., Ltd., (WALTEK) on our behalf shall have the same effects as acts of our own. l, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C 853(a). This authorization is valid until further written notice from the applicant. Sincerely, Signa e: Christopher B President, Fo
Reference No.: WTX23X05105848W Page 2 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Reference No.: WTX23X05105848W Page 3 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTX23X05105848W Page 4 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6
Reference No.: WTX23X05105848W Page 1 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn ANNEX EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format Packaging Label E-label Specifications: Due to the sizing and usage of the product, the product label is in the APP, and on the product packaging box. Proposed Label Location on EUT FCC ID Label Location Label on Product Packaging Box Label in APP
Reference No.: WTX23X05105848W Page 5 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 Solder Board-Component View 1 Reference No.: WTX23X05105848W Page 6 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 2 Antenna View
1. RF Exposure Requirements 1.1 General Information Client Information Applicant: Sensified LLC Address of applicant: 958 Austin Ave, Atlanta, GA 30307 Manufacturer: Sensified LLC Address of manufacturer: 958 Austin Ave, Atlanta, GA 30307 General Description of EUT: Product Name: Seguro Trade Name / Model No.: 150 Adding Model(s): / Rated Voltage: Battery:DC3V Power Adapter: / FCC ID: 2A3LI-PM06 Equipment Type: Portable device Technical Characteristics of EUT: Bluetooth Bluetooth Version: V5.0 (BLE mode) Frequency Range: 2402-2480MHz RF Output Power: 1Mbps: -3.96dBm (Conducted) 2Mbps: -3.99dBm (Conducted) Data Rate: 1Mbps, 2Mbps Modulation: GFSK Quantity of Channels: 40 Channel Separation: 2MHz Type of Antenna: PCB Antenna Antenna Gain: -3.6dBi 1.2 RF Exposure Exemption According to §1.1307(b)(3) and KDB 447498 D04 Interim General RF Exposure Guidance v01, system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. Option A: FCC Rule Part 1.1307 (b)(3)(i)(A):The available maximum time-averaged power is no more than 1mW, regardless of separation distance. Option B: FCC Rule Part 1.1307 (b)(3)(i)(B): The available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold P th (mW) described in the following formula. P th is given by: Option C: FCC Rule Part 1.1307 (b)(3)(i)(C): The minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. R must be at least λ/2π, where λ is the free-space operating wavelength in meters. Single RF Sources Subject to Routine Environmental Evaluation RF Source frequency (MHz) Threshold ERP (watts) 0.3-1.34 1,920 R 2 1.34-30 3,450 R 2 /f 2 30-300 3.83 R 2 300-1,500 0.0128 R 2 f 1,500-100,000 19.2R 2 For Multiple RF sources: FCC Rule Part 1.1307(b)(3)(ii): (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). (B) In the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation. 1.3 Calculated Result Radio Access Technology Prediction Frequency Output Power Antenna Gain Duty Cycle Tune-Up Time-Averaged Power ERP (MHz) (dBm) (dBi) (%) (dBm) (dBm) Bluetooth 2402 -3.96 -3.6 100 -3.00 -8.75 Frequency Option Min. Distance Max. Power Exposure Limit Ratio Result (MHz) (cm) (dBm) (mW) (mW) Pass/Fail 2402 B 0.5 -3.00 0.50 2.788 0.18 Pass Note: 1. Time-Averaged Power=Output Power * Duty Cycle; ERP= Time-Averaged Power+ Antenna gain-2.15dB 2. Option A, B and C refers as clause 1.2. 3. For option B, Max (time-averaged power, effective radiated power (ERP)) converts to Max. Power. For option C, ERP converts to Max. Power; 4. For option B, P th (mW) converts to Exposure Limit (mW); For option C, ERP (W) converts to Exposure Limit (mW). 5. Ratio= Tune-Up ERP (mW)/ Exposure Limit (mW) Mode for Simultaneous Multi-band Transmission: Radio Access Technology Ratio 1 Ratio 2 Simultaneous Ratio Limit Result Pass/Fail -- -- -- -- -- -- Result: Pass
