2A3M2-25A083Radio Board 60556R-F-915

November 24 2022 To whom it may concern: FCC ID: 2A3M2-25A083 The applicant has declared that the module is for their own use to be installed only in UMPI Srl host products (exhibit “UMPI Limited Module Approval Letter_signed.pdf”). As per module KDB 996369 D03 v01 Section 2.1, User Manual integration instructions are filed in the Operational Description exhibit folder as a long-term confidentiality document and may not be detailed. The application is therefore filed as a Single Limited Modular Approval. UL International (UK) Ltd. TCB

866.885.4575 www.icertifi.com [email protected] 1001 SW Disk Drive. Ste. 250. Bend, Oregon 97702. USA Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 03/21/2023 Ref: Attestation Statement Part 2.911(d)(7) Filing Validity Period: Permanent FCC ID: 2A3M2-25A083 FCC FRN: 0033399411 Manufacturer Name Umpi S.r.l Address S.S. Consolare Rimini-RSM 11-47923 Rimini (RN), Italy certifies that, as of the dates of this application, Americas Compliance Consulting LLC dba iCertifi “iCertifi” is our designated U.S. agent for service of process for the above referenced FCC ID. We accept to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission-related proceeding involving the equipment. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. iCertifi accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service process for the above: Designated U.S. Agent Information: Name Americas Compliance Consulting, LLC dba iCertifi FCC FRN 0033399411 Address 1001 SW Disk Drive, Suite 250 Bend, Oregon 97702 USA Contact Person Paul Preston / President and CEO Telephone (866) 885-4575 Email [email protected] Sincerely, Umpi S.r.l. Americas Compliance Consulting LLC dba iCertifi Claudio Contini / Legal Representive Paul Preston / President

© Umpi Srl. Tutti i diritti riservati. I marchi sono di proprietà di Umpi o dei rispettivi detentori. © Umpi Srl. All rights reserved. he brands are property of Umpi or of their respective owners. Umpi Srl società a socio unico- www.umpi.it - Sede principale/Headquarters: Strada Statale Rimini-San Marino 11, 47923 Rimini (RN) Tel: 0541833160 Sede secondaria/Secondary Office: Via Cremona 1, Ed.B5, 20025 Legnano (MI) Pag. 1 CFR 47 §2.911 (d)(5) Attestation Date: 03-23-2023 FCC ID: 2A3M2-25A083 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Umpi Srl (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Umpi Srl (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment and is not an affiliate or subsidiary of an entity identified on the Covered List. Sincerely yours, ________________________ Name: Filippo Damiani Job Title: Product Development Manager Company Name: Umpi Srl

© Umpi Srl. Tutti i diritti riservati. I marchi sono di proprietà di Umpi o dei rispettivi detentori. © Umpi Srl. All rights reserved. he brands are property of Umpi or of their respective owners. Umpi Srl società a socio unico- www.umpi.it - Sede principale/Headquarters: Strada Statale Rimini-San Marino 11, 47923 Rimini (RN) Tel: 0541833160 Sede secondaria/Secondary Office: Via Cremona 1, Ed.B5, 20025 Legnano (MI) Pag. 1 CFR 47 §2.911 (d)(7) Agent Designation Attestation Date: 03-23-2023 FCC ID: 2A3M2-25A083 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Umpi Srl (“the applicant”) as required by section 2.911(d)(7), designates the following agent, located in the United States, for purposes of acting as the applicant’s agent for service of process. The applicant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the agent information changes. US Agent Information: Paul Preston America Compliance Consulting LLC dba iCertifi 1001 SW Disk Drive, Ste 250, Bend, Oregon 97702 USA [email protected] Sincerely yours, ________________________ Name: Filippo Damiani Job Title: Product Development Manager Company Name: Umpi Srl

© Umpi Srl. Tutti i diritti riservati. I marchi sono di proprietà di Umpi o dei rispettivi detentori. © Umpi Srl. All rights reserved. he brands are property of Umpi or of their respective owners. Umpi Srl società a socio unico- www.umpi.it - Sede principale/Headquarters: Strada Statale Rimini-San Marino 11, 47923 Rimini (RN) Tel: 0541833160 Sede secondaria/Secondary Office: Via Cremona 1, Ed.B5, 20025 Legnano (MI) Pag. 1 December 14, 2022 Telecommunication Certification Body UL International (UK) Ltd. Units 1-3, Horizon Wade Road Kingsland Business Park Basingstoke Hampshire RG24 8AH United Kingdom Subject: Limited Single Modular Approval - LMA Attestation Letter Certification Application FCC ID: 2A3M2-25A083 To whom it may concern We, Umpi Srl, hereby attest that we will be installing all units of our Radio Board 60556C-F-915 radio module, FCC ID: 2A3M2-25A083, into our own host products. Umpi Srl will, therefore, retain full control of the Radio Board 60556C-F-915 radio module installation process and ensure host compliance. Umpi Srl, further attest that the Radio Board 60556C-F-915 radio module is only approved for use in Umpi Srl host products and not intended for sale to third-parties. The module integration instructions are Umpi Srl internal confidential manufacturing documents. Furthermore, these module integration instructions are to be held permanently confidential as an Operational Description exhibit as allowed by KDB 996369 D03 OEM Manual section 2.1. Yours faithfully, ________________________ Filippo Damiani Product Development Manager

© Umpi Srl. Tutti i diritti riservati. I marchi sono di proprietà di Umpi o dei rispettivi detentori. © Umpi Srl. All rights reserved. he brands are property of Umpi or of their respective owners. Umpi Srl società a socio unico- www.umpi.it - Sede principale/Headquarters: Strada Statale Rimini-San Marino 11, 47923 Rimini (RN) Tel: 0541833160 Sede secondaria/Secondary Office: Via Cremona 1, Ed.B5, 20025 Legnano (MI) Pag. 1 November 18, 2022 Telecommunication Certification Body UL International (UK) Ltd. Units 1-3, Horizon Wade Road Kingsland Business Park Basingstoke Hampshire RG24 8AH United Kingdom Subject: Authorisation Letter To whom it may concern This is to certify that Umpi Srl hereby authorises UL International (UK) Ltd. to act as the TCB for the application of the Radio Board 60556C-F-915, FCC ID: 2A3M2-25A083 to the FCC. We certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. Yours faithfully, ________________________ Filippo Damiani Product Development Manager

© Umpi Srl. Tutti i diritti riservati. I marchi sono di proprietà di Umpi o dei rispettivi detentori. © Umpi Srl. All rights reserved. he brands are property of Umpi or of their respective owners. Umpi Srl società a socio unico- www.umpi.it - Sede principale/Headquarters: Strada Statale Rimini-San Marino 11, 47923 Rimini (RN) Tel: 0541833160 Sede secondaria/Secondary Office: Via Cremona 1, Ed.B5, 20025 Legnano (MI) Pag. 1 November 18, 2022 Telecommunication Certification Body UL International (UK) Ltd. Units 1-3, Horizon Wade Road Kingsland Business Park Basingstoke Hampshire RG24 8AH United Kingdom Subject: FCC Limited Single-Modular Approval Letter FCC ID: 2A3M2-25A083 To whom it may concern We, Umpi Srl, hereby declare that the product, FCC ID: 2A3M2-25A083, has met the Limited Single-modular approval requirements of FCC rule part §15.212(a)(1) and this is shown in the table below. Furthermore, we declare that the module Radio Board 60556C-F-915 is not for sale – it is for use in UMPI Srl manufactured host devices only and the user manual integration instructions are internal confidential manufacturing documents. Requirement Compliance: Yes or No along with a justification The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly Yes, the radio frequency circuitry of the radio module is shielded The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal Yes, the used radio chip includes the buffered modulation/data inputs The module must contain power supply regulation on the module Yes, the module has it © Umpi Srl. Tutti i diritti riservati. I marchi sono di proprietà di Umpi o dei rispettivi detentori. © Umpi Srl. All rights reserved. he brands are property of Umpi or of their respective owners. Umpi Srl società a socio unico- www.umpi.it - Sede principale/Headquarters: Strada Statale Rimini-San Marino 11, 47923 Rimini (RN) Tel: 0541833160 Sede secondaria/Secondary Office: Via Cremona 1, Ed.B5, 20025 Legnano (MI) Pag. 2 The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per Sections 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b) Yes, the module has a permanently attached antenna The module must demonstrate compliance in a stand-alone configuration No, the module operates on different host products The module must be labelled with its permanently affixed FCC ID label, or use an electronic display (See KDB Publication 784748 about labelling requirements) Yes, the FCC ID is printed on the product label The module must comply with all specific rules applicable to the transmitter including all the conditions provided in the integration instructions by the grantee Yes, see radio Test Report The module must comply with RF exposure requirements Yes, see radio Test Report Yours faithfully, ________________________ Filippo Damiani Product Development Manager

© Umpi Srl. Tutti i diritti riservati. I marchi sono di proprietà di Umpi o dei rispettivi detentori. © Umpi Srl. All rights reserved. he brands are property of Umpi or of their respective owners. Umpi Srl società a socio unico- www.umpi.it - Sede principale/Headquarters: Strada Statale Rimini-San Marino 11, 47923 Rimini (RN) Tel: 0541833160 Sede secondaria/Secondary Office: Via Cremona 1, Ed.B5, 20025 Legnano (MI) Pag. 1 December 07, 2022 Telecommunication Certification Body UL International (UK) Ltd. Units 1-3, Horizon Wade Road Kingsland Business Park Basingstoke Hampshire RG24 8AH United Kingdom Subject: Permanent Confidentiality Request Certification Application FCC ID: 2A3M2-25A083 To whom it may concern Pursuant to Sections 0.457(d) and 0.459 of CFR 47, Umpi Srl request that the following information, provided to support the FCC application for the Radio Board 60556C-F-915, FCC ID: 2A3M2-25A083 be held permanently confidential: Schematics Block Diagrams Parts List Operational Description Tune Up Letter The above material contains trade secrets not customarily released to public that are judged to have the potential to cause detriment to the applicant and provide unjustified benefits to its competitors. This information should not be available for public disclosure for an indefinite period of time. Yours faithfully, ________________________ Filippo Damiani Product Development Manager

Foto Pictures www.umpi.it FCC ID 2A3M2-25A080 [email protected] Il costruttore: UMPI Srl The manufacturer: Indirizzo: Address: Strada Statale Rimini-San Marino n.11, 47923 Rimini (RN), ltaly Radio Board 60556C-F-915 Modulo radio che fornisce una connessione radio sub-GHz utilizzabile con due diverse modulazioni radio, una connessione cellulare tramite NB2 o Cat-M1, un localizzatore GPS, un accelerometro ed un luxmetro. Radio module that provides a sub-GHz radio connectivity with two possible radio modulation types, a cellular connection via NB2 or Cat-M1, a global position module, a linear accelerometer and a light sensor. Foto Pictures www.umpi.it FCC ID 2A3M2-25A080 [email protected] Foto Pictures www.umpi.it FCC ID 2A3M2-25A080 [email protected]

Etichetta Label www.umpi.it FCC ID 2A3M2-25A083 [email protected] Il costruttore: UMPI Srl The manufacturer: Indirizzo: Address: Strada Statale Rimini-San Marino n.11, 47923 Rimini (RN), ltaly Radio Board 60556C-F-915 Modulo radio che fornisce una connessione radio sub-GHz utilizzabile con due diverse modulazioni radio, una connessione cellulare tramite NB2 o Cat-M1, un localizzatore GPS, un accelerometro ed un luxmetro. Radio module that provides a sub-GHz radio connectivity with two possible radio modulation types, a cellular connection via NB2 or Cat-M1, a global position module, a linear accelerometer and a light sensor. STRUTTURA ETICHETTA – LABEL STRUCTURE FCC ID: 2A3M2-25A083 Contains FCC ID: XMR201912BG77 Etichetta Label www.umpi.it FCC ID 2A3M2-25A083 [email protected] POSIZIONE ETICHETTA – LABEL POSITION

Foto Pictures www.umpi.it FCC ID 2A3M2-25A080 [email protected] Il costruttore: UMPI Srl The manufacturer: Indirizzo: Address: Strada Statale Rimini-San Marino n.11, 47923 Rimini (RN), ltaly Radio Board 60556C-F-915 Modulo radio che fornisce una connessione radio sub-GHz utilizzabile con due diverse modulazioni radio, una connessione cellulare tramite NB2 o Cat-M1, un localizzatore GPS, un accelerometro ed un luxmetro. Radio module that provides a sub-GHz radio connectivity with two possible radio modulation types, a cellular connection via NB2 or Cat-M1, a global position module, a linear accelerometer and a light sensor. Foto Pictures www.umpi.it FCC ID 2A3M2-25A080 [email protected] Foto Pictures www.umpi.it FCC ID 2A3M2-25A080 [email protected]

© Umpi Srl. Tutti i diritti riservati. I marchi sono di proprietà di Umpi o dei rispettivi detentori. © Umpi Srl. All rights reserved. he brands are property of Umpi or of their respective owners. Umpi Srl società a socio unico- www.umpi.it - Sede principale/Headquarters: Strada Statale Rimini-San Marino 11, 47923 Rimini (RN) Tel: 0541833160 Sede secondaria/Secondary Office: Via Cremona 1, Ed.B5, 20025 Legnano (MI) Pag. 1 January 27, 2023 Telecommunication Certification Body UL International (UK) Ltd. Units 1-3, Horizon Wade Road Kingsland Business Park Basingstoke Hampshire RG24 8AH United Kingdom Subject: RF Exposure Considerations for Radio Board 60556C-F-915 FCC ID: 2A3M2-25A083, Contains Pre approved Cellular Module FCC ID: XMR201912BG77 The FCC requires that the Maximum ERP be less than the threshold value at a distance of 20 cm from a device to the body of a user. The transmitter operation for the Radio Board 60556C-F-915 utilizes different technologies:  Sub-GHz  915 MHz LoRa or 915 MHz FSK  LTE  Cat M1 or NB2 Simultaneous transmission of LoRa and FSK, as that of Cat M1 and NB2, cannot take place. While the simultaneous transmission of Sub-GHz and LTE technologies is avoided by the application. The following FCC Rule Parts and procedures are applicable: Part 1.1310 – Radiofrequency radiation exposure limits Part 2.1091 – Radiofrequency radiation exposure evaluation: mobile devices KDB447498 D01 v07 Mobile and Portable Devices RF Exposure Procedures and Equipment Authorisation Policies EIRP Calculation For 915 MHz FSK Transmitter frequency range = 915.25 MHz to 927.5MHz Maximum measured ERP = +85.37 dBuV/mm = -9.86 dBm = (0.103mW) For 915 MHz LoRa Transmitter frequency range = 915.25 MHz to 927.5MHz Maximum Conducted Power = 22dBm Antenna gain: +2dBi EIRP = 22dBm + 2dBi = 24dBm ERP = EIRP-2.15dBm = +21.85dBm (153.11mW) © Umpi Srl. Tutti i diritti riservati. I marchi sono di proprietà di Umpi o dei rispettivi detentori. © Umpi Srl. All rights reserved. he brands are property of Umpi or of their respective owners. Umpi Srl società a socio unico- www.umpi.it - Sede principale/Headquarters: Strada Statale Rimini-San Marino 11, 47923 Rimini (RN) Tel: 0541833160 Sede secondaria/Secondary Office: Via Cremona 1, Ed.B5, 20025 Legnano (MI) Pag. 2 Power Thresholds From Appendix A of KDB 447498 Do1 v07. RF exemption applies if the maximum transmitted power is less than the maximum of the following three criteria: i) Less than 1 mw Blanket exemption. PTH = 0.001 W (the Radio Board 60556C-F-915 is not compliant) ii) determination of exemption under the MPE-based §1.1307(b)(3)(i)(C), if i) not meet iii) determination of exemption under the SAR-based §1.1307(b)(3)(i)(B) if both i) and ii) are not met. Determination of threshold power (PTH) under the MPE-based §1.1307(b)(3)(i)(C) From table 1 - § 1.1307(b)(3)(i)(C) - Single RF Sources Subject to Routine Environmental Evaluation for 915 MHz: Threshold ERP (watts) PTH = 0.0128 * R2 * f (f in MHz) For R = 0.2 m f = 915 MHz PTH = 0.0128 * 0.22 * 915 PTH = 0.0128 * 0.04 * 915 PTH = 0.468 W (468mW) Conclusion The maximum ERP is below the applicable 0.468W threshold for operation at 915MHz, and therefore RF Exposure Evaluation is not required for the Radio Board 60556C-F-915 with a user/antenna separation distance of 20cm and is exempt from evaluation in accordance with §1.1307(b)(3). It’s important to emphasize that the device acknowledge the use of cellular modem, which has been installed iaw the grant conditions, so it doesn't transmit simultaneously with it. ________________________ Filippo Damiani Product Development Manager

UL INTERNATIONAL GERMANY GMBH Hedelfinger Str. 61 70327 Stuttgart, Germany [email protected] TEST REPORT Test Report No. : UL-RPT-RP-13534277-3416-2-FCC Applicant : Umpi S.r.l Model No. : Syra RE-C 61456NCF-915-H-6L FCC ID : Contains FCC ID: 2A3M2-25A083 Technology : 802.15.4 (6LoWPAN/WiMesh) Test Standard(s) : FCC Parts 15.207, 15.209(a) & 15.249 For details of applied tests refer to test result summary 1. This test report shall not be reproduced in full or partial, without the written approval of UL International Germany GmbH. 2. The results in this report apply only to the sample tested. 3. The test results in this report are traceable to the national or international standards. 4. Test Report Version 1.1 supersede Version 1.0 with immediate effect Test Report No. UL-RPT-RP-1 3534277-3416-2-V1.1-FCC Version 1.1, Issue Date 05 DECEMBER 2022 replaces Test Report No. UL-RPT-RP-13534277-3416-2-FCC Version 1.0, Issue Date 16 NOVEMBER 2022, which is no longer valid. 5. Result of the tested sample: PASS ______________________________ ____________________________ Prepared by: Muhamamd Faiq, Khan Approved by: Rachid, Acharkaoui Title: Project Engineer Title: Operations Manager Date: 05 December 2022 Date: 05 December 2022 This laboratory is accredited by DAkkS. The tests reported herein have been performed in accordance with its’ terms of accreditation. UL INTERNATIONAL GERMANY GMBH TEST REPORT NO: UL-RPT-RP-13534277-3416-2-FCC TEST REPORT VERSION 1.1 ISSUE DATE: 05 DECEMBER 2022 Page 2 of 43 FCC 15.249 - Template Vers. 1.4 This page has been left intentionally blank. UL INTERNATIONAL GERMANY GMBH TEST REPORT NO: UL-RPT-RP-13534277-3416-2-FCC TEST REPORT VERSION 1.1 ISSUE DATE: 05 DECEMBER 2022 Page 3 of 43 FCC 15.249 - Template Vers. 1.4 Table of Contents 1. Customer Information .............................................................................................................. 4 1.1. Applicant Information 4 1.2. Manufacturer Information 4 2. Summary of Testing ................................................................................................................. 5 2.1. General Information 5 Applied Standards 5 Location 5 Date information 5 2.2. Summary of Test Results 6 2.3. Methods and Procedures 6 2.4. Deviations from the Test Specification 6 3. Equipment Under Test (EUT) .................................................................................................. 7 3.1. Identification of Equipment Under Test (EUT) 7 3.2. Untested Variants 7 3.3. Description of EUT 7 3.4. Modifications Incorporated in the EUT 7 3.5. Additional Information Related to Testing 8 3.6. Support Equipment 8 A. Support Equipment (In-house) 8 B. Support Equipment (Manufacturer supplied) 8 4. Operation and Monitoring of the EUT during Testing ........................................................... 9 4.1. Operating Modes 9 4.2. Configuration and Peripherals 9 5. Measurements, Examinations and Derived Results ............................................................ 10 5.1. General Comments 10 5.2. Test Results 11 5.2.1. Transmitter AC Conducted Spurious Emissions 11 5.2.2. Transmitter Fundemantal Field Strength 17 5.2.3. Transmitter Minimum 20 dB Bandwidth 21 5.2.4. Transmitter Radiated Emissions 25 5.2.5. Transmitter Band Edge Radiated Emissions 35 6. Measurement Uncertainty ..................................................................................................... 40 7. Used equipment ..................................................................................................................... 41 8. Annex A .................................................................................................................................. 42 9. Report Revision History ........................................................................................................ 43 UL INTERNATIONAL GERMANY GMBH TEST REPORT NO: UL-RPT-RP-13534277-3416-2-FCC TEST REPORT VERSION 1.1 ISSUE DATE: 05 DECEMBER 2022 Page 4 of 43 FCC 15.249 - Template Vers. 1.4 1. Customer Information 1.1. Applicant Information Company Name: Umpi S.r.l Company Address: Via S.S. Consolare Rimini-RSM 11, 47923 Rimini, Italy Company Phone No.: +39 0541 833160 Company E-Mail: [email protected] Contact Person: Luca Pietro Borsani Contact E-Mail Address: [email protected] Contact Phone No.: +39 0331 4561 59 1.2. Manufacturer Information Company Name: Umpi S.r.l Company Address: Via S.S. Consolare Rimini-RSM 11, 47923 Rimini, Italy Company Phone No.: +39 0541 833160 Company E-Mail: [email protected] Contact Person: Luca Pietro Borsani Contact E-Mail Address: [email protected] Contact Phone No.: +39 0331 4561 59 UL INTERNATIONAL GERMANY GMBH TEST REPORT NO: UL-RPT-RP-13534277-3416-2-FCC TEST REPORT VERSION 1.1 ISSUE DATE: 05 DECEMBER 2022 Page 5 of 43 FCC 15.249 - Template Vers. 1.4 2. Summary of Testing 2.1. General Information Applied Standards Specification Reference: 47CFR15.249 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications): Part 15 Subpart C (Intentional Radiators) - Section 15.249 Specification Reference: 47CFR15.207 and 47CFR15.209 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications): Part 15 Subpart C (Intentional Radiators) – Sections 15.209 Location Location of Testing: UL International Germany GmbH Hedelfinger Str. 61 70327 Stuttgart Germany Test Firm Registration: 399704 Date information Order Date: 30 September 2020 EUT Arrived: 09 June 2022 Test Dates: 21 July 2022 to 01 December 2022 EUT Returned: -/- UL INTERNATIONAL GERMANY GMBH TEST REPORT NO: UL-RPT-RP-13534277-3416-2-FCC TEST REPORT VERSION 1.1 ISSUE DATE: 05 DECEMBER 2022 Page 6 of 43 FCC 15.249 - Template Vers. 1.4 2.2. Summary of Test Results Clause Measurement Complied Did not comply Not performed Not applicable Part 15.207 Transmitter AC Conducted Emissions ☒ ☐ ☐ ☐ Part 15.249(a)(e) Transmitter Fundamental Field Strength ☒ ☐ ☐ ☐ Part 2.1049 Transmitter 20…

Text truncated - open the document above for the full version.

UL INTERNATIONAL GERMANY GMBH Hedelfinger Str. 61 70327 Stuttgart, Germany [email protected] TEST REPORT Test Report No. : UL-RPT-RP-13534277-4616-2-FCC Applicant : Umpi S.r.l Model No. : Syra RE-ZC 61556CF-915-6L FCC ID : Contains FCC ID: 2A3M2-25A083 Technology : 802.15.4 (6LoWPAN/WiMesh) Test Standard(s) : FCC Parts 15.207, 15.209(a) & 15.249 For details of applied tests refer to test result summary 1. This test report shall not be reproduced in full or partial, without the written approval of UL International Germany GmbH. 2. The results in this report apply only to the sample tested. 3. The test results in this report are traceable to the national or international standards. 4. Test Report Version 1.0 5. Result of the tested sample: PASS _______________________________ ____________________________ Prepared by: Muhamamd Faiq, Khan Approved by: Rachid, Acharkaoui Title: Project Engineer Title: Operations Manager Date: 16 November 2022 Date: 16 November 2022 This laboratory is accredited by DAkkS. The tests reported herein have been performed in accordance with its’ terms of accreditation. UL INTERNATIONAL GERMANY GMBH TEST REPORT NO: UL-RPT-RP-13534277-4616-2-FCC TEST REPORT VERSION 1.0 ISSUE DATE: 16 NOVEMBER 2022 Page 2 of 33 FCC 15.249 - Template Vers. 1.4 This page has been left intentionally blank. UL INTERNATIONAL GERMANY GMBH TEST REPORT NO: UL-RPT-RP-13534277-4616-2-FCC TEST REPORT VERSION 1.0 ISSUE DATE: 16 NOVEMBER 2022 Page 3 of 33 FCC 15.249 - Template Vers. 1.4 Table of Contents 1. Customer Information .............................................................................................................. 4 1.1. Applicant Information 4 1.2. Manufacturer Information 4 2. Summary of Testing ................................................................................................................. 5 2.1. General Information 5 Applied Standards 5 Location 5 Date information 5 2.2. Summary of Test Results 6 2.3. Methods and Procedures 6 2.4. Deviations from the Test Specification 6 3. Equipment Under Test (EUT) .................................................................................................. 7 3.1. Identification of Equipment Under Test (EUT) 7 3.2. Untested Variants 7 3.3. Description of EUT 7 3.4. Modifications Incorporated in the EUT 7 3.5. Additional Information Related to Testing 8 3.6. Support Equipment 8 A. Support Equipment (In-house) 8 B. Support Equipment (Manufacturer supplied) 8 4. Operation and Monitoring of the EUT during Testing ........................................................... 9 4.1. Operating Modes 9 4.2. Configuration and Peripherals 9 5. Measurements, Examinations and Derived Results ............................................................ 10 5.1. General Comments 10 5.2. Test Results 11 5.2.1. Transmitter AC Conducted Spurious Emissions 11 5.2.2. Transmitter Radiated Emissions 15 Transmitter Radiated Emissions (continued) 18 Transmitter Radiated Emissions (continued) 20 5.2.3. Transmitter Band Edge Radiated Emissions 25 6. Measurement Uncertainty ..................................................................................................... 30 7. Used equipment ..................................................................................................................... 31 8. Annex A .................................................................................................................................. 32 9. Report Revision History ........................................................................................................ 33 UL INTERNATIONAL GERMANY GMBH TEST REPORT NO: UL-RPT-RP-13534277-4616-2-FCC TEST REPORT VERSION 1.0 ISSUE DATE: 16 NOVEMBER 2022 Page 4 of 33 FCC 15.249 - Template Vers. 1.4 1. Customer Information 1.1. Applicant Information Company Name: Umpi S.r.l Company Address: Via S.S. Consolare Rimini-RSM 11, 47923 Rimini, Italy Company Phone No.: +39 0541 833160 Company E-Mail: [email protected] Contact Person: Luca Pietro Borsani Contact E-Mail Address: [email protected] Contact Phone No.: +39 0331 4561 59 1.2. Manufacturer Information Company Name: Umpi S.r.l Company Address: Via S.S. Consolare Rimini-RSM 11, 47923 Rimini, Italy Company Phone No.: +39 0541 833160 Company E-Mail: [email protected] Contact Person: Luca Pietro Borsani Contact E-Mail Address: [email protected] Contact Phone No.: +39 0331 4561 59 UL INTERNATIONAL GERMANY GMBH TEST REPORT NO: UL-RPT-RP-13534277-4616-2-FCC TEST REPORT VERSION 1.0 ISSUE DATE: 16 NOVEMBER 2022 Page 5 of 33 FCC 15.249 - Template Vers. 1.4 2. Summary of Testing 2.1. General Information Applied Standards Specification Reference: 47CFR15.249 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications): Part 15 Subpart C (Intentional Radiators) - Section 15.249 Specification Reference: 47CFR15.207 and 47CFR15.209 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications): Part 15 Subpart C (Intentional Radiators) – Sections 15.209 Location Location of Testing: UL International Germany GmbH Hedelfinger Str. 61 70327 Stuttgart Germany Test Firm Registration: 399704 Date information Order Date: 30 September 2020 EUT Arrived: 09 June 2022 Test Dates: 09 September 2022 to 19 September 2022 EUT Returned: -/- UL INTERNATIONAL GERMANY GMBH TEST REPORT NO: UL-RPT-RP-13534277-4616-2-FCC TEST REPORT VERSION 1.0 ISSUE DATE: 16 NOVEMBER 2022 Page 6 of 33 FCC 15.249 - Template Vers. 1.4 2.2. Summary of Test Results Clause Measurement Complied Did not comply Not performed Not applicable Part 15.207 Transmitter AC Conducted Emissions ☒ ☐ ☐ ☐ Part 15.249(a)(e) Transmitter Fundamental Field Strength (1) ☐ ☐ ☒ ☐ Part 2.1049 Transmitter 20 dB Bandwidth (1) ☐ ☐ ☒ ☐ Part 15.249(d)(e) & 15.209(a) Transmitter Radiated Emissions ☒ ☐ ☐ ☐ Part 15.249(d) & 15.209(a) Transmitter Band Edge Radiated Emissions ☒ ☐ ☐ ☐ Note: 1. As per applicant’s declaration F…
