2A3NOTD174Guest Pager System

TD174 Guest Pager System User Manual Menu Summary.............................................................................. Features............................................................................... Technical data..................................................................... 10 Diagram of Keypad Transmitter................................... Diagram of Pager................................................................ Button function................................................................... Operation instruction......................................................... Pairing method................................................................... Change number paper....................................................... Charge the Pager................................................................ FAQ...................................................................................... DE(9-16) FR(17-24) IT(25-32) ES(33-40) 1 1 1 2 2 2 3 3 3 4 4 EU Importer: Germany Retevis Technology GmbH Address: Uetzenacker 29,38176 wendeburg Summary Thanks for choosing Retekess TD174 Pager System. It adopts RF wireless technology with millions of different learning codes. The system includes 1 keypad transmitter and 10 pagers. The keypad transmitter has 10 charging slots. Each pager is labeled with a number. In standby status, the pagers are put into the charging slot, while the client places an order, he(she) will be dispatched one pager with a number , when the order is ready, press the keypad to call the number, the client will receive signal through the beep/vibration/flash indications The pager system is greatly improve the work efficiency and avoid the client waiting in a long queue. It is widely used in fast food restaurant, dessert shop, auto 4S shop or other queue occasions. Features • 10 channels keypad call buttons • 10 charging slots • Portable and rechargeable vibration & b eep pager • Independent storage memory avoiding data lost • High receive sensitivity • Self testing while power on • Beautiful and fashionable designing Technical data 1 Receiver Working voltage DC3.7V (rechargeable battery) Charging voltage DC5V Working frequency 433.92MHz Standby current 10±5mA Working current 75±10mA (vibration) Receive sensitivity -107±2dBm Battery capacity 200mAh Decoder Learning code (AM) Dimension 49x101x11mm Keypad Transmitter Working voltage DC5V / power adapter Working frequency 433.92MHz Standby current 24±5mA Transmit current 100±30mA Encoder Learning code (AM) Dimension 130x190x33mm 10 Diagram of Keypad Transmitter Diagram of Pager 2 Charging slot Number paper ReceiverAntenna Power in 10 Keyboard area LED1 Charging LED Power ON/ OFF Reset Built-in battery Charging pins Mode LED2 Pair Paper slot LED3 Button function POWER Press and hold the button for 3s to power on/off the pager, Short press the button to stop the notice of the pager. SET Short press the button to enter pairing mode;Press and hold on the button for 3s to delete the paired information MODE Change the prompt mode of the pager. KEYPAD Enter the number to call the corresponding pager Operation instruction 1.Connect the keypad transmitter to power source, it executes the self-testing procedure and then power indicator turns on 2.Take out the pager and plug it into the charging slot, the pager will be powered on automatically, the LED1 indicator lights up and flashes once every 3s. The blue LED lights on when the pager enters charging mode. 3.When client places an order, the waiter gives one pager to him(her) and note down the number on the pager 4.While the order is ready, the waiter enters the number through keypad to call the client (number), the pager receives signal and prompts vibration/buzzer/light for 5min, after that only the 3 LED indicators flicker. Client can press the "Power/Reset" button to sop the notice or put it back to charging slot to stop it. 5.The client gives the pager back, then the waiter can put the pager into to charging slot and provide service for other clients. 6.While the pager is in charging, press the number on keypad, the corresponding pager LED indicators will flicker 3 times to report its position Note: 1)In daily working, the pager can be powered on all the time. If not use them for a long, remember to power them off. 2)If the pager system has not been used for a long time, you need to charge it for a while before giving the pagers to the clients. 3)The pager must be paired to the keypad before using. Please refer to the pairing method below. Pairing method PARING Short press the "SET" button, the LED1 indicator lights on, then press the call number on the keypadThe pager gets the signal and LED1 lamp turns off the pairing is successful. If the pager does not gets any signal in 10s, it will quit pairing status automatically. DELETING Press and hold on the "SET" button for 5s, the LED1 indicator will be ON-OFF,then release the button, the paired pager will be deleted MODE Switch mode: Vibration /Beep/Vibration + Beep Note: You need to take off the transparent cover and number paper to find the SET and MODE buttons. Change number paper Take out the transparent cover in the front of the pager, then put a number paper inside the paper slot. And then put the transparent cover back. 3 Charge the Pager When the pager battery is low, the LED1 and blue charging LED indicator flicker with short beep sound, then you need to charge the pager in time. Plug the pager into the charging slot, the blue charging LED indicator will flash, and the LED indicator will light on all the time when the it’s fully charged. FAQ The pager can not receive signal from keypad transmitter Put on the charging base but the LED screen does not display Receiving distance is greatly shortened The pager battery is lowCharge the pager in time The pager has not been paired with the keypad Out of range The power adapter is failed Pair the pager with keypad Try it in a short distance Put on the …

Text truncated - open the document above for the full version.

ZHENGZHOU YSAIR TECHNOLOGY CO.,LTD The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 4/14/2023 U.S. Agent Designation ZHENGZHOU YSAIR TECHNOLOGY CO.,LTD acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2A3NOTD174): Contact Name: Liuye Li Company of U.S. agent: RETEVIS INC Physical U.S. address of agent: 1733 E BROOKPORT ST Covina, CA 91724 FRN of U.S. agent: 0033657701 Email address of U.S. agent: [email protected] RETEVIS INC acknowledges their obligation to accept service of process on behalf of ZHENGZHOU YSAIR TECHNOLOGY CO.,LTD. ZHENGZHOU YSAIR TECHNOLOGY CO.,LTD with the FRN 0031620636 accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). Sincerely, Signature Weidong Shen General Manager ZHENGZHOU YSAIR TECHNOLOGY CO.,LTD Signature Liuye Li Manager RETEVIS INC 48_[mo del] US_Agent_2.911(d)(7) - U, V04

Page 1 of 4 FCC ID: 2A3NOTD174 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity External Photos of the EUT Fig. 1 Fig. 2 ANT Page 2 of 4 FCC ID: 2A3NOTD174 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 4 FCC ID: 2A3NOTD174 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Page 4 of 4 FCC ID: 2A3NOTD174 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7 Fig. 8

Page 1 of 1 FCC ID: 2A3NOTD174 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity LABEL AND LOCATION (Size: L5.0cm x 4.0cm) Label Location

Page 1 of 3 FCC ID: 2A3NOTD174 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Internal Photos of the EUT Fig. 1 Fig. 2 Page 2 of 3 FCC ID: 2A3NOTD174 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 3 FCC ID: 2A3NOTD174 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6

Page 1 of 3 FCC ID: 2A3NOTD174 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC RF Exposure Evaluation 1. Product Information Product name Guest Pager System Test Model TD174 Additional Model No. TD183 Model Declaration PCB board, structure and internal of these model(s) are the same, So no additional models were tested Power Supply Input: 5V3000mA For Adapter Input: 100-240V~, 50/60Hz, 0.6A For Adapter Output: 5V3000mA Hardware Version / Software Version / Frequency Range 433.92MHz Channel Number 1 Modulation Type ASK Antenna Description External Antenna, 3.5dBi (max.) Exposure category General population/uncontrolled environment EUT Type Production Unit Device Type Mobile Devices Page 2 of 3 FCC ID: 2A3NOTD174 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2.Evaluation method and Limit Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modelled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. 3. Limit 3. 1 Refer Evaluation Method ANSI C95.1–2019: IEEE Standard for Safety Levels with Respect to Human Exposure to Electric, Magnetic, and Electromagnetic Fields, 0 Hz to 300 GHz FCC KDB publication 447498 D01 General 1 RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices. 3. 2 Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Uncontrolled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density Page 3 of 3 FCC ID: 2A3NOTD174 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 4. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 5. Antenna Information EUT can only use antennas certificated as follows provided by manufacturer; Antenna type and antenna number Operate frequency band Maximum antenna gain Notes External Antenna 433.92MHz 3.5dBi SRD Antenna 6. Conducted Power Test Procedure TX frequency range: 433.92 MHz Field Strength: 50.44dBuV/m @3m EIRP=E-104.7+20logD=50.44-104.7+20log3=-44.72dBm Maximum Conducted Output Power: -44.72dBm Turn-up: -44±1 7. Evaluation Results As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used antenna refer to antenna information, the RF power density can be obtained. [SRD] Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) MPE (mW/cm2) MPE Limits (mW/cm2) dBm mW ASK -43 0.0001 3.5 1.0 0.00000002 0.28928 Remark: 1. Output power including tune up tolerance; 2. Output power was adjust to duty cycle at 100% if measured duty cycle less than 98%; 3. MPE evaluate distance is 20cm from user manual provide by manufacturer. 8. Conclusion The measurement results co…

Text truncated - open the document above for the full version.

Shenzhen Guan De Tong Technology CO., LTD TEL：+86 0755-88298396 FAX：+86 755 88298399 MOBILE: 18165722639 深圳悦信通电子有限公司 versions:A1 Client : 品 名 规 格 DESCRIPTION: 料 号 PART NO. ： 客 户 料 号 CUS PART NO.： 日 期 D A T E： 呈样签章 工 程 ENGINEERING DEPARTMENT 品 保 Q C DEPARTMENT 业 务 SALES DEPARTMENT 田宏 田青 胡海芯 客户承认签章 工 程 ENGINEERING DEPARTMENT 品 保 Q C DEPARTMENT 采 购 PURCHASING DEPARTMENT ж客户确认样品附意栏： APPROVA L SHEET SMA2.4G 3.5DB JJX008-TG000092 2023.5-5 Shenzhen Guan De Tong Technology CO., LTD TEL：+86 0755-88298396 FAX：+86 755 88298399 MOBILE: 18165722639 深圳悦信通电子有限公司 电器技术参数  Technical parameters of electrical appliances 电 性 能 指 标 Electrical Specifications 频率范围 2400-2500MHZ Frequency Range 2400-2500MHZ 电压驻波比 ≤2.0 VSWR ≤2.0 增益 3.5DBI GAIN 3.5DBI 输入阻抗 50 Ω Input Impedance 50 Ω 机 械 指 标 Mechanical Specifications 天线颜色 白色 Antenna Color white 接口形式 SMA Input connector SMA 天线长度 136mm＋3 Cable length 136mm+3 工作温度 -40°C~+85°C Working Temperature -40°C~+85°C 工作湿度 20~80% Working Humidity 20~80% Shenzhen Guan De Tong Technology CO., LTD TEL：+86 0755-88298396 FAX：+86 755 88298399 MOBILE: 18165722639 深圳悦信通电子有限公司 Product picture; Built-in Copper Material Shenzhen Guan De Tong Technology CO., LTD TEL：+86 0755-88298396 FAX：+86 755 88298399 MOBILE: 18165722639 深圳悦信通电子有限公司  Network analysis test： Shenzhen Guan De Tong Technology CO., LTD TEL：+86 0755-88298396 FAX：+86 755 88298399 MOBILE: 18165722639 深圳悦信通电子有限公司 Shenzhen Guan De Tong Technology CO., LTD TEL：+86 0755-88298396 FAX：+86 755 88298399 MOBILE: 18165722639 深圳悦信通电子有限公司 Shenzhen Guan De Tong Technology CO., LTD TEL：+86 0755-88298396 FAX：+86 755 88298399 MOBILE: 18165722639 深圳悦信通电子有限公司 Agilent network analyzer test chart：

Page 1 of 29 FCC ID: 2A3NOTD174 Report No.: LCSA032223006EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT For ZHENGZHOU YSAIR TECHNOLOGY CO.,LTD Guest Pager System Test Model: TD174 Additional Model No.: Please Refer to Page 6 Prepared for : ZHENGZHOU YSAIR TECHNOLOGY CO.,LTD Address : ROOM 709, SANJIANG BUILDING, NO.170NANYANG ROAD, HUIJI DISTRICT, ZHENGZHOU HENAN CHINA Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel : (+86)755-82591330 Fax : (+86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : April 24, 2023 Number of tested samples : A032223006-1, A032223006-2 Serial number : Prototype Date of Test : April 24, 2023 ~ May 06, 2023 Date of Report : May 08, 2023 Page 2 of 29 FCC ID: 2A3NOTD174 Report No.: LCSA032223006EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT FCC CFR 47 PART 15 C(15.231) Report Reference No. .............. : LCSA032223006EA Date of Issue ............................... : May 08, 2023 Testing Laboratory Name ......... : Shenzhen LCS Compliance Testing Laboratory Ltd. Address ...................................... : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Testing Location/ Procedure ....... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name ...................... : ZHENGZHOU YSAIR TECHNOLOGY CO.,LTD Address ...................................... : ROOM 709, SANJIANG BUILDING, NO.170NANYANG ROAD, HUIJI DISTRICT, ZHENGZHOU HENAN CHINA Test Specification Standard ..................................... : FCC CFR 47 PART 15 Subpart C, ANSI C63.10-2013 Test Report Form No. ............... : LCSEMC-1.0 TRF Originator ............................ : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF ................................. : Dated 2011-03 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Shenzhen LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test Item Description. ............... : Guest Pager System Trade Mark ................................. : RETEKESS Test Model .................................. : TD174 Ratings ....................................... : Input: 5V3000mA For Adapter Input: 100-240V~, 50/60Hz, 0.6A For Adapter Output: 5V3000mA Result ....................................... : Positive Compiled by: Supervised by: Approved by: Vera Deng/ Administrator Cary Luo/ Technique principal Gavin Liang/ Manager Page 3 of 29 FCC ID: 2A3NOTD174 Report No.: LCSA032223006EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC -- TEST REPORT EUT......................................... : Guest Pager System Test Model........................... : TD174 Applicant............................... : ZHENGZHOU YSAIR TECHNOLOGY CO.,LTD Address.................................. : ROOM 709, SANJIANG BUILDING, NO.170NANYANG ROAD, HUIJI DISTRICT, ZHENGZHOU HENAN CHINA Telephone............................... : / Fax.......................................... : / Manufacturer....................... : ZHENGZHOU YSAIR TECHNOLOGY CO.,LTD Address................................... : ROOM 709, SANJIANG BUILDING, NO.170NANYANG ROAD, HUIJI DISTRICT, ZHENGZHOU HENAN CHINA Telephone............................... : / Fax.......................................... : / Factory....................... : / Address................................... : / Telephone............................... : / Fax.......................................... : / Test Result Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCSA032223006EA May 08, 2023 Date of issue Page 4 of 29 FCC ID: 2A3NOTD174 Report No.: LCSA032223006EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Revision History Report Version Issue Date Revision Content Revised By 000 May 08, 2023 Initial Issue -- Page 5 of 29 FCC ID: 2A3NOTD174 Report No.: LCSA032223006EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity TABLE OF CONTENTS 1. GENERAL INFORMATION ...................................................................…

Text truncated - open the document above for the full version.

Page 1 of 2 FCC ID: 2A3NOTD174 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Setup Photos of the EUT Test Setup Photo(s) of Radiated Emissions Measurement Fig. 1 Fig. 2 Page 2 of 2 FCC ID: 2A3NOTD174 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Setup Photo(s) of Conducted Emissions Measurement Fig. 3
