2A3NQ-ECO-SDWB15WSmart LED Downlight

NOTE: 1. WiFi light just can use 2.4GHz only, router must chose 2.4GHz. 2. Please turn on WIFI and Bluetooth before connecting. WiFi light should flash when connecting and WIFI signal should be good when using WIFI light. 3. WiFi light should be best within 3 meters to the router 4. Sometimes the WiFi light can't be connected maybe the router is full, restart the router or delete other WiFi devices, also you can add t h e rout er quant i ty , connect again. 5.The Smart Life app has a detailed description of the connection between Alexa and Google assistant. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. FCC Caution. § 15.19 Labelling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. § 15.21 Information to user. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. § 15.105 Information to the user. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. RF warning for Mobile device: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated withminimum distan ce 20cm between the radiator & your body.

ECOBENE TECHNOLOGY LIMITED Model Difference Model : ECO-SDWB15W-001, ECO-SDWB30W-001, ECO-SDWB20W-001, ECO-SDWB09W-001, ECO-SDWB07W-001, ECO-SDWB05W-001, ECO-SDME30W-001, ECO-SDME20W-001, ECO-SDME15W-001, ECO-SDME09W-001, ECO-SDME07W-001, ECO-SDME05W-001, ECO-SDBC30W-001, ECO-SDBC20W-001, ECO-SDBC15W-001, ECO-SDBC09W-001, ECO-SDBC07W-001, ECO-SDBC05W-001, ECO-SDWB30W-002, ECO-SDWB20W-002, ECO-SDWB15W-002, ECO-SDWB09W-002, ECO-SDWB07W-002, ECO-SDWB05W-002, ECO-SDME30W-002, ECO-SDME20W-002, ECO-SDME15W-002, ECO-SDME09W-002, ECO-SDME07W-002, ECO-SDME05W-002, ECO-SDBC30W-002, ECO-SDBC20W-002, ECO-SDBC15W-002, ECO-SDBC09W-002, ECO-SDBC07W-002, ECO-SDBC05W-002 All the models are the same circuit and RF module, except the model name. Regards Sincerely, Client’s signature: Client’s name / title : Luo Wanghua/ Manager Contact information / address: East Side, 4th Floor, No. 29, Beitoudu West Road, Longxi Community, Longcheng Street, Longgang District, Shenzhen, China

ECOBENE TECHNOLOGY LIMITED 9/24/2022 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Smart LED Downlight / # AND FCC ID: 2A3NQ-ECO-SDWB15W To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above documents are company proprietary information that could never get into the possession of your competition. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : Luo Wanghua/ Manager Contact information / address: East Side, 4th Floor, No. 29, Beitoudu West Road, Longxi Community, Longcheng Street, Longgang District, Shenzhen, China

ECOBENE TECHNOLOGY LIMITED 9/24/2022 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen CTA Testing Technology Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : Luo Wanghua/ Manager Contact information / address: East Side, 4th Floor, No. 29, Beitoudu West Road, Longxi Community, Longcheng Street, Longgang District, Shenzhen, China

FCC ID: 2A3NQ-ECO-SDWB15W ECO-SDWB15W-001 External Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2A3NQ-ECO-SDWB15W Photo 4 Photo 5 Photo 6

2.5*2.9cm

FCC ID: 2A3NQ-ECO-SDWB15W ECO-SDWB15W-001 Internal Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2A3NQ-ECO-SDWB15W Photo 4 Photo 5 Photo 6 Internal Antenna FCC ID: 2A3NQ-ECO-SDWB15W Photo 7 Photo 8

1. Antenna Description: Antenna type Internal Antenna Model ECO-SDWB15W-001 Frequency range 2402-2480MHz Manufacturer ECOBENE TECHNOLOGY LIMITED ANT Peak Gain 1.99 dBi 2. Antenna Photo: 3. Test Equipment & Conditions 3.1 Test instrument Length:11.19mm Width:0.90mm VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern 2402MHz 2440MHz 2480MHz

RF Exposure evaluation FCC ID: 2A3NQ-ECO-SDWB15W Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Antenna Information Antenna No. Model No. of antenna: Type of antenna: Gain of the antenna (Max.) Frequency range: BT / Internal antenna 1.99dBi for 2400-2500MHz; 2.4GWIFI / Internal antenna 1.99dBi for 2400-2500MHz 5. Manufacturing Tolerance [Bluetooth] GFSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) 3.0 3.0 2.0 Tolerance ±(dB) 1.0 1.0 1.0 [2.4GHz WLAN] ANT IEEE 802.11b (Average) Frequency (MHz) 2412 2437 2462 Target (dBm) 13.0 13.0 13.0 Tolerance ± (dB) 1.0 1.0 1.0 IEEE 802.11g (Average) Frequency (MHz) 2412 2437 2462 Target (dBm) 14.0 14.0 14.0 Tolerance ± (dB) 1.0 1.0 1.0 IEEE 802.11n HT20 (Average) Frequency (MHz) 2412 2437 2462 Target (dBm) 14.0 14.0 14.0 Tolerance ± (dB) 1.0 1.0 1.0 6. Standalone MPE Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, the RF power density can be obtained. Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) MPE (mW/cm 2 ) MPE Limits (mW/cm 2 ) dBm mW BT 4.0 2.51 1.99 1.58 0.0008 1.0000 2.4GWIFI ANT 15.0 31.62 1.99 1.58 0.009 1.0000 Remark: 1. Output power (Peak) including turn-up tolerance; 2. MPE evaluate distance is 20cm from user manual provide by manufacturer. 7. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. ----------------THE END OF REPORT---------------

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID............................................. : CTA22080800101 2A3NQ-ECO-SDWB15W Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Amy Wen Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Aug. 16, 2022 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ............................ : ECOBENE TECHNOLOGY LIMITED Address ............................................ : East Side, 4th Floor, No. 29, Beitoudu West Road, Longxi Community, Longcheng Street, Longgang District, Shenzhen, China Test specification ........................... : Standard ........................................... : FCC Part 15.247 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Equipment description .................. : Smart LED Downlight Trade Mark ....................................... : Manufacturer .................................... : ECOBENE TECHNOLOGY LIMITED Model/Type reference ...................... : ECO-SDWB15W-001 Listed Models .................................. : See Report 2 Modulation ....................................... : GFSK Frequency ......................................... From 2402MHz to 2480MHz Ratings ............................................. : AC120V 50/60Hz Result ............................................... : PASS Report No.: CTA22080800101 Page 2 of 35 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Smart LED Downlight Model /Type : ECO-SDWB15W-001 Listed Models : ECO-SDWB30W-001, ECO-SDWB20W-001, ECO-SDWB09W-001, ECO-SDWB07W-001, ECO-SDWB05W-001, ECO-SDME30W-001, ECO-SDME20W-001, ECO-SDME15W-001, ECO-SDME09W-001, ECO-SDME07W-001, ECO-SDME05W-001, ECO-SDBC30W-001, ECO-SDBC20W-001, ECO-SDBC15W-001, ECO-SDBC09W-001, ECO-SDBC07W-001, ECO-SDBC05W-001, ECO-SDWB30W-002, ECO-SDWB20W-002, ECO-SDWB15W-002, ECO-SDWB09W-002, ECO-SDWB07W-002, ECO-SDWB05W-002, ECO-SDME30W-002, ECO-SDME20W-002, ECO-SDME15W-002, ECO-SDME09W-002, ECO-SDME07W-002, ECO-SDME05W-002, ECO-SDBC30W-002, ECO-SDBC20W-002, ECO-SDBC15W-002, ECO-SDBC09W-002, ECO-SDBC07W-002, ECO-SDBC05W-002 Applicant : ECOBENE TECHNOLOGY LIMITED Address : East Side, 4th Floor, No. 29, Beitoudu West Road, Longxi Community, Longcheng Street, Longgang District, Shenzhen, China Manufacturer : ECOBENE TECHNOLOGY LIMITED Address : East Side, 4th Floor, No. 29, Beitoudu West Road, Longxi Community, Longcheng Street, Longgang District, Shenzhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA22080800101 Page 3 of 35 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 6 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 TES T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emissions and Band Edge 13 4.3 Maximum Peak Output Power 20 4.4 Power Spectral Density 21 4.5 6dB Bandwidth 23 4.6 Out-of-band Emissions 25 4.7 Antenna Requirement 29 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 30 6 P H O T O S O F T H E E U T ........................................................... 31 Report No.: CTA22080800101 Page 4 of 35 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and…
