2A3QW-WM3WIRELESS MOUSE

WM3 WM3 Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. FOR PORTABLE DEVICE USAGE Radiation Exposure Statement: The product comply with the FCC portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available.

HANMI MICRONICS INC. Apr 12, 2021 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370a Newberry, Florida 32669 USA Letter of Authorization We, the undersigned, hereby authorize Yeong Hwan Hong of ICR Co.,Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID : 2A3QW-WM3 including signing of all documents relating to these matters. Any and all acts carried out by Yeong Hwan Hong of ICR Co.,Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from HANMI MICRONICS INC. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Jay Maeng / Senior Researcher

HANMI MICRONICS INC. Rev 11/20/07 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of 2A3QW-WM3 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram WM3_Blk.pdf Part list WM3_Part List.pdf Schematics WM3_Schematic.pdf Operational Description WM3_OpDesc.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); Exhibit Type File Name External Photo WM3_External Photos.pdf Internal Photo WM3_Internal Photos.pdf Manual WM3_Manual.pdf Test Set-up Photo WM3_Tsup Photos.pdf For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. Sincerely, Jay Maeng / Senior Researcher

Front Rear Side 1 Side 2 Side 3 Side 4

WM3

Internal of sample (mouse) Antenna (Close-up and Location) Main Board(mouse, front) Main Board (mouse, rear)

페이지(page) : ( 2 )/( 총(Total) 6 ) ICRT-QPA-17-03 Rev.2 Report No. ICRT-TR-E221964-0A Contents 1. Applicant & Manufacturer & Test Laboratory Information .................................................................................. 4 1.1 Applicant information ........................................................................................................................................ 4 1.2 Manufacturer Information ................................................................................................................................. 4 1.3 Test Laboratory Information ............................................................................................................................ 4 2. Equipment under Test(EUT) Information ................................................................................................................. 5 2.1 General Information ........................................................................................................................................... 5 2.2 Additional Information ...................................................................................................................................... 5 2.3 Mode of operation during the test .................................................................................................................. 5 2.4 Modifications of EUT ......................................................................................................................................... 5 3. Maximum Permissible Exposure ............................................................................................................................... 6 3.1 RF Exposure calculation .................................................................................................................................. 6 3.2 Result ..................................................................................................................................................................... 7 페이지(page) : ( 3 )/( 총(Total) 6 ) ICRT-QPA-17-03 Rev.2 Report No. ICRT-TR-E221964-0A Revision History Issued Report No. Issued Date Revisions Effect Section ICRT-TR-E221964-0A 2022-08-03 Initial Issue All 페이지(page) : ( 4 )/( 총(Total) 6 ) ICRT-QPA-17-03 Rev.2 Report No. ICRT-TR-E221964-0A 1. Applicant & Manufacturer & Test Laboratory Information 1.1 Applicant information Applicant HANMI MICRONICS INC. Address 72, Samdo-ro 48beon-gil, Yangchon-eup, Gimpo-si, Gyeonggi-do, Korea. Contact Person Jay Maeng Telephone No. 82-01-3301-8347 Fax No. 82-07-3273-2420 E-mail [email protected] 1.2 Manufacturer Information Manufacturer HANMI MICRONICS INC. Address 72, Samdo-ro 48beon-gil, Yangchon-eup, Gimpo-si, Gyeonggi-do, Korea. 1.3 Test Laboratory Information Conducted tests were performed at Laboratory ICR Co., Ltd. Address 112, Hwanggeum 3-ro 7beon-gil, Hagun-ri, Yangchon-eup, Gimpo-si, Gyeonggi- do, Korea Telephone No. +82-2-6351-9002 Fax No. +82-2-6351-9007 RRA No. KR0165 KOLAS No. KT652 페이지(page) : ( 5 )/( 총(Total) 6 ) ICRT-QPA-17-03 Rev.2 Report No. ICRT-TR-E221964-0A 2. Equipment under Test(EUT) Information 2.1 General Information Product Name WIRELESS MOUSE Brand Name - Model Name WM3 Additional Model Name - FCC ID 2A3QW-WM3 Hardware Version 1.0 2.2 Additional Information Equipment Class FHSS - Frequency Hopping Spread Spectrum system DTS - Digital Transmission System Device Type Stand-alone Operating Frequency 2 402 ㎒ ~ 2 480 ㎒ RF Output Power FHSS : GFSK -3.44 ㏈m DTS : Bluetooth LE -4.63 ㏈m Number of Channel 79 Modulation Type GFSK Antenna Type PCB Antenna Antenna Gain -1.52 ㏈i Antenna Operating Mode Single Antenna Equipment with only one antenna 2.3 Mode of operation during the test - The EUT is continuous transmission mode during the test with set at Low Channel, Middle Channel, and High Channel. To get a maximum radiated emission levels from the EUT, the EUT was moved throughout the XY, YZ, XZ planes. 2.4 Modifications of EUT - None 페이지(page) : ( 6 )/( 총(Total) 6 ) ICRT-QPA-17-03 Rev.2 Report No. ICRT-TR-E221964-0A 3. Maximum Permissible Exposure 3.1 RF Exposure calculation According to the FCC rule §1.1310 the limit for General Population/Uncontrolled exposure is 1 ㎽/㎠ for the device operating 1 500 ㎒ ~ 100 000 ㎒. Kind of EUT WIRELESS MOUSE Operating Frequency Band □ WLAN(802.11b/g/n(HT20)): 2 412 ㎒ ~ 2 462 ㎒ □ WLAN(802.11n(HT40)): 2 422 ㎒ ~ 2 452 ㎒ □ WLAN: 5 180 ㎒ ~ 5 320 ㎒ / 5 500 ㎒ ~ 5 700 ㎒ □ WLAN: 5 745 ㎒ ~ 5 825 ㎒ ■ Bluetooth: 2 402 ㎒ ~ 2 480 ㎒ Max. Output Power GFSK -3.44 ㏈m Bluetooth LE -4.63 ㏈m Exposure Evaluation Applied □ MPE □ SAR ■ N/A 페이지(page) : ( 7 )/( 총(Total) 6 ) ICRT-QPA-17-03 Rev.2 Report No. ICRT-TR-E221964-0A 3.2 Result According to the procedure, KDB 447498 D01, the standalone SAR test exclusion threshold is [(Max. Power of channel, including tune-up tolerance, ㎽) / (Min. test separation distance, ㎜)] x [√f(㎓)] < 3 Conclusion: The SAR test exclusion threshold is less than 3, so the device meets the RF Exposure Requirement and excluded SAR Test. Operating Mode Frequency (㎒) Target Power W / tolerance Max tune up power Separation distance (㎜) RF exposure Limit (㏈m) (㏈m) (㎽) GFSK 2 402 -3.44 ± 0.5 -2.94 0.51 5.00 0.16 3.00 Bluetooth LE 2 402 -4.63 ± 0.5 -4.13 0.39 5.00 0.12 - END -

페이지(page) : ( 2 )/( 총(Total) 34 ) ICRT-QPA-17-03 Rev.2 Report No. ICRT-TR-E221962-0A Contents 1. Applicant & Manufacturer & Test Laboratory Information .................................................................................. 5 1.1 Applicant information ........................................................................................................................................ 5 1.2 Manufacturer Information ................................................................................................................................. 5 1.3 Test Laboratory Information ............................................................................................................................ 5 2. Equipment under Test(EUT) Information ................................................................................................................. 6 2.1 General Information ........................................................................................................................................... 6 2.2 Additional Information ...................................................................................................................................... 6 2.3 Mode of operation during the test .................................................................................................................. 6 2.4 Modifications of EUT ......................................................................................................................................... 6 3. Test Summary ................................................................................................................................................................. 7 3.1 Test standards and results .............................................................................................................................. 7 3.2 Purpose of the test ............................................................................................................................................. 7 3.3 Test Methodology ............................................................................................................................................... 7 3.4 Configuration of Test System ......................................................................................................................... 7 3.5 Antenna requirement ......................................................................................................................................... 8 4. Used equipment on test ............................................................................................................................................... 9 5. 6 ㏈ Bandwidth ............................................................................................................................................................ 10 5.1 Operating environment ................................................................................................................................... 10 5.2 Measurement method ...................................................................................................................................... 10 5.3 Test setup ........................................................................................................................................................... 10 5.4 Test data ............................................................................................................................................................. 11 6. Maximum Conducted Output Power ....................................................................................................................... 13 6.1 Operating environment ................................................................................................................................... 13 6.2 Measurement method ...................................................................................................................................... 13 6.3 Test setup ........................................................................................................................................................... 13 6.4 Test data ............................................................................................................................................................. 14 7. Power Spectral Density .............................................................................................................................................. 16 7.1 Operating environment ................................................................................................................................... 16 7.2 Measurement method ...................................................................................................................................... 16 7.3 Test setup ........................................................................................................................................................... 16 7.4 Test data ............................................................................................................................................................. 17 8. Conducted Spurious Emission ................................................................................................................................ 19 8.1 Operating environment ................................................................................................................................... 19 8.2 Measurement method ...................................................................................................................................... 19 8.3 Test setup ........................................................................................................................................................... 19 8.4 Test data ...............................................................................................................…

Text truncated - open the document above for the full version.

페이지(page) : ( 1 )/( 총 3 ) ICRT-QP-22-02 Rev.5 Report No. Test Setup Photo Test Setup Radiated measurement for Above 1 ㎓ (Front side) Test Setup Radiated measurement for Above 1 ㎓ (Rear side) 페이지(page) : ( 2 )/( 총 3 ) ICRT-QP-22-02 Rev.5 Report No. Test Setup Radiated measurement for below 1 ㎓ (Front side) Test Setup Radiated measurement for below 1 ㎓ (Rear side) 페이지(page) : ( 3 )/( 총 3 ) ICRT-QP-22-02 Rev.5 Report No. Test Setup Conducted measurement (Front) Test Setup Conducted measurement (Side)
