WIRELESS BRIDGE USER MANUAL Model: CPE806S Tips: Thank you for purchasing and using the ULNA CPE806S Wireless Bridge. Please read this manual carefully before use. If you encounter any issues during setup or operation, feel free to contact us at any time. Installing this device requires basic networking knowledge. If you're unsure how to install it, please contact us or seek assistance from a professional technician. Customer Service Email: [email protected] ULNA Store: https://www.amazon.com/ulna 1. Product Overview 1. 1 Introduction 1.2. Specifications 1.3 Package List 1.4 Interface Details 1.5 LED Indicator Details 2. Quick Start Guide 3. Network Connection 4. Digital & IP & WiFi Chart 5. Application Case 5.1 Point-to-Point Network Extension 5.2 Point-to-Multipoint Network Extension 5.3 Starlink Internet Transmission 5.4 Point-to-Point Surveillance Extension 5.5 Point-to-Multipoint Surveillance Expansion 5.6 Wireless Relay Mode 6. WEB Access 6.1 Windows System Login 6.2 macOS System Login 6.3 Mobile Device Login 7. Advanced Settings 8. Troubleshooting 9. After-sales Service 10. FCC Statement 01 01 02 04 04 06 07 1 1 13 14 14 14 15 15 16 16 17 17 22 25 29 43 45 46 Content -01- 1. Product Overview 1. 1 Introduction The ULNA CPE806S is a dual-band, long-range WiFi 6 outdoor wireless bridge that operates on both 5.8GHz and 2.4GHz frequencies. Featuring advanced wireless communication technology, it supports both point-to-point and point-to-multipoint connections with transmission distances of up to 5 km (3.1 miles). Leveraging the benefits of WiFi 6, the CPE806S delivers faster speeds, greater capacity, and improved stability in outdoor wireless deployments. The CPE806S system includes two units: a Master bridge (Transmitter, A) and a Slave bridge (Receiver, B). The device roles can be easily switched using the physical A-B toggle switch, offering flexible deployment options for various scenarios. This wireless bridge is ideal for extending network coverage to remote buildings such as barns, garages, warehouses, churches, or nearby homes—without the need to install additional modems or pay recurring monthly service fees. It provides a cost-effective, reliable solution for wireless network expansion. The wireless bridge is widely used in outdoor surveillance and connectivity scenarios including highway traffic moni- toring, water reservoir and river systems, elevator and crane operations, construction sites, seaports, marine aquaculture, and other environ- ments requiring stable long-distance transmission. -01- 8UJHNƴHFYNTSX ULNABrand CPE806SModel MT7981AB+MT7976DANChipset 256MB/16MB Memory / Flash 16dBiAntenna Gain Dual-band MIMO directional antennas Antenna SYS, LAN1, LAN2, 4 × 5G WiFi signal strength LEDs, WLAN LED Indicators 1 × 10/100/1000Mbps RJ45 1 × 2.5Gbps RJ45 1 × DC power socket Ports 802.11b: 1/2/5.5/11Mbps 802.11g: 6/9/12/18/24/36/48/54Mbps 802.11n: up to 300Mbps 802.11ac: up to 900Mbps 802.11ax: up to 2400Mbps Wireless Speeds Bridge Unit -02- Short press (1s): Cycle through frequency channels (0–9, A–F); LED display indicates selected channel Long press (10s): Restore factory settings Frequency Switch Button / Reset Button Buttons <27dBm Max Transmit Power RF Perfor- mance 24V-48V PoEPoE Power 12V 1.0A, CCC certified (adapter not included) DC Input Power Supply IEEE802.11b/g/n, IEEE802.11a, IEEE802.11ac+, IEEE802.3u Standards Supported +/-6KVESD Protection Differential Mode+/-2KVSurge Protection IP65-ratedIngress Protection <15W Max Power Consumption -20°C to 75°C / -4°F to 167°F Operating Temperature SupportedSSID Hiding SupportedWDS Bridging OPEN, WPA, WPA2, WPA-PSK, WPA2-PSK, WPA3 Encryption Modes 4 total, customizable for 2.4GHz and 5.8GHz Custom SSIDs -03- Wireless Features Environ- mental Parameters 50+ devices Max Client Connections Client Con- nections 1.3 Package List 1.4 Interface Details Fixed Bracket Universal Ball Head A-B Button Digital Tube 2 x ULNA CPE806S Wireless Bridge Units 2 x Mounting Brackets 2 x 24V POE Adapter 2 x 3ft Ethernet Test Cables 4 x Large Metal Zip Ties 2 x Small Metal Zip Ties 2 x Mounting Screw Kits 1 x User Manual -04- DC Power Port 1000Mbps LAN2 Port 2.5Gbps LAN1 Port Reset Button WIRELESS BRIDGE USER MANUAL Model: CPE806S Tips: Thank you for purchasing and using the ULNA CPE806S Wireless Bridge. Please read this manual carefully before use. If you encounter any issues during setup or operation, feel free to contact us at any time. Installing this device requires basic networking knowledge. If you're unsure how to install it, please contact us or seek assistance from a professional technician. Customer Service Email: [email protected] ULNA Store: https://www.amazon.com/ulna -05- DescriptionPort and Button 2.5Gbps auto-sensing RJ45 Ethernet portLAN1 Port 1000Mbps auto-sensing RJ45 Ethernet portLAN2 Port Shows the current pairing channel (0–9, A–F)Digital Display DescriptionPOE Adapter Reset Button Short press once to cycle through pairing channels (0–9, A–F); press and hold for 10 seconds to restore factory settings A-B Button Toggle between device roles:A = Master Bridge (Transmitter), B = Slave Bridge (Receiver) DC 12V / 1A DC input, 5.5×2.1mm barrel connector (power adapter not included) POE Port Supplies power to the wireless bridge via Power over Ethernet (24V PoE output) LAN Port 1000Mbps Ethernet port for data transmission to and from your network. Power Indicator POE Port 1000Mbps LAN Port 1.5 LED Indicator Details Transmitter A ModeReceiver B Mode 01 2F Power Indicator LAN1/LAN2 SIG1–SIG4— Signal Lights WLAN Light PWR LAN1 LAN2 WLAN -06- Status Description The digital tube displays paired numbers and letters, 0~9, A~F. LED Light PWR Power status, solid or flashing light means power is on LAN1 Solid or flashing green: LAN1 port is connected and actively transmitting data LAN2 Solid or flashing green: LAN2 port is connected and actively transmitting data Digital display LED display "L" and flashing indicat- es setti…
