Quanturi monitoring system with mobile base station User manual Manuel d‘utilisation HAYTECH Tango M Tango XN 2 © 2020 Quanturi Oy. All rights reserved. Reproduction, transmittion or transcription of this manual are not permitted without Quanturi's prior consent. Quanturi reserves the right to change the content of this manual at any time and without prior notice. In case of problems please contact: [email protected] Find more instructions at: www.quanturi.com Support 3 EN FR English 4 Start-up guide 6 HAYTECH probes 9 Tango M and Tango XN probes 12 Troubleshooting 14 General information 16 Français 19 Guide de démarrage 21 Sondes HAYTECH 24 Sondes Tango M et Tango XN 27 Dépannage 29 Informations générales 31 Content 4 EN English Introduction Usage and precautions The User is expected to thoroughly familiarize themselves with the system usage instructions, and then use the product with care and diligence. The User's installation of the system is not to replace the normal usage and safety precautions that the User should continue to take to avoid a fire breaking out. The system acts as an additional tool to safeguard the material, but under no circumstances should it be used as the sole surveillance system. Quanturi cannot be held responsible for a fire breaking out nor for any of the consequences of this. The User undertakes to regularly check that the whole Quanturi system works properly, and to take all necessary precautions with respect to the material’s upkeep. The Quanturi monitoring system is used for the monitoring of fermentable materials during the storage period. The system is composed of monitoring probes, a base station and optional repeater(s). The probes are placed inside the fermentable materials at the time of storage. The base station sends the measurement data to quanturi.app. This manual walks you through the installation and setup procedure. After going through all the steps in this manual, the Quanturi monitoring system is ready for use. 5 EN The User hereby notes that each probe is to be used to monitor only the material the probe is inserted in, and may not be used to measure several nearby entities. Furthermore, the User undertakes to remove the probes from the material before it is used for any purpose other than conservation. Quanturi may not under any circumstances be held liable for any damages arising from the User's negligent use of the material whether this be directly or indirectly, including – but not limited to – loss of profits, loss of savings or any other damages or expense. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. For more information about the terms of use, please visit: https://quanturi.com/pages/terms 6 EN     Base station 1 2 1 Place the base station so that the distance between the probes and the base station is ideally less than 50 meters. 2 In case base station is placed outside it is recommended to install it in a place where it is covered from direct sunlight and rain. 2 Do not keep the base station on a metallic surface. Keep the base station at least 10 cm away from solid metallic structures. 3 Create an account by specifying your credentials like username, password, phone number etc. You will receive an SMS to confirm your phone number. Alerts will be sent to this phone number. 4 Upon your first login, you will be prompted to add your probes to the system, using code 2 from your probe package. 1 Go to the web address: www.quanturi.app/activation to start the activation. 2 Activate your system by entering code 1 from your base station package. Activation 1 QNT100-00 CODE-1234 EFGH-5678 HAYTECH System 10 www.quanturi.app/activation Activation code 2 / Code d’activation 2 PRODUCT STICKER ACTIVATION STICKER PROBE ID X00001, X000002, X000003, X000004, X000005, X000006, X000007, X000008, X000009, X000010 BS ID X0000001 MADE IN FINLAND 20 PAP 1 2 standardmobile 220V (USB-C) AC socket NETWORK (Ethernet) 220V (USB-C) Prise d'alimentation secteur RÉSEAU (Ethernet) 220V (USB-C) AC-Buchse NETZWERK (Ethernet) 220V (USB-C) Presa AC RETE (Ethernet) 230VAC Outlet socket IP44 or higher Outlet socket IP44 or higher 220V AC ADAPTATER 5V 230VAC Prise de courant IP44 ou supérieur 230VAC Steckdose IP44 oder höher 230VAC Presa di corrente IP44 o superiore Prise de courant IP44 ou supérieur 220V ADAPTATEUR CA 5V Steckdose IP44 oder höher 220V NETZEIL 5V Presa di corrente IP44 o superiore 220V ADATTATORE AC 5V 2 The distance depends on the landscape. On open space the distance can be longer, but having hills or buildings in between will reduce the maximum distance. 1 Devices meant for outdoor use have a protection class of IP44 for the enclosure and the power adapter. In case conditions for the IP44 can not be met, external protection is needed. Start-up guide 7 EN Indicator Light 4 Wait for the base station to initialize. A blue light will circulate around the base station. Once it switches to a solid blue state, it indicates that the base station is connected to the network and operational. Circulating blue light Base station is looking for network connection Solid blue light Base station is connected Blinking orange light Base station has an internal error (refer to page 14) 5 The probes start sending data within 1 hour from the base station start-up. Login to: https://www.quanturi.app for the data visualization. 79°C 74°C 68°C 62°C 55°C 49°C 45°C 38 °C 38°C TemperatureID 1321 1232 1234 2223 1112 2333 2096 2124 2243 220V NETWORK AC ADAPTER 5V   2 m  If the light does not enter the solid blue state after 5 min refer to the troubleshooting section on page 14. 3 Connect the included power supply to an electrical outlet (with an IP-rating of IP44 or higher). 8 EN Quanturi.app 3 quanturi.app is the service application for visualizing the sensor data and for customizing your account settings. The application is available under the web address: https://w…

Text truncated - open the document above for the full version.

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 1 of 2 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Quanturi Oy Address Lars Sonckin kaari 10, 02600 Espoo, Finland Grantee Code 2A3UF FCC ID QNT2X3 Authorized Contact Name Nadine Pesonen Contact Email [email protected] Contact Phone +358405876976 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List Quanturi Oy (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Quanturi Oy (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date: 09.02.2023 Print Name: Nadine Pesonen Title: CEO Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 2 of 2 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

12.9.2022 Quanturi Oy www.quanturi.com Lars Sonckin Kaari 10 +358 40 587 6976 02600 Espoo, Finland [email protected] 1 To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: Quanturi Oy Lars Sonckin kaari 10 02600 Espoo Finland Regarding: Confidentiality Request regarding application for FCC ID 2A3UFQNT2X3 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions Parts List / BOM The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY Additionally, the applicant requests the following documents be held confidential until the device is marketed or 180 days from the grant date, whichever is less. If the device is marketed within 180 days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. External Photos Internal Photos Test Setup Photos User manual(s) Sincerely, Nadine Pesonen CEO Quanturi

UNITED STATES DESIGNATED AGENT LETTER Date: 13 April 2023 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Applicant U.S. designated agent Company Name: Quanturi Oy Company Name: Quanturi INC Grantee Code: 2A3UF FRN: 0033651803 Contact Name: Nadine Pesonen Contact Name: Nadine Pesonen Address: Lars Sonckin kaari 10 Address: 470 Ramona Street City/Province/Zip: 02600 Espoo, Finland City/Province/Zip: Palo Alto Telephone: +358405876976 Telephone: 650 666 9500 Fax: Fax: Email: [email protected] Email: [email protected] Applicable Equipment: FCC ID: QNT2X3, QNT2XX, QNT30602, QNT30502 ATTN: Director of Certification: We, Quanturi Oy and Quanturi INC understand and acknowledge the applicants consent and the designated agent’s obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and e-mail of the designated agent listed above. We, Quanturi Oy and Quanturi INC acknowledge the applicant’s acceptance of its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Applicant U.S. designated agent Nadine Pesonen Nadine Pesonen CEO CEO

8.8.2022 Quanturi Oy www.quanturi.com Lars Sonckin Kaari 10 +358 40 587 6976 02600 Espoo, Finland [email protected] 1 External Photos: Haytech V1.0 Summary: This document contains the external photos of the Haytech device. 8.8.2022 Quanturi Oy www.quanturi.com Lars Sonckin Kaari 10 +358 40 587 6976 02600 Espoo, Finland [email protected] 2 8.8.2022 Quanturi Oy www.quanturi.com Lars Sonckin Kaari 10 +358 40 587 6976 02600 Espoo, Finland [email protected] 3 1- Document Version Date – Author Version Comments 08.08.2022 – Maxime DAUPHIN V1.0 Initial Version

26.7.2022 Quanturi Oy www.quanturi.com Lars Sonckin Kaari 10 +358 40 587 6976 02600 Espoo, Finland [email protected] 1 QNT203 HAYTECH probe label specifications Design and location Label specifications Base material: HERMA PP 50 transparent tc, glossy polypropylene film Advesive: Herma Adhesive 63S Ink: Domino N-SERIES UV CURABLE BLACK INK Overlaminating film: Fasson 3 Mil Velvet Lexan

20.2.20233 Quanturi Oy www.quanturi.com Lars Sonckin Kaari 10 +358 40 587 6976 02600 Espoo, Finland [email protected] 1 Internal Photos: Haytech V2.0 Summary: This document contains the internal photos of the Haytech device. 20.2.20233 Quanturi Oy www.quanturi.com Lars Sonckin Kaari 10 +358 40 587 6976 02600 Espoo, Finland [email protected] 2 20.2.20233 Quanturi Oy www.quanturi.com Lars Sonckin Kaari 10 +358 40 587 6976 02600 Espoo, Finland [email protected] 3 20.2.20233 Quanturi Oy www.quanturi.com Lars Sonckin Kaari 10 +358 40 587 6976 02600 Espoo, Finland [email protected] 4 20.2.20233 Quanturi Oy www.quanturi.com Lars Sonckin Kaari 10 +358 40 587 6976 02600 Espoo, Finland [email protected] 5 20.2.20233 Quanturi Oy www.quanturi.com Lars Sonckin Kaari 10 +358 40 587 6976 02600 Espoo, Finland [email protected] 6 20.2.20233 Quanturi Oy www.quanturi.com Lars Sonckin Kaari 10 +358 40 587 6976 02600 Espoo, Finland [email protected] 7 1- Document Version Date – Author Version Comments 08.08.2022 – Maxime DAUPHIN V1.0 Initial Version 09.02.2023 – Nhut Tran V2.0 Update photos

Reference number: HELEM2111000438-4 Page 1 of 15 These test results are valid for the tested unit only. This report shall not be reproduced, except in full, without a written permission of SGS Fimko. Test Report Electromagnetic Compatibility (EMC) HELEM2111000438-4 TESTS ACCORDING TO FCC PART 15 B AND ISED CANADA REQUIREMENTS Equipment Under Test: Temperature probe with SRD Model: Haytech QNT200-00 Manufacturer: Quanturi Oy Lars Sonckin kaari 10 FI-02600 Espoo FINLAND Customer: Quanturi Oy Lars Sonckin kaari 10 FI-02600 Espoo FINLAND FCC Rule Part: FCC CFR 47 Part 15 Subpart B, Class B IC Rule Part: ICES-003 Issue 7, Class B Date: 14 February 2022 Date: 14 February 2022 Issued by: Checked by: Rauno Repo Henri Mäki Senior EMC Specialist Testing Engineer Reference number: HELEM2111000438-4 Page 2 of 15 Table of Contents TABLE OF CONTENTS TABLE OF CONTENTS ................................................................................................................................. 2 GENERAL REMARKS ................................................................................................................................... 3 Disclaimer ................................................................................................................................................. 3 RELEASE HISTORY...................................................................................................................................... 4 PRODUCT DESCRIPTION ............................................................................................................................ 5 Equipment Under Test (EUT) .................................................................................................................... 5 General description ................................................................................................................................... 5 Samples and modifications........................................................................................................................ 5 Ports and cables ....................................................................................................................................... 5 Peripherals ............................................................................................................................................... 5 TEST CONDITION ......................................................................................................................................... 6 EUT Test Conditions During EMC-Testing ................................................................................................. 6 Operation modes ...................................................................................................................................... 6 Emission Measurement Uncertainty .......................................................................................................... 6 SUMMARY OF TESTING .............................................................................................................................. 7 EMISSION TESTS ......................................................................................................................................... 8 Radiated Emissions In The Frequency Range 9 kHz – 10 GHz.................................................................. 8 TEST EQUIPMENT ....................................................................................................................................... 15 Reference number: HELEM2111000438-4 Page 3 of 15 Disclaimer GENERAL REMARKS Disclaimer This document is issued by the Company subject to its General Conditions of Service printed overleaf, avail- able on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for electronic for- mat documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms- and-Conditions/Terms-e-Document.aspx Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole respon- sibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. Reference number: HELEM2111000438-4 Page 4 of 15 Release History RELEASE HISTORY Version Changes Issued 1.0 Initial release 14 February 2022 Reference number: HELEM2111000438-4 Page 5 of 15 Product Description PRODUCT DESCRIPTION Equipment Under Test (EUT) EUT information General Product Description Temperature probe with SRD Trademark Model Haytech QNT200-00 Type - Serial number - Power input port type Internal lithium battery Rated voltage 3.6 V Rated current - Rated frequency - Rated power - EUT Highest operation freq. SRD radio 927 MHz Hardware Version (if any) - Software Version (if any) - Mechanical size of the EUT Height: 60 mm Width: 60 mm Length: 405 mm Parallel models - Radio module or chip ON Semiconductor AX8052F143-D The EUT was tested as a tabletop unit. General description The HAYTECH system is designed to monitor the temperature of hay bales during storage. The system is used to prevent hay fires from spontaneous combustion and improve hay quality management. Probe transmits a packet once per hour. If the Base Station and/or repeater are in the receiving range …

Text truncated - open the document above for the full version.

TEST SETUP PHOTOGRAPHS Page 1 of 2 Project number: HELEM2111000483-4 SGS Fimko Ltd. Takomotie 8, FI-00380 Helsinki Finland t +358 9 6963 361 f +358 9 692 5474 www.sgs.fi Member of SGS Group (Société Générale de Surveillance) Photograph 1. The EUT Photograph 2. Radiated emissions 9 kHz – 30 MHz TEST SETUP PHOTOGRAPHS Page 2 of 2 Project number: HELEM2111000483-4 SGS Fimko Ltd. Takomotie 8, FI-00380 Helsinki Finland t +358 9 6963 361 f +358 9 692 5474 www.sgs.fi Member of SGS Group (Société Générale de Surveillance) Photograph 3. Radiated emissions 30 - 1000 MHz Photograph 4. Radiated emissions 1 – 10 GHz
