2A3YA-O24GPS NAVIGATOR

DEAR PILOT Thank you for choosing Omni! This manual will help you get started with your new device right out of the box. Follow the instructions to get the most out of your Omni and to keep it in top shape for years to come. We wish you many happy adventures and safe landings with this Omni as your co-pilot. For more information, news, fi rmware updates and support please visit: https://www.naviter.com IN THE BOX Omni, Protective case, Getting started manual, velcro, wall charger, USB-C data and charging cable, SIM tray opener tool. ABOUT YOUR OMNI 1. Fanet+ antenna 2. Speaker 3. QR Code scanner 4. + / - buttons 5. Power button 6. SIM Card tray 7. USB-C connector 8. Reset button 9. Charging light 10. Light sensor CONNECTIVITY Omni has full Wifi , Bluetooth and 2G/3G/4G/LTE connectivity. The cellular connectivity is unlocked, you can use a SIM card from any provider. Simply insert the SIM card in the slot and start the device. Communication is enabled by default. To use Wifi , you must slide down from the top of the screen two times to open the Android Wifi settings. Connect to a Wifi network or share a Hotspot connection from your phone. FIRST RUN & REGISTRATION Omni requires you sign into your SeeYou account during the fi rst run. This will guarantee a seamless experience. 1. Press and hold the Power button to turn on Omni. 2. Login to SeeYou or create a new account. 3. Complete the on-boarding process. 4. SeeYou Navigator will start and it is ready to fl y. 5. To turn the device off, press and hold the power button for one second. SEEYOU NAVIGATOR SOFTWARE SEEYOU You will enjoy all the benefi ts and seamless experience when Omni is used in connection with SeeYou Cloud. One year free use of SeeYou Cloud is included with the purchase of a new Omni. The evaluation starts automatically when you login to SeeYou on your new Omni. Plan your fl ights, manage waypoints, keep your logbook, share and learn from your fl ights - with SeeYou Cloud. https://seeyou.cloud HARDWARE SeeYou Navigator will prompt you to update itself whenever a new version is available and Omni is connected to the internet. It is highly recommended to keep Omni up-to-date at all times. Detailed instructions about SeeYou Navigator are available at: https://kb.naviter.com SCREEN • 3.5 inch screen size, 800×400 pixels • 1000 nits brightness • Portrait and Landscape orientation • Multi-touch (pinch&zoom) SIZE AND WEIGHT • 97×87×25 mm / 3.8×3.4×1 inch • 222 grams SENSORS • Fanet & Flarm • High-precision pressure sensor (<10 cm) • High-accuracy GPS sensors, Galileo & GLONASS GPS receiver • Gyro-assisted instant Vario BATTERY • 6000 mAh, 2.5 hours charge time from empty to full • 11 hours autonomy with default settings / 12–15 hours with battery saver settings • 40+ hours of continuous fl ight recording with screen powered off CONNECTIVITY • USB Type-C and USB OTG • Wifi , Bluetooth LE, 2G/3G/4G/LTE • Wifi and Bluetooth Internet tethering MEMORY • 4 GB RAM and 64 GB Flash MENULAYERS 1 2 3 5 4 10 6, 7, 8, 9 WARRANTY Naviter company warrants your Omni against defects in materials and workmanship for two years from the date of purchase. The warranty is non-transferable. Should any part of the Omni become defective within the warranty period return the Omni with a description of what and why it is not functioning and we will repair or replace it, at our discretion, free of charge (you only cover the shipping costs to Naviter). Warranty is non-transferable and only valid if Naviter determines that the system and its components have not been damaged due to improper use, been submerged in fluids, dismantled or abused. Naviter reserves the right to determine if repairs are to be done under warranty or at a nominal charge. As a proof of activated warranty you must send a copy of the purchase invoice. NOTICE OF NON-LIABILITY This is a personal navigation assistance device only. It is not a replacement for any legally required device, method or service. It is in the responsibility of any user who will use this device to become familiar with functions and safety aspects of this device. Using the system improperly could cause failure and lead to possible property damage and/or personal injury. Naviter assumes no responsibility for property damage, accidents, injury or death that may result from the misuse of this device/equipment. This includes any use of this device/ equipment outside the scope of common sense, Getting started manual, inserts and other related documentation. BATTERY SAFETY WARNING This product contains a large Li-Ion battery pack. You must read these safety instructions and warnings before using or charging your device. By purchasing this product, you assume all risks associated with lithium batteries. If you do not agree with these conditions, please consider using another product for your activities. In rare cases, Li-Ion and Polymer battery packs may swell up, smoke, explode and cause a fire. Avoid charging your device around flammable materials, such as a bed, couch, or paper. Never keep li-ion batteries near heat sources or in high temperatures, for example in a car or in the cockpit. If you notice signs that the battery has a problem, such as overheating, odor, leaks, bulging, or a change in color/shape, shut off the device and move it away from anything that can catch on fi re. For long-term storage, keep the batteries charged between 30-70% of capacity. Never throw lithium-ion batteries in the trash. FCC COMPLIAN CE / F CC ID: 2A3YA-O24 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with t…

Text truncated - open the document above for the full version.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: UGK-LVM UNITED INC FRN: 0033476375 Contact Name: Jimmychen Address: 6547NAcademyBlvd#2266,ColoradoSprings,CO80918 Telephone No: 001-323-51 04660 Email: [email protected] Applicant: Company name: Naviter d.o.o. Grantee code: 2A3YA FCC ID: 2A3YA-O24 FRN: 0026362798 Contact Name: Andrej Kolar Address: PLANINA 3 Telephone: 059055970 Fax: 059055970 E-mail: [email protected] [Naviter d.o.o.] certifies that, as of the date of this filing of the application with the TCB, [UGK-LVM UNITED INC] is our designated US agent for service of process for the above referenced FCC ID. [Naviter d.o.o.] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [UGK-LVM UNITED INC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2024/06/17 Applicant’s Name: Andrej Kolar US Agent for Service of Process’s Name: Jimmychen Title: Manager Title: Manager Signature Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Naviter d.o.o. Grantee code: 2A3YA FCC ID: 2A3YA-O24 FRN: 0026362798 Contact Name: Andrej Kolar Address: PLANINA 3 Telephone: 059055970 Fax: 059055970 E-mail: [email protected] i. [Naviter d.o.o.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Naviter d.o.o.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [Naviter d.o.o.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered List as an entity producing “covered”equipment . Date: 2024/06/17 Applicant’s Name: Andrej Kolar Title: Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Naviter d.o.o. Product Similarity Declaration Company: Naviter d.o.o. Address: PLANINA 3 Product Name: GPS NAVIGATOR Model Number: O24, O25, O26, O31, P71, P72 FCC Identifier: 2A3YA-O24 We (Naviter d.o.o.) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the only difference is the model name and appearance color. Client’s signature Name: Andrej Kolar Date: 2024-06-17 Title: Manager Signature of applicant:

Naviter d.o.o. 1/1 Letter of Authorization Company: Naviter d.o.o. Address: PLANINA 3 Product Name: GPS NAVIGATOR Model Number: O24, O25, O26, O31, P71, P72 FCC Identifier: 2A3YA-O24 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Andrej Kolar Date: 2024-06-17 Title: Manager Signature of applicant:

Naviter d.o.o. 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2024-06-17 Subject: Request for Confidentiality FCC ID: 2A3YA-O24 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☒ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Name: Andrej Kolar Date: 2024-06-17 Title: Manager Signature of applicant:

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(External Photos) Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

Size: 22*18mm M/N: O24 FCC ID: 2A3YA-O24 Label location

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(Internal Photos) Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. MAIN ANT LTE/WCDMA/GSM AUX ANT LTE/WCDMA/GSM ANT WIFI/BT Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

TotalorpartialreproductionofthisdocumentwithoutpermissionoftheLaboratoryisnotallowed. Page1of67 BTFTestingLab(Shenzhen)Co.,Ltd. F101,201and301,Building1,Block2,TantouIndustrialPark,TantouCommunity,SonggangStreet,Bao'anDistrict,Shenzhen,China SARTestReport For ApplicantName:Naviterd.o.o. Address:PLANINA3 EUTName:GPSNAVIGATOR BrandName:NAVITER ModelNumber:O24 SeriesModelNumber:O25,O26,O31,P71,P72 IssuedBy CompanyName:BTFTestingLab(Shenzhen)Co.,Ltd. Address: F101,201and301,Building1,Block2,TantouIndustrialPark, TantouCommunity,SonggangStreet,Bao'anDistrict,Shenzhen, China ReportNumber:BTF240508R00201 TestStandards: 47CFRPart2.1093IEC/IEEE62209-1528:2020 IEEEC95.1-2019KDB447498D04KDB865664D01 KDB865664D02KDB941225D01KDB941225D05 KDB248227D01KDB690783D01 FCCID:2A3YA-O24 TestConclusion:Pass TestDate:2024-05-15to2024-05-16 DateofIssue:2024-05-20 PreparedBy: AmendaZhong/ProjectEngineer Date:2024-05-20 ApprovedBy: Ryan.CJ/EMCManager Date:2024-05-20 Note:Allthetestresultsinthisreportonlyrelatedtothetestingsamples.Whichcanbeduplicatedcompletelyforthelegalusewithapprovalof applicant;itshallnotbereproducedexceptinfullwithoutthewrittenapprovalofBTFTestingLab(Shenzhen)Co.,Ltd.,Alltheobjectionsshouldbe raisedwithinthirtydaysfromthedateofissue.Tovalidatethereport,youcancontactus. TestReportNumber:BTF240508R00201 TotalorpartialreproductionofthisdocumentwithoutpermissionoftheLaboratoryisnotallowed. Page2of67 BTFTestingLab(Shenzhen)Co.,Ltd. F101,201and301,Building1,Block2,TantouIndustrialPark,TantouCommunity,SonggangStreet,Bao'anDistrict,Shenzhen,China RevisionHistory VersionIssueDateRevisionsContent R_V02024-05-20Original Note:Oncetherevisionhasbeenmade,thenpreviousversionsreportsareinvalid. TestReportNumber:BTF240508R00201 TotalorpartialreproductionofthisdocumentwithoutpermissionoftheLaboratoryisnotallowed. Page3of67 BTFTestingLab(Shenzhen)Co.,Ltd. F101,201and301,Building1,Block2,TantouIndustrialPark,TantouCommunity,SonggangStreet,Bao'anDistrict,Shenzhen,China TableofContents 1.Introduction...................................................................................................................................................................................................4 1.1IdentificationofTestingLaboratory.....................................................................................................................................................4 1.2IdentificationoftheResponsibleTestingLocation..............................................................................................................................4 1.3LaboratoryCondition...........................................................................................................................................................................4 1.4Announcement....................................................................................................................................................................................4 2.ProductInformation.......................................................................................................................................................................................5 2.1ApplicationInformation........................................................................................................................................................................5 2.2ManufacturerInformation....................................................................................................................................................................5 2.3FactoryInformation.............................................................................................................................................................................5 2.4GeneralDescriptionofEquipmentunderTest(EUT).........................................................................................................................5 2.5EquipmentunderTestAncillaryEquipment........................................................................................................................................5 2.6TechnicalInformation..........................................................................................................................................................................5 3.SummaryofTestResults..............................................................................................................................................................................6 3.1TestStandards....................................................................................................................................................................................6 3.2DeviceCategoryandSARLimit..........................................................................................................................................................7 3.3TestResultSummary..........................................................................................................................................................................7 3.4TestUncertainty..................................................................................................................................................................................8 4.MeasurementSystem.................................................................................................................................................................................10 4.1SpecificAbsorptionRate(SAR)Definition........................................................................................................................................10 4.2MVGSARSystem.............................................................................................................................................................................10 5.SystemVerification.........................................................................................................................................................…

Text truncated - open the document above for the full version.

深圳市兴华锐科技有限公司 Shenzhen Xinghuarui Technology Co., LTD E-mail ： [email protected] 地址 : 深圳市龙华区大浪街道中核工业园 A 栋 1 楼传真/电话：0755-29588096 第 1 页 共 19 页 产品规格书 ProductSpecification 客户名称CustomerName: 项目名称ProjectName： K7112 客户料号CustomerP/N ： 规格描述ProductSpec：4G 主天线/分集天线/WIFI天线 供方料号SupplierP/N ： 版本 REV ：V1.0 日期 Date：2024/04/25 客户承认CustomerApprove: 客户确认 / 日期 制 作 drawing审 核 check批 准 approved 冯宪嘉王顺冯嘉锐 深圳市兴华锐科技有限公司 E-mail ： [email protected] 地址 : 深圳市龙华区大浪街道中核工业园 A 栋 1 楼传真/电话：0755-29588096 第 2 页共 19 页 1.工程图纸ProductDrawing 深圳市兴华锐科技有限公司 E-mail ： [email protected] 地址 : 深圳市龙华区大浪街道中核工业园 A 栋 1 楼传真/电话：0755-29588096 第 3 页共 19 页 深圳市兴华锐科技有限公司 E-mail ： [email protected] 地址 : 深圳市龙华区大浪街道中核工业园 A 栋 1 楼传真/电话：0755-29588096 第 4 页共 19 页 深圳市兴华锐科技有限公司 E-mail ： [email protected] 地址 : 深圳市龙华区大浪街道中核工业园 A 栋 1 楼传真/电话：0755-29588096 第 5 页共 19 页 2.有源测试测试数据 深圳市兴华锐科技有限公司 E-mail ： [email protected] 地址 : 深圳市龙华区大浪街道中核工业园 A 栋 1 楼传真/电话：0755-29588096 第 6 页共 19 页 深圳市兴华锐科技有限公司 E-mail ： [email protected] 地址 : 深圳市龙华区大浪街道中核工业园 A 栋 1 楼传真/电话：0755-29588096 第 7 页共 19 页 3.无源测试数据 4G主天线： Frequency/MhzEfficiency/%MaxGain/dBi 82036.481.7 83034.911.69 84035.561.73 85034.431.56 86031.991.11 87031.921.2 88032.360.33 89029.720.01 90029.170.34 91029.990.45 92025.76-0.19 93023.07-0.84 94020.99-1.3 95017.18-2.48 96014.83-3.27 170043.451.43 1750523.2 180062.664.06 185058.753.71 190045.52.08 195035.891.28 200032.581.42 205031.841.41 210044.982.78 215055.213.72 220054.334.23 225040.463.26 230032.432.17 235032.892.11 240036.392.13 245040.462.12 250038.111.62 255044.262.77 260041.212.32 265040.181.85 270034.751.87 深圳市兴华锐科技有限公司 E-mail ： [email protected] 地址 : 深圳市龙华区大浪街道中核工业园 A 栋 1 楼传真/电话：0755-29588096 第 8 页共 19 页 深圳市兴华锐科技有限公司 E-mail ： [email protected] 地址 : 深圳市龙华区大浪街道中核工业园 A 栋 1 楼传真/电话：0755-29588096 第 9 页共 19 页 深圳市兴华锐科技有限公司 E-mail ： [email protected] 地址 : 深圳市龙华区大浪街道中核工业园 A 栋 1 楼传真/电话：0755-29588096 第 10 页 共 19 页 WIFI/BT 天线增益效率： Frequency/MhzEfficiency/ %MaxGain/dBi 240065.923.77 241066.223.95 242067.143.93 243067.923.93 244068.083.75 245069.023.75 246070.793.89 247070.963.98 248071.294.1 Frequency/MhzEfficiency/ %MaxGain/dBi 510054.73.08 520056.233.25 530051.292.81 540046.032.47 550045.191.89 560042.852.14 570042.762.05 580042.562.22 590041.592.02 深圳市兴华锐科技有限公司 E-mail ： [email protected] 地址 : 深圳市龙华区大浪街道中核工业园 A 栋 1 楼传真/电话：0755-29588096 第 11 页共 19 页 深圳市兴华锐科技有限公司 E-mail ： [email protected] 地址 : 深圳市龙华区大浪街道中核工业园 A 栋 1 楼传真/电话：0755-29588096 第 12 页共 19 页 深圳市兴华锐科技有限公司 E-mail ： [email protected] 地址 : 深圳市龙华区大浪街道中核工业园 A 栋 1 楼传真/电话：0755-29588096 第 13 页共 19 页 深圳市兴华锐科技有限公司 E-mail ： [email protected] 地址 : 深圳市龙华区大浪街道中核工业园 A 栋 1 楼传真/电话：0755-29588096 第 14 页共 19 页 分集天线增益效率： Frequency/MhzEfficiency/%MaxGain/dBi 170048.191.27 180038.730.23 190029.38-0.52 200020.28-1.54 210019.95-2.05 220027.54-0.55 230048.872.88 240066.073.78 250069.824.12 260070.634.65 270058.482.58 深圳市兴华锐科技有限公司 E-mail ： [email protected] 地址 : 深圳市龙华区大浪街道中核工业园 A 栋 1 楼传真/电话：0755-29588096 第 15 页共 19 页 深圳市兴华锐科技有限公司 E-mail ： [email protected] 地址 : 深圳市龙华区大浪街道中核工业园 A 栋 1 楼传真/电话：0755-29588096 第 16 页共 19 页 深圳市兴华锐科技有限公司 E-mail ： [email protected] 地址 : 深圳市龙华区大浪街道中核工业园 A 栋 1 楼传真/电话：0755-29588096 第 17 页共 19 页 4.安装位置 深圳市兴华锐科技有限公司 E-mail ： [email protected] 地址 : 深圳市龙华区大浪街道中核工业园 A 栋 1 楼传真/电话：0755-29588096 第 18 页共 19 页 5.可靠性实验报告 项目测试条件规格 储存环境 在没有指定的情况下测试温度、湿度、气压如下： 1.温度为-40°C～+85°C 2.相对湿度为45%-85% 3.气压为86kpa-106kpa 电气机械性能正常 高低温试验 在70°C与-40°C之间进行5次循环，然后在正常条件下 1-2H，检查外观质量。 尺寸应满足规定并 应满足满足 于机械、电气性能 耐恒定湿热 试验 相对湿度95±3%，试验温度：40°C.持续2H作用后， 试品取出后5min之内测定电气性能，试品在正常条 件下1-2H，检查外观质量 尺寸应满足规定并 应满足满足 于机械、电气性能 振动试验 振频范围10-55HZ，位移幅值：0.35MM，加速度幅值： 50.0M/S，扫频循环次数：30次 电气机械性能正常 跌落试验1M高空按照互相垂直的轴方向自由跌落3次电气机械性能正常 深圳市兴华锐科技有限公司 E-mail ： [email protected] 地址 : 深圳市龙华区大浪街道中核工业园 A 栋 1 楼传真/电话：0755-29588096 第 19 页共 19 页 产品包装规范Codeforproductpackaging 产品名称/规 一、标签要求 ************ 采购单号*************采购单号************* 物料编码*****************物料编码***************** 品名规格********品名规格******* 数量/单位*****数量/单位***** 备注*************备注************* 二、装箱要求 作业说明： 1．内包装： 产品100PCS一小袋 2．外包装： 根据实际数量定数量/箱 注意事项： 1．是否要增设隔板、珍珠棉； 2．标签的贴附，如ROHS等；

Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20240423095E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 52 FCC Part 15C Test Report FCC ID: 2A3YA-O24 Applicant: Naviter d.o.o. Address: PLANINA 3 Manufacturer: Naviter d.o.o. Address: PLANINA 3 EUT: GPS NAVIGATOR Trade Mark: NAVITER Model Number: O24 O25, O26, O31, P71, P72 Date of Receipt: Apr. 23, 2024 Test Date: Apr. 23, 2024 – May. 23, 2024 Date of Report: May. 23, 2024 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC PART 15 C 15.247 ANSI C63.10:2013 Test Result: Pass Report Number: DL-20240423095E Prepared (Test Engineer): Alisa Song Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20240423095E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 52 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 7 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 8 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 8 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 9 3 . EMC EMISSION TEST 10 3.1 CONDUCTED EMISSION MEASUREMENT 10 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 10 3.1.2 TEST PROCEDURE 10 3.1.3 DEVIATION FROM TEST STANDARD 10 3.1.4 TEST SETUP 11 3.1.5 EUT OPERATING CONDITIONS 11 3.1.6 TEST RESULTS 11 3.2 RADIATED EMISSION MEASUREMENT 14 3.2.1 RADIATED EMISSION LIMITS 14 3.2.2 TEST PROCEDURE 15 3.2.3 DEVIATION FROM TEST STANDARD 15 3.2.4 TEST SETUP 15 3.2.5 EUT OPERATING CONDITIONS 16 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 17 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 18 3.2.8 TEST RESULTS (1GHZ~25GHZ) 20 3.3 RADIATED BAND EMISSION MEASUREMENT 23 3.3.1 TEST REQUIREMENT: 23 3.3.2 TEST PROCEDURE 23 3.3.3 DEVIATION FROM TEST STANDARD 24 3.3.4 TEST SETUP 24 3.3.5 EUT OPERATING CONDITIONS 24 3.4 CONDUCTED BAND EDGE EMISSION&CONDUCTED SPURIOUS EMISSIONS MEASUREMENT 28 3.4.1 APPLICABLE STANDARD 28 3.4.2 TEST PROCEDURE 28 3.4.3 DEVIATION FROM STANDARD 28 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20240423095E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 52 Table of Contents Page 3.4.4 TEST SETUP 28 3.4.5 EUT OPERATION CONDITIONS 28 3.4.6 TEST RESULTS 28 4 . PEAK OUTPUT POWER 36 4.1 APPLIED PROCEDURES / LIMIT 36 4.1.1 TEST PROCEDURE 36 4.1.2 DEVIATION FROM STANDARD 36 4.1.3 TEST SETUP 36 4.1.4 EUT OPERATION CONDITIONS 36 4.1.5 TEST RESULTS 37 5 . NUMBER OF HOPPING CHANNEL 40 5.1 APPLIED PROCEDURES / LIMIT 40 5.1.1 TEST PROCEDURE 40 5.1.2 DEVIATION FROM STANDARD 40 5.1.3 TEST SETUP 40 5.1.4 EUT OPERATION CONDITIONS 40 5.1.5 TEST RESULTS 40 6 . BANDWIDTH TEST 42 6.1 APPLIED PROCEDURES / LIMIT 42 6.1.1 TEST PROCEDURE 42 6.1.2 DEVIATION FROM STANDARD 42 6.1.3 TEST SETUP 42 6.1.4 EUT OPERATION CONDITIONS 42 6.1.5 TEST RESULTS 43 7 . HOPPING CHANNEL SEPARATION MEASUREMENT 46 7.1 APPLIED PROCEDURES / LIMIT 46 7.1.1 TEST PROCEDURE 46 7.1.2 DEVIATION FROM STANDARD 46 7.1.3 TEST SETUP 46 7.1.4 EUT OPERATION CONDITIONS 46 7.1.5 TEST RESULTS 46 8 . DWELL TIME OF OCCUPANCY 48 8.1 APPLIED PROCEDURES / LIMIT 48 8.1.1 TEST PROCEDURE 48 8.1.2 DEVIATION FROM STANDARD 48 8.1.3 TEST SETUP 48 8.1.4 EUT OPERATION CONDITIONS 48 8.1.5 TEST RESULTS 49 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20240423095E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 52 Table of Contents Page 9 . ANTENNA REQUIREMENT 52 9.1 STANDARD REQUIREMENT 52 9.2 EUT ANTENNA 52 10 . TEST SEUUP PHOTO 52 11 . EUT PHOTO 52 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20240423095E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 52 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(c) Radiated Spurious Emission PASS 15.205 Band Edge Emission PASS 15.205, 15.247(d) Band Edge Emission& Conducted Spurious Emissions PASS 15.247(b)(1) Peak Output Power PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.247(a)(1) Hopping Channel Separation PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Test lab: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China FCC Test Firm Registration Number: 854456 Designation Number: CN1307 IC Registered No.: 27485 CAB ID.: CN0118 1.1 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% 8 6dB Bandwidth ±0.2MHz 9 PSD ±2.45dBm Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20240423095E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 6 of 52 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: GPS NAVIGATOR Trademark NAVITER Model No.: O24 O25, O26, O31, P71, P72 Model Differen…
