2A433-DT62Dog Training Collar

Model DT-62 *Please read this manual before use Package List Remote Control Charging Cable Test Light ToolLong Contact Point Hang StrapUser Manual Conductive Silicone Cap Receiver Model DT-62 *Please read this manual before use Remote Control Digital Display Vibration Mode Electric Shock Keypad Lock Channel Select Adjustable Vibration L/M/H 3levels Electric shock"+" and "-" buttons Shock Boost Beep Mode Shock Channel Display (1-2) Shock Level Display (00-99) Battery Status (Remote) Vibration Intensity Warning Vibration Sound Keypad Lock LED Status Light ON& OFF Switch Magnetic Charging Port Charging Power Indicator Not for aggressive dogs. Do not use this product if your dog is aggressive, or if your dog is prone to aggressive behavior. Aggressive dogs can cause severe injury and even death to their owner and others. If you are unsure whether this product is appropriate for your dog, please consult your veterinarian or a certified trainer. Please read the user's manual carefully before using it to avoid injury caused by improper use. The proper fit of the collar is important. A collar worn for too long or made too tight on the pet's neck may cause skin damage. Ranging from redness to pressure ulcers, which are commonly known as bed sores. • Avoid leaving the receiver on the dog for more than 12 hours per day. • When possible Reposition the receiver on your dog's neck every 1-2h. • Check the fit to prevent excessive pressure; follow the instructions in this manual. • Never connect a leash to the electronic collar; it will cause excessive pressure on the contacts. • When using a separate collar for a leash, don't put pressure on the electronic collar. • Wash the dog's neck area and the contacts of the collar weekly with a damp cloth. • Check the contact area daily for signs of a rash or a sore. • If a rash or sore is found, discontinue the use of the collar until the skin has healed. • Don't use an Adapter with an output greater than 5V1A to charge. • Avoid contact with other metals while charging, as it may cause a short circuit. Safety during on-leash training. It is vitally important that you and your dog remain safe while learning during on-leash training. Your dog should be on a strong leash, long enough for him to attempt to chase an object, but short enough for him not to reach a road or other unsafe area. You must also be physically strong enough to restrain your dog when he tries to chase. • This pet training device is not a toy, keep it away from children. Charging instructions(2h charging time): Wearing Instructions: When charging is completed, the green light will appear. Charger takes two hours respectively. Note: The Contact Points must have direct contact with the Dog’s skin on the underside of the neck. Check the tightness of the Collar by inserting one finger snugly between the collar and neck. Switch description of transmitter and Receiver: Switch lock description: Turn ON the Receiver: Hold the power button for 1 second. Turn OFF the Receiver: Hold the power button for 3 seconds. Security Keypad: Lock or unlock. Explanation of beep commands: Description of the vibration command (How to adjust the level, level description): Beep command: Delivers a beep tone with a non-adjustable volume to the collar. Vibration command: Press the vibration key, and the receiver vibrates once. Intensity adjustment: After pressing the side vibration button, adjust the vibration level (L/M/H) by the side vibration button. Instructions for the electric shock order (How to adjust the level, level instructions): Channel switching instructions: shock button: Delivers currently selected level shock Adjust the shock level level by pressing the "+" "-" on the left side of the remote control Channel switching: It is possible to train 2 dogs at the same time. Press the channel button to select a different channel. 3 Training Modes (beep, Vibration, Shock ) 3 levels vibration adjustable and 0-99 shock adjustable L M H Receiver Collar IPX7 Waterproof, Remote IPX4 Waterproof Remote Range 1600 Ft 2-Hour Rapid Charging Lithium Polymer Battery Color Eye Protection Screen + Big Digital Display Shows Support 2 Receiver Collars with One Remote Magnetic Charging Port Product Features A: Electric shock test 1. Make sure the Remote and Receiver Collar is on. 2. Hold the Test Light tool contacts to the Contact Points. 3. Press a shock button on the Remote Transmitter. The Test Light will be lighted. B: As a tool to tighten or loosen the contact points For dogs with shorter coats, use 2pcs shorter contact points. For dogs with thicker coats, use 2pcs longer contact points. Install the conductive Silicone onto the contact point to make it softer. It may be better for your dog’s skin. Long Contact Points Install the conductive Silicone cap 1. Reward your dog with food / treats will usually help to achieve the best training result. 2. Do not use the device on dogs aged below 6-month, old, pregnant, easily frightened, aggressive, in heat, and in inferior health conditions. 3. Use verbal commands first, and supplement with a corrective stimulus only as needed. Be consistent with your verbal commands, use the same words every time. Work with your pet on one behavior at a time to avoid confusion and frustration. 4. Use as little stimulus as possible and only to reinforce verbal commands when necessary. Do not over correct your dog. 5. For example, use the beep sound as warning by pressing the beep button. The dog will become conditioned to the beep preceding the corrective stimulus and will soon learn to recognize the beep as a warning along with your verbal command. 6. Do not rely on this product solely to train your dog. Some dogs will not respond to this product. We cannot guarantee the effectiveness of this or any trainer on your dog. If your dog shows signs of growling, biting or aggression while using the collar, discontinue use immediately and contact a professional trainer for advice. 7. It is recommended to trai…

Text truncated - open the document above for the full version.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: FCC US AgentLLC FRN: 0033402884 Contact Name: Tim Payne Address: 3722 Illinois AveneSaint CharlesIL60174 USA Telephone No: 708-571-3148 Email: [email protected] Applicant: Company name: Shenzhen Kensonic Intelligent Technology Co., Ltd. Product Description: Dog Training Collar Grantee code: 2A432 FCC ID: 2A433-DT62 Contact Name: Liao Xin Address: Room 401A, No. 111-2, Jinshan Mountain, Bantian Community, Bantian Street, Longgang District, Shenzhen, Guangdong Province Telephone No: 13620902251 Email: [email protected] [Shenzhen Kensonic Intelligent Technology Co., Ltd.] certifies that, as of the date of this filing of the application with the TCB, [FCC US AgentLLC] is our designated US agent for service of process for the above referenced FCC ID. [Shenzhen Kensonic Intelligent Technology Co., Ltd.] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [FCC US AgentLLC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2023-07-24 Applicant’s Name: Liao Xin US Agent’s Name: Tim Payne Title: Manager Title: Manager Signature Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Shenzhen Kensonic Intelligent Technology Co., Ltd. Grantee code: 2A433 FCC ID: 2A433-DT62 Contact Name: Liao Xin Address: Room 401A, No. 111-2, Jinshan Mountain, Bantian Community, Bantian Street, Longgang District, Shenzhen, Guangdong Province Telephone No: 13620902251 Fax No: 13620902251 Email: [email protected] i. [Shenzhen Kensonic Intelligent Technology Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Shenzhen Kensonic Intelligent Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [Shenzhen Kensonic Intelligent Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered List as an entity producing “covered”equipment . Date: 2023/07/24 Applicant’s Name: Liao Xin Title: Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Shenzhen Kensonic Intelligent Technology Co., Ltd. 1/1 Letter of Authorization Company: Shenzhen Kensonic Intelligent Technology Co., Ltd. Address: Room 401A, No. 111-2, Jinshan Mountain, Bantian Community, Bantian Street, Longgang District, Shenzhen, Guangdong Province, China Product Name: Dog Training Collar Model Number: DT-62 FCC Identifier: 2A433-DT62 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Liao Xin Date: 2023-07-24 Title: Manager Signature of applicant:

Shenzhen Kensonic Intelligent Technology Co., Ltd. 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2023-07-24 Subject: Request for Confidentiality FCC ID: 2A433-DT62 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Liao Xin Title: Manager

Size:12*8mm M/N: DT-62 FCC ID: 2A433-DT62 Label location

ANT

FCC ID: 2A433-DT62 RF Exposure Evaluation According to KDB 447498 D01 V06 and part 2.1093，Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f (GHz) ] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f (GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison EIRP=E Meas +20log(d Meas )-104.7 EIRP is the equivalent isotropically radiated power, in dBm E Meas is the field strength of the emission at the measurement distance, in dBμV/m d Meas is the measurement distance, in m Here, For 433.92MHz Field strength (dBuV/m) EIRP (dBm) Max tune-up (mW) Frequency (MHz) Min. distance(mm) Calc. thresholds limit 42.96 -52.2 0.00001 2480 5 0.000001 3.0 So a SAR test is not required

Address:402TEL:0755-23203435fax:0755-23203435,BlockC,JuxinScienceand TechnologyIndustrialPark,Nanchangcommunity,xixiang,BaoanDistrict,Shenzhen ShenzhenAihuiTechnologyCo.,Ltd. Antennaspecification AntennaSampleConfirmationFrom Nameof supplier ShenZhenAihuiTechnologyCo.，Ltd Customer name LeChang Samplename PT26-DT68TX model Samplesize Inspection item Performance test Visual inspection Structure Inthe news Test results Notes QualityAudit ProjectAudit Business confirm ation Thefollowingistobecompletedbytheclient Address:402TEL:0755-23203435fax:0755-23203435,BlockC,JuxinScienceand TechnologyIndustrialPark,Nanchangcommunity,xixiang,BaoanDistrict,Shenzhen ShenzhenAihuiTechnologyCo.,Ltd. Customer feedback Customer signature/seal date: AntennaTestReport TestUnit:ShenzhenAihuiTechnologyCo.,Ltd. Materials Spring Antenna form Monopole Polarizationmode Linear Application scenario Workingband 433MhzVSWR≤2 Address:402TEL:0755-23203435fax:0755-23203435,BlockC,JuxinScienceand TechnologyIndustrialPark,Nanchangcommunity,xixiang,BaoanDistrict,Shenzhen ShenzhenAihuiTechnologyCo.,Ltd. Power Max：2W Impedance50Ω dBi≥-1dBi TestEquipmentHPE5071C、ShieldingRoom、3Dautomaticturntable AntennaDescription:： 1.Groundingprocessingandpicturedescription:no 2.Needtochangethemotherboardtomatch:no  Testvoltage:3.6V,checktheantennacontactisgoodbeforetesting. TheRFcableoftheintegratedtesteriskeptinanaturalstateandcannotbe curled. Specification:testthespecifiedpowerlevel,allindicatorsmustconformtothe specifications. Address:402TEL:0755-23203435fax:0755-23203435,BlockC,JuxinScienceand TechnologyIndustrialPark,Nanchangcommunity,xixiang,BaoanDistrict,Shenzhen ShenzhenAihuiTechnologyCo.,Ltd. 1.ProjectImage 2.TestFixture 3.Antennamatchingcircuit 4.S11test 5.Antennapassiveefficiencyandgain 6.Darkroomtestequipmentanddata 7.Schematicdiagramofantennaassembly 8.Antennaenvironmenthandling 9.Antennamassproductionindex 10.Structuraldrawing Address:402TEL:0755-23203435fax:0755-23203435,BlockC,JuxinScienceand TechnologyIndustrialPark,Nanchangcommunity,xixiang,BaoanDistrict,Shenzhen ShenzhenAihuiTechnologyCo.,Ltd. 1.ProjectImage Thefinalverificationantennaperformanceprototypeinourcompanyforatleastoneyear, easytoanalyzeandsolvetheproblemofantennamassproduction,toensurethequality ofantennashipment 2.TestFixture Objective:totestthepassiveparametersofantennaasaccuratelyaspossible.Making Method:thehandsetismadeofa50ohmcoaxialcable,oneendofwhichisconnectedto thetestpointofthebackendofthematchingcircuitofthehandsetmotherboard(frontend oftheRFtesthole),andtheotherendisconnectedtotheSMAjoint.Thediagramisas follows: 3、Antennamatchingcircuit Modify Address:402TEL:0755-23203435fax:0755-23203435,BlockC,JuxinScienceand TechnologyIndustrialPark,Nanchangcommunity,xixiang,BaoanDistrict,Shenzhen ShenzhenAihuiTechnologyCo.,Ltd. E01E02E03 NoNoNo Note:Thematchisunmodified. 4.S11test 4.04.0s11testmethoddescriptionoftestequipment:NetworkAnalyzer(E5071C)test method:a50ohmCABLEisusedtoexportfromtheinstrumenttestport.TheSMA connectorforconnectingthehandsetiscalibratedusingacalibrationpiece,recordthe echolossandstandingwaveratiocorrespondingtotherelevantfrequencypoints.The testschematicisasfollows: Address:402TEL:0755-23203435fax:0755-23203435,BlockC,JuxinScienceand TechnologyIndustrialPark,Nanchangcommunity,xixiang,BaoanDistrict,Shenzhen ShenzhenAihuiTechnologyCo.,Ltd. 4.1SWR Address:402TEL:0755-23203435fax:0755-23203435,BlockC,JuxinScienceand TechnologyIndustrialPark,Nanchangcommunity,xixiang,BaoanDistrict,Shenzhen ShenzhenAihuiTechnologyCo.,Ltd. 5.Darkroomtestequipmentanddata 6.TestEquipment Testsystem:shieldeddarkroom Thetemperaturewas22°C±3°Candthe humiditywas50%±15% Testequipment:whentestingpassivedata,usetheNetworkanalyzerAGILENTE5071C totestactivedata,usetheomnibusCMW500 Address:402TEL:0755-23203435fax:0755-23203435,BlockC,JuxinScienceand TechnologyIndustrialPark,Nanchangcommunity,xixiang,BaoanDistrict,Shenzhen ShenzhenAihuiTechnologyCo.,Ltd. 7.Activeantennatestdata 测试数据： 433Mhz Freq(MHz)Efficiency(%)Gain(dBi) 43030.50.25 43131.40.36 43232.50.48 43333.60.52 43434.50.16 43531.60.19 43632.50.21 43730.5-0.15 43829.50.14 Address:402TEL:0755-23203435fax:0755-23203435,BlockC,JuxinScienceand TechnologyIndustrialPark,Nanchangcommunity,xixiang,BaoanDistrict,Shenzhen ShenzhenAihuiTechnologyCo.,Ltd. 8.Schematicdiagramofantennaassembly 9.Antennaenvironmenthandling 10.Antennamassproductionindex Whentheantennais mass-produced,the standingwaveratiois takenasthe mass-producedtest standard.Basedonthe differencesoftheproject itself,thefollowingcriteria aregiven: Standardforvolume production 824Mhz-2170Mhz VSWR(MassProduction performance)< Address: 402TEL: 0755-23203435fax: 0755-23203435, Block C, Juxin Science and Technology Industrial Park, Nanchang community, xixiang, Baoan District, Shenzhen Shenzhen Aihui Technology Co. , Ltd. VSWR(recognition performance) 0.5 10.1 Structuraldrawings（mm）

Test Report Number: BTF230718R00901 Te s t R e p o r t Te l : + 8 6-0 7 5 5-2 3 1 4 6 130 Em a il: R y a n . c j @ b t f-l a b . c o m P a g e 1 o f 36 FCC Part 15C Test Report FCC ID: 2A433-DT62 Applicant: Shenzhen Kensonic Intelligent Technology Co., Ltd. Address: Room 401A, No. 111-2, Jinshan Mountain, Bantian Community, Bantian Street, Longgang District, Shenzhen, Guangdong Province Manufacturer: Shenzhen Kensonic Intelligent Technology Co., Ltd. Address: Room 401A, No. 111-2, Jinshan Mountain, Bantian Community, Bantian Street, Longgang District, Shenzhen, Guangdong Province EUT: Dog Training Collar Trade Mark: Jugbow Model Number: DT-62 Date of Receipt: Jul. 06, 2023 Test Date: Jul. 06, 2023 - Jul. 13, 2023 Date of Report: Jul. 13, 2023 Prepared By: BTF Testing Lab (Shenzhen) Co., Ltd. Address: F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China Applicable Standards: FCC PART 15 C 15.231 ANSI C63.10:2013 Test Result: Pass Report Number: BTF230718R00901 Project Engineer: Elma.yang EMC Manager: Ryan.CJ This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of BTF Testing Lab (Shenzhen) Co., Ltd. Test Report Number: BTF230718R00901 Te s t R e p o r t Te l : + 8 6-0 7 5 5-2 3 1 4 6 130 Em a il: R y a n . c j @ b t f-l a b . c o m P a g e 2 o f 36 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 5 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 6 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 6 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 6 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 7 3 . EMC EMISSION TEST 8 3.1 CONDUCTED EMISSION MEASUREMENT 8 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 8 3.1.2 TEST PROCEDURE 8 3.1.3 DEVIATION FROM TEST STANDARD 8 3.1.4 TEST SETUP 9 3.1.5 EUT OPERATING CONDITIONS 9 3.1.6 TEST RESULTS 9 3.2 RADIATED EMISSION MEASUREMENT 12 3.2.1 RADIATED EMISSION LIMITS 12 3.2.2 TEST PROCEDURE 13 3.2.3 DEVIATION FROM TEST STANDARD 13 3.2.4 TEST SETUP 14 3.2.5 EUT OPERATING CONDITIONS 15 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 16 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 17 3.2.8 TEST RESULTS (1GHZ~25GHZ) 20 4 . BANDWIDTH TEST 21 4.1 APPLIED PROCEDURES / LIMIT 21 4.1.1 TEST PROCEDURE 21 4.1.2 DEVIATION FROM STANDARD 21 4.1.3 TEST SETUP 21 4.1.4 EUT OPERATION CONDITIONS 21 4.1.5 TEST RESULTS 22 5 . CALCULATION OF AVERAGE FACTOR 23 5.1 APPLIED PROCEDURES / LIMIT 23 5.1.1 TEST PROCEDURE 23 5.1.2 TEST SETUP 23 5.1.3 EUT OPERATION CONDITIONS 23 5.1.4 TEST RESULTS 24 Test Report Number: BTF230718R00901 Te s t R e p o r t Te l : + 8 6-0 7 5 5-2 3 1 4 6 130 Em a il: R y a n . c j @ b t f-l a b . c o m P a g e 3 o f 36 Table of Contents Page 6 . TRANSMISSION CEASE TIME 25 6.1 APPLIED PROCEDURES / LIMIT 25 6.1.1 TEST PROCEDURE 25 6.1.2 DEVIATION FROM STANDARD 25 6.1.3 TEST SETUP 25 6.1.4 EUT OPERATION CONDITIONS 25 6.1.5 TEST RESULTS 26 7 . ANTENNA REQUIREMENT 27 7.1 STANDARD REQUIREMENT 27 7.2 EUT ANTENNA 27 8 . TEST SEUUP PHOTO 28 9 . EUT PHOTO 30 Test Report Number: BTF230718R00901 Te s t R e p o r t Te l : + 8 6-0 7 5 5-2 3 1 4 6 130 Em a il: R y a n . c j @ b t f-l a b . c o m P a g e 4 o f 36 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.231) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.209,15.231b Fundamental &Radiated Spurious Emission Measurement PASS 15.231a Transmission cease time PASS 15.215 20dB Bandwidth PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2,providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Test Report Number: BTF230718R00901 Te s t R e p o r t Te l : + 8 6-0 7 5 5-2 3 1 4 6 130 Em a il: R y a n . c j @ b t f-l a b . c o m P a g e 5 o f 36 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: Dog Training Collar Trademark Jugbow Model No.: DT-62 Model Difference N/A Operation Frequency: 433.92MHz Channel numbers: 1 Channels Modulation technology: FSK Antenna Type: Internal Antenna Antenna gain: 0.52dBi Power supply: DC 3.7V from battery DC 5V from adapter Note: 1.For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2.The EUT’s all information provided by client. 2.2 DESCRIPTION OF TEST MODES Note: (1) New battery is used during the test To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 TX Mode For Conducted & Radiated Emission Final Test Mode Description Mode 1 TX Mode Test Report Number: BTF230718R00901 Te s t R e p o r t Te l : + 8 6-0 7 5 5-2 3 1 4 6 130 Em a il: R y a n . c j @ b t f-l a b . c o m P a g e 6 o f 36 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED Radiated Spurious Emission Test Conducted Spurious Emission Test 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representat…

Text truncated - open the document above for the full version.

Radiated Measurement Photos Conducted Measurement Photos
