2A48C-GX60Wireless presenter

Do not repair or replace any part of the machine yourself (unless specifically instructed in this manual). Please complete the repairs to your dealer or authorized agent. 2 Laser hole 3 LED indicator 1 Switch 11 volume - 10 volume + 8 USB-A Receiver 4 Hyperlink/Enter 5 Page up/Full screen 6 Page down/Black screen 7 Laser button Instructions for use This product is an electronic product specially designed for computers and multimedia projection. In addition to the traditonal laser pointer function, it can also remotely turn the computer remotely by simple pressing the page up and down buttons. Operation, users can move freely in the classroom or presentation hall, closer to the audience, increase good interaction, freely flip the page in a static state, and get wonderful results. Widely used in product demonstrations, e-learning, conferences and training and many other occasions. Product Introduction Insert the bottom receiver into the computer with USB interface after putting the battery into the product, then open the button on the product, open the PPT file at the same time, and point at the curtain or other display device to start the demonstration. Function Description Product specifications (1) Do not disassemble, bump, crush or throw it into fire! (2) If severe swelling occurs, do not continue to use it! (3) Do not place in high temperature environment! (4) Donnot use the laser to directly shine on yourself or others’ eyes, otherwise it will cause serious damage to the eyes! Cautions (1) Main material: ABS (2) Working frequency:2400-2490MHz (3) Laser control distance:<200m (4) Remote control distance:50m+ (5) Laser color: red laser (6) Laser wavelength:635-650nm (7) Battery type: 1pcs AAA battery (8) Operating system: Windows, Mac OS, Linux, etc (9) Compatible interfaces: USB-A interface (10) Product size: 131*19*13mm (±2mm ) lnstruction PRESENTER 激光遥控翻页笔说明书 使用产品之前,请仔细阅读本说明书，并 妥善保管以供日后参考。 本产品是专门为电脑及多媒体投影设计的一款电子产品，它 除了具有传统的镭射教鞭的功能之外，还可以通过简单地按动上 下翻页按钮，以无线的方式遥控电脑进行远程的翻页操作。广泛 用于产品演示，电化教学，会议及培训等众多场合。 产品简介 将电池放入产品中后，将底部接收器插入USB接口的电脑 上，打开产品的开关键，同时打开PPT文件，对准幕布或者其 他显示设备即可开始演示。 功能说明 1.禁止拆卸、撞击、积压或投入火中！ 2.若出现严重膨胀，请勿继续使用！ 3.请勿至于高温环境中！ 4.禁止将激光直射自己或他人的眼睛，否则会对眼睛造成严重损伤！ 警告事项 产品规格 1.主要材质：ABS 2.工作频率：2400-2490MHz 3.激光距离：<200m 4.遥控距离：50m+ 5.激光颜色：红光 6.激光波长：635-650nm 7.电池类型：1 pcs 7号 电池 8.支持系统： Windows,Mac OS,Linux等 9.兼容接口：USB-A接口 10.产品尺寸：131*19*13mm (±2mm ) 请勿自行对本机器进行维修，或是更换其中任何零件（除非 本手册有特别指示相关做法）。请将维修事宜完全交给您的经销 商或是授权代理商。 2 激光出口 3 指示灯 1 开关键 10 音量+ 11 音量- 8 USB-A接收器 4 单击选中超链接 双击打开超链接 5 单击上翻页 长按全屏/退出全屏 6 单击下翻页,长按黑屏 (仅在全屏模式下可黑屏) 7 激光按键 使用说明 lnstruction PRESENTER Wireless Presenter Before using the product, please read this manual carefully and Keep it properly for future reference. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) thi s device may not cause harmful interference, and (2) thi s device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance co ul d void the user's authority to operate the equipment. NOTE: This equipment has bee n tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed t o provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or r elocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be u sed in portable exposure condition without restriction

DONGGUAN GUANGXIN ELECTRONIC CO.,LTD Model Difference Product description:Wireless presenter Model name: GX60,GX08, GX15, GX22, GX37-G, GX53, GX37, GX71, GX75, GX76, GX79 Trade Name: KTPYRP FCC ID: 2A48C-GX60 All the model are the same circuit and RF module, only for model name. Regards Sincerely Client’s signature: Client’s name / title : Xiang lei(manager) Contact information / address: 703a, Minghe dianzi guangchang Aqu 7 Lou A703a,Changan zhen Shangsha Shequ S358 Shengdao ,Donguan City,Guangdong Province.

C5266091_X8_Ed.1 1/1 Letter of Authorization DONGGUAN GUANGXIN ELECTRONIC CO.,LTD Company:DONGGUAN GUANGXIN ELECTRONIC CO.,LTD Address: 703a, Minghe dianzi guangchang Aqu 7 Lou A703a,Changan zhen Shangsha Shequ S358 Shengdao ,Donguan City,Guangdong Province. Product Name:Wireless presenter Model Number: GX60,GX08, GX15, GX22, GX37-G, GX53, GX37, GX71, GX75, GX76, GX79 FCC Identifier: 2A48C-GX60 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name:Xiang lei Date: 2022.03.01 Title: manager Signature of applicant:

C5266091_X10_Ed.2 1/1 DONGGUAN GUANGXIN ELECTRONIC CO.,LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2022.03.01 Subject: Request for Confidentiality FCC ID: 2A48C-GX60 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, C5266091_X10_Ed.2 1/1 Signature: Name: Xiang lei Title: manager

External Photos

Model:GX60 FCC ID:2A48C-GX60 Label Location

Internal Photos ANT

Shenzhen CTB Testing Co., Ltd. FCC ID: 2A48C-GX60 Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.404-7.7280.17-7±1-6.000.25<50.077893.00YES 2.24-7.9070.16-7±1-6.000.25<50.075193.00YES 2.530-7.9930.16-7±1-6.000.25<50.079913.00YES GFSK Conclusion: For the max result : 0. 07991W/Kg ≤ FCC Limit 3.0 for 1g SAR.

Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB220301026RFX TEST REPORT Compiled by: Reviewed by: Approved by: Chen Zheng Arron Liu Bin Mei / Director The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen CTB Testing Technology Co., Ltd. this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. Product Name: Wireless presenter FCC ID: 2A48C-GX60 Trademark: UBUYONE Model Number: GX60, GX08, GX15, GX22, GX37-G, GX53, GX37, GX71, GX75, GX76, GX79, GX60B Prepared For: DONGGUAN GUANGXIN ELECTRONIC CO., LT D Address: 703a, Minghe dianzi guangchang Aqu 7 Lou A703a, Changan zhen Shangsha Shequ S358 Shengdao, Donguan City, Guangdong Province, China Manufacturer: DONGGUAN GUANGXIN ELECTRONIC CO., LT D Address: 703a, Minghe dianzi guangchang Aqu 7 Lou A703a, Changan zhen Shangsha Shequ S358 Shengdao, Donguan City, Guangdong Province, China Prepared By: Shenzhen CTB Testing Technology Co., Ltd. Address: Floor 1&2, Building A, No. 26 of Xinhe Road, Xinqiao Community, Xinqiao Street, Baoan District, Shenzhen, Guangdong China Sample Received Date: Feb. 23, 2022 Sample tested Date: Feb. 23, 2022 to Mar. 1, 2022 Issue Date: Mar. 1, 2022 Report No.: CTB220301026RFX Te s t Standards FCC Part15.247 ANSI C63.10:2013 Test Results PASS Remark: This is 2.4G radio test report. Report Tel: 4008-707-283Web: http://www.ctb-lab.net Page 1 of 35 Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB220301026RFX TABLE OF CONTENT Test Report Declaration Page 1. VERSION ...................................................................................................... 4 2. TEST SUMMARY ........................................................................................... 5 3. MEASUREMENT UNCERTAINTY .................................................................. 6 4. PRODUCT INFORMATION AND TEST SETUP ............................................... 7 4.1 Product Information ............................................................................................. 7 4.2 Test Setup Configuration ..................................................................................... 7 4.3 Support Equipment .............................................................................................. 7 4.4 Channel List ........................................................................................................ 8 4.5 Test Mode ........................................................................................................... 8 4.6 Test Environment ................................................................................................ 8 5. TEST FACILITY AND TEST INSTRUMENT USED .......................................... 9 5.1 Test Facility ......................................................................................................... 9 5.2 Test Instrument Used .......................................................................................... 9 6. AC POWER LINE CONDUCTED EMISSION ................................................... 12 6.1 Block Diagram Of Test Setup ............................................................................ 12 6.2 Limit ................................................................................................................... 12 6.3 Test procedure .................................................................................................. 12 6.4 Test Result ........................................................................................................ 14 7. RADIATED SPURIOUS EMISSION............................................................... 15 7.1 Block Diagram Of Test Setup ............................................................................ 15 7.2 Limit ................................................................................................................... 15 7.3 Test procedure .................................................................................................. 16 7.4 Test Result ........................................................................................................ 17 8. BAND EDGE AND RF COUNDUCTED SPURIOUS EMISSIONS ................... 24 8.1 Block Diagram Of Test Setup ............................................................................ 24 8.2 Limit ................................................................................................................... 24 8.3 Test procedure .................................................................................................. 24 8.4 Test Result ........................................................................................................ 25 9. COUDUCTED PEAK OUTPUT POWER ........................................................ 27 9.1 Block Diagram Of Test Setup ............................................................................ 27 Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 35 Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB220301026RFX 9.2 Limit ................................................................................................................... 27 9.3 Test procedure .................................................................................................. 27 9.4 Test Result ........................................................................................................ 28 10. 6DB OCCUPIED BANDWIDTH ..................................................................... 30 10.1 Block Diagram Of Test Setup .......................................................................... 30 10.2 Limit ................................................................................................................. 30 10.3 Test procedure ...................................................................................…

Text truncated - open the document above for the full version.

Radiated Emissions Below 1G Above 1G
