2A49V-QE02BPORTABLE POWER STATION

便携储能电源使用手册 Portable Power Station User Manual 安全指引 • 本产品不适合儿童使用。 • 如果有其他人使用本产品，应确保他们已充分了解如何安全使用本产品，并已阅读和理解本使用手册。 • 在使用本产品前，请拆卸掉所有的外包装并解开线缆。 • 请勿私自拆卸本产品，避免造成未知危险发生，如果需要维修，请联系客服寻求帮助。 • 如果本产品受到猛烈的打击、摔落或以其它任何方式损坏，请勿操作本产品，并将其交给合格的服务人员。 • 请勿将本产品靠近热源，如火源或加热炉。 • 请勿在易燃气体或易燃液体附近使用本产品。 • 请勿将本产品放置在易燃物品上，如地毯、室内装潢、纸张、纸板等。在设备运行时, 请远离容易受高温影响的物品，如毛毯、枕头、 床褥等。 • 请勿让产品接触任何液体，请勿将本产品浸入水中或将其弄湿。请勿在雨中或者潮湿的环境中使用本产品。 • 本产品在使用过程中会发热，必须适当通风。请确保本产品四周至少有7.5厘米以上的空隙。 • 使用本产品时，请严格遵循本使用手册的使用环境温度。温度过高，可能会引起电池起火，甚至爆炸；温度过低，产品性能将会严重 降低，甚至无法正常使用。 • 本产品在使用或储存过程中出现异味，异常发热等情况，请立即关机，并放置在空旷的地方远距离观察，确认安全后，联系厂家或者 经销商。 • 请勿在本产品上堆放其它重物。 • 请勿在使用过程中强行堵转风扇，或让本产品处于不通风或多尘的空间内。 • 请勿在强静电或者强磁场环境中使用本产品。 • 请勿在海拔超过2000m环境下使用本产品。 • 本产品AC交流输出220V，请勿将手或者手持金属导体插入AC电源插座。 • 请勿将本产品输出短路。 • 本产品为供电电源，请根据用电设备功率匹配相应型号，禁止超功率、超负荷使用本产品。 • 请勿用已损坏的电源线或插头操作本产品。如有损坏，请立即更换电源线或插头。 • 请勿用已损坏的充电线给本产品充电。 • 本产品请用配备的适配器充电。 • 请按照本使用手册规定的电气参数选择太阳能板充电。 • 为了降低触电的风险，在进行任何维护或清洁之前,请先关机及拔掉产品上的所有插头。 在使用产品前，请阅读本产品的使用手册，并确保在完全理解后正确使用。阅读后，请将使用手册妥善保管以备日后参 考。如果没有正确操作本产品，您可能会对自身或他人造成严重伤害，或者导致产品和财物损失。一旦开始使用本产品，即视 为您已理解、认可和接受本手册全部条款和内容。使用者承诺对自己的行为及因此产生的所有后果负责。制造商不承担因用户 未按《使用手册》使用产品所引发的一切损失。 在遵从相关法律法规的情况下，制造商享有对本手册及本产品所有相关文档的最终解释权。 如有更新、改版或终止，恕不另行通知。 免责声明 障。本产品具有多端口交流输出与直流输出功能，可满足手机、笔记本电脑、摄像机、电视机、各种充电器、游戏机、影碟 机、小型电动工具等设备的供电需求，同时内置了LED照明灯。 非常感谢您使用本公司研制的便携储能电源。本产品在设计上，采用了多级安全机制，产品安全性和可靠性具有充分保 产品概述 包装清单 使用手册 电源适配器 便携储能电源 规格参数 产品示意图 1. 显示屏 2. DC充电口 3. AC电源开关 4. AC电源插座*2 * 本产品AC电源插座、AC输出电压与频率因国家或地区的不同会作变更，请以实物为准！ 5. DC开关 6. 车充口 7. DC输出口*2 8. USB开关 9. USB-C 10. USB-A1 11. USB-A2 & USB-A3 12. LED开关(一键关机) 13. LED照明灯 14. 无线充电 1. 电量格/充电状态 2. 剩余电量 3. 放电剩余时间/充放电状态 显示屏 4. 高低温保护警告 5. AC输出 6. DC输出 注意： a. 不使用本产品时，请及时关闭显示屏 b. 长按LED开关可以一键关机 7. USB输出 8. 无线充电输出 9. AC输出频率(50Hz) 12 3 4 56789 3 2 9 10 11 8 6 7 1 5 4 13 12 14 基本 参数 输出 电池 规格 输入 使用 环境 型号 容量 尺寸(长×深×高) 净重 DC充电 USB-C充电 额定电压 USB-A*3 USB-C 5525*2 车充 无线充电 LED照明灯 循环寿命 保护类型 充电温度 放电温度 QE01A(CN) 500Wh, 14.8V, 33.8Ah 306×171×202(mm) 约4.8Kg 12V～30V⎓3.42A 65W(Max) 5V⎓3.0A/9V⎓3.0A/12V⎓3.0A/15V⎓3.0A/20V⎓3.25A 65W(Max) 220V/50Hz(纯正弦波) USB-A1:5V⎓3.0A/9V⎓2.0A/12V⎓1.5A 18W(Max), USB-A2 & USB-A3:5V⎓2.4A 12W(Max) 5V⎓3.0A/9V⎓3.0A/12V⎓3.0A/15V⎓3.0A/20V⎓3.25A 65W(Max) 12～16.8V⎓7～10A, 共享功率120W(Max) 5V⎓1.0A/9V⎓1.0A 10W(Max) 2W 800次 高温保护、低温保护、过压保护、欠压保护、过载保护、短路保护、过流保护 0°C～40°C -10°C～40°C 名称 便携储能电源 QE01B(CN)QE02A(CN)QE02B(CN) 448Wh, 16V, 28Ah 1065.6Wh, 22.2V, 48Ah 1008Wh, 22.4V, 45Ah 413×203×232(mm) 约5.6Kg约9.1Kg约10.2Kg 12V～30V⎓7A 182W(Max) 额定功率 共享功率 500W(Max) AC 输出*2 共享功率 600W(Max) 共享功率 1000W(Max) 共享功率 1200W(Max) 13～18V⎓7～10A, 共享功率130W(Max) 13.6V⎓10A , 共享功率136W(Max) 3000次800次3000次 使用AC交流输出 长按AC电源开关，开启或关闭AC电源插座 1. 将交流用电设备连接到AC电源插座(在插头插入AC电源插座前，请确保用电设备处于关闭状态)。 2. 长按AC电源开关，开启AC电源插座，显示屏会显示AC输出符号。 3. 使用完毕后，长按AC电源开关，关闭AC电源插座，并将用电设备插头从AC电源插座拔出。 * 当不使用本产品AC输出供电时，请关闭AC电源插座以便节能。 • • 请勿将其它交流电源连接到本产品AC电源插座上。 • 请勿将适配器插头插到本产品AC电源插座上对自己充电。 • AC输出发生短路或者负载电器功率超过本产品AC输出功率时，将触发本产品保护功能，请先排除 短路或者移除电器设备后，重新开关机，以恢复AC输出功能。 不同国家或地区的AC电压标准和插座规格不同，使用前请务必确认本产品是否与用电设备规格相符。 注意： 充放电 • • 充电时，本产品会先进行初始化，显示屏上的所有符号会亮起，自检正常后，进入充电模式，显示屏长亮显示“CH” (charging)，充满显示“FU”(full)。 • 请勿用本产品输出端对自己充电。 • 放电时，会显示当前放电剩余时间，并根据负载大小自动调整剩余时间，电池放完电后会自动熄屏。 • 请勿将内部电池完全放电，以免影响电池寿命。 • 当显示屏出现高低温保护警告符号时，请暂停使用并立即关机。 建议购买后立即充电。电池剩余电量低于20%时请立即充电，以保持最佳性能，延长使用寿命。 使用DC直流输出 短按DC开关，开启或关闭DC直流输出 DC输出口： 1. 将用电设备DC直流插头插入本产品的DC输出口，然后按下DC开关，开启DC直流输出，显示屏会显示DC输出符号。 2. 使用完毕后，按下DC开关，关闭本产品DC直流输出，并将用电设备插头从DC输出口抜出。 车充口： 1. 将车充插头插入本产品车充口，按下DC开关，开启DC直流输出，显示屏会显示DC输出符号。 2. 使用完毕后，按下DC开关，关闭本产品DC直流输出,并将车充插头从车充口拔出。 使用USB输出 短按USB开关，开启或关闭USB输出 1. 将USB线插头插入本产品USB-A端口或USB-C端口，然后按下USB开 关，开启USB输出，显示屏会显示USB输出。 2. 使用完毕后，按下USB开关，关闭本产品USB输出，并将USB线插头 从本产品USB-A或USB-C输出端口拔出。

使用无线充电 1. 长按USB开关，开启无线充电功能，显示屏会显示无线充电输出符号。 2. 将待充电设备置于顶部中心位置进行无线充电，对于不同的充电设备 可能需要适当调整充电位置。 3. 使用完毕后，长按USB开关，可关闭无线充电功能。 使用LED照明灯 1. 短按LED开关 ，开启LED照明灯功能。 2. 短按LED开关，可以依次切换LED模式：弱、中、强、SOS、爆闪、关闭。 使用一键关机 长按LED开关，可以一键关机(关闭所有已开启功能)，显示屏会关闭。 适配器充电 1. 将配备的适配器圆充电插头插入本产品的DC充电口， 再将适 配 器 电 源插头插 入 市 电插座，充电开始。 2. 充电完成后，请从市电插座拔下适配器电源插头，再 从DC充电口拔下圆充电插头。 USB-C充电 1. 将USB-C充电线连接到本产品USB-C口，再将USB-C充电线另一端 插入USB充电插座，充电开始。 2. 充电完成后，请从USB-C口拔下USB-C充电线。 3. USB-C充电可与电源适配器充电/太阳能充电/车充充电同时进行。 注意：请勿将适配器电源线插头插到本产品AC电源插座上对自己充电。 注意：请勿用本产品输出端对本产品USB-C口进行充电。 太阳能充电（选配） 1. 将太阳能充电板放置于阳光直射处。(注：请勿将本产品曝露在阳光直射下或潮湿的环境中) 2. 将太阳能充电板输出圆插头(5.5mm)连接到本产品DC充电口，充电开始。 3. 充电完成后，请从DC充电口拔下太阳能充电板的圆插头。 车充充电（选配） 1. 将 车 充充电线圆插头(5.5mm)连 接 到本产品DC充 电 口 ， 再 将车充插 头 插 入车辆12V车充口，充电开始。 2. 充电完成后，请先拔下车充插头，再从DC充电口拔下圆充电插头。 注意：请勿将汽车充电器插头插到本产品车充口上对自己充电。 1 . 产品开机无反应，DC，USB，AC，LED照明灯均无输出。解决办法： • 将用电设备全部移除，然后充电5- 10分钟，重新开机。 • 请确保产品当前处于正常温度范围内使用。 2 . 产品能开机，但是对应输出的接口无输出(DC，USB，AC)。解决办法： • 检查产品电量是否过低，如果是请及时充电。 • 检查用电设备是否高出本产品的输出功率导致保护，移除负载，重新开机。 • 确认本产品输出是否满足用电设备电源要求。 • 检查输出端口到用电设备之间是否短路，移除设备后重新开机 • 将设备用其它电源上看是否正常使用，可能个别设备不兼容导致。 3 . 产品使用过程中意外关机。解决办法： 内部保护系统启动导致产品关机，可能导致保护系统启动的事件有过充，过放，高温，低温，过流，短路。为了快速解决问题，请撤 掉所有用电设备，保持产品温度在正常温度范围内静置，给产品充电5-10分钟。 同时检查用电设备是否存在故障。然后重新开机。 4 . 产品无法进行充电。解决办法： • 请确认充电电气参数是否与本产品充电范围之内。 检查当前设备是否因为温度过高或过低而启动了温度保护。 故障排除 • 推荐在20°C至30°C的环境下使用或存储本产品，远离水源、热源，以及其它金属物件。 • 安全起见，请勿将本产品存储在高于45°C或者低于-20°C的环境中。 • 如需长期存储，请每隔3个月为本产品充放电1次(即先将本产品放电至30%，然后再充电至60%)。 • 若本产品使用完毕后电量低于1%，请充电至60%再存放。若在电量严重不足的情况下长时间闲置，会造成电芯不可逆转的损坏，缩短 本产品使用寿命。 维护和保养 Q：产品可以存放多久？ A：充满电可存放6个月，建议每三个月充电一次。 常规问题解答 Q：产品有温度保护吗？ A：充电时内部温度高于55°C会保护，放电时内部温度高于60°C会保护。 Q：产品充满电需要多久？ A：用配备的适配器从3%充电到90%约6小时，9小时左右可以充满。 Q：可以同时用DC充电口和USB-C口对产品充电吗？ A：可以同时充电，充电时间会缩短。 Q：产品可以边充电边使用吗？ A：本产品支持边充电边使用。当输出功率大于充电功率时，电池电量会减少，减少至低电量状态时，会关闭输出。 Q：产品会自动关机吗？ A：如产品在极低功耗的使用情况下，AC电源插座半小时后可能会关闭，DC和USB不会关闭；产品完全放电后，会自动关机。 Q：产品可以用于启动汽车吗？ A：产品不能直接用于启动汽车。但可以另外选配充电线给汽车启动电瓶充电，在产品电量≥20%时，一般充电 5- 10分钟后，可以启动汽车。 Q充满电后，电量百分比与FU未同步显示或有误差，是否正常？ A：正常现像，充满电后，显示FU，但电量百分比有可能显示99% 。 ： 尊敬的用户，感谢您使用本公司生产的产品。我们将为您提供不低于国家三包政策的售后服务，服务内容如下： 自购买之日起7日内，因产品质量问题可退货；30日内因质量问题可换货；保修期内享受免费保修服务，保修期为12个月。 为保障您的合法权益，请注意以下事项： • 购买时须由销售单位开立有效购买凭证。 • 保修卡及购买凭证应由用户妥善保管，遗失不补。 • 若本产品发生非人为原因造成的故障，用户可凭保修卡和购买凭证，在保修期内到客户服务中心进行免费维修。 售后服务说明 在用户使用的过程中，符合下列情况之一者不在保修范围内： 1. 超过保修有效期。 2. 在使用过程中因产品跌落或水浸而造成损坏。 3. 由于擅自拆卸，改装等人为原因造成的故障。 4. 由于使用环境不符合产品要求而造成的故障。 5. 由于不可抗因素（如火灾、地震、雷击等）而造成的故障或损坏。 6. 未按使用手册中的要求使用而造成的损坏。 7. 保修卡或购机凭证与产品序列号不符，或者被涂改。 8. 产品SN条码被撕掉或被损坏，模糊不清无法识别。 尊敬的用户，感谢您使用本公司生产的产品。为了能更好地为您服务，在购买产品后，请您阅读、填写并妥善保存此保修卡。 保修卡 用户信息 用户姓名： 电子邮件： 用户地址： 联系电话： 邮政编码： 产品信息 产品型号：产品序列： 销售信息 购买日期： 销售单位： 销售地址： 发票号码： 联系电话： 检验员：01 执行标准：Q/QSSJ003-2022 产品合格证 QC PASS 检01

Safety Guidelines A photovoltaic panel as an input for charging the internal batter y shall be provided with an inverter and/or a charge controller in accordance with UL 1741 or UL 62109-1; The external power supply shall be a power source in accordance with the Standard UL 60950-1 and CAN/CSA C22.2 No. 60950-1, or UL 1310 and No. 1, CAN/CSA C22.2 No. 223, or No.1, CAN/CSA C22.2 No. 223; A vehicle adapter that complies with the enclosure and input contacts requirements in the Standard for Vehicle Batter y Adapters, UL 2089, and Power Supplies, CAN/CSA C22.2 No. 107.1. The connector plug shall incorporate a fuse or other protective device having a current rating not greater than 15 A. INSTRUCTIONS PERTAINING TO RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS IMPORTANT SAFETY INSTRUCTIONS 1. WARNING – When using this product, basic precautions should always be followed, including the following: a) Read all the instructions before using the product. b) To reduce the risk of injur y, close super vision is necessar y when the product is used near children. c) Do not put fingers or hands into the product. d) Use of an attachment not recommended or sold by power pack manufacturer may result in a risk of fire, electric shock, or injur y to persons. e) To reduce risk of damage to the electric plug and cord, pull the plug rather than the cord when disconnecting the power pack. f ) Do not use a batter y pack or appliance that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behavior resulting in fire, explosion or risk of injur y. g) Do not operate the power pack with a damaged cord or plug, or a damaged output cable. h) Do not disassemble the power pack, take it to a qualified ser vice person when ser vice or repair is required. Incorrect reassembly may result in a risk of fire or electric shock. I) To reduce the risk of electric shock, unplug the power pack form the outlet before attempting any instructed ser vicing. j) WARNING – RISK OF EXPLOSIVE GASES. 1) To reduce risk of batter y explosion, follow these instructions and those published by batter y manufacturer and manufacturer of any equipment you intend to use in vicinity of the batter y. Review cautionar y marking on these products and on engine. k) PERSONAL PRECAUTIONS 1) Have plenty of fresh water and soap nearby in case batter y acid contacts skin, clothing, or eyes. 2) Wear complete eye protection and clothing protection. Avoid touching eyes while working near batter y. 3) If batter y acid contacts skin or clothing, wash immediately with soap and water. If acid enters eye, immediately flood eye with running cold water for at least 10 minutes and get medical attention immediately. 4) NEVER smoke or allow a spark or flame in vicinity of batter y or engine. 5) Be extra cautious to reduce risk of dropping a metal tool onto batter y. It might spark or short-circuit batter y or other electrical part that may cause explosion. l) When charging the internal batter y, work in a well ventilated area and do not restrict ventilation in any way. m) Under abusive conditions, liquid may be ejected from the batter y; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the batter y may cause irritation or burns. n) Do not expose a power pack to fire or excessive temperature. Exposure to fire or temperature above 130°C may cause explosion. The temperature of 130°C can be replaced by the temperature of 265°F. o) Have ser vicing performed by a qualified repair person using only identical replacement parts. This will ensure that the safety of the product is maintained. SAVE THESE INSTRUCTIONS This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. FCC Radiation Exposure Statement Q: How long can the product be stored? A: It can be stored for 6 months when fully charged. It is recommended to charge it ever y three months. General Questions And Answers Q: Does the product have temperature protection? A: When the internal temperature is higher than 55 °C during charging, it will be protected; when the internal temperature is higher than 60 °C during discharging, it will be protected. Q: How long does it take for the product to be fully charged? A: Charge from 3% to 90% with the original adapter for about 6 hours, and it can be fully charged in about 9 hours. Q: Can you charge the product with DC charging port and usb-c port at the same time? A: It can be charged at the same time, and the charging time will be shortened. Q: Can the product be used while charging? A: It can be used while charging. When the output power is greater than the charging power, the batter y power will be reduced. When it is reduced to a low power state, the output will be turned off. Q: Will the product shut down automatically? A: It will not shut down automatically until it is fully discharged. Under normal circumstances, it will not shut down automatically after power on. Q: Can the product be used to start the car? A: It cannot be directly used to start the car. However, another charging line can be selected to charge the starting batter y of the car. When the power of the product is ≥ 20%, the car can be started after charging for 5-10 minutes. Q: After being fully charged, the power percentage and Fu are not displayed synchronously or have errors. Is it normal? A: Normal image: "Fu" will be displayed when fully charged, but the power percentage may be 99%. This device complies with Part 18 of the FCC Rules. Refer to FCC Part 18.213(c)and KDB 784748 Anner A section A.5: (a)Max.Electric Field Emissions:5.37V/m Max. Magnetic Field Emissions:0.43V/m (b) The maintenance of the system is the responsibility of the manufacturer. (c) To prevent interference, the product should be as far away from devices operating at…

Text truncated - open the document above for the full version.

DC Output Press the DC switch to turn on or off the DC output DC output port: 1. Insert the DC plug of the electrical device into the DC output port of this product, then press the DC switch to turn on the DC output, and the display screen will show DC output. 2. After use, press the DC switch to turn off the DC output, and pull the plug of electrical device out of the DC output port. Car charging port: 1. Insert the car charger plug into the car charger port, press the DC switch to turn on the DC output, and the display screen will show DC output. 2. After use, press the DC switch to turn off the DC output, and pull the plug of electrical device out of the car charger port. USB Output Press the USB switch to turn on or off the USB output 1. Insert the USB cable plug into the USB-A port or USB-C port of the product, then press the USB switch to turn on the USB output, and the display screen will show USB output. 2. After use, press the USB switch to turn off the USB output, and pull the USB cable plug out of the USB-A or USB-C output port. AC Output Press and hold the AC power switch to turn on or off the AC power socket 1. Connect the AC powered device to the AC socket (make sure the powered device is turned off before inserting the plug into the AC socket). 2. Press and hold the AC power switch to turn on the AC power outlet, and the display will show AC output. 3. After use, long press the AC power switch, turn off the AC power socket, and unplug the device from the AC power socket. * When AC output of the product is not used, please turn off the AC power switch to save energy. • make sure that this product conforms to the specifications of the electrical equipment before use. • Do not connect other AC power sources to the product's AC outlet. • Do not put the plug of adapter into the product's AC outlet to charge itself. • When the AC output is short-circuited or the power of the load appliance exceeds the AC output power, the protection function of the product will be activated. Please remove the short-circuit or remove the electrical equipment, and then restart the machine to restore the AC output function. The AC voltage standards and socket specifications are different in different countries or regions. Please Notice: Charge and Discharge • to maintain optimum performance and extend ser vice life. • When charging, the product will be initialized first, and all symbols on the display will light up. After the self-check, it will enter the charging mode, and the display will show "CH" for a long time(charging), "FU" means fully charged. • Do not charge the product with its output. • When discharging, the current remaining time of discharge will be displayed, and the remaining time will be automatically adjusted according to the load. After the batter y is discharged, the screen will automatically turn off. • Do not fully discharge the internal batter y as it may affect batter y life. • When the warning symbol of high and low temperature protection appears on the display, please stop using it and shut it down immediately. It is recommended to charge it immediately after purchase. Charge the batter y immediately when the remaining power is below 20% Product Diagram 1. Display screen 2. DC charging port 3. AC power switch 4. AC power socket*2 * The AC power socket, AC output voltage and frequency of this product will be changed due to different countries or regions, please refer to the actual product! 5. DC switch 6. Car charger port 7. DC output port*2 8. USB switch 9. USB-C 10. USB-A 1 11. USB-A 2 & USB-A 3 12. LED switch (one button to power off ) 13. LED lighting 14. Wireless charging 1. Batter y level/Charge status 2. Remaining power 3. Discharge remaining time/Charge/Discharge status 4. High and low temperature protection warning 5. AC output Display Screen Note: a. Please turn off the display screen in time if the product is not in use; b. Press and hold the LED switch to turn off with one button. 12 3 4 56789 6. DC output 7. USB output 8. Wireless charging output 9. AC output frequency (60Hz) Basic Parameters DC Output Batter y Parameters Input Operating Environment Model No. Capacity of Li-ion batter y pack Size Net Weight DC Charging USB-C Charging Rated Voltage USB-A*3 USB-C 5525*2 Car Charger LED Light Cycle Time Safety Protection Charging Temperature Discharging Temperature QE01A(KR) 500Wh, 14.8V, 33.8Ah 306×171×202(mm) ≈4.8Kg 12V～30V⎓3.42A 65W(Max) 5V⎓3.0A/9V⎓3.0A/12V⎓3.0A/15V⎓3.0A/20V⎓3.25A 65W(Max) 230V/50Hz(Pure sine wave) USB-A1:5V⎓3.0A/9V⎓2.0A/12V⎓1.5A 18W(Max), USB-A2 & USB-A3:5V⎓2.4A 12W(Max) 5V⎓3.0A/9V⎓3.0A/12V⎓3.0A/15V⎓3.0A/20V⎓3.25A 65W(Max) 12～16.8V⎓7～10A, Total 120W(Max) 2W 800 times High temperature protection, low temperature protection, over voltage protection, under voltage protection, overload protection, short circuit protection and overcurrent protection 0°C～40°C -10°C～40°C Name Portable Power Station QE01B(KR)QE02A(KR)QE02B(KR) 448Wh, 16V, 28Ah 1065.6Wh, 22.2V, 48Ah 1008Wh, 22.4V, 45Ah 413×203×232(mm) ≈5.6Kg ≈9.1Kg≈10.2Kg 12V～30V⎓7A 182W(Max) Rated Power Totle 500W(Max) AC Output*2 Totle 600W(Max)Totle 1000W(Max)Totle 1200W(Max) 13～18V⎓7～10A, Total 130W(Max) 13.6V⎓10A, Total 136W(Max) 3000 times800 times3000 times Specification 3 6 7 5 4 2 9 10 11 8 1 14 13 12 Basic Parameters DC Output Batter y Parameters Input Operating Environment Model No. Capacity of Li-ion batter y pack Size Net Weight DC Charging USB-C Charging Rated Voltage USB-A*3 USB-C 5525*2 Car Charger Wireless charging LED Light Cycle Time Safety Protection Charging Temperature Discharging Temperature QE01A(JP) 500Wh, 14.8V, 33.8Ah 306×171×202(mm) ≈4.8Kg 12V～30V⎓3.42A 65W(Max) 5V⎓3.0A/9V⎓3.0A/12V⎓3.0A/15V⎓3.0A/20V⎓3.25A 65W(Max) 100V～50/60Hz(Pure sine wave) USB-A1:5V⎓3.0A/9V⎓2.0A/12V⎓1.5A 18W(Max), USB-A2 & USB-A3:5V⎓2.4A 12W(Max) 5V⎓3.0A/9V⎓3.0A/12V⎓3.0A/15V⎓3.0A/20V⎓3.25A 65W(Max) 12～16.8V⎓7～10A, Total 120W(Max) 5V⎓1.0A/9V⎓1.0A 10W(Max) 800 times High temperature protection, low temperat…

Text truncated - open the document above for the full version.

GuangzhouKeyshopSci&TechCo.,Ltd. Company:GuangzhouKeyshopSci&TechCo.,Ltd. Address:BuildingB,No.29Kefengroad,Sciencecity,Hi-techdevelopment zone,Guangzhou,China TheEUTdoescomplywithitem5.2ofKDB680106D01v03asfollowstable RequirementsofKDB680106D01Yes/NoDescription (1)Powertransferfrequencyislessthan 1MHz Yes (2)Outputpowerfromeachprimarycoil islessthanorequalto15watts. Yes (3)Thesystemmayconsistofmorethan onesourceprimarycoils,chargingoneor moreclients.If morethanoneprimarycoilispresent,the coilpairsmaybepoweredonatthesame time The EUT frequency range is: 110kHz- 205kHz The output power is 1 0 W . YesEUThastwocoils (4)Clientdeviceisplaceddirectlyin contactwiththetransmitter. YesEUTcanbedirectlycharged (5)Mobileexposureconditionsonly (portableexposureconditionsarenot coveredbythisexclusion). YesEUTisamobiledevice (6)TheaggregateH-fieldstrengths anywhereatorbeyond15cm surroundingthedevice,and20cm awayfromthesurfacefromallcoilsthat bydesigncansimultaneouslytransmit, andwhilethose coilsaresimultaneouslyenergized,are demonstratedtobelessthan50%ofthe applicableMPE limit. YesFulfilrequirements Name:WeijiYuDate:18.08.2022 Signatureofapplicant:

GuangzhouKeyshopSci&TechCo.,Ltd. AgentAuthorization Company:GuangzhouKeyshopSci&TechCo.,Ltd. Address:BuildingB,No.29Kefengroad,Sciencecity,Hi-techdevelopmentzone, Guangzhou,China ModelNumber(s):QE02B(US) ProductDescription:PORTABLEPOWERSTATION WeauthorizeMiCOMLabsInc.,575BoulderCourt,Pleasanton,California94566,USA, toactonourbehalfonallmattersconcerningthecertificationofabovenamed equipment. WedeclarethatMiCOMLabsInc.isallowedtoforwardallinformationrelatedtothe approvalandcertificationofequipmenttotheregulatoryagenciesasrequiredandto discussanyissuesconcerningtheapprovalapplication.Anyandallactscarriedoutby MiCOMLabsonourbehalfshallhavethesameeffectasactsofourown. Signature:Date:August18,2022. Name:WeijiYu Title:Manager Company: GuangzhouKeyshopSci&TechCo.,Ltd.

GuangzhouKeyshopSci&TechCo.,Ltd. OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:2022-08-18 Subject;RequestforConfidentiality FCCID:2A49V-QE02B ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthesedocuments mightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantageinthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:WeijiYu Title:Manager

FCCID:2A49V-QE02B

Labelsize:10*7cm

FCCID:2A49V-QE02B

KSIGN(Guangdong)TestingCo,Ltd. FirstFloorWestSide,BuildingC,ZoneA,FuyuanNewFactory,JiujiuIndustrialPark,MinzhuVillage, ShatouCommunity,ShajingStreet,Bao'anDistrict,ShenzhenCity,GuangdongProvince,P.R.China Tel.:+(86)755-29852678Fax:+(86)755-29852397E-mail:[email protected]:www.gdksign.com KSIGN(Guangdong)TestingCo.,Ltd. RFExposureEvaluation FCCID:2A49V-QE02B MeasuringStandard FCCPart1(1.1310)andPart2(2.1091) KDB680106D01RFExposureWirelessChargingBaseAppv03 TestConfiguration ThetestdistanceofPositionEonthefrontsideis20cm,thetestdistanceofPositionA,B,C,Dis15cmusing theequipmentlistabovefordeterminingcompliancewiththeMPErequirementsofFCCPart1.1310. TheRFpowerdensitywasmeasuredatUndermaximumloadtest. ThetestdistanceofPositionEonthefrontsideis20cm,thetestdistanceofPositionA,B,C,Dis15cm,the fieldprobeswerepositionedatthelocationwherethereismaximumfieldstrength.ThemaximumE-fieldand H-fieldisreportedbelow. Thisdeviceusesawirelesschargingcircuitforpowertransferoperatingatthefrequencyof110.1KHz -205kHz.Thus,the300kHzlimitswereused:E-fieldLimit=614(V/m);H-fieldlimit=1.63(A/m). TESTSetup KSIGN(Guangdong)TestingCo,Ltd. FirstFloorWestSide,BuildingC,ZoneA,FuyuanNewFactory,JiujiuIndustrialPark,MinzhuVillage, ShatouCommunity,ShajingStreet,Bao'anDistrict,ShenzhenCity,GuangdongProvince,P.R.China Tel.:+(86)755-29852678Fax:+(86)755-29852397E-mail:[email protected]:www.gdksign.com KSIGN(Guangdong)TestingCo.,Ltd. TESTLimits MeasuringDeviceandTestEquipment DescriptionManufacturerModelS/N Cal.Until ProbeFHP(1Hz-400KHz) NardaSafetyTest SolutionsGmbH EHP-50F J-0015 Nov11,2022 AdapterN/AN/AN/AN/A PHONE1HUAWEIP40N/AN/A PHONE2HUAWEIMATE40N/AN/A KSIGN(Guangdong)TestingCo,Ltd. FirstFloorWestSide,BuildingC,ZoneA,FuyuanNewFactory,JiujiuIndustrialPark,MinzhuVillage, ShatouCommunity,ShajingStreet,Bao'anDistrict,ShenzhenCity,GuangdongProvince,P.R.China Tel.:+(86)755-29852678Fax:+(86)755-29852397E-mail:[email protected]:www.gdksign.com KSIGN(Guangdong)TestingCo.,Ltd. TESTMODE MODETESTMODEDESCRIPTION 1TwoCoilwirelesssimultaneouschargingmode(Fullload) 2TwoCoilwirelesssimultaneouschargingmode(Halfload) 3TwoCoilwirelesssimultaneouschargingmode(Nullload) 4Coil1-Wirelesschargingmode(Fullload) 5Coil1-Wirelesschargingmode(Halfload) 6Coil1-Wirelesschargingmode(Nullload) 7Coil2-Wirelesschargingmode(Fullload) 8Coil2-Wirelesschargingmode(Halfload) 9Coil2-Wirelesschargingmode(Nullload) Note: 1.TheMode1wastheworstcaseandonlythedataoftheworstcaserecordinthisreport. TESTRESULT PassedNotApplicable KSIGN(Guangdong)TestingCo,Ltd. FirstFloorWestSide,BuildingC,ZoneA,FuyuanNewFactory,JiujiuIndustrialPark,MinzhuVillage, ShatouCommunity,ShajingStreet,Bao'anDistrict,ShenzhenCity,GuangdongProvince,P.R.China Tel.:+(86)755-29852678Fax:+(86)755-29852397E-mail:[email protected]:www.gdksign.com KSIGN(Guangdong)TestingCo.,Ltd. EUT PORTABLEPOWER STATION ModelName.:QE02B(US) Pressure:1010hPaTestDate:2022-8-29 TestVoltage:Output:10W(Max)TestMode:Mode1(worsecase) E-FieldStrengthat15cmsurroundingtheEUTand20cmabovethetopsurfaceoftheEUT EUTSide Frequency Range (KHz) Probe A (V/m) Probe B (V/m) Probe C (V/m) Probe D (V/m) Probe E (V/m) Limits (V/m) 50%Limit (V/m) Fullload110~2050.770.780.760.750.82 614307 Halfload110~2050.740.730.720.710.78 Nullload110~2050.710.700.690.690.77 H-FieldStrengthat15cmsurroundingtheEUTand20cmabovethetopsurfaceoftheEUT EUTSide Frequency Range (KHz) Probe A (A/m) Probe B (A/m) Probe C (A/m) Probe D (A/m) Probe E (A/m) Limits (A/m) 50%Limit (A/m) Fullload110~2050.490.480.450.460.68 1.630.815Halfload110~2050.450.450.430.430.64 Nullload110~2050.420.420.410.400.62 Remark:ThedevicemeetsthemobileRFexposurelimitata15cmseparationdistanceasspecified in§2.1091oftheFCCRules. Note:OnlytheMode1worstcasemodesisrecordedinthereport. KSIGN(Guangdong)TestingCo,Ltd. FirstFloorWestSide,BuildingC,ZoneA,FuyuanNewFactory,JiujiuIndustrialPark,MinzhuVillage, ShatouCommunity,ShajingStreet,Bao'anDistrict,ShenzhenCity,GuangdongProvince,P.R.China Tel.:+(86)755-29852678Fax:+(86)755-29852397E-mail:[email protected]:www.gdksign.com KSIGN(Guangdong)TestingCo.,Ltd. PHOTOGRAPHSOFTESTSETUP PositionE PositionA KSIGN(Guangdong)TestingCo,Ltd. FirstFloorWestSide,BuildingC,ZoneA,FuyuanNewFactory,JiujiuIndustrialPark,MinzhuVillage, ShatouCommunity,ShajingStreet,Bao'anDistrict,ShenzhenCity,GuangdongProvince,P.R.China Tel.:+(86)755-29852678Fax:+(86)755-29852397E-mail:[email protected]:www.gdksign.com KSIGN(Guangdong)TestingCo.,Ltd. PositionB PositionC KSIGN(Guangdong)TestingCo,Ltd. FirstFloorWestSide,BuildingC,ZoneA,FuyuanNewFactory,JiujiuIndustrialPark,MinzhuVillage, ShatouCommunity,ShajingStreet,Bao'anDistrict,ShenzhenCity,GuangdongProvince,P.R.China Tel.:+(86)755-29852678Fax:+(86)755-29852397E-mail:[email protected]:www.gdksign.com KSIGN(Guangdong)TestingCo.,Ltd. PositionD **********************THEEND**********************

ReportNo.:KS2208S3588E TRFNo.FCCPart18_R2 Add：WestSideof1/F.,BuildingC,ZoneA,FuyuanNewFactory,JiujiuIndustrialPark,Minzhu,Shatou, Shajing,Bao'anDistrict,Shenzhen,Guangdong,China Tel：+(86)0755-29852678Fax:+(86)0755-29852397E-mail：[email protected]:www.gdksign.com Page 1 of 32 TESTREPORT ReportNo...........................................:KS2208S3588E FCCID.............................................:2A49V-QE02B Applicant............................................:GuangzhouKeyshopSci&TechCo.,Ltd. Address................................................: BuildingB,No.29Kefengroad,Sciencecity,Hi-techdevelopment zone,Guangzhou,China Manufacturer....................................:GuangzhouKeyshopSci&TechCo.,Ltd. Address............................................: BuildingB,No.29Kefengroad,Sciencecity,Hi-techdevelopment zone,Guangzhou,China ProductName...................................:PORTABLEPOWERSTATION TradeMark..........................................:N/A Model/Typereference........................:QE02B(US) Standard ............................................. :FCCRulesandRegulationsPart18 DateofReceipt ................................... :August17,2022 DateofTestDate ............................... : August17,2022~ September 15,2022 Dateofissue.......................................: September15,2022 Testresult..........................................:Pass Preparedby: (PrintedName+Signature) PaiZheng Approvedby: (PrintedName+Signature) SkyDong TestingLaboratoryName..............:KSIGN(Guangdong)TestingCo.,Ltd. Address ................................................ : WestSideof1/F.,BuildingC,ZoneA,FuyuanNewFactory,Jiujiu IndustrialPark,Minzhu,Shatou,Shajing,Bao'anDistrict, Shenzhen,Guangdong,China Thistestreportmaybeduplicatedcompletelyforlegalusewiththeapprovaloftheapplicant.Itshouldnot bereproducedexceptinfull,withoutthewrittenapprovalofourlaboratory.Theclientshouldnotuseitto claimproductendorsementbyKSIGN.Thetestresultsinthereportonlyapplytothetestedsample.The testreportshallbeinvalidwithoutallthesignaturesoftestingengineers,reviewerandapprover. AnyobjectionsmustberaisedtoKSIGNwithin15dayssincethedatewhenthereportisreceived.Itwillnot betakenintoconsiderationbeyondthislimit.Thetestreportmerelycorrespondtothetestsample. ReportNo.:KS2208S3588E TRFNo.FCCPart18_R2 Add：WestSideof1/F.,BuildingC,ZoneA,FuyuanNewFactory,JiujiuIndustrialPark,Minzhu,Shatou, Shajing,Bao'anDistrict,Shenzhen,Guangdong,China Tel：+(86)0755-29852678Fax:+(86)0755-29852397E-mail：[email protected]:www.gdksign.com Page 2 of 32 Contents 1TESTSUMMARY..............................................................................................................................................3 1.1TestStandards................................................................................................................................................3 1.2ReportVersion................................................................................................................................................3 1.3Addressofthetestlaboratory.........................................................................................................................4 1.4TestFacility.....................................................................................................................................................4 1.5Environmentalconditions................................................................................................................................4 1.6Summaryofmeasurementresults..................................................................................................................5 1.7Statementofthemeasurementuncertainty...................................................................................................5 2GENERALINFORMATION...............................................................................................................................6 2.1ProductDescription.........…

Text truncated - open the document above for the full version.
