2A4DV-A1171PROJECTOR

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

HUNAN ETOE Technology Co., Ltd 1/1 Letter of Authorization Company: HUNAN ETOE Technology Co., Ltd Address: Room 603, Building 3, Zone A, Jindaoyuan, NO.169, Huizhi Zhong Road, High-tech District, Changsha Product Name: PROJECTOR Model Number: A1171 FCC Identifier: 2A4DV-A1171 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Pual Li Date: 2022-02-08 Title: Manager Signature of applicant:

HUNAN ETOE Technology Co., Ltd 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2022-02-08 Subject: Request for Confidentiality FCC ID: 2A4DV-A1171 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Pual Li Title: Manager

Size:12*5mm M/N: A1171 FCC ID: 2A4DV-A1171 Label location

ANT: WiFi2.4G ANT: BT+ WiFi5G

FCC ID: 2A4DV-A1171 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation wifi 2.4G mode Channel Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b 16.48 44.463 0.02222 1.0 PASS 802.11g 16.44 44.055 0.02202 1.0 PASS 802.11n HT20 15.77 37.757 0.01887 1.0 PASS 802.11n HT40 15.65 36.728 0.01835 1.0 PASS Remark: antenna gain=4dBi wifi 5G mode Channel Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result Band 1 802.11a 15.44 34.995 0.01749 1.0 PASS 802.11n HT20 15.56 35.975 0.01798 1.0 PASS 802.11n HT40 14.35 27.227 0.01361 1.0 PASS 802.11ac HT20 14.34 27.164 0.01357 1.0 PASS 802.11ac HT40 14.69 29.444 0.01471 1.0 PASS 802.11ac HT80 13.09 20.370 0.01018 1.0 PASS Band 4 802.11a 13.82 24.099 0.01204 1.0 PASS 802.11n HT20 14.86 30.620 0.01530 1.0 PASS 802.11n HT40 14.10 25.704 0.01284 1.0 PASS 802.11ac HT20 14.83 30.409 0.01520 1.0 PASS 802.11ac HT40 14.33 27.102 0.01354 1.0 PASS 802.11ac HT80 13.59 22.856 0.01142 1.0 PASS Remark: antenna gain=4dBi

Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220121038E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 60 FCC Part 15C Test Report FCC ID:2A4DV-A1171 Applicant: HUNAN ETOE Technology Co., Ltd Address: Room 603, Building 3, Zone A, Jindaoyuan, NO.169, Huizhi Zhong Road, High-tech District, Changsha Manufacturer: HUNAN ETOE Technology Co., Ltd Address: Room 603, Building 3, Zone A, Jindaoyuan, NO.169, Huizhi Zhong Road, High-tech District, Changsha EUT: PROJECTOR Trade Mark: ETOE Model Number: A1171 Date of Receipt: Jan. 14, 2022 Test Date: Jan. 14, 2022 – Jan. 21, 2022 Date of Report: Jan. 21, 2022 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC PART 15 C 15.247 ANSI C63.10:2013 Test Result: Pass Report Number: DL-20220121038E Prepared (Test Engineer): Pxing Huang Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220121038E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 60 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 6 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 7 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 7 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 7 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3 . EMC EMISSION TEST 9 3.1 CONDUCTED EMISSION MEASUREMENT 9 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 9 3.1.2 TEST PROCEDURE 9 3.1.3 DEVIATION FROM TEST STANDARD 9 3.1.4 TEST SETUP 10 3.1.5 EUT OPERATING CONDITIONS 10 3.1.6 TEST RESULTS 10 3.2 RADIATED EMISSION MEASUREMENT 13 3.2.1 RADIATED EMISSION LIMITS 13 3.2.2 TEST PROCEDURE 14 3.2.3 DEVIATION FROM TEST STANDARD 14 3.2.4 TEST SETUP 14 3.2.5 EUT OPERATING CONDITIONS 15 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 16 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 17 3.2.8 TEST RESULTS (1GHZ~25GHZ) 19 3.3 RADIATED BAND EMISSION MEASUREMENT 25 3.3.1 TEST REQUIREMENT: 25 3.3.2 TEST PROCEDURE 25 3.3.3 DEVIATION FROM TEST STANDARD 25 3.3.4 TEST SETUP 26 3.3.5 EUT OPERATING CONDITIONS 26 4 . PEAK OUTPUT POWER 39 4.1 APPLIED PROCEDURES / LIMIT 39 4.1.1 TEST PROCEDURE 39 4.1.2 DEVIATION FROM STANDARD 39 4.1.3 TEST SETUP 39 4.1.4 EUT OPERATION CONDITIONS 39 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220121038E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 60 Table of Contents Page 4.1.5 TEST RESULTS 40 5 . POWER SPECTRAL DENSITY TEST 43 5.1 APPLIED PROCEDURES / LIMIT 43 5.1.1 TEST PROCEDURE 43 5.1.2 DEVIATION FROM STANDARD 43 5.1.3 TEST SETUP 43 5.1.4 EUT OPERATION CONDITIONS 43 5.1.5 TEST RESULTS 44 6 . 6DB BANDWIDTH TEST 47 6.1 APPLIED PROCEDURES / LIMIT 47 6.1.1 TEST PROCEDURE 47 6.1.2 DEVIATION FROM STANDARD 47 6.1.3 TEST SETUP 47 6.1.4 EUT OPERATION CONDITIONS 47 6.1.5 TEST RESULTS 48 7 . ANTENNA REQUIREMENT 51 7.1 STANDARD REQUIREMENT 51 7.2 EUT ANTENNA 51 8 . TEST SEUUP PHOTO 52 9 . EUT PHOTO 54 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220121038E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 60 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(c) Radiated Spurious Emission PASS 15.205 Band Edge Emission PASS 15.247(b)(1) Peak Output Power PASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(d) Power Spectral Density PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220121038E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 60 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: PROJECTOR Trademark ETOE Model No.: A1171 Model Difference N/A Operation Frequency: 2412~2462 MHz for 802.11b/g/nHT20 2422~2452 MHz for 802.11nHT40 Channel numbers: 11 Channels for 802.11b/g/n(HT20) 7 channels for 802.11nHT40 Channel separation: 5MHz Modulation technology: 802.11b: DSSS (CCK, DQPSK, DBPSK) 802.11g/n(20): DSSS (CCK, DQPSK,DBPSK)+OFDM (QPSK, BPSK, 16-QAM, 64-QAM) Rate of Transmitter 802.11b: 11/5.5/2/1Mbps 802.11g: 54/48/36/24/18/12/9/6Mbps 802.11n: up to 150Mbps Antenna Type: Internal Antenna Antenna gain: 4dBi Power supply: DC 19V from adapter Adapter: Model Number: NSA60ED-190300 Input: 100-240V~ 50/60Hz 1.5A Output: 19.0V3.0A 57.0W Note: 1.For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2.The EUT’s all information provided by client. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220121038E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 6 of 60 2. Channel List(802.11b/g/nHT20) Channel Frequency (GHz) Channel Frequency (GHz) 01 2.412 07 2.442 02 2.417 08 2.447 03 2.422 09 2.452 04 2.427 10 2.457 05 2.432 11 2.462 06 2.437 Channel List(802.11nHT40) Channel Frequency (GHz) Channel Frequency (GHz…

Text truncated - open the document above for the full version.

Radiated Measurement Photos Conducted Measurement Photos
