2A4EP-WR01USTESSAN Charging Station
Zhuhai Tessan Power Technology Co., Ltd.
Click to zoom
Application Details
- Equipment Class
- DCD - Part 15 Low Power Transmitter Below 1705 kHz
- Date of Grant
- Jul 07, 2026
- Application Purpose
- Original Equipment
- Equipment Note
- TESSAN Charging Station
- Frequency Range
- 0.11500000 - 0.20500000
- Country
- China
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
Model: TS-WR01US00 Ratings: 15A 125V~ 60Hz 1875W MAX Total DC Output: 35W TESSAN Charging Station Manufacturer: Zhuhai Tessan Power Technology Co.,Ltd. This equipment complied with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
External Photos
Externalphoto ReportNo.LP26040189C01-02 FCCID:2A4EP-WR01US Page 1 / 5 Externalphoto ReportNo.LP26040189C01-02 FCCID:2A4EP-WR01US Page 2 / 5 Externalphoto ReportNo.LP26040189C01-02 FCCID:2A4EP-WR01US Page 3 / 5 Externalphoto ReportNo.LP26040189C01-02 FCCID:2A4EP-WR01US Page 4 / 5 Externalphoto ReportNo.LP26040189C01-02 FCCID:2A4EP-WR01US Page 5 / 5 ---END---
ID Label/Location Info
LabelLocation
ID Label/Location Info
15A 125V~ 60Hz 1875W MAX 15A 125V~ 60Hz 1875W MAX
Internal Photos
Internalphoto ReportNo.LP26040189C01-02 FCCID:2A4EP-WR01US Page 1 / 4 Internalphoto ReportNo.LP26040189C01-02 FCCID:2A4EP-WR01US Page 2 / 4 Loopantenna Internalphoto ReportNo.LP26040189C01-02 FCCID:2A4EP-WR01US Page 3 / 4 Internalphoto ReportNo.LP26040189C01-02 FCCID:2A4EP-WR01US Page 4 / 4 ---END---
RF Exposure Info
ReportNo.LP26040189C01-02-01 page 1 of 15 DongguanLepontTestingServiceCo.,Ltd. MPEREPORT Applicant: Address: ZhuhaiTessanPowerTechnologyCo.,Ltd. Building14,XiangzhouChuanggangCenter,No.199,Weikang Road,XiangzhouDistrict,Zhuhai,GuangdongProvince,China Manufacturer: Address: ZhuhaiTessanPowerTechnologyCo.,Ltd. Building14,XiangzhouChuanggangCenter,No.199,Weikang Road,XiangzhouDistrict,Zhuhai,GuangdongProvince,China Factory: Address: DONGGUANPOWERTECHNOELECTRICCO.,LTD ROOM801,BUILDING1,NO.9,FUTANGSTREET, DALINGSHANTOWN,DONGGUANCITY,GUANGDONG PROVINCE,CHINA E.U.T.:TESSANChargingStation ModelNumber:TS-WR01US00 TradeMark:TESSAN FCCID:2A4EP-WR01US DateofReceipt:2026-04-29DateofTest:2026-04-29to2026-05-18 TestSpecification: FCCPart1(1.1310)andPart2(2.1093) KDB680106D01RFExposureWirelessChargingAppv04 TestResult:Theequipmentundertestwasfoundtobecompliancewiththe requirementsofthestandardsapplied. Preparedby:Approved&AuthorizedSigner: Una.Wang/EngineerFrank.Shen/Manager IssueDate:2026-07-01 Thistestreportisbasedonasingleevaluationofonesampleofabovementionedproducts.Itisnotpermitted tobeduplicatedinextractswithoutwrittenapprovalofDongguanLepontTestingServiceCo.,Ltd. ReportNo.LP26040189C01-02-01 page 2 of 15 DongguanLepontTestingServiceCo.,Ltd. TABLEOFCONTENTS 1.GENERALPRODUCTINFORMATION....................................................................................................4 1.1.PRODUCTFUNCTION.....................................................................................................................................4 1.2.EUTTECHNICALDESCRIPTION..............................................................................................................4 1.3.DESCRIPTIONOFTESTMODES.............................................................................................................5 1.4.DESCRIPTIONOFSUPPORTDEVICE.....................................................................................................5 2.TESTSTANDARDSANDSITES..............................................................................................................6 2.1.DESCRIPTIONOFSTANDARDSANDRESULTS..................................................................................................6 2.2.LISTOFTESTANDMEASUREMENTINSTRUMENTS...........................................................................................6 2.3.TESTFACILITY...............................................................................................................................................6 3.RFEXPOSURE..........................................................................................................................................7 3.1.MEASURINGSTANDARD..........................................................................................................................7 3.2.REQUIREMENTS.......................................................................................................................................7 3.3.TESTCONFIGURATION............................................................................................................................8 3.4.BLOCKDIAGRAMOFTESTSETUP.........................................................................................................8 3.5.LIMITS.......................................................................................................................................................10 3.6.MEASURINGRESULTS...........................................................................................................................12 3.7.TESTDATA:...............................................................................................................................................13 ReportNo.LP26040189C01-02-01 page 3 of 15 DongguanLepontTestingServiceCo.,Ltd. RevisionHistoryofThisTestReport ReportNumberDescriptionIssuedDate LP26040189C01-02-01InitialIssue2026-07-01 ReportNo.LP26040189C01-02-01 page 4 of 15 DongguanLepontTestingServiceCo.,Ltd. 1.GENERALPRODUCTINFORMATION 1.1.PRODUCTFUNCTION RefertoTechnicalConstructionFormandUserManual. 1.2.EUTTECHNICALDESCRIPTION ProductName:TESSANChargingStation ModelNo.:TS-WR01US00 TestModelNo:TS-WR01US00 Difference: N/A SerialNo.:N/A Testsample(s)ID:LP26040189C01-S001 Sample(s)StatusEngineersample Hardware:V1.0 Software:V1.0 Operationfrequency: 115-205KHz ModulationType: MSK AntennaType: InductiveLoopAntennawith10Turns AntennaGain:N/A Rating: 15A125V~60Hz1875WMAX USB-CCableOutput:5V3A/9V3A/12V2.9A/ 15V2.33A/20V1.75A USB-C1/C2Output:5V3AMAXPerPort USB-AOutput:5V2.4AMAX USB-CCable+USB-A/C1/C2Output:20W+15WMAX USB-A+USB-C1/C2Output:5V3A15W USB-C1+C2Output:5V3A15W USB-CCable+(USB-A+C1+C2)Output:20W+15WMAX Wireless(Phone)Output:5W/7.5W/10W/15WMAX TotalDCOutput:35W Note:formoredetails,pleaserefertotheUser’smanualoftheEUT. ReportNo.LP26040189C01-02-01 page 5 of 15 DongguanLepontTestingServiceCo.,Ltd. 1.3.DESCRIPTIONOFTESTMODES AllthetestmodeswerecarriedoutwiththeEUTinnormaloperation,thefinaltestmodeoftheEUTwasthe worsttestmodeforemissiontest,whichwasshowninthisreportanddefinedas: Mode:TESTMODEDESCRIPPTION 1 WirelessOutput:15W 2 WirelessOutput:10W 3 WirelessOutput:7.5W 4WirelessOutput:5W Note: 1.Productfoldinghasbeenevaluatedforuse. 2.Alltestmodeswerepre ‐ tested,butweonlyrecordedtheworstcaseinthisreport.Theworstcase isMode1 1.4.DESCRIPTIONOFSUPPORTDEVICE No.EquipmentTradenameModelS/NInput/Output 1. Iphone14 plus Iphone MQ3D3 CH/A DG209WYGY6 15WMax. 2. ///// ReportNo.LP26040189C01-02-01 page 6 of 15 DongguanLepontTestingServiceCo.,Ltd. 2.TESTSTANDARDSANDSITES 2.1.DESCRIPTIONOFSTANDARDSANDRESULTS TheEUThavebeentestedaccordingtotheapplicablestandardsasreferencedbelow. EMISSION DescriptionofTestItemStandard&LimitsResults MPE FCCPart1(1.1310)andPart2(2.1093) KDB680106D01RFExposureWirelessCharging Appv04 Pass Note:N/AisanabbreviationforNotApplicable. 2.2.LISTOFTESTANDMEASUREMENTINSTRUMENTS EquipmentManufacturerModelNo.SerialNo.LastCal.Cal.Interval ElectricandMagneticField Probe-Analyzer SPE…
Text truncated - open the document above for the full version.
Test Report
Product Specification Customer NameQIHUI Customer Material Number / Part Number TX-HBY20240412002-43.5，10TS L=20MM PEC NO. 20260421001 versions 001 ♦、size (Unit: mm) A43.5 ±0.5 B39.0 ±0.5 C20.5 ±0.5 D 5.3Ref±0.5 E10.0 Ref F3.0 ±1.0 G3.3MAX H20.0 ±1.0 I0.8 ±0.1 (1)wire diameter: 0.08*24 (2)Number of turns:10TS ♦、Electrical specification: parameterspecificationtest condition test equipment L06.5±0.3μH100KHz/1V■TH1816B Q>30 min100KHz/1V■TH1816B DCR<100mΩ@ 25°C■CH-502BC ♦、Temperature grade: operating temperature -40°C~ 125°C ♦、BOM: S/NP/NSpecificationsupplierNote 1 magnetic sheet 43.5*0.8*5.3T 2 copper wire0.08*24*2P 3 high- temperature 8MM 4 Tin107H 5 glueglue 6 glue 41 double-slot round double-sided adhesive tape EditorAuditorAuthorize xiaoshufangpengyongzhuhui
Test Report
ReportNo.LP26040189C01-02 page 1 of 27 DongguanLepontTestingServiceCo.,Ltd. TESTREPORT Applicant: Address: ZhuhaiTessanPowerTechnologyCo.,Ltd. Building14,XiangzhouChuanggangCenter,No.199,Weikang Road,XiangzhouDistrict,Zhuhai,GuangdongProvince,China Manufacturer: Address: ZhuhaiTessanPowerTechnologyCo.,Ltd. Building14,XiangzhouChuanggangCenter,No.199,Weikang Road,XiangzhouDistrict,Zhuhai,GuangdongProvince,China Factory: Address: DONGGUANPOWERTECHNOELECTRICCO.,LTD ROOM801,BUILDING1,NO.9,FUTANGSTREET,DALINGSHAN TOWN,DONGGUANCITY,GUANGDONGPROVINCE,CHINA E.U.T.:TESSANChargingStation ModelNumber:TS-WR01US00 TradeMark:TESSAN FCCID:2A4EP-WR01US DateofReceipt:2026-04-29DateofTest:2026-04-29to2026-05-18 TestSpecification:FCC47CFRPart15,SubpartC TestResult:Theequipmentundertestwasfoundtobecompliancewiththe requirementsofthestandardsapplied. Preparedby:Approved&AuthorizedSigner: UnaWang/EngineerFrankShen/Manager IssueDate:2026-07-01 Thistestreportisbasedonasingleevaluationofonesampleofabovementionedproducts.Itisnotpermittedtobe duplicatedinextractswithoutwrittenapprovalofDongguanLepontTestingServiceCo.,Ltd. ReportNo.LP26040189C01-02 page 2 of 27 DongguanLepontTestingServiceCo.,Ltd. TABLEOFCONTENTS 1.GENERALPRODUCTINFORMATION....................................................................................................4 1.1.PRODUCTFUNCTION.....................................................................................................................................4 1.2.EUTTECHNICALDESCRIPTION..............................................................................................................4 1.3.DESCRIPTIONOFTESTMODES.......................................................................................................................5 2.TESTSTANDARDSANDSITES..............................................................................................................6 2.1.DESCRIPTIONOFSTANDARDSANDRESULTS..................................................................................................6 2.2.LISTOFTESTANDMEASUREMENTINSTRUMENTS...........................................................................................7 2.3.MEASUREMENTUNCERTAINTY.............................................................................................................8 2.4.TESTFACILITY...............................................................................................................................................8 3.SETUPOFEQUIPMENTUNDERTEST...................................................................................................9 3.1.RADIOFREQUENCYTESTSETUP1.......................................................................................................9 3.2.RADIOFREQUENCYTESTSETUP2.......................................................................................................9 3.3.CONDUCTEDEMISSIONTESTSETUP.................................................................................................11 3.4.BLOCKDIAGRAMCONFIGURATIONOFTESTSYSTEM....................................................................11 3.5.SUPPORTEQUIPMENT..........................................................................................................................12 4.TESTRESULTSANDMEASUREMENTDATA.....................................................................................13 4.1.20DBBANDWIDTH..................................................................................................................................13 4.2.RADIATEDSPURIOUSEMISSION.........................................................................................................15 4.3.CONDUCTEDEMISSIONTEST..............................................................................................................23 4.4.ANTENNAAPPLICATION........................................................................................................................26 ReportNo.LP26040189C01-02 page 3 of 27 DongguanLepontTestingServiceCo.,Ltd. RevisionHistoryofThisTestReport ReportNumberDescriptionIssuedDate LP26040189C01-02InitialIssue2026-07-01 ReportNo.LP26040189C01-02 page 4 of 27 DongguanLepontTestingServiceCo.,Ltd. 1.GENERALPRODUCTINFORMATION 1.1.PRODUCTFUNCTION RefertoTechnicalConstructionFormandUserManual. 1.2.EUTTECHNICALDESCRIPTION ProductName:TESSANChargingStation ModelNo.:TS-WR01US00 TestModelNo:TS-WR01US00 Difference: N/A SerialNo.:N/A Testsample(s)ID:LP26040189C01-S001 Sample(s)StatusEngineersample Hardware:V1.0 Software:V1.0 Operationfrequency: 115-205KHz ModulationType: MSK AntennaType: InductiveLoopAntennawith10Turns AntennaGain:N/A Rating: 15A125V~60Hz1875WMAX USB-CCableOutput:5V3A/9V3A/12V2.9A/ 15V2.33A/20V1.75A USB-C1/C2Output:5V3AMAXPerPort USB-AOutput:5V2.4AMAX USB-CCable+USB-A/C1/C2Output:20W+15WMAX USB-A+USB-C1/C2Output:5V3A15W USB-C1+C2Output:5V3A15W USB-CCable+(USB-A+C1+C2)Output:20W+15WMAX Wireless(Phone)Output:5W/7.5W/10W/15WMAX TotalDCOutput:35W Note:formoredetails,pleaserefertotheUser’smanualoftheEUT. ReportNo.LP26040189C01-02 page 5 of 27 DongguanLepontTestingServiceCo.,Ltd. 1.3.DESCRIPTIONOFTESTMODES AllthetestmodeswerecarriedoutwiththeEUTinnormaloperation,thefinaltestmodeoftheEUT wastheworsttestmodeforemissiontest,whichwasshowninthisreportanddefinedas: Mode:TESTMODEDESCRIPPTION 1 WirelessOutput:15W 2 WirelessOutput:10W 3 WirelessOutput:7.5W 4WirelessOutput:5W Note: 1.Productfoldinghasbeenevaluatedforuse. 2.Alltestmodeswerepre ‐ tested,butweonlyrecordedtheworstcaseinthisreport.Theworstcase isMode1 ReportNo.LP26040189C01-02 page 6 of 27 DongguanLepontTestingServiceCo.,Ltd. 2.TESTSTANDARDSANDSITES 2.1.DESCRIPTIONOFSTANDARDSANDRESULTS TheEUThavebeentestedaccordingtotheapplicablestandardsasreferencedbelow. FCCPartClauseTestParameterVerdictRemark FCCPart15,SubpartC-Section15.207 ANSIC63.10-2020+Cor.1-2023 ConductedEmissionPASS FCCPart15,SubpartC-Section15.209 ANSIC63.10-2020+Cor.1-2023 RadiatedEmissionPASS FCCPart15,SubpartC-Section15.215 ANSIC63.10-2020+Cor.…
Text truncated - open the document above for the full version.
Test Setup Photos
Testphoto ReportNo.LP26040189C01-02 FCCID:2A4EP-WR01US Page 1 / 2 ConductedEmission Testphoto ReportNo.LP26040189C01-02 FCCID:2A4EP-WR01US Page 2 / 2 RadiatedEmission ---END---
Contact Information
Applicant
Shaopeng Lyu
[email protected]Fax: 0756-2550031
Technical Contact
TESSAN POWER INCGuiming Wang
1266 NORTH KING ST. #1008 WILMINGTON, DE 19801 · United States
Test Firm
Dongguan Lepont Testing Service Co., Ltd.Frank Shen
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 0.115 MHz - 0.205 MHz | - |
