2A4FB-BP-M13PoC Radio
Guangzhou TID Electronic Technology Co., Ltd
Click to zoom
Application Details
- Equipment Class
- PCB - PCS Licensed Transmitter
- Date of Grant
- Mar 20, 2026
- Application Purpose
- Original Equipment
- Equipment Note
- PoC Radio
- Frequency Range
- 826.50000000 - 846.50000000
- Country
- China
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
1 2 3 4 5 6 7 8 9 10 11 12 13 o C o C 14 οΌB2/4/5/7/66 15 16 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction Specific Absorption Rate (SAR) information: This product meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. FCC RF Exposure Information and Statement The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device type: BP-M13 (FCC ID: 2A4FB-BP-M13) was also tested against these values. The highest SAR value for accessories worn on the body is 0.75 W/kg. The device tested typical body wear operations with the back of the product 5mm from the body. To meet FCC RF exposure requirements, use accessories that maintain a separation distance of 5mm between the user's body and the back of the product. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Test Report
Report FCC ID: 2A4FB-BP-M13 Appendix-BAND2 1. Conducted output power Band Bandwidth (MHz) UL Channel RB Size RB Position Modulation Conducted Power (dBm) EIRP Limit (mW) Verdict Band2 1.4 18607 1 #0 QPSK 13.45 33.01 PASS Band2 1.4 18607 1 #Mid QPSK 13.57 33.01 PASS Band2 1.4 18607 1 #Max QPSK 13.68 33.01 PASS Band2 1.4 18607 3 #0 QPSK 13.46 33.01 PASS Band2 1.4 18607 3 #Max QPSK 13.61 33.01 PASS Band2 1.4 18607 6 #0 QPSK 12.74 33.01 PASS Band2 1.4 18607 1 #0 QAM16 12.65 33.01 PASS Band2 1.4 18607 1 #Mid QAM16 12.70 33.01 PASS Band2 1.4 18607 1 #Max QAM16 12.77 33.01 PASS Band2 1.4 18607 3 #0 QAM16 12.68 33.01 PASS Band2 1.4 18607 3 #Max QAM16 12.81 33.01 PASS Band2 1.4 18607 6 #0 QAM16 11.88 33.01 PASS Band2 1.4 18900 1 #0 QPSK 13.32 33.01 PASS Band2 1.4 18900 1 #Mid QPSK 13.26 33.01 PASS Band2 1.4 18900 1 #Max QPSK 13.12 33.01 PASS Band2 1.4 18900 3 #0 QPSK 13.15 33.01 PASS Band2 1.4 18900 3 #Max QPSK 13.05 33.01 PASS Band2 1.4 18900 6 #0 QPSK 12.31 33.01 PASS Band2 1.4 18900 1 #0 QAM16 12.44 33.01 PASS Band2 1.4 18900 1 #Mid QAM16 12.46 33.01 PASS Band2 1.4 18900 1 #Max QAM16 12.35 33.01 PASS Band2 1.4 18900 3 #0 QAM16 12.49 33.01 PASS Band2 1.4 18900 3 #Max QAM16 12.45 33.01 PASS Band2 1.4 18900 6 #0 QAM16 11.42 33.01 PASS Band2 1.4 19193 1 #0 QPSK 13.29 33.01 PASS Band2 1.4 19193 1 #Mid QPSK 13.74 33.01 PASS Band2 1.4 19193 1 #Max QPSK 13.28 33.01 PASS Report Band2 1.4 19193 3 #0 QPSK 13.45 33.01 PASS Band2 1.4 19193 3 #Max QPSK 13.25 33.01 PASS Band2 1.4 19193 6 #0 QPSK 12.66 33.01 PASS Band2 1.4 19193 1 #0 QAM16 12.61 33.01 PASS Band2 1.4 19193 1 #Mid QAM16 12.94 33.01 PASS Band2 1.4 19193 1 #Max QAM16 12.73 33.01 PASS Band2 1.4 19193 3 #0 QAM16 12.55 33.01 PASS Band2 1.4 19193 3 #Max QAM16 12.89 33.01 PASS Band2 1.4 19193 6 #0 QAM16 11.58 33.01 PASS Band2 3 18615 1 #0 QPSK 13.34 33.01 PASS Band2 3 18615 1 #Mid QPSK 13.69 33.01 PASS Band2 3 18615 1 #Max QPSK 13.76 33.01 PASS Band2 3 18615 8 #0 QPSK 12.58 33.01 PASS Band2 3 18615 8 #Max QPSK 12.88 33.01 PASS Band2 3 18615 15 #0 QPSK 12.75 33.01 PASS Band2 3 18615 1 #0 QAM16 12.80 33.01 PASS Band2 3 18615 1 #Mid QAM16 13.12 33.01 PASS Band2 3 18615 1 #Max QAM16 13.26 33.01 PASS Band2 3 18615 8 #0 QAM16 11.81 33.01 PASS Band2 3 18615 8 #Max QAM16 12.23 33.01 PASS Band2 3 18615 15 #0 QAM16 11.91 33.01 PASS Band2 3 18900 1 #0 QPSK 13.20 33.01 PASS Band2 3 18900 1 #Mid QPSK 13.12 33.01 PASS Band2 3 18900 1 #Max QPSK 12.86 33.01 PASS Band2 3 18900 8 #0 QPSK 12.32 33.01 PASS Band2 3 18900 8 #Max QPSK 12.25 33.01 PASS Band2 3 18900 15 #0 QPSK 12.31 33.01 PASS Band2 3 18900 1 #0 QAM16 12.35 33.01 PASS Band2 3 18900 1 #Mid QAM16 12.26 33.01 PASS Band2 3 18900 1 #Max QAM16 12.06 33.01 PASS Band2 3 18900 8 #0 QAM16 11.48 33.01 PASS Band2 3 18900 8 #Max QAM16 11.30 33.01 PASS Band2 3 18900 15 #0 QAM16 11.41 33.01 PASS Band2 3 19185 1 #0 QPSK 13.19 33.01 PASS Band2 3 19185 1 #Mid QPSK 13.25 33.01 PASS Band2 3 19185 1 #Max QPSK 13.13 33.01 PASS Band2 3 19185 8 #0 QPSK 12.30 33.01 PASS Band2 3 19185 8 #Max QPSK 12.51 33.01 PASS Band2 3 19185 15 #0 QPSK 12.40 33.01 PASS Band2 3 19185 1 #0 QAM16 12.68 33.01 PASS Band2 3 19185 1 #Mid QAM16 12.66 33.01 PASS Band2 3 19185 1 #Max QAM16 12.65 33.01 PASS Band2 3 19185 8 #0 QAM16 11.46 33.01 PASS Band2 3 19185 8 #Max QAM16 11.53 33.01 PASS Report Band2 3 19185 15 #0 QAM16 11.46 33.01 PASS Band2 5 18625 1 #0 QPSK 13.77 33.01 PASS Band2 5 18625 1 #Mid QPSK 14.10 33.01 PASS Band2 5 18625 1 #Max QPSK 14.59 33.01 PASS Band2 5 18625 12 #0 QPSK 12.83 33.01 PASS Band2 5 18625 12 #Max QPSK 13.28 33.01 PASS Band2 5 18625 25 #0 QPSK 13.05 33.01 PASS Band2 5 18625 1 #0 QAM16 12.98 33.01 PASS Band2 5 18625 1 #Mid QAM16 13.50 33.01 PASS Band2 5 18625 1 #Max QAM16 13.97 33.01 PASS Band2 5 18625 12 #0 QAM16 11.91 33.01 PASS Band2 5 18625 12 #Max QAM16 12.35 33.01 PASS Band2 5 18625 25 #0 QAM16 12.08 33.01 PASS Band2 5 18900 1 #0 QPSK 13.47 33.01 PASS Band2 5 18900 1 #Mid QPSK 13.08 33.01 PASS Band2 5 18900 1 #Max QPSK 12.98 33.01 PASS Band2 5 18900 12 #0 QPSK 12.38 33.01 PASS Band2 5 18900 12 #Max QPSK 12.39 33.01 PASS Band2 5 18900 25 #0 QPSK 12.47 33.01 PASS Band2 5 18900 1 #0 QAM16 13.30 33.01 PASS Band2 5 18900 1 #Mid QAM16 12.88 33.01 PASS Band2 5 18900 1 #Max QAM16 12.72 33.01 PASS Band2 5 18900 12 #0 QAM16 11.67 33.01 PASS Band2 5 18900 12 #Max QAM16 11.36 33.01 PASS Band2 5 18900 25 #0 QAM16 11.52 33.01 PASS Band2 5 19175 1 #0 QPSK 14.34 33.01 PASS Band2 5 19175 1 #Mid QPSK 13.32 33.01 PASS Band2 5 19175 1 #Max QPSK 13.26 33.01 PASS Band2 5 19175 12 #0 QPSK 12.96 33.01 PASS Band2 5 19175 12 #Max QPSK 12.46 33.01 PASS Band2 5 19175 25 #0 QPSK 12.62 33.01 PASS Band2 5 19175 1 #0 QAM16 13.63 33.01 PASS Band2 5 19175 1 #Mid QAM16 12.72 33.01 PASS Band2 5 19175 1 #Max QAM16 13.21 33.01 PASS Band2 5 19175 12 #0 QAM16 12.25 33.01 PASS Band2 5 19175 12 #Max QAM16 11.65 33.01 PASS Band2 5 19175 25 #0 QAM16 11.99 33.01 PASS Band2 10 18650 1 #0 QPSK 13.44 33.01 PASS Band2 10 18650 1 #Mid QPSK 14.54 33.01 PASS Band2 10 18650 1 #Max QPSK 16.91 33.01 PASS Band2 10 18650 25 #0 QPSK 12.77 33.01 PASS Band2 10 18650 25 #Max QPSK 14.67 33.01 PASS Band2 10 18650 50 #0 QPSK 13.82 33.01 PASS Band2 10 18650 1 #0 QAM16 12.71 33.01 PASS Report Band2 10 18650 1 #Mid QAM16 13.95 33.01 PASS Band2 10 18650 1 #Max QAM16 16.23 33.01 PASS Band2 10 18650 25 #0 QAM16 11.97 33.01 PASS Band2 10 18650 25 #Max QAM16 13.83 33.01 PASS Band2 10 18900 1 #0 QPSK 14.15 33.01 PASS Band2 10 18900 1 #Mid QPSK 13.06 33.01 PASS Band2 10 18900 1 #Max QPSK 12.97 33.01 PASS Band2 10 18900 25 #0 QPSK 12.44 33.01 PASS Band2 10 18900 25 #Max QPSK 11.97 33.01 PASS Band2 10 18900 50 #0 QPSK 12.15 33.01 PASS Band2 10 18900 1 #0 QAM16 13.35 33.01 PASS Band2 10 18900 1 #Mid QAM16 12.40 33.01 PASS Band2 10 18900 1 #Max QAM16 12.31 33.01 PASS Band2 10 18900 25 #0 QAM16 11.46 33.01 PASS Band2 10 18900 25 #Max QAM16 11.02 33.01 PASS Band2 10 19150 1 #0 QPSK 17.19 33.01 PASS Band2 10 19150 1 #Mid QPSK 14.43 33.01 PASS Band2 10 19150 1 #Max QPSK 13.42 33.01 PASS Band2 10 19150 25β¦
Text truncated - open the document above for the full version.
Test Setup Photos
Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB25112611702RH01 Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 77 of 79 16 Setup Photo Body-worn(Front side)Body-worn(Back side) Front of Face 5mm separation 5mm separation 25mm separation
Test Setup Photos
Setup Appendix FCC ID οΌ2A4FB-BP-M13 Model: BP-M13
Test Report
V1.0 Report No.: DACE251106002RF001 102, Building H1, & 1/F., Building H, Hongfa Science & Technology Park, Tangtou Community, Shiyan Subdistrict, Bao'an District, Shenzhen, Guangdong, China Web: http://www.dace-lab.com Tel: +86-755-23010613 E-mail: [email protected] Page 1 of 52 RF TEST REPORT For Guangzhou TID Electronic Technology Co.,Ltd Product Name: PoC Radio Test Model(s): TD-M13 Report Reference No. : DACE251106002RF001 FCC ID : 2A4FB-M13 Applicantβs Name : Guangzhou TID Electronic Technology Co.,Ltd Address : Room 913A, Bentley International Building, Building 7, No. 50, Juyuan Street, Shijing Street, Baiyun District, Guangzhou, Guangdong, China Testing Laboratory : Shenzhen DACE Testing Technology Co., Ltd. Address : 102, Building H1, & 1/F., Building H, Hongfa Science & Technology Park, Tangtou Community, Shiyan Subdistrict, Bao'an District, Shenzhen, Guangdong, China Test Specification Standard : 47 CFR Part 24E 47 CFR Part 22H 47 CFR Part 27 Date of Receipt : November 11, 2025 Date of Test : November 11, 2025 to December 12, 2025 Data of Issue : December 12, 2025 Result : Pass Note: This report shall not be reproduced except in full, without the written approval of Shenzhen DACE Testing Technology Co., Ltd. This document may be altered or revised by Shenzhen DACE Testing Technology Co., Ltd. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample V1.0 Report No.: DACE251106002RF001 102, Building H1, & 1/F., Building H, Hongfa Science & Technology Park, Tangtou Community, Shiyan Subdistrict, Bao'an District, Shenzhen, Guangdong, China Web: http://www.dace-lab.com Tel: +86-755-23010613 E-mail: [email protected] Page 2 of 52 Apply for company information Applicantβs Name : Guangzhou TID Electronic Technology Co.,Ltd Address : Room 913A, Bentley International Building, Building 7, No. 50, Juyuan Street, Shijing Street, Baiyun District, Guangzhou, Guangdong, China Product Name : PoC Radio Test Model(s) : TD-M13 Series Model(s) : TD-G13 Test Specification Standard(s) : 47 CFR Part 24E 47 CFR Part 22H 47 CFR Part 27 NOTE1: The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Compiled by: Supervised by: Approved by: Keren Huang / Test Engineer Ben Tang / Project Engineer Machael Mo / Manager December 12, 2025 December 12, 2025 December 12, 2025 V1.0 Report No.: DACE251106002RF001 102, Building H1, & 1/F., Building H, Hongfa Science & Technology Park, Tangtou Community, Shiyan Subdistrict, Bao'an District, Shenzhen, Guangdong, China Web: http://www.dace-lab.com Tel: +86-755-23010613 E-mail: [email protected] Page 3 of 52 Revision History Of Report Version Description REPORT No. Issue Date V1.0 Original DACE251106002RF001 December 12, 2025 V1.0 Report No.: DACE251106002RF001 102, Building H1, & 1/F., Building H, Hongfa Science & Technology Park, Tangtou Community, Shiyan Subdistrict, Bao'an District, Shenzhen, Guangdong, China Web: http://www.dace-lab.com Tel: +86-755-23010613 E-mail: [email protected] Page 4 of 52 CONTENTS 1 TEST SUMMARY ........................................................................................................................................... 5 1.1 TEST STANDARDS .................................................................................................................................. 5 1.2 SUMMARY OF TEST RESULT .................................................................................................................... 5 2 GENERAL INFORMATION ............................................................................................................................ 6 2.1 CLIENT INFORMATION ............................................................................................................................. 6 2.2 DESCRIPTION OF DEVICE (EUT) .............................................................................................................. 6 2.3 DESCRIPTION OF TEST MODES ................................................................................................................ 7 2.4 DESCRIPTION OF SUPPORT UNITS ........................................................................................................... 7 2.5 EQUIPMENTS USED DURING THE TEST .................................................................................................... 7 2.6 STATEMENT OF THE MEASUREMENT UNCERTAINTY ................................................................................. 9 2.7 AUTHORIZATIONS ................................................................................................................................... 9 2.8 ANNOUNCEMENT .................................................................................................................................... 9 3 EVALUATION RESULTS (E VA L U AT I O N ) ................................................................................................... 10 3.1 ANTENNA REQUIREMENT ....................................................................................................................... 10 3.1.1 Conclusion: ............................................................................................................................. 10 4 RADIO SPECTRUM MATTER TEST RESULTS (RF) .................................................................................. 11 4.1 EFFECTIVE (ISOTROPIC) RADIATED POWER OUTPUT ............................................................................... 11 4.1.1 E.U.T. Operation: ..................................................................................................................... 11 4.1.2 Test Setup Diagram: .............................β¦
Text truncated - open the document above for the full version.
Test Report
Report FCC ID: 2A4FB-BP-M13 Appendix-BAND66 1. Conducted output power Band Bandwidth (MHz) UL Channel RB Size RB Position Modulation Conducted Power (dBm) (Limit) (dBm) Verdict Band66 1.4 131979 1 #0 QPSK 17.27 30.01 PASS Band66 1.4 131979 1 #Mid QPSK 17.14 30.01 PASS Band66 1.4 131979 1 #Max QPSK 17.05 30.01 PASS Band66 1.4 131979 3 #0 QPSK 17.18 30.01 PASS Band66 1.4 131979 3 #Max QPSK 17.23 30.01 PASS Band66 1.4 131979 6 #0 QPSK 16.20 30.01 PASS Band66 1.4 131979 1 #0 QAM16 16.33 30.01 PASS Band66 1.4 131979 1 #Mid QAM16 16.29 30.01 PASS Band66 1.4 131979 1 #Max QAM16 16.21 30.01 PASS Band66 1.4 131979 3 #0 QAM16 16.13 30.01 PASS Band66 1.4 131979 3 #Max QAM16 16.02 30.01 PASS Band66 1.4 131979 6 #0 QAM16 15.29 30.01 PASS Band66 1.4 132322 1 #0 QPSK 15.56 30.01 PASS Band66 1.4 132322 1 #Mid QPSK 15.48 30.01 PASS Band66 1.4 132322 1 #Max QPSK 15.43 30.01 PASS Band66 1.4 132322 3 #0 QPSK 15.47 30.01 PASS Band66 1.4 132322 3 #Max QPSK 15.35 30.01 PASS Band66 1.4 132322 6 #0 QPSK 14.76 30.01 PASS Band66 1.4 132322 1 #0 QAM16 14.67 30.01 PASS Band66 1.4 132322 1 #Mid QAM16 14.46 30.01 PASS Band66 1.4 132322 1 #Max QAM16 14.50 30.01 PASS Band66 1.4 132322 3 #0 QAM16 14.71 30.01 PASS Band66 1.4 132322 3 #Max QAM16 14.51 30.01 PASS Band66 1.4 132322 6 #0 QAM16 13.78 30.01 PASS Band66 1.4 132665 1 #0 QPSK 16.33 30.01 PASS Band66 1.4 132665 1 #Mid QPSK 15.98 30.01 PASS Band66 1.4 132665 1 #Max QPSK 15.90 30.01 PASS Band66 1.4 132665 3 #0 QPSK 16.09 30.01 PASS Band66 1.4 132665 3 #Max QPSK 15.77 30.01 PASS Band66 1.4 132665 6 #0 QPSK 14.93 30.01 PASS Band66 1.4 132665 1 #0 QAM16 15.19 30.01 PASS Band66 1.4 132665 1 #Mid QAM16 14.94 30.01 PASS Report Band66 1.4 132665 1 #Max QAM16 14.73 30.01 PASS Band66 1.4 132665 3 #0 QAM16 15.16 30.01 PASS Band66 1.4 132665 3 #Max QAM16 14.89 30.01 PASS Band66 1.4 132665 6 #0 QAM16 14.01 30.01 PASS Band66 3 131987 1 #0 QPSK 17.12 30.01 PASS Band66 3 131987 1 #Mid QPSK 16.96 30.01 PASS Band66 3 131987 1 #Max QPSK 16.65 30.01 PASS Band66 3 131987 8 #0 QPSK 16.14 30.01 PASS Band66 3 131987 8 #Max QPSK 15.77 30.01 PASS Band66 3 131987 15 #0 QPSK 16.08 30.01 PASS Band66 3 131987 1 #0 QAM16 16.36 30.01 PASS Band66 3 131987 1 #Mid QAM16 16.03 30.01 PASS Band66 3 131987 1 #Max QAM16 15.78 30.01 PASS Band66 3 131987 8 #0 QAM16 15.33 30.01 PASS Band66 3 131987 8 #Max QAM16 14.84 30.01 PASS Band66 3 131987 15 #0 QAM16 15.12 30.01 PASS Band66 3 132322 1 #0 QPSK 15.48 30.01 PASS Band66 3 132322 1 #Mid QPSK 15.31 30.01 PASS Band66 3 132322 1 #Max QPSK 15.22 30.01 PASS Band66 3 132322 8 #0 QPSK 14.85 30.01 PASS Band66 3 132322 8 #Max QPSK 14.55 30.01 PASS Band66 3 132322 15 #0 QPSK 14.74 30.01 PASS Band66 3 132322 1 #0 QAM16 14.97 30.01 PASS Band66 3 132322 1 #Mid QAM16 14.64 30.01 PASS Band66 3 132322 1 #Max QAM16 14.52 30.01 PASS Band66 3 132322 8 #0 QAM16 14.00 30.01 PASS Band66 3 132322 8 #Max QAM16 13.69 30.01 PASS Band66 3 132322 15 #0 QAM16 13.85 30.01 PASS Band66 3 132657 1 #0 QPSK 16.87 30.01 PASS Band66 3 132657 1 #Mid QPSK 16.17 30.01 PASS Band66 3 132657 1 #Max QPSK 15.76 30.01 PASS Band66 3 132657 8 #0 QPSK 15.64 30.01 PASS Band66 3 132657 8 #Max QPSK 15.05 30.01 PASS Band66 3 132657 15 #0 QPSK 15.35 30.01 PASS Band66 3 132657 1 #0 QAM16 16.05 30.01 PASS Band66 3 132657 1 #Mid QAM16 15.30 30.01 PASS Band66 3 132657 1 #Max QAM16 14.84 30.01 PASS Band66 3 132657 8 #0 QAM16 14.80 30.01 PASS Band66 3 132657 8 #Max QAM16 14.10 30.01 PASS Band66 3 132657 15 #0 QAM16 14.32 30.01 PASS Band66 5 131997 1 #0 QPSK 17.30 30.01 PASS Band66 5 131997 1 #Mid QPSK 16.69 30.01 PASS Band66 5 131997 1 #Max QPSK 16.24 30.01 PASS Band66 5 131997 12 #0 QPSK 16.13 30.01 PASS Report Band66 5 131997 12 #Max QPSK 15.45 30.01 PASS Band66 5 131997 25 #0 QPSK 15.66 30.01 PASS Band66 5 131997 1 #0 QAM16 16.53 30.01 PASS Band66 5 131997 1 #Mid QAM16 15.94 30.01 PASS Band66 5 131997 1 #Max QAM16 15.44 30.01 PASS Band66 5 131997 12 #0 QAM16 15.18 30.01 PASS Band66 5 131997 12 #Max QAM16 14.37 30.01 PASS Band66 5 131997 25 #0 QAM16 14.70 30.01 PASS Band66 5 132322 1 #0 QPSK 15.80 30.01 PASS Band66 5 132322 1 #Mid QPSK 15.55 30.01 PASS Band66 5 132322 1 #Max QPSK 15.18 30.01 PASS Band66 5 132322 12 #0 QPSK 15.00 30.01 PASS Band66 5 132322 12 #Max QPSK 14.64 30.01 PASS Band66 5 132322 25 #0 QPSK 14.77 30.01 PASS Band66 5 132322 1 #0 QAM16 15.12 30.01 PASS Band66 5 132322 1 #Mid QAM16 14.74 30.01 PASS Band66 5 132322 1 #Max QAM16 14.52 30.01 PASS Band66 5 132322 12 #0 QAM16 14.10 30.01 PASS Band66 5 132322 12 #Max QAM16 13.60 30.01 PASS Band66 5 132322 25 #0 QAM16 13.72 30.01 PASS Band66 5 132647 1 #0 QPSK 17.54 30.01 PASS Band66 5 132647 1 #Mid QPSK 16.60 30.01 PASS Band66 5 132647 1 #Max QPSK 15.65 30.01 PASS Band66 5 132647 12 #0 QPSK 16.16 30.01 PASS Band66 5 132647 12 #Max QPSK 15.06 30.01 PASS Band66 5 132647 25 #0 QPSK 15.63 30.01 PASS Band66 5 132647 1 #0 QAM16 16.74 30.01 PASS Band66 5 132647 1 #Mid QAM16 15.73 30.01 PASS Band66 5 132647 1 #Max QAM16 14.89 30.01 PASS Band66 5 132647 12 #0 QAM16 15.39 30.01 PASS Band66 5 132647 12 #Max QAM16 14.29 30.01 PASS Band66 5 132647 25 #0 QAM16 14.83 30.01 PASS Band66 10 132022 1 #0 QPSK 17.17 30.01 PASS Band66 10 132022 1 #Mid QPSK 15.77 30.01 PASS Band66 10 132022 1 #Max QPSK 14.70 30.01 PASS Band66 10 132022 25 #0 QPSK 15.27 30.01 PASS Band66 10 132022 25 #Max QPSK 13.73 30.01 PASS Band66 10 132022 50 #0 QPSK 14.68 30.01 PASS Band66 10 132022 1 #0 QAM16 16.17 30.01 PASS Band66 10 132022 1 #Mid QAM16 14.52 30.01 PASS Band66 10 132022 1 #Max QAM16 13.32 30.01 PASS Band66 10 132022 25 #0 QAM16 14.31 30.01 PASS Band66 10 132022 25 #Max QAM16 12.98 30.01 PASS Band66 10 132322 1 #0 QPSK 15.88 30.01 PASS Report Band66 10 132322 1 #Mid QPSK 15.34 30.01 PASS Band66 10 132322 1 #Max QPSK 14.82 30.01 PASS Band66 10 132322 25 #0 QPSK 14.85 30.01 PASS Band66 10 132322 25 #Max QPSK 14.06 30.01 PASS Band66 10 132322 50 #0 QPSK 14.36 30.01 PASS Band66 10 132322 1 #0 QAM16 15.22 30.01 PASS Band66 10 132322 1 #Mid QAM16 14.64 30.01 PASS Band66 10 132322 1 #Max QAM16β¦
Text truncated - open the document above for the full version.
Test Report
Report FCC ID: 2A4FB-BP-M13 Appendix-BAND7 1. Conducted output power Band Bandwidth (MHz) UL Channel RB Size RB Position Modulation Conducted Power (dBm) (Limit) (dBm) Verdict Band7 5 20775 1 #0 QPSK 10.56 33.01 PASS Band7 5 20775 1 #Mid QPSK 11.33 33.01 PASS Band7 5 20775 1 #Max QPSK 11.44 33.01 PASS Band7 5 20775 12 #0 QPSK 9.99 33.01 PASS Band7 5 20775 12 #Max QPSK 10.58 33.01 PASS Band7 5 20775 25 #0 QPSK 10.29 33.01 PASS Band7 5 20775 1 #0 QAM16 10.07 33.01 PASS Band7 5 20775 1 #Mid QAM16 10.67 33.01 PASS Band7 5 20775 1 #Max QAM16 10.86 33.01 PASS Band7 5 20775 12 #0 QAM16 9.23 33.01 PASS Band7 5 20775 12 #Max QAM16 9.77 33.01 PASS Band7 5 20775 25 #0 QAM16 9.51 33.01 PASS Band7 5 21100 1 #0 QPSK 8.67 33.01 PASS Band7 5 21100 1 #Mid QPSK 8.89 33.01 PASS Band7 5 21100 1 #Max QPSK 9.19 33.01 PASS Band7 5 21100 12 #0 QPSK 7.66 33.01 PASS Band7 5 21100 12 #Max QPSK 8.03 33.01 PASS Band7 5 21100 25 #0 QPSK 7.84 33.01 PASS Band7 5 21100 1 #0 QAM16 8.00 33.01 PASS Band7 5 21100 1 #Mid QAM16 8.34 33.01 PASS Band7 5 21100 1 #Max QAM16 8.61 33.01 PASS Band7 5 21100 12 #0 QAM16 6.84 33.01 PASS Band7 5 21100 12 #Max QAM16 7.27 33.01 PASS Band7 5 21100 25 #0 QAM16 7.10 33.01 PASS Band7 5 21425 1 #0 QPSK 8.44 33.01 PASS Band7 5 21425 1 #Mid QPSK 7.98 33.01 PASS Band7 5 21425 1 #Max QPSK 7.65 33.01 PASS Band7 5 21425 12 #0 QPSK 7.28 33.01 PASS Band7 5 21425 12 #Max QPSK 6.96 33.01 PASS Band7 5 21425 25 #0 QPSK 7.15 33.01 PASS Report Band7 5 21425 1 #0 QAM16 7.66 33.01 PASS Band7 5 21425 1 #Mid QAM16 7.32 33.01 PASS Band7 5 21425 1 #Max QAM16 7.06 33.01 PASS Band7 5 21425 12 #0 QAM16 6.30 33.01 PASS Band7 5 21425 12 #Max QAM16 5.99 33.01 PASS Band7 5 21425 25 #0 QAM16 6.22 33.01 PASS Band7 10 20800 1 #0 QPSK 11.05 33.01 PASS Band7 10 20800 1 #Mid QPSK 11.27 33.01 PASS Band7 10 20800 1 #Max QPSK 10.80 33.01 PASS Band7 10 20800 25 #0 QPSK 10.26 33.01 PASS Band7 10 20800 25 #Max QPSK 10.28 33.01 PASS Band7 10 20800 50 #0 QPSK 10.28 33.01 PASS Band7 10 20800 1 #0 QAM16 10.29 33.01 PASS Band7 10 20800 1 #Mid QAM16 10.59 33.01 PASS Band7 10 20800 1 #Max QAM16 10.22 33.01 PASS Band7 10 20800 25 #0 QAM16 9.53 33.01 PASS Band7 10 20800 25 #Max QAM16 9.54 33.01 PASS Band7 10 21100 1 #0 QPSK 8.37 33.01 PASS Band7 10 21100 1 #Mid QPSK 8.82 33.01 PASS Band7 10 21100 1 #Max QPSK 9.82 33.01 PASS Band7 10 21100 25 #0 QPSK 7.42 33.01 PASS Band7 10 21100 25 #Max QPSK 8.15 33.01 PASS Band7 10 21100 50 #0 QPSK 7.73 33.01 PASS Band7 10 21100 1 #0 QAM16 7.48 33.01 PASS Band7 10 21100 1 #Mid QAM16 8.30 33.01 PASS Band7 10 21100 1 #Max QAM16 9.12 33.01 PASS Band7 10 21100 25 #0 QAM16 6.82 33.01 PASS Band7 10 21100 25 #Max QAM16 7.55 33.01 PASS Band7 10 21400 1 #0 QPSK 9.38 33.01 PASS Band7 10 21400 1 #Mid QPSK 8.16 33.01 PASS Band7 10 21400 1 #Max QPSK 7.54 33.01 PASS Band7 10 21400 25 #0 QPSK 7.71 33.01 PASS Band7 10 21400 25 #Max QPSK 6.89 33.01 PASS Band7 10 21400 50 #0 QPSK 7.34 33.01 PASS Band7 10 21400 1 #0 QAM16 8.10 33.01 PASS Band7 10 21400 1 #Mid QAM16 6.90 33.01 PASS Band7 10 21400 1 #Max QAM16 6.31 33.01 PASS Band7 10 21400 25 #0 QAM16 6.51 33.01 PASS Band7 10 21400 25 #Max QAM16 5.71 33.01 PASS Band7 15 20825 1 #0 QPSK 11.53 33.01 PASS Band7 15 20825 1 #Mid QPSK 11.34 33.01 PASS Band7 15 20825 1 #Max QPSK 10.24 33.01 PASS Band7 15 20825 36 #0 QPSK 10.82 33.01 PASS Band7 15 20825 36 #Max QPSK 10.04 33.01 PASS Report Band7 15 20825 75 #0 QPSK 10.42 33.01 PASS Band7 15 20825 1 #0 QAM16 10.89 33.01 PASS Band7 15 20825 1 #Mid QAM16 10.77 33.01 PASS Band7 15 20825 1 #Max QAM16 9.70 33.01 PASS Band7 15 20825 27 #0 QAM16 10.04 33.01 PASS Band7 15 20825 27 #Max QAM16 9. 11 33.01 PASS Band7 15 21100 1 #0 QPSK 8.67 33.01 PASS Band7 15 21100 1 #Mid QPSK 9.19 33.01 PASS Band7 15 21100 1 #Max QPSK 10.82 33.01 PASS Band7 15 21100 36 #0 QPSK 7.82 33.01 PASS Band7 15 21100 36 #Max QPSK 9.00 33.01 PASS Band7 15 21100 75 #0 QPSK 8.49 33.01 PASS Band7 15 21100 1 #0 QAM16 7.92 33.01 PASS Band7 15 21100 1 #Mid QAM16 8.58 33.01 PASS Band7 15 21100 1 #Max QAM16 10.10 33.01 PASS Band7 15 21100 27 #0 QAM16 6.98 33.01 PASS Band7 15 21100 27 #Max QAM16 8.43 33.01 PASS Band7 15 21375 1 #0 QPSK 10.79 33.01 PASS Band7 15 21375 1 #Mid QPSK 8.81 33.01 PASS Band7 15 21375 1 #Max QPSK 7.66 33.01 PASS Band7 15 21375 36 #0 QPSK 8.95 33.01 PASS Band7 15 21375 36 #Max QPSK 7.22 33.01 PASS Band7 15 21375 75 #0 QPSK 8.69 33.01 PASS Band7 15 21375 1 #0 QAM16 10.39 33.01 PASS Band7 15 21375 1 #Mid QAM16 8.55 33.01 PASS Band7 15 21375 1 #Max QAM16 7.31 33.01 PASS Band7 15 21375 27 #0 QAM16 8.72 33.01 PASS Band7 15 21375 27 #Max QAM16 6.51 33.01 PASS Band7 20 20850 1 #0 QPSK 11.52 33.01 PASS Band7 20 20850 1 #Mid QPSK 11.24 33.01 PASS Band7 20 20850 1 #Max QPSK 9.52 33.01 PASS Band7 20 20850 50 #0 QPSK 10.70 33.01 PASS Band7 20 20850 50 #Max QPSK 9.49 33.01 PASS Band7 20 20850 100 #0 QPSK 10.15 33.01 PASS Band7 20 20850 1 #0 QAM16 10.71 33.01 PASS Band7 20 20850 1 #Mid QAM16 10.43 33.01 PASS Band7 20 20850 1 #Max QAM16 8.73 33.01 PASS Band7 20 20850 27 #0 QAM16 9.89 33.01 PASS Band7 20 20850 27 #Max QAM16 8.12 33.01 PASS Band7 20 21100 1 #0 QPSK 8.64 33.01 PASS Band7 20 21100 1 #Mid QPSK 9.19 33.01 PASS Band7 20 21100 1 #Max QPSK 11.47 33.01 PASS Band7 20 21100 50 #0 QPSK 7.93 33.01 PASS Band7 20 21100 50 #Max QPSK 9.09 33.01 PASS Report Band7 20 21100 100 #0 QPSK 8.52 33.01 PASS Band7 20 21100 1 #0 QAM16 7.92 33.01 PASS Band7 20 21100 1 #Mid QAM16 8.46 33.01 PASS Band7 20 21100 1 #Max QAM16 10.61 33.01 PASS Band7 20 21100 27 #0 QAM16 6.73 33.01 PASS Band7 20 21100 27 #Max QAM16 8.74 33.01 PASS Band7 20 21350 1 #0 QPSK 11.81 33.01 PASS Band7 20 21350 1 #Mid QPSK 9.73 33.01 PASS Band7 20 21350 1 #Max QPSK 7.76 33.01 PASS Band7 20 21350 50 #0 QPSK 10.11 33.01 PASS Band7 20 21350 50 #Max QPSK 7.70 33.01 PASS Band7 20 21350 100 #0 QPSK 9.10 33.01 PASS Band7 20 21350 1 #0 QAM16 10.92 33.01 PASS Band7 20 21350 1 #Mid QAM16 9.06 33.01 PASS Band7 20 21350 1 #Max QAM16 6.98 33.01 PASS Band7 20 21350 27 #0 QAM16 9.86 33.01 PASS Band7 20 21350 27 #Max QAM16 6.45 β¦
Text truncated - open the document above for the full version.
Test Report
Report FCC ID: 2A4FB-BP-M13 Appendix-BAND5 1. Conducted output power Band Bandwidth (MHz) UL Channel RB Size RB Position Modulation Conducted Power (dBm) (Limit) (dBm) Verdict Band5 1.4 20407 1 #0 QPSK 16.97 38.45 PASS Band5 1.4 20407 1 #Mid QPSK 17.37 38.45 PASS Band5 1.4 20407 1 #Max QPSK 17.62 38.45 PASS Band5 1.4 20407 3 #0 QPSK 17.06 38.45 PASS Band5 1.4 20407 3 #Max QPSK 17.48 38.45 PASS Band5 1.4 20407 6 #0 QPSK 16.32 38.45 PASS Band5 1.4 20407 1 #0 QAM16 16.14 38.45 PASS Band5 1.4 20407 1 #Mid QAM16 16.58 38.45 PASS Band5 1.4 20407 1 #Max QAM16 16.76 38.45 PASS Band5 1.4 20407 3 #0 QAM16 16.35 38.45 PASS Band5 1.4 20407 3 #Max QAM16 16.84 38.45 PASS Band5 1.4 20407 6 #0 QAM16 15.42 38.45 PASS Band5 1.4 20525 1 #0 QPSK 17.84 38.45 PASS Band5 1.4 20525 1 #Mid QPSK 17.86 38.45 PASS Band5 1.4 20525 1 #Max QPSK 17.80 38.45 PASS Band5 1.4 20525 3 #0 QPSK 17.73 38.45 PASS Band5 1.4 20525 3 #Max QPSK 17.78 38.45 PASS Band5 1.4 20525 6 #0 QPSK 16.80 38.45 PASS Band5 1.4 20525 1 #0 QAM16 17.00 38.45 PASS Band5 1.4 20525 1 #Mid QAM16 17.07 38.45 PASS Band5 1.4 20525 1 #Max QAM16 17.05 38.45 PASS Band5 1.4 20525 3 #0 QAM16 16.87 38.45 PASS Band5 1.4 20525 3 #Max QAM16 16.90 38.45 PASS Band5 1.4 20525 6 #0 QAM16 16.00 38.45 PASS Band5 1.4 20643 1 #0 QPSK 17.48 38.45 PASS Band5 1.4 20643 1 #Mid QPSK 17.16 38.45 PASS Band5 1.4 20643 1 #Max QPSK 16.83 38.45 PASS Band5 1.4 20643 3 #0 QPSK 17.22 38.45 PASS Band5 1.4 20643 3 #Max QPSK 16.90 38.45 PASS Band5 1.4 20643 6 #0 QPSK 16.17 38.45 PASS Report Band5 1.4 20643 1 #0 QAM16 16.35 38.45 PASS Band5 1.4 20643 1 #Mid QAM16 16.06 38.45 PASS Band5 1.4 20643 1 #Max QAM16 15.84 38.45 PASS Band5 1.4 20643 3 #0 QAM16 16.31 38.45 PASS Band5 1.4 20643 3 #Max QAM16 16.03 38.45 PASS Band5 1.4 20643 6 #0 QAM16 15.43 38.45 PASS Band5 3 20415 1 #0 QPSK 16.98 38.45 PASS Band5 3 20415 1 #Mid QPSK 18.06 38.45 PASS Band5 3 20415 1 #Max QPSK 18.49 38.45 PASS Band5 3 20415 8 #0 QPSK 16.51 38.45 PASS Band5 3 20415 8 #Max QPSK 17.30 38.45 PASS Band5 3 20415 15 #0 QPSK 16.97 38.45 PASS Band5 3 20415 1 #0 QAM16 16.46 38.45 PASS Band5 3 20415 1 #Mid QAM16 17.48 38.45 PASS Band5 3 20415 1 #Max QAM16 17.85 38.45 PASS Band5 3 20415 8 #0 QAM16 15.66 38.45 PASS Band5 3 20415 8 #Max QAM16 16.40 38.45 PASS Band5 3 20415 15 #0 QAM16 15.95 38.45 PASS Band5 3 20525 1 #0 QPSK 17.78 38.45 PASS Band5 3 20525 1 #Mid QPSK 17.80 38.45 PASS Band5 3 20525 1 #Max QPSK 17.82 38.45 PASS Band5 3 20525 8 #0 QPSK 16.79 38.45 PASS Band5 3 20525 8 #Max QPSK 16.86 38.45 PASS Band5 3 20525 15 #0 QPSK 16.79 38.45 PASS Band5 3 20525 1 #0 QAM16 16.99 38.45 PASS Band5 3 20525 1 #Mid QAM16 17.03 38.45 PASS Band5 3 20525 1 #Max QAM16 17.22 38.45 PASS Band5 3β¦
Text truncated - open the document above for the full version.
Contact Information
Applicant
Nian Harry
[email protected]Fax: 18928869460
Technical Contact
HOPEK CORPORATION INCYangyang Xu
16755 Coyote Bush Dr Unit 84, Β· San Diego, 92127 Β· United States
Test Firm
Shenzhen DACE Testing Technology Co., Ltd.Colin Huang
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 1 | 24E | 1.86 GHz - 1.90 GHz | 56.10 mW | 17M8G7D | 2.5ppm |
| 2 | 24E | 1.86 GHz - 1.90 GHz | 47.53 mW | 5M21W7D | 2.5ppm |
| 3 | 24E | 1.86 GHz - 1.90 GHz | 64.86 mW | 13M4G7D | 2.5ppm |
| 4 | 24E | 1.86 GHz - 1.90 GHz | 57.41 mW | 5M07W7D | 2.5ppm |
| 5 | 27 | 1.72 GHz - 1.75 GHz | 48.87 mW | 18M0G7D | 2.5ppm |
| 6 | 27 | 1.72 GHz - 1.75 GHz | 40.64 mW | 5M19W7D | 2.5ppm |
| 7 | 27 | 1.71 GHz - 1.75 GHz | 52.36 mW | 1M10G7D | 2.5ppm |
| 8 | 27 | 1.71 GHz - 1.75 GHz | 44.16 mW | 4M50W7D | 2.5ppm |
| 9 | 22H | 829 MHz - 844 MHz | 75.86 mW | 8M94G7D | 2.5ppm |
| 1 | 22H | 829 MHz - 844 MHz | 63.83 mW | 4M93W7D | 2.5ppm |
| 11 | 22H | 826.5 MHz - 846.5 MHz | 77.62 mW | 4M49G7D | 2.5ppm |
| 12 | 22H | 826.5 MHz - 846.5 MHz | 67.92 mW | 4M49W7D | 2.5ppm |
| 13 | 27 | 2.51 GHz - 2.56 GHz | 15.17 mW | 17M9G7D | 2.5ppm |
| 14 | 27 | 2.51 GHz - 2.56 GHz | 12.36 mW | 5M22W7D | 2.5ppm |
| 15 | 27 | 1.72 GHz - 1.77 GHz | 52.00 mW | 17M8G7D | 2.5ppm |
| 16 | 27 | 1.72 GHz - 1.77 GHz | 42.46 mW | 5M20W7D | 2.5ppm |
| 17 | 27 | 1.72 GHz - 1.77 GHz | 62.81 mW | 13M3G7D | 2.5ppm |
| 18 | 27 | 1.72 GHz - 1.77 GHz | 50.23 mW | 5M06W7D | 2.5ppm |
