2A4FVCBST03BLORB12VIndoor/Outdoor Step Light

Cloudy Bay Lighting Supply Inc

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jul 03, 2022
Application Purpose: Original Equipment
Date of Application: Jul 02, 2022
Equipment Note: Indoor/Outdoor Step Light
Frequency Range: 2402.00000000 - 2480.00000000
Company: Cloudy Bay Lighting Supply Inc
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Thank you for purchasing CloudyBay Smart LED Lighting Fixtures. 1.Fix the Mounting Bracket(3) to the OUTLET BOX(1) with attached FIXTURE SCREW(2) 2.Pull out low voltage wires from OUTLET BOX(1). Unlike Line voltage products, you don’t need to specify live wire/ neutral wire. Connect LOW VOLTAGE WIRE ONE(8) to BLACK FIXTURE WIRE ONE(4), LOW VOLTAGE WIRE TWO(9) TO BLACK FIXTURE WIRE TWO(5). Please make sure the wires are firm connection, and seal the WIRE NUTS(6) with silicone to ensure stable performance in long term. 3. Check the MOUNTING BRACKET(3) is fixed flat on OUTLET BOX(1)’s surface, press the SPRING CLIP evenly into the MOUNTING BRACKET(3) until all clips have a good connection with MOUNTING BRACKET(3)’s edge. 4.Installation Complete For Outdoor application: caulk the connection area between face cover and wall with outdoor rated sealant for stable performance. Junction Box for Indoor Tips: Junction Box excluded in the package Screws spaced 3-3/8 inch Depth: 1-5/8 inch Wide: 2-1/8 inch Length: 4 inch Junction Box for Outdoor Tips: Junction Box excluded in the package Screws spaced 3-3/8 inch Depth: 2 inch Wide: 2-3/4 inch Length: 4-5/8 inch 10 1.OUTLET BOX (EXCLUDED) 2. FIXTURE SCREWS 3. MOUNTING BRACKET 4. BLACK FiXTURE WIRE ONE 5. BLACK FIXTURE WIRE TWO 6. WIRE NUTS 7. LIGHT BOD Y INTERGRATED WITH FACE COVER 8. LOW VOL TAGE WIRE ONE 9. LOW VOL T AGE WIRE TWO 10. WASHER (2PCS 6x25 and 2PCS 6x16 SCREW INCLUDED) Indoor/Outdoor Step Light DON’T SUBMERGE THE LIGHT BODY INTO WATER INSTALL IT IN AREA WITH HIGH SALTY MOISTURE OR CORROSIVE ENVIROMENT WILL LEAD TO FAST CORROSION SINCE IT IS NOT DESIGNED FOR THIS PURPOSE * * Please add washers between MOUNTING BRACKET and this type Junction Box so that light body can be inserted into mounting bracket 1.Make sure you have low voltage transformer or adaptor before you start your project 2. Make sure you connect your step light to proper low voltage power source 3. Improper voltage input may distroy your lights and make your warranty invalid +  CBST03BLXX12V LOW VOLTAGE TRANSFORMER LOW VOLTAGE TRANSFORMER (EXCLUDED)

Cover Letter(s)

CloudyBayLightingSupplyInc AgentAuthorization Company:CloudyBayLightingSupplyInc Address:131217thStreetSuite692DenverCO80202UnitedStates ProductName:Indoor/OutdoorStepLight TradeMark:CloudyBay ModelNumber(s):CBST03BLORB12V,CBST03BLWH12V,CBST03BLBN12V, CBST03BLBK12VorCBST03BLXX12V,XX=other FCCID:2A4FVCBST03BLORB12V WeauthorizeMiCOMLabsInc.,575BoulderCourt,Pleasanton,California94566,USA, toactonourbehalfonallmattersconcerningthecertificationofabovenamed equipment. WedeclarethatMiCOMLabsInc.isallowedtoforwardallinformationrelatedtothe approvalandcertificationofequipmenttotheregulatoryagenciesasrequiredandto discussanyissuesconcerningtheapprovalapplication.Anyandallactscarriedoutby MiCOMLabsonourbehalfshallhavethesameeffectasactsofourown. Signature:Date:2022-06-28 Name:LarryLee Title:ProductManager Company:CloudyBayLightingSupplyInc

Cover Letter(s)

CloudyBayLightingSupplyInc Add:131217thStreetSuite692DenverCO80202UnitedStates Tel:2812018879Fax:/ Date:2022-06-28 To:MiCOMLabsInc 575BoulderCourt,Pleasanton,California94566,USA DearSir/Madam, We,CloudyBayLightingSupplyIncHerebydeclaresthefollowingstatementforMiCOM LabsInc,PCBboard,structureandinternalofthesemodel(s)arethesame,Onlymodels nameisdifferentforthesemodels: Productname:Indoor/OutdoorStepLight TradeMark:CloudyBay ModelNo.:CBST03BLORB12V,CBST03BLWH12V,CBST03BLBN12V,CBST03BLBK12V orCBST03BLXX12V,XX=other Sincerely, Client’sname/title:LarryLee/ProductManager Address:131217thStreetSuite692DenverCO80202UnitedStates Tel:2812018879Fax:/ E-mail:[email protected]

Cover Letter(s)

CloudyBayLightingSupplyInc OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:2022-06-28 Subject;RequestforConfidentiality FCCID:2A4FVCBST03BLORB12V ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthesedocuments mightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantageinthemarket. SchematicDiagram BlockDiagram OperationalDescription Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:LarryLee Title:ProductManager

External Photos

ID Label/Location Info

Page1of1FCCID:2A4FVCBST03BLORB12V ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity LABELANDLOCATION (Size:L2.5cmx2.0cm) LabelLocation Indoor/OutdoorStepLight Model:CBST03BLORB12V FCCID:2A4FVCBST03BLORB12V

Internal Photos

Page1of6FCCID:2A4FVCBST03BLORB12V ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity InternalPhotosoftheEUT Fig.1 Fig.2 Page2of6FCCID:2A4FVCBST03BLORB12V ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Fig.3 Fig.4 Page3of6FCCID:2A4FVCBST03BLORB12V ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Fig.5 Fig.6 Page4of6FCCID:2A4FVCBST03BLORB12V ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Fig.7 Fig.8 Page5of6FCCID:2A4FVCBST03BLORB12V ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Fig.9 Fig.10 BTantenna Page6of6FCCID:2A4FVCBST03BLORB12V ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Fig.11 Fig.12

RF Exposure Info

Page 1 of 4 FCCID:2A4FVCBST03BLORB12V ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity FCCRFExposureEvaluation 1.ProductInformation FCCID2A4FVCBST03BLORB12V ProductnameIndoor/OutdoorStepLight ModelnumberCBST03BLORB12V AdditionalModelNo.CBST03BLWH12V,CBST03BLBN12V,CBST03BLBK12Vor CBST03BLXX12V,XX=other ModelDeclaration PCBboard,structureandinternalofthesemodel(s)arethe same,Sonoadditionalmodelsweretested PowersupplyDC12V/AC12V ModulationTypeGFSKforBluetoothV5.0(DTS) AntennaTypemonopoleantenna AntennaGain0dBi(Max.) Hardwareversion/ Softwareversion/ FCCOperationfrequency2402MHz-2480MHz ExposurecategoryGeneralpopulation/uncontrolledenvironment EUTTypeProductionUnit DeviceTypeMobileDevices 2.EvaluationMethod SystemsoperatingundertheprovisionsofFCC47CFRsectionshallbeoperatedinamannerthatensures thatthepublicisnotexposedtoradiofrequencyenergylevelinexcessoftheCommission’sguidelines. Inaccordancewith47CFRFCCPart2SubpartJ,section2.1091thisdevicehasbeendefinedasmobile devicewherebyadistanceof0.2mnormallycanbemaintainedbetweentheuserandthedevice,andbelow RFPermissibleExposurelimitshallcomplywith. InaccordancewithKDB447498D01forSimultaneoustransmissionMPEtestexclusionapplieswhenthesum oftheMPEratiosforallsimultaneoustransmittingantennasincorporatedinahostdevice,basedonthe calculated/estimated,numericallymodelledormeasuredfieldstrengthsorpowerdensity,is≤1.0.TheMPE ratioofeachantennaisdeterminedattheminimumtestseparationdistancerequiredbytheoperating configurationsandexposureconditionsofthehostdevice,accordingtotheratiooffieldstrengthsorpower densitytoMPElimit,atthetestfrequency.Eitherthemaximumpeakorspatiallyaveragedresultsfrom measurementsornumericalsimulationsmaybeusedtodeterminetheMPEratios.Spatialaveragingdoesnot applywhenMPEisestimatedusingsimplecalculationsbasedonfar-fieldplane-waveequivalentconditions. Theantennainstallationandoperatingrequirementsforthehostdevicemustmeettheminimumtest separationdistancesrequiredbyallantennas,inbothstandaloneandsimultaneoustransmissionoperations, tosatisfycompliance. Page 2 of 4 FCCID:2A4FVCBST03BLORB12V ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 3.Limit 3.1ReferEvaluationMethod ANSIC95.1–1999:IEEEStandardforSafetyLevelswithRespecttoHumanExposuretoRadioFrequency ElectromagneticFields,3kHzto300GHz. FCCKDBpublication447498D01General1RFExposureGuidancev06:MobileandPortableDevicesRF ExposureProceduresandEquipmentAuthorizationPolicies. FCCCFR47part11.1310:Radiofrequencyradiationexposurelimits. FCCCFR47part22.1091:Radiofrequencyradiationexposureevaluation:mobiledevices 3.2Limit LimitsforMaximumPermissibleExposure(MPE)/ControlledExposure Frequency Range(MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) PowerDensity (mW/cm²) AveragingTime (minute) LimitsforOccupational/ControlledExposure 0.3–3.0 3.0–30 30–300 300–1500 1500–100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100)* (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 LimitsforMaximumPermissibleExposure(MPE)/UncontrolledExposure Frequency Range(MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) PowerDensity (mW/cm²) AveragingTime (minute) LimitsforOccupational/ControlledExposure 0.3–3.0 3.0–30 30–300 300–1500 1500–100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100)* (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequencyinMHz *=Plane-waveequivalentpowerdensity 4.MPECalculationMethod PredicationofMPElimitatagivendistance Equationfrompage18ofOETBulletin65,Edition97-01 S=PG/4πR² Where:S=powerdensity P=powerinputtoantenna G=powergainoftheantennainthedirectionofinterestrelativetoanisotropicradiator R=distancetothecenterofradiationoftheantenna 5.AntennaInformation monopoleantennacanonlyuseantennascertificatedasfollowsprovidedbymanufacturer; Internal Identification Antennatypeand antennanumber Operatefrequency band Maximumantenna gain Note Antennamonopoleantenna2400MHz-2480MHz0dBiBTAntenna Page 3 of 4 FCCID:2A4FVCBST03BLORB12V ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 6.ConductedPower <BTLEMaxConductedPower> ModeChannelFrequency(MHz) MaxConductedPower (dBm) GFSK 024022.17 1924402.35 3924802.75 7.ManufacturingTolerance <BTLE> GFSK(Peak) ChannelChannel0Channel19Channel39 Target(dBm)2.02.02.0 Tolerance±(dB)1.01.01.0 Page 4 of 4 FCCID:2A4FVCBST03BLORB12V ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 8.MeasurementResults 8.1StandaloneMPE AsdeclaredbytheApplicant,theEUTisawirelessdeviceusedinafixapplication,atleast20cmfromany bodypartoftheuserornearbypersons;fromthemaximumEUTRFoutputpower,theminimumseparation distance,r=20cm,aswellasthegainoftheusedantennarefertoantennainformation,theRFpowerdensity canbeobtained. [Antenna] <BTLE> Band/Mode RFoutputpower AntennaGain (dBi) MPE (mW/cm2) MPE Limits (mW/cm2) dBmmW GFSK3.01.995300.00041.0000 Remark: 1.Outputpowerincludingtune-uptolerance; 2.MPEevaluatedistanceis20cmfromusermanualprovidebymanufacturer; 8.2SimultaneousTransmissionMPEEvaluation TheEUTwithonemoduleandoneantenna.Sononeedconsidersimultaneoustransmission. 9.Conclusion ThemeasurementresultscomplywiththeFCCLimitper47CFR2.1091fortheuncontrolledRFExposureof mobiledevice. .......................THEENDOFREPORT.........................

Test Report

Page1of24FCCID:2A4FVCBST03BLORB12VReportNo.:LCSA061522069E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity AppendixA RFTestDataforBLE(ConductedMeasurement) ProductName:Indoor/OutdoorStepLight TestModel:CBST03BLORB12V EnvironmentalConditions Temperature: 23.8C RelativeHumidity:52.2% ATMPressure:100.0kPa TestEngineer: LhLi Supervisedby: LiHuan Page2of24FCCID:2A4FVCBST03BLORB12VReportNo.:LCSA061522069E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity A.1DTSBandwidth TestResult TestModeAntennaChannel DTSBW [MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict BLE_1MAnt1 24020.6722401.6522402.3240.5PASS 24400.6762439.6482440.3240.5PASS 24800.6722479.6482480.3200.5PASS Page3of24FCCID:2A4FVCBST03BLORB12VReportNo.:LCSA061522069E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity TestGraphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 Page4of24FCCID:2A4FVCBST03BLORB12VReportNo.:LCSA061522069E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity BLE_1M_Ant1_2480 Page5of24FCCID:2A4FVCBST03BLORB12VReportNo.:LCSA061522069E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity A.2Maximumconductedoutputpower TestResult TestModeAntennaChannelResult[dBm]Limit[dBm]Verdict BLE_1MAnt1 24022.17≤30PASS 24402.35≤30PASS 24802.75≤30PASS Page6of24FCCID:2A4FVCBST03BLORB12VReportNo.:LCSA061522069E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity TestGraphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 Page7of24FCCID:2A4FVCBST03BLORB12VReportNo.:LCSA061522069E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity BLE_1M_Ant1_2480 Page8of24FCCID:2A4FVCBST03BLORB12VReportNo.:LCSA061522069E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity A.3Maximumpowerspectraldensity TestResult TestModeAntennaChannelResult[dBm/3kHz]Limit[dBm/3kHz]Verdict BLE_1MAnt1 2402-10.41≤8.00PASS 2440-10.19≤8.00PASS 2480-9.84≤8.00PASS Page9of24FCCID:2A4FVCBST03BLORB12VReportNo.:LCSA061522069E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity TestGraphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 Page10of24FCCID:2A4FVCBST03BLORB12VReportNo.:LCSA061522069E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity BLE_1M_Ant1_2480 Page11of24FCCID:2A4FVCBST03BLORB12VReportNo.:LCSA061522069E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity A.4Bandedgemeasurements TestResult TestModeAntennaChNameChannelRefLevel[dBm]Result[dBm]Limit[dBm]Verdict BLE_1MAnt1 Low24021.76-42.1≤-18.25PASS High24802.30-40.74≤-17.7PASS Page12of24FCCID:2A4FVCBST03BLORB12VReportNo.:LCSA061522069E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity TestGraphs BLE_1M_Ant1_Low_2402 BLE_1M_Ant1_High_2480 Page13of24FCCID:2A4FVCBST03BLORB12VReportNo.:LCSA061522069E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity A.5ConductedSpuriousEmission TestResult TestModeAntennaChannel FreqRange [MHz] RefLevel [dBm] Result[dBm]Limit[dBm]Verdict BLE_1MAnt1 2402 Reference1.711.71---PASS 30~10001.71-59.2≤-18.29PASS 1000~265001.71-45.16≤-18.29PASS 2440 Reference1.871.87---PASS 30~10001.87-57.09≤-18.13PASS 1000~265001.87-46.34≤-18.13PASS 2480 Reference2.252.25---PASS 30~10002.25-57.35≤-17.75PASS 1000~265002.25-45.95≤-17.75PASS Page14of24FCCID:2A4FVCBST03BLORB12VReportNo.:LCSA061522069E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity TestGraphs BL…

Text truncated - open the document above for the full version.

Test Report

Page1of34FCCID:2A4FVCBST03BLORB12VReportNo.:LCSA061522069E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity FCCTESTREPORT For CloudyBayLightingSupplyInc Indoor/OutdoorStepLight TestModel:CBST03BLORB12V AdditionalModelNo.:PleaseRefertoPage6 Preparedfor:CloudyBayLightingSupplyInc Address:131217thStreetSuite692DenverCO80202UnitedStates Preparedby:ShenzhenLCSComplianceTestingLaboratoryLtd. Address:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei, ShajingStreet,BaoanDistrict,Shenzhen,518000,China Tel:(+86)755-82591330 Fax:(+86)755-82591332 Web:www.LCS-cert.com Mail:[email protected] Dateofreceiptoftestsample:June17,2022 Numberoftestedsamples:2 SampleNo.:A061522069-1,A061522069-2 Serialnumber:Prototype DateofTest:June17,2022~June27,2022 DateofReport:June27,2022 Page2of34FCCID:2A4FVCBST03BLORB12VReportNo.:LCSA061522069E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity FCCTESTREPORT FCCCFR47PART15C(15.247) ReportReferenceNo......................:LCSA061522069E DateofIssue.......................................:June27,2022 TestingLaboratoryName..............:ShenzhenLCSComplianceTestingLaboratoryLtd. Address................................................:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei, ShajingStreet,BaoanDistrict,Shenzhen,518000,China TestingLocation/Procedure............:FullapplicationofHarmonisedstandards■ PartialapplicationofHarmonisedstandards□ Otherstandardtestingmethod□ Applicant’sName.............................:CloudyBayLightingSupplyInc Address................................................:131217thStreetSuite692DenverCO80202UnitedStates TestSpecification Standard..............................................:FCCCFR47PART15C(15.247) TestReportFormNo......................:LCSEMC-1.0 TRFOriginator....................................:ShenzhenLCSComplianceTestingLaboratoryLtd. MasterTRF.........................................:Dated2011-03 ShenzhenLCSComplianceTestingLaboratoryLtd.Allrightsreserved. Thispublicationmaybereproducedinwholeorinpartfornon-commercialpurposesaslongasthe ShenzhenLCSComplianceTestingLaboratoryLtd.isacknowledgedascopyrightownerandsourceofthe material.ShenzhenLCSComplianceTestingLaboratoryLtd.takesnoresponsibilityforandwillnot assumeliabilityfordamagesresultingfromthereader'sinterpretationofthereproducedmaterialduetoits placementandcontext. EUTDescription...............................:Indoor/OutdoorStepLight TradeMark..........................................:CloudyBay TestModel...........................................:CBST03BLORB12V Ratings.................................................:DC12V/AC12V Result...................................................:Positive Compiledby:Supervisedby:Approvedby: DiamondLu/AdministratorJinWang/TechniqueprincipalGavinLiang/Manager Page3of34FCCID:2A4FVCBST03BLORB12VReportNo.:LCSA061522069E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity FCC--TESTREPORT TestModel...............................:CBST03BLORB12V EUT.........................................:Indoor/OutdoorStepLight Applicant...............................:CloudyBayLightingSupplyInc Address..................................:131217thStreetSuite692DenverCO80202UnitedStates Telephone...............................:/ Fax..........................................:/ Manufacturer........................:CloudyBayLightingSupplyInc Address...................................:131217thStreetSuite692DenverCO80202UnitedStates Telephone...............................: / Fax..........................................: / Factory...................................:FoshanNanhaiPingyiElectronicCo.,Ltd Address...................................:No7,TaojinRoad,WujinIndustrialArea,DanzhaoTown,Nanhai District,FoshanCity,Guangdong,PRC528000 Telephone...............................:/ Fax..........................................:/ TestResultPositive Thetestreportmerelycorrespondstothetestsample. Itisnotpermittedtocopyextractsofthesetestresultwithoutthewrittenpermissionofthetestlaboratory. TestReportNo.:LCSA061522069E June27,2022 Dateofissue Page4of34FCCID:2A4FVCBST03BLORB12VReportNo.:LCSA061522069E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity RevisionHistory ReportVersionIssueDateRevisionContentRevisedBy 000June27,2022InitialIssue--- Page5of34FCCID:2A4FVCBST03BLORB12VReportNo.:LCSA061522069E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity TABLEOFCONTENTS 1.GENERALINFORMATION....................................................................................................................................................6 1.1.DESCRIPTIONOFDEVICE(EUT)........................................................................................................................................6 1.2.HOSTSYSTEMCONFIGURATIONLISTANDDETAILS.........................................................................................................7 1.3.EXTERNALI/OCABLE...............................................................................................…

Text truncated - open the document above for the full version.

Test Setup Photos

Page1of2FCCID:2A4FVCBST03BLORB12V ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity TestSetupPhotosoftheEUT TestSetupPhoto(s)ofRadiatedEmissionsMeasurement Fig.1 Fig.2 Page2of2FCCID:2A4FVCBST03BLORB12V ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity TestSetupPhotoofLineConductedEmissionsMeasurement Fig.3

Contact Information

Applicant

Larry Lee(Product Manager)

[email protected]281 201 8879Fax: 281 201 8879

Technical Contact

Cloudy Bay Lighting Supply Inc

[email protected]

United States

Test Firm

Shenzhen LCS Compliance Testing Laboratory Ltd.Gavin Liang

[email protected]0755-82591330Fax: 0755-82591132

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	1.90 mW

Confidentiality

Long Term

Grant Notes

Output power listed is conducted power. The antenna used with this transmitter must be installed to provide a minimum separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-users must be provided with operating procedures for satisfying RF exposure compliance.
