JuiceBox Pro User Manual 2 Table of contents Welcome to JuiceBox Pro 3 Package Contents 3 Required Tools 3 Installation 4 Installation Prerequisites 4 Installation 5 Load Balancing 8 Locking Your JuiceBox 9 Wi-Fi Setup 9 JuiceBox Configuration 11 Configure JuiceBox Using Bluetooth Connectivity 11 Configure JuiceBox Using Wi-Fi Connectivity 16 Specifications 21 Characteristics 21 Connectivity 21 Dimensions 22 LED Indicator 24 Using the Dashboard 25 Enterprise Dashboard Manual 25 Business Dashboard Manual 25 RFID Cards 25 RFID Reader 25 Activating And Managing 25 Important Safety Information 26 FCC Compliance 26 3 Welcome to JuiceBox Pro Package Contents >JuiceBox NOTE In some markets, JuiceBox arrives secured to a cable holder that includes keys. >Wall bracket >2 wall bracket screws (#10 self-tapping Phillips head wood screws) >2 screws to hang JuiceBox onto wall bracket (#10-32 Phillips head machine screws) >1 RFID card (except 80A) Required Tools >Phillips Screwdriver (No. 2 drive size) >Stud sensor >Stripper >Wire nut or wire coupler >Allen key >Electrical tape >Wrench or torque wrench 4 Installation Installation Prerequisites OVERVIEW JuiceBox requires either a hardwired electrical connection or a NEMA 14-50 outlet. The JuiceBox power supply must be connected to a non-GFI circuit breaker that is rated for at least 125% of the device's continuous load. NOTE Ensure that all power connection wiring conforms to the rules and regulations of any national and local codes. >The JuiceBox may require a disconnecting means if: > Not within line of sight of the Electrical Panel > Required by local code >Hardwire Version: Only the pre-installed, hard wire whip shall be used to connect to a junction box or disconnect. It is not long enough, nor is it meant to go directly into the electrical panel. CAUTION Do NOT drill any additional holes into the JuiceBox enclosure as it can cause damage to the PCB and/or electronics inside. LO CAT I O N When selecting a location to install the hardwire connection or outlet, keep in mind that JuiceBox should be positioned: >Within reach of the vehicle's charge port >18 inches above the floor or ground >If applicable, within range of a cellular connection or the local WiFi network 5 32A40A48A80A CIRCUIT REQUIREMENTS 40 Amp 2 pole breaker 50 Amp 2 pole breaker 60 Amp 2 pole breaker 100 Amp 2 pole breaker RECOMMEND WIRING #8AWG or larger gauge copper wires for the conductors (NEC 625.17(A) (2) #6AWG or larger gauge copper wires for the conductors (NEC 625.17(A) (2) #4AWG or larger gauge copper wires for the conductors (NEC 625.17(A) (2) #2 or 3AWG or larger gauge copper wires for the conductors (NEC 625.17(A) (2) #10AWG Green or bare copper for the ground conductor (no NEU) #10AWG Green or bare copper for the ground conductor (no NEUTRAL is used) #8AWG Green or bare copper for the ground conductor (no NEU) #6AWG Green or bare copper for the ground conductor (no NEU) WARNING Do not continue this installation until the circuit breaker is turned off. WIRING AND CIRCUIT REQUIREMENTS For additional specifications, refer to the Specifications section. Installation Fully read and understand the directions before installation. Refer to important safety information at the end of this document. This section describes installing the JuiceBox Pro onto a wall mount. If installing onto a JuiceStand, refer to the JuiceStand Manual. 1. Turn off the circuit breaker to the NEMA 14-50 outlet, NEMA 6-50 outlet, or hardwired electrical connection. 2. Use a stud sensor to determine an appropriate mounting location, then use the 2 screws to secure the wall bracket. 6 Version with cable holder Version without cable holder Version with cable holderVersion without cable holder 3. Insert the enclosure screws into the enclosure, as shown. Tighten the screws until approximately 2 mm of thread are visible. 7 Version with cable holderVersion without cable holder 4. Hang the JuiceBox onto the wall bracket. NOTE If the JuiceBox does not hang securely, adjust the screws that were installed in step 3. The 48 and 80 amp are hardwire only and do not have a plug as shown. NOTE The hardwire versions of the JuiceBox are shipped with appropriate wires that meet the National Electric Code (NEC) NFPA 70 and require a nearby junction box connection. Any alteration of the supplied wiring will invalidate the warranty and may not conform to NEC. 5. Connect the JuiceBox: >Plug-In Version: Plug the JuiceBox into the NEMA 14-50 outlet or NEMA 6-50 outlet. >1-Phase Hardwired Version: Connect the harness to the wiring terminal. WARNING It is the installers responsibility to ensure that the JuiceBox is wired in accordance with the local electrical code. 8 3 2 A /4 0A 48A80A L1 (Black)8 AWG 6 AWG 3 AWG L2 (Red)8 AWG 6 AWG 3 AWG Ground (Green) 8 AWG (THHN) 8 AWG (THHN) 6 AWG (THHN) 6. Turn on the circuit breaker that supplies power to the NEMA 14-50 outlet, NEMA 6-50 outlet, or hardwired electrical connection. Load Balancing >Load balance to Circuit only. >Load balance to panel is NOT recommended. NOTE Balancing to the panel or location can be done on a system that would otherwise work safely on its own. This can reduce usage during peak hours, saving cost to both the user and the owner of the stations. >Can only balance stations with the same specifications. >Balancing specifications cannot exceed the rated continuous load of the circuit. (50 amp circuit = 40 amp continuous load allowed) (NEC 625.41 & 42) 2017 code. >Per NEC 625.42 additional outlets per circuit can be added due to the JuiceNet Automated Load Management System. >Recommend no more than 3 per circuit. The maximum number of stations per circuit is determined by dividing the number of continuous load amps allowed based on circuit size by 8. (e.g. 40 amps / 8 amps = 5 stations maximum). Note this may result in a slower charge per car. 9 Locking Your JuiceBox After installing your JuiceBox, use the included keys to lock the JuiceBox to the wall frame. Wi-Fi S…

Text truncated - open the document above for the full version.

Enel X North America, Inc. 360 Industrial Road San Carlos, CA 94070 USA 1 02/25/2022 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Eurofins Electrical and Electronic Testing NA, Inc. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Giovanni Bertolino Head of e-Mobility, North America

Enel X North America, Inc. 360 Industrial Road San Carlos, CA 94070 USA 1 02/25/2022 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (JuiceBox 2.01, FCC ID: 2A4LRJB201NA) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We request that following information accompanying this application be permanently withheld from public review. - Schematics - Block Diagram - Operational Description - Part List The above materials are company proprietary information. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Giovanni Bertolino Head of e-Mobility, North America

Enel X North America, Inc. 360 Industrial Road San Carlos, CA 94070 USA 1 02/25/2022 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (JuiceBox 2.01, FCC ID: 2A4LRJB201NA) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We request that following information accompanying this application be temporary withheld from public review for 45 days after grant is issued: - Internal Photos - Test Setup Photos The above materials are company proprietary information. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Giovanni Bertolino Head of e-Mobility, North America

EUT Open The Enclose View NFC main board with antenna Top View Antenna NFC Module NFC main board with antenna Bottom View PCB 1 with cellular module Top View PCB 1 with cellular module Top View 1 PCB 1 with cellular module Bottom View Cellular Module Top View Cellular Bottom View PCB 2 with WLAN module and Bluetooth module Top View PCB 2 with WLAN module and Bluetooth module Bottom View Bluetooth Module WIFI Module Bluetooth module and Antenna WIFI module and Antenna Bluetooth Module Bluetooth Antenna WIFI Module WIFI Antenna

HEADQUARTERS: 914 WEST PATAPSCO AVENUE • BALTIMORE, MARYLAND 21230 • PHONE (410) 354-3300 • FAX (410) 354-3313 Report: WIR113585‐FCC‐RF Exposure © 2022, Eurofins Electrical and Electronic Testing NA, Inc. Page i of 6 Maryland | California | Texas www.metlabs.com DOC-WIR TEMP-FCC22-24-27-90-7-12-2021 – Rev 1 - Approved by DOC Manager RF Exposure Report (FCC) Report No.: WIR113585-FCC-RF Exposure Test Model: JuiceBox 2.01 40A FCC ID: 2A4LRJB201NA Received Date: 02 /14 /2022 Test Date: 02 /17/ 2022 – 02 /28 /2022 Issued Date: 04/ 06/ /2022 Applicant: CESI S.p.A Address: Via Raffaele Rubattino 54 Milano, Italy 20134 Issued By: Eurofins Electrical and Electronic Testing NA, Inc. Lab Address: 3162 Belick St. Santa Clara CA, 95054 HEADQUARTERS: 914 WEST PATAPSCO AVENUE • BALTIMORE, MARYLAND 21230 • PHONE (410) 354-3300 • FAX (410) 354-3313 Report: WIR113585‐FCC‐RF Exposure © 2022, Eurofins Electrical and Electronic Testing NA, Inc. Page 2 of 6 Maryland | California | Texas www.metlabs.com DOC-WIR-TEMP-ETS301-07-19-2021–Rev. 01 - Approved by DOC Manager 1. Certificate of Conformity Product: EV Charger Brand: CESI S.p.A Test Model: JuiceBox 2.01 40A Series Model: JuiceBox 2.01 32A, JuiceBox 2.01 48A, JuiceBox 2.01 80A Sample Status: Engineering Sample Applicant: CESI S.p.A Test Date: 02 /17/ 2022 – 03 /31 /2022 Standard: 47 CFR FCC Part 2.1093 Gary Chou Wireless Engineering Manager, Wireless Laboratory Eleazar Zuniga, Director, Wireless Laboratory Revision Report Date Reason for Revision  April 06, 2022 Initial Issue. HEADQUARTERS: 914 WEST PATAPSCO AVENUE • BALTIMORE, MARYLAND 21230 • PHONE (410) 354-3300 • FAX (410) 354-3313 Report: WIR113585‐FCC‐RF Exposure © 2022, Eurofins Electrical and Electronic Testing NA, Inc. Page 3 of 6 Maryland | California | Texas www.metlabs.com DOC-WIR-TEMP-ETS301-07-19-2021–Rev. 01 - Approved by DOC Manager 2. RF Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f 2 )* 30 30-300 27.5 0.073 0.2 30 300-1500 ... ... f/1500 30 1500-100,000 ... ... 1.0 30 f = Frequency in MHz; *Plane-wave equivalent power density 2.1 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm HEADQUARTERS: 914 WEST PATAPSCO AVENUE • BALTIMORE, MARYLAND 21230 • PHONE (410) 354-3300 • FAX (410) 354-3313 Report: WIR113585‐FCC‐RF Exposure © 2022, Eurofins Electrical and Electronic Testing NA, Inc. Page 4 of 6 Maryland | California | Texas www.metlabs.com DOC-WIR-TEMP-ETS301-07-19-2021–Rev. 01 - Approved by DOC Manager 2.2 Antenna Gain NFC : PCB LOOP ANTENNA WLAN : Chip Antenna with 1.83 dBi gain BLE : PCB Antenna with 1 dBi gain Cellular: The antenna type is Flexible Ultra Wide Band Antenna antenna with BAND 2/ 4 : 5 dBi gain. BAND 5/ 12/ 13 : 2.7 dBi gain. 2.3 Calculation Result of Maximum Conducted Power Type Frequency Band (MHz) Max Power (dBm) Max Power (mW) Turn-Up Tolerance Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) WLAN 2.4GHz 2437 18.79 75.683 ±1dB 1.86 20 0.029104 1 WCDMA B2 1852.4 23.66 232.273 ±1dB 5 20 0.184056 1 WCDMA B5 836.6 23.59 228.559 ±1dB 2.7 20 0.106647 0.5577 LTE B2 1880 23.43 220.292 ±1dB 5 20 0.174562 1 LTE B13 847.5 22.90 194.984 ±1dB 2.7 20 0.090981 0.656 BLE 2402 -3.08 0.4920 ±1dB 1 20 0.000155 1 NFC 13.56 -28.49 0.00141579±1dB 0 20 0 0.703 Note: 1. Determining compliance based on the results of the compliance measurement, not taking into account measurement instrumentation uncertainty. 2. This device contains Model No. FCC ID Note Cellular Telit RI7LE910NAV2 - WLAN Silicon Labs QOQWGM160P - RFID NXP OWRCLEV6630B - BLE Silicon Labs QOQ13 - HEADQUARTERS: 914 WEST PATAPSCO AVENUE • BALTIMORE, MARYLAND 21230 • PHONE (410) 354-3300 • FAX (410) 354-3313 Report: WIR113585‐FCC‐RF Exposure © 2022, Eurofins Electrical and Electronic Testing NA, Inc. Page 5 of 6 Maryland | California | Texas www.metlabs.com DOC-WIR-TEMP-ETS301-07-19-2021–Rev. 01 - Approved by DOC Manager 3. Conclusion Conclusion: The formula of calculated the MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density Co-location worse case (WLAN 2.4GHz & WCDMA/ LTE & NFC) Total MPE Percentage for 1.WLAN 2.4GHz, LTE/ WCDMA, NFC to transmit simultaneously. t = 0.2204 < 1 Therefore, the maximum calculations of above situations are less than the “1” limit. The SAR evaluation is not required. HEADQUARTERS: 914 WEST PATAPSCO AVENUE • BALTIMORE, MARYLAND 21230 • PHONE (410) 354-3300 • FAX (410) 354-3313 Report: WIR113585‐FCC‐RF Exposure © 2022, Eurofins Electrical and Electronic Testing NA, Inc. Page 6 of 6 Maryland | California | Texas www.metlabs.com DOC-WIR-TEMP-ETS301-07-19-2021–Rev. 01 - Approved by DOC Manager 4. Model difference declaration Letter:

Reference number: 289936-2-1-2 Page 2 of 58 Table of Contents PRODUCT DESCRIPTION .................................................................................................................................. 3 Equipment Under Test (EUT) .......................................................................................................................... 3 Description of the EUT .................................................................................................................................... 3 Ratings and Declarations ................................................................................................................................ 3 Power Supply .................................................................................................................................................. 3 Mechanical Size of the EUT ............................................................................................................................ 3 Samples ........................................................................................................................................................... 4 GENERAL REMARKS .......................................................................................................................................... 5 Disclaimer ........................................................................................................................................................ 5 SUMMARY OF TESTING ..................................................................................................................................... 6 EUT Test Conditions during Testing ............................................................................................................... 6 TEST RESULTS ................................................................................................................................................... 8 Conducted Emissions In The Frequency Range 150 kHz - 30 MHz ............................................................... 8 Maximum Peak Conducted Output Power ...................................................................................................... 11 Transmitter Radiated Spurious Emissions 30 - 26500 MHz ........................................................................... 17 Transmitter Band Edge Measurement and Conducted Spurious Emissions .................................................. 37 6 dB Bandwidth of the Channel ....................................................................................................................... 44 Power Spectral Density ................................................................................................................................... 48 99% Occupied Bandwidth ............................................................................................................................... 52 TEST EQUIPMENT .............................................................................................................................................. 58 Reference number: 289936-2-1-2 Page 3 of 58 Product Description PRODUCT DESCRIPTION Equipment Under Test (EUT) Trade mark: Silicon Labs Model: BGM13S32A, BGM13S32N, BGM13S22A, BGM13S22N Type: Bluetooth Low Energy Module Serial no: - FCC ID: QOQ13 IC: 5123A-13 Description of the EUT BGM13S32 (max power 19 dBm), Bluetooth low energy module with two antenna variants (A / N). BGM13S22 (max power 10 dBm), Bluetooth low energy module with two antenna variants (A / N). Variant A is equipped with chip antenna while the N variant has RF pin for the use of external antenna. Classification of the device Fixed device Mobile Device (Human body distance > 20cm) Portable Device (Human body distance < 20cm) Modifications Incorporated in the EUT One sample was modified to allow conducted measurements to be made. Ratings and Declarations Operating Frequency Range (OFR): 2402 - 2480 MHz Channels: 40 Channel separation: 2 MHz Effective conducted power: 18.46 dBm (Peak) Modulation: GFSK Integral Antenna gain: A-variant: 1 dBi External Antenna gain: N-variant: 2.14 dBi Power Supply Operating voltage range: 2.0 - 3.8 VDC (tested with 3.3V regulated by the development board) Separate AC/DC adaptor, Huawei model: HW-050100E01 (115 V, 60 Hz input / 5 V output) was used during the tests to power up the development board which feeds the module (EUT) during AC emissions test. Supply is not provided by the manufacturer. In other tests the development board was supplied with laboratory power supply. Mechanical Size of the EUT Height: 2 mm Width: 20 mm Length: 15 mm Reference number: 289936-2-1-2 Page 4 of 58 Product Description Samples EUT Description 1. BGM13S32N Original N variant with RF pin for external antenna 2. BGM13S32A Original A variant, equipped with chip antenna 3. BGM13S32A Modified A variant, Short RF cable added for conducted tests 4. BGM13S22N Original N variant with RF pin for external antenna Reference number: 289936-2-1-2 Page 5 of 58 General remarks GENERAL REMARKS Disclaimer This document is issued by the Company under its General Conditions of service accessible at http://www.sgs.com/terms_and_conditions.htm. attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company's findings at the time of its intervention only and within the limits of Client's instructions, if any. The Company's sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the s…
