FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. XDL-WA04S

Page 1 of 4 Appendix C: Photographs of EUT Product: Watch Wireless Charger Model: XDL-WA04S External Photos Page 2 of 4 Page 3 of 4 Page 4 of 4

Label Artwork and Location Model: XDL-WA04S Label : Location Size: L*W=21.96*11.01mm

Page 1 of 4 Appendix C: Photographs of EUT Product: Watch Wireless Charger Model: XDL-WA04S Internal Photos Page 2 of 4 Page 3 of 4 Page 4 of 4 Antenna

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2A4MTXDL-WA04S Test Report No. ............... : TCT220217E022 Date of issue ................... : Feb. 28, 2022 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: TCT Testing Industrial Park Fuqiao 5th Industrial Zone, Fuhai Street, Bao'an District Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Shenzhen Zhenghaixin Technology Co., Ltd. Address ........................... : Area 301A, No.7 Xiongyu Road, Tangxiachong Community, Yanchuan Street, Baoan District, Shenzhen, China Manufacturer's name ... : Shenzhen Zhenghaixin Technology Co., Ltd. Address ........................... : Area 301A, No.7 Xiongyu Road, Tangxiachong Community, Yanchuan Street, Baoan District, Shenzhen, China Standard(s) ..................... : FCC CFR Title 47 Part 1.1310 KDB 680106 D01 RF Exposure Wireless Charging App v03r01 Test item description ..... : Watch Wireless Charger Trade Mark ...................... : N/A Model/Type reference ..... : XDL-WA04S, XDL-WA04C, ZHX-WA04C, XDL-WA04S-2, XDL-WA04, XDL-WA04s Rating(s) ......................... : Input: DC 5V, 1A Output: 2W Date of receipt of test item ......................................... : Feb. 17, 2022 Date (s) of performance of test ................................... : Feb. 17, 2022 ~ Feb. 28, 2022 Tested by (+signature) ... : Rleo LIU Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT220217E022 Page 2 of 12 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information ................................................................... 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list............................................................................................................ 3 2. General Information .................................................................................. 4 2.1. Test environment and mode ................................................................................. 4 3. Facilities and Accreditations ................................................................... 5 3.1. Facilities ................................................................................................................. 5 3.2. Location ................................................................................................................. 5 4. Test Results and Measurement Data ...................................................... 6 4.1. Requirements ......................................................................................................... 6 4.2. Test Setup .............................................................................................................. 7 4.3. Test Procedure ...................................................................................................... 7 4.4. Test Equipment List .............................................................................................. 7 4.5. Test Result ............................................................................................................. 8 4.6. Test Set-up Photo ................................................................................................ 10 Report No.: TCT220217E022 Page 3 of 12 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Test item description ........... : Watch Wireless Charger Model/Type reference ........... : XDL-WA04S Sample Number....................: TCT220217E021-0101 Operation Frequency ........... : 324.67kHz Modulation Type ................... : Load modulation Antenna Type ........................ : Inductive loop coil Antenna Rating(s) ............................... : Input: DC 5V, 1A Output: 2W Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list No. Model No. Tested with 1 XDL-WA04S Other models XDL-WA04C, ZHX-WA04C, XDL-WA04S-2, XDL-WA04, XDL-WA04s Note: XDL-WA04S is tested model, other models are derivative models. The models are identical in circuit and PCB layout, only different on the model names and colors. So the test data of XDL-WA04S can represent the remaining models. Report No.: TCT220217E022 Page 4 of 12 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. General Information 2.1. Test environment and mode Item Normal condition Temperature +25ºC Voltage DC 5V Humidity 56% Atmospheric Pressure: 1008 mbar Test Mode: Engineering mode: Keep the EUT in continuous transmitting Report No.: TCT220217E022 Page 5 of 12 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. Facilities and Accreditations 3.1. Facilities The test facility is recognized, certified, or accredited by the following organizations: ● FCC - Registration No.: 645098 SHENZHEN TONGCE TESTING LAB Designation Number: CN1205 The testing lab has been registered and fully described in a report with the (FCC) Federal Communications Commission. The acceptance letter from the FCC is maintained in our files. ● IC - Registration No.: 10668A-1 SHENZHEN TONGCE TESTING LAB CAB identifier: CN0031 The testing lab has been registered by Certification and Engineering Bureau of Industry Canada for radio equipm…

Text truncated - open the document above for the full version.

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2A4MTXDL-WA04S Test Report No. ............... : TCT220217E021 Date of issue ................... : Feb. 28, 2022 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: TCT Testing Industrial Park Fuqiao 5th Industrial Zone, Fuhai Street, Bao'an District Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Shenzhen Zhenghaixin Technology Co., Ltd. Address ........................... : Area 301A, No.7 Xiongyu Road, Tangxiachong Community, Yanchuan Street, Baoan District, Shenzhen, China Manufacturer's name ... : Shenzhen Zhenghaixin Technology Co., Ltd. Address ........................... : Area 301A, No.7 Xiongyu Road, Tangxiachong Community, Yanchuan Street, Baoan District, Shenzhen, China Standard(s) ..................... : FCC CFR Title 47 Part 15 Subpart C Test item description ..... : Watch Wireless Charger Trade Mark ...................... : N/A Model/Type reference..... : XDL-WA04S, XDL-WA04C, ZHX-WA04C, XDL-WA04S-2, XDL-WA04, XDL-WA04s Rating(s).......................... : Input: DC 5V, 1A Output: 2W Date of receipt of test item ......................................... : Feb. 17, 2022 Date (s) of performance of test ................................... : Feb. 17, 2022 ~ Feb. 28, 2022 Tested by (+signature) ... : Rleo LIU Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT220217E021 Page 2 of 31 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 2. Test Result Summary .............................................................................. 4 3. General Information ................................................................................. 5 3.1. Test environment and mode ................................................................................. 5 3.2. Description of Support Units ................................................................................ 5 4. Facilities and Accreditations .................................................................. 6 4.1. Facilities ................................................................................................................. 6 4.2. Location ................................................................................................................. 6 4.3. Measurement Uncertainty ..................................................................................... 6 5. Test Results and Measurement Data ..................................................... 7 5.1. Antenna requirement ............................................................................................ 7 5.2. Conducted Emission ............................................................................................. 8 5.3. Radiated Spurious Emission Measurement ...................................................... 12 Appendix A: Photographs of Test Setup Appendix B: Photographs of EUT Report No.: TCT220217E021 Page 3 of 31 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Test item description ........... : Watch Wireless Charger Model/Type reference........... : XDL-WA04S Sample Number....................: TCT220217E021-0101 Operation Frequency ........... : 324.67kHz Modulation Technology ....... : Load modulation Antenna Type ........................ : Inductive loop coil Antenna Rating(s)................................ : Input: DC 5V, 1A Output: 2W Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list No. Model No. Tested with 1 XDL-WA04S Other models XDL-WA04C, ZHX-WA04C, XDL-WA04S-2, XDL-WA04, XDL-WA04s Note: XDL-WA04S is tested model, other models are derivative models. The models are identical in circuit and PCB layout, only different on the model names and colors. So the test data of XDL-WA04S can represent the remaining models. Report No.: TCT220217E021 Page 4 of 31 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna requirement §15.203 PASS AC Power Line Conducted Emission §15.207 PASS Spurious Emission §15.209(a)(f) PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Report No.: TCT220217E021 Page 5 of 31 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. General Information 3.1. Test environment and mode Operating Environment: Condition Conducted Emission Radiated Emission Temperature: 25 C 25.3 C Humidity: 55 % RH 54 % RH Atmospheric Pressure: 1010 mbar 1010 mbar Test Mode: Engineering mode: Keep the EUT in continuous transmitting. The sample was placed 0.8m for the measurement below above the ground plane of 3m chamber. Measurements in both horizontal and vertical polarities were performed. During the test, each emission was maximized b…

Text truncated - open the document above for the full version.

Page 1 of 2 Appendix A: Photographs of Test Setup Product: Watch Wireless Charger Model: XDL-WA04S Radiated Emission Page 2 of 2 Conducted Emission
