2A4VC-BX-ZO-001LED Under Cabinet Lighting

433.8580MHz FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. RF Exposure Information The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

Shenzhen Baixue Optoelectronics Co., Ltd. Add: Room 301, No. 74, Dongpu Road, Hongxing Community,Songgang Street, Baoan District, Shenzhen China Date: 2022-2-26 FCC ID: 2A4VC-BX-ZO-001 Dear Sir/Madam, We, Shenzhen Baixue Optoelectronics Co., Ltd. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: LED Under Cabinet Lighting Model no.: BX-ZO-001, BX-ZO-002,BX-ZO-003,BX-ZO-004,BX-ZO-005,BX-ZO-006,BX-ZO-007, BX-ZO-008,BX-ZO-009,BX-ZO-010 Sincerely, Name/Title： Chunhua Ou/Manager Company: Shenzhen Baixue Optoelectronics Co., Ltd. Address: Room 301, No. 74, Dongpu Road, Hongxing Community,Songgang Street, Baoan District, Shenzhen China Phone: 15112684264 Fax: N/A E-Mail: [email protected]

Shenzhen Baixue Optoelectronics Co., Ltd. Room 301, No. 74, Dongpu Road, Hongxing Community,Songgang Street, Baoan District, Shenzhen China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2022-2-26 To whom it may concern: We, Shenzhen Baixue Optoelectronics Co., Ltd. the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2A4VC-BX-ZO-001 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Chunhua Ou/Manager Company: Shenzhen Baixue Optoelectronics Co., Ltd. Address: Room 301, No. 74, Dongpu Road, Hongxing Community,Songgang Street, Baoan District, Shenzhen China Phone: 15112684264 Fax: N/A E-Mail: [email protected]

FCC ID: 2A4VC-BX-ZO-001 External Photos of the EUT TX RX FCC ID: 2A4VC-BX-ZO-001 FCC ID: 2A4VC-BX-ZO-001

FCC ID: 2A4VC-BX-ZO-001 Label and Location Size: L: 1.0cm*W: 0.5cm Label and Location FCC ID: 2A4VC-BX-ZO-001

FCC ID: 2A4VC-BX-ZO-001 Internal Photos of the EUT Antenna FCC ID: 2A4VC-BX-ZO-001

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China FCC PART 15 SUBPART C TEST REPORT FCC PART 15.231 Report Reference No. ..................... : FCC ID. ............................................ : CTA22022201401 2A4VC-BX-ZO-001 Compiled by ( position+printed name+signature) .. : File administrators Kevin Liu Supervised by ( position+printed name+signature) .. : Project Engineer Kevin Liu Approved by ( position+printed name+signature) .. : RF Manager Eric Wang Date of issue ..................................... : Feb. 23, 2022 Testing Laboratory Name .............: Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ............................ : Shenzhen Baixue Optoelectronics Co., Ltd. Address ............................................ : Room 301, No. 74, Dongpu Road, Hongxing Community,Songgang Street, Baoan District, Shenzhen Test specification ...........................: Standard ........................................... : FCC Part 15.231 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: LED Under Cabinet Lighting Trade Mark ....................................... : N/A Manufacturer .................................... : Shenzhen Baixue Optoelectronics Co., Ltd. Model/Type reference....................... : BX-ZO-001 Listed Models .................................. : BX-ZO-002,BX-ZO-003,BX-ZO-004,BX-ZO-005,BX-ZO-006,BX-ZO -007,BX-ZO-008,BX-ZO-009,BX-ZO-010 Ratings ............................................. : DC 3.0V From Battery Modulation ....................................... : ASK Frequency .......................................... 433.8580MHz Result................................................ : PASS Report No.: CTA22022201401 Page 2 of 22 T E S T R E P O R T Equipment under Test : LED Under Cabinet Lighting Model /Type : BX-ZO-001 Listed Models : BX-ZO-002,BX-ZO-003,BX-ZO-004,BX-ZO-005,BX-ZO-006,BX- ZO-007,BX-ZO-008,BX-ZO-009,BX-ZO-010 Model Declaration : PCB board, structure and internal of these model(s) are the same, So no additional models were tested. Applicant : Shenzhen Baixue Optoelectronics Co., Ltd. Address : Room 301, No. 74, Dongpu Road, Hongxing Community, Songgang Street, Baoan District, Shenzhen Manufacturer : Shenzhen Baixue Optoelectronics Co., Ltd. Address : Room 301, No. 74, Dongpu Road, Hongxing Community, Songgang Street, Baoan District, Shenzhen Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA22022201401 Page 3 of 22 Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 Block Diagram of Test Setup 5 2.6 Special Accessories 5 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emission 11 4.3 20dB Bandwidth 15 4.4 Deactivation Time 16 4.5 Antenna Requirement 17 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 18 6 P H O T O S O F T H E E U T ........................................................... 19 Report No.: CTA22022201401 Page 4 of 22 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.231:Periodic operation in the band 40.66-40.70 MHz and above 70 MHz. ANSI C63.10:2013 : American National Standard for Testing Unlicensed Wireless Devices Report No.: CTA22022201401 Page 5 of 22 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Feb. 18, 2022 Testing commenced on : Feb. 18, 2022 Testing concluded on : Feb. 23, 2022 2.2 Product Description Product Name: LED Under Cabinet Lighting Model/Type reference: BX-ZO-001 Testing sample ID： CTA220222014-1# (Engineer sample), CTA220222014-2#(Normal sample) Power supply: DC 3.0V From Battery Modulation: ASK Operation frequency: 433.8580MHz Channel number: 1 Antenna type: Internal antenna Antenna gain: 0 dBi 2.3 Equipment Under Test Power supply system utilised Power supply voltage : ○ 230V / 50 Hz ○ 120V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC 3.0V From Battery 2.4 Short description of the Equipment under Test (EUT) This is a LED Under Cabinet Lighting. For more details, refer to the user’s manual of the EUT. 2.5 Block Diagram of Test Setup 2.6 Special Accessories Follow auxiliary equipment(s) test with EUT that provided by the manufacturer or laboratory is listed as follow: Description Manufacturer Model Technical Parameters Certificate Provided by / / / / / / / / / / / / EUT Report No.: CTA22022201401 Page 6 of 22 2.7 Related Submittal(s) / G…

Text truncated - open the document above for the full version.

FCC ID: 2A4VC-BX-ZO-001 Test Setup Photos of the EUT Test Setup Photo(s) of Radiated Emissions Measurement Fig. 1 Fig. 2
