2A4WMABC-A1513 in 1 wireless charger

3 in 1 Wireless Charger User Manual 1. After connecting to the power supply, the blue indicator lights up, and automatically turns off after three seconds, and the charging board enters the standby state. 2. The mobile phone with wireless charging function is placed on the charging board, and the LED indicator lights up. 3. When the blue indicator light is on, it is the normal charging state. 4. When there are foreign objects, high temperature, low temperature, over voltage, over current, etc ,the indicator light will flash. 5. Take off the devices light turns off. Model: A151 Input: 5V/3A 9V/2A Output: 5W/7.5W/10W for Phones 3W for AirPods 2.5W for iWatch iPhone 15,iPhone 15 Plus,iPhone 15 Pro,iPhone 15 Pro Max, iPhone 14,iPhone 14 Plus,iPhone 14 Pro,iPhone 14 Pro Max, iPhone 13 mini,iPhone 13,iPhone 13 Pro,iPhone 13 Pro Max, iPhone 12 mini,iPhone 12,iPhone 12 Pro,iPhone 12 Pro Max iWatch2/3/4/5/6/7/8/9/SE/SE2/Ultra/Ultra2 2. Smart Watch 1. Smartphone 3.Earbuds AirPods 2/3/Pro/Pro 2 1 xWireless Charger 1xPower Adapter 1xUserr Manual 1xPower Cable Please pay attention to the following issues, otherwise it may cause abnormal charging, high charging temperature, intermittent charging, or even not charging. 2.Do not pull the silicone part, otherwise it will easily damage the precision components under the silicone part and affect the charging. 1.Notcompatible for devices other than Apple,such as Samsung. 3.Please put the phone/watch at the center of charge area. 4.We recommend Quick Charger adapter (9v/2A), which can charge three devices at the same time while maintaining the fastest speed. The 5V/2A charger can only provide a normal charging speed, which will be slower than that of a fast charger. ANY OTHER QUESTIONS? FCC Warning: About the FCC Function Introduction System Specifications Compatibility Sheet Package Contents Precautions for Use 5.Avoid high ambient temperature,the optimal temperature is 82-86°F. 6. When the phone or watch cannot be fully charged,try the following:Open[Settings]-[Battery Health]-[Turn off battery optimization]. 7.When the earphones are exhausted and cannot be charged, please take out the earphones and charge the storage compartment separately. 8. When the blue light flashes, indicating abnormal charging please check whether there are foreign objects around. Your satisfaction is always our top priority Please feel free to contact us through the following steps: 1. Log in to your Amazon account. 2. Open your purchased orders. 3. Click the store name next to"Sold by:" 4. Click "Ask a question." FCC ID :2A4WMABC-A151 This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on. The user is encouraged to try to correct the interference by one or more of the following measures: 1.Reorient or relocate the receiving antenna. 2.Increase the separation between the equipment and receiver. 3.Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 4.Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC rules，operation is subject to the following two conditions: 1.this device may not cause harmful interference. 2. this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. Watch charging Charging indicator light Headphone charging Phone charging 5.The charging distance is 2-8mm, please don't wear protective case which is over 3mm thick. 6.The watch has temperature control. When the temperature reaches 104 °F, it will stop charging automatically. lf the temperature is normal, it will continue to charge. 7.No metal or magnetic objects around 6cm of the back center of the phone during charging. 8.The lower temperature，the faster charging speed.The charging speed is faster in winter than in summer. 9.Please don't charge in high temperature and humid environments to avoid damage of circuit. 10.Put it at the place that children can't reach to avoid unnecessary accidents. 1.Update the device to the latest system. Trouble shooting 2.Make sure your device that supports wireless charging. 3.Make sure to use the original charging cable and adapter. 4.Avoid thick device covers.

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: DongGuanShi WeizhiChuang Technology Co., Ltd. Grantee code: 2A4WM FRN: 0032004665 FCC ID: 2A4WMABC-A151 Contact Name: Guoquan Gan Address: Room 801, Building 5, No.1, Fengjing Road, Daping, Tangxia Town, Dongguan City, Guangdong Province Telephone No: 18926068126 Fax No: Email: [email protected] i. [DongGuanShi WeizhiChuang Technology Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [DongGuanShi WeizhiChuang Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [DongGuanShi WeizhiChuang Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List as an entity producing “covered” equipment . Date: 2024/08/05 Applicant’s Name: Guoquan Gan Title: Manager Signature The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: DongGuanShi WeizhiChuang Technology Co., Ltd. Address: Room 801, Building 5, No.1, Fengjing Road, Daping, Tangxia Town, Dongguan City, Guangdong Province Product Name: 3 in 1 wireless charger Model Number: A151 FCC Identifier: 2A4WMABC-A151 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Guoquan Gan Date: 2024.08.05 Title: Manager Signature of applicant:

C5266091_X10_Ed.2 1/1 < DongGuanShi WeizhiChuang Technology Co., Ltd.> Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2024.08.05 Subject: Request for Confidentiality FCC ID: 2A4WMABC-A151 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name: Guoquan Gan Title: Manager

External Photo FCC ID: 2A4WMABC-A151

Label

Internal Photo FCC ID: 2A4WMABC-A151 ANT for Phone ANT for AirPods ANT for Watch

MPE REPORT 3 in 1 wireless charger MODEL No.: A151 FCC ID: 2A4WMABC-A151 REPORT NO.:NCT24032193-2 ISSUE DATE: Aug. 07, 2024 Prepared for DongGuanShi WeizhiChuang Technology Co., Ltd Room 801, Building 5, No.1, Fengjing Road, Daping, Tangxia Town, Dongguan City, Guangdong Province Prepared by Shenzhen NCT Testing Technology Co., Ltd. A101&2F B2, Fuqiao 6th Area, Xintian Community, Fuhai Street, Baoan District, Shenzhen, People’s Republic of China TEL: 400-8868-419 FAX: 86-755-27790922 Report No.: NCT24032193-2 Page 2 of 15 Hotline: 400-8868-419 Fax: 86-755-27790922 http://www.ncttesting.cn TABLE OF CONTENT Test Report Description Page 1. SUMMARY OF TEST RESULT ......................................................................................................4 2. GENERAL INFORMATION .............................................................................................................5 2.1. DESCRIPTION OF DEVICE (EUT) ................................................................................................................................ 5 2.2. TEST SETUP ................................................................................................................................................................ 6 2.3. DESCRIPTION OF TEST FACILITY ................................................................................................................................ 7 2.4. MEASUREMENT UNCERTAINTY ................................................................................................................................... 7 3. MEASURING DEVICE AND TEST EQUIPMENT .......................................................................8 3.1. FOR MPE MEASUREMENT ......................................................................................................................................... 8 4. RF EXPOSURE.................................................................................................................................9 4.1. MEASURING STANDARD .............................................................................................................................................. 9 4.2. REQUIMENTS ............................................................................................................................................................... 9 4.3. TEST CONFIGURATIO ................................................................................................................................................. 10 4.4. LIMITS ......................................................................................................................................................................... 11 4.5. MEASURING RESULTS ............................................................................................................................................... 13 5. PHOTOGRAPHS OF TEST SETUP ...........................................................................................15 Report No.: NCT24032193-2 Page 3 of 15 Hotline: 400-8868-419 Fax: 86-755-27790922 http://www.ncttesting.cn TEST REPORT DESCRIPTION Applicant : DongGuanShi WeizhiChuang Technology Co., Ltd Address : Room 801, Building 5, No.1, Fengjing Road, Daping, Tangxia Town, Dongguan City, Guangdong Province Manufacturer : DongGuanShi WeizhiChuang Technology Co., Ltd Address : Room 801, Building 5, No.1, Fengjing Road, Daping, Tangxia Town, Dongguan City, Guangdong Province EUT : 3 in 1 wireless charger Model Name : A151 Trademark : UCOMX, QGeeM, RTOPS Measurement Procedure Used: FCC Part 1(1.1310) and Part 2(2.1091) KDB 680106 D01 Wireless Power Transfer v04 The device described above is tested by Shenzhen NCT Testing Technology Co., Ltd. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen NCT Testing Technology Co., Ltd. is assumed full of responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen NCT Testing Technology Co., Ltd. Test Engineer: Keven Wu / Engineer Technical Manager: Henry Wang / Manager Report No.: NCT24032193-2 Page 4 of 15 Hotline: 400-8868-419 Fax: 86-755-27790922 http://www.ncttesting.cn 1. SUMMARY OF TEST RESULT EMISSION Description of Test Item Standard & Limits Results MPE FCC Part 1(1.1310) and Part 2(2.1091) KDB 680106 D01 Wireless Power Transfer v04 Pass Note: N/A is an abbreviation for Not Applicable. Report No.: NCT24032193-2 Page 5 of 15 Hotline: 400-8868-419 Fax: 86-755-27790922 http://www.ncttesting.cn 2. GENERAL INFORMATION 2.1. Description of Device (EUT) EUT : 3 in 1 wireless charger Model Number : A151 Model different : / Power Rating : Input: 5Vdc,3A or 9Vdc,2A Wireless Output: Phone:5W/7.5W/10W, Watch:2.5W, AirPods:3W Operation Frequency for WPT : 110-205 KHz for Phone and AirPods 320-330kHz for Watch Modulation : FSK Antenna Type: : Coil Antenna Date of Received : Jul.24, 2024 Date of Test : Jul.25, 2024 to Jul.30, 2024 Report No.: NCT24032193-2 Page 6 of 15 Hotline: 400-8868-419 Fax: 86-755-27790922 http://www.ncttesting.cn 2.2. Test Setup Report No.: NCT24032193-2 Page 7 of 15 Hotline: 400-8868-419 Fax: 86-755-27790922 http://www.ncttesting.cn 2.3. Description of Test Facility 2.4. Measurement Uncertainty Parameter Uncertainty RF output power, conducted ±1.0dB Power Spectral Density, conducted ±2.2dB Radio Frequency ± 1 x 10 -6 Bandwidth ± 1.5 x 10 -6 Time ±2% Duty Cycle ±2% Temperature ±1°C Humidity ±5% DC and low frequency voltages ±3% Conducted Emissions (150kHz~30MHz) 3.64dB Radiated Emission(30MHz~1GHz) 5.03dB Radiated Emission(1GHz~25GHz) 4.74dB Electric Field Emissions 0.08V/m Magnetic Field Emissions 0.02A…

Text truncated - open the document above for the full version.

零 件 承 认 书 Part acknowledgement 供 应 商 全 称Full name of supplier： 东莞捷瑞思科技有限公司 Dongguan Jerice Technology Co. , Ltd. 供应商地址Address of supplier：东莞市大岭山朗湖路96号（金雄达科技园L栋3楼） 96 Long Wu Road, Tai Ling Shan, Dongguan (3F, building L, Kam Hung Tat Science and Technology Park) 物 料 名 称Name of material：： 手表线圈Watch coil 物 料 规 格：Material specifications：软磁25*2.6MM 0.08*24P 7.7UH-8.0UH单股双层 带 N52 磁铁 磁力 3400GS±200GS 带背胶 L=7MM 机 种 型 号Type and model: 客 户 名 称Customer name :络鑫电子 客 户 料 号Customer data: 送 样 时 间Sample delivery time:2023年7月20日 备注 Notes: 新物料 New materials ：代料 Alternative ： 承认结果 Acknowledge the results 合格 Qualified 不合格 Disqualified 不合格原因 Reasons for non-conformance ： 不合格承认书及样品处理方式 Acceptance of non-conformance and sample handling ： 退回采购 Return purchase 销毁处理 Disposal 供应商签章Signature of supplier承认签章 Recognize the signature 申请人 Applicant 品质 Quality 核准 Approved 申请人 pplicant 测 试 员 Tester 工程 Proje ct 品质 Qualit y 核准 Approve d 陆琳梁梅香陆如圣 承认章 Recognition Stamp 承认章 Recognition Stamp 日期 Date : 2023.7.20日期 Date: 一、 目录：Tableof contents 1.封面Cover.....................................................................第1-1页 2.目录Tableof contents......................................................第2-2页 3.产品图Productdrawings...................................................第3-3页 4.尺寸图Size Map............................................................第4-4页 5.产品参数Productparameters.............................................第5-5页 6.技术要求Technicalrequirements.......................................第5-5页 7.电性参数Electricalparameters..........................................第5-5页 8.包装Packaging...............................................................第6-6页 9.材料清单Bill of materials................................................第7-7页 二、产品图面Product drawing： 三、平面结构图A plan： 单位:MM M 7±1 四、 产品参数Productparameters： 脚位Feet线径Diameterof the line圈数Numberof turns备注Notes 1 - 20.08*24P14 热风绞合线 Hot Air Strand 五、技术要求Technicalrequirements： 1.固定好线头线尾，防止线松断线等现象 Fix the headand tail of threadto preventlooseand brokenthread 2.按客户要求把过长的线头剪，镀上锡，镀锡深度统一为2±1MM Accordingto customer'srequirements,the lengthof wire shears,Tinning,tinningdepthof 2 ± 1MM 3．在磁片上点上适当的白胶，贴上线圈，过程中要保证产品表面干净整洁 In the magneticpointon the appropriatewhiteglue,pastethe coil, the processto ensurethat the productsurfacecleanand tidy 4.所用软磁片为带圆孔,无破损 The soft disk usedis withroundhole,no damage 5.附加工序（按客户要求）：于成品中间圆孔装上7. 65 x2. 5mm的磁铁并在成品 背后加贴直径14mm的圆双面胶，后包装 Install7.65x2.5mm magnetin the middleholeof the finishedproductand paste14mmdiameterrounddouble-sided adhesiveon the backof the finishedproduct 六、电性参数Electricalparameters： 1.电感值，Q值Inductancevalue,Q value： PINPIN1 — 2 = 7.7~8.0UH 以上电感值以铨华10 62A仪器,以10KHZ/0.3Vrms为标准或等同仪器。 Q值以 铨华10 62A仪器，以100 KHZ/0.3Vrms为标准或等同仪器 The aboveinductancevaluesare basedon chuanhua1062Ainstrument,using10KHZ/0.3vrmsas the standardor equivalent instrument.The Q valueis basedon chuanhua1062Ainstrumentand 100KHZ/0.3vrmsor equivalentinstrument 七、包装Packaging： 图 1：单层泡棉托盘，1 盒包装240 PCS Figure1: Single-layerfoamtray, 1 box packing240 pcs 图 2：统一方向线头朝上整齐排放入盘中 Figure2: UniformDirectionLine headup neatlyinto the disk 图3：放入包装箱，每箱放置10层 Figure3: put into the packingbox, eachbox put 10 layers 图4：封箱，用透明胶封箱 Figure4: sealingthe box withtransparentglue 图5：包装箱贴标签 Figure5: Packaginglabel 图6：物料堆放，整齐，标签往外方便寻找物料 Figure6: materialsstacked,neat,labelsto facilitatethe searchfor materials 八、材料清单Bill of materials： 序号NO名称Name材质Material供应商Suppliers备注Notes 1 热风线 Hot Air Line 0.08*24P 维汉或等同 Uyghuror equivalent 2 磁片 Disk G25软基材 G25 soft substrate 天通或等同 TX or equivalent 3 锡 Tin 高温环保 Hightemperature environmentalprotection 千岛或等同 ThondIslandor equivalent 4 白胶Whiteglue BY882 宝月或等同 Treasuremonthor equivalent 5 双面胶 Double-sidedglue 513- 14mm 鸿辉或等同 HungFai or equivalent 6 强 磁 Strongmagnetism 7. 65 *2 .5 (强度3400± 200 GS) 联胜或等同 Win-winor equal

零 件 承 认 书 Part acknowledgement 供 应 商 全 称Full name of supplier：东莞捷瑞思科技有限公司 Dongguan Jerice Technology Co. , Ltd. 供 应 商 地 址Address of supplier ：东莞市大岭山朗湖路 96 号（金雄达科技园 L 栋 3 楼） 96 Long Wu Road, Tai Ling Shan, Dongguan (3F, building L, Kam Hung Tat Science and Technology Park) 物 料 名 称Name of material ： A11线圈 物 料 规 格 ： Material specifications： A11 6.3uH\ 单股单层 \20.5*42*0.08*105P\10TS\ 磁 片φ 43*1.0mm\ 材质 PC95\L=10mm\ 带背胶 机 种 型 号Type and model: 客 户 名 称Customer name:络鑫电子 客 户 料 号Customer data: 送 样 时 间Sample delivery time:2023年10月07日 备注Notes:新物料New materials：替代料Alternative： 承认结果 Acknowledge the results 合格 Qualified 不合格 Disqualified 不合格原因 Reasons for non-conformance ： 不合格承认书及样品处理方式 Acceptance of non-conformance and sample handling ： 退回采购 Return purchase 销毁处理 Disposal 供应商签章 DisposalSignature of supplier 承认签章 Recognize the signature 申请人 Applicant 品质 Quality 核准 Approved 申请人 pplicant 测试员 Tester 工程 Project 品质 Quality 核准 Approved 陆琳 梁梅香陆如圣 承认章 Recognition Stamp 承认章 Recognition Stamp 日期 Date : 2023.10.07 日期 Date : 一、 目录Tableof contents： 1.封面Cover..................................................................第 1-1 页 2.目录Tableof contents......................................................第2-2 页 3.产品图Productdrawings...................................................第 3-3 页 4.平面结构图A plan............................................................第 4-4 页 5.产品参数Productparameters.............................................第5-5 页 6.电性参数Electricalparameters..........................................第 5-5 页 7.材料清单.....................................................................第 5-5 页 8.包装Packaging...............................................................第6-6 页 二、产品图面Productdrawing： 三、平面结构图A plan： 单位:MM 四．产品参数Productparameters： 圈数 Turns 线径 WireDia 绕线方式疏/密 Thewayofwindingis sparse/dense 绕线方向 Directionof winding 相交是/否 Intersection yes/No 线圈正/反贴 Positive/negativ ecoil 10TS0.08*105P 丝包线 密绕 Encircling 逆时针 Counterclockwise 是Yes 反贴 Counter-post 所有材料要求合格ROHS标准AllmaterialsrequiredtomeetROHSstandards 五．电气特性Electricalcharacteristics 温度：25º±10C湿度：65º±10%Temperature:25O±10chumidity:65o±10% 序号 NO 项目Project端子 Terminal 标准 Standards 测试条件 Testconditions 测试仪器 Testequipment 1IND1-2 线脚加磁片 PINanddisk： 电感：6.3uH±5% Q值：≧60 DCR值：0.05Ω±5% 1kHz/V LCZMETER1062 六．材料清单Billofmaterials： 序号 NO 材料名称 Nameof material 品名描述 Descriptionofproductname 物料代码 MaterialCode 厂商代码 VendorCode 1 线材Wire 0.08*105P丝包线 Silk-cladwire JR-RQ-0046WH 2 铁氧体Ferrite 43*5.2*1.0带孔双槽L型 G43-1.0-1008TT 3 双面胶 Double-sided glue 42*5.3*0.08H（带孔，带手撕) OT-42HH 4 金手指胶布 Goldfingertape 高温胶带 Hightemperatureadhesive tape8MN GR-0008GK 5 胶水Glue白胶Whiteglue BR-0001BY 6 锡条Tinstrips 环保无铅焊锡条 Environmentallyfriendlylead-free solderrod 无铅高温锡条 QD 七、包装Packaging： 图 1：单层泡棉托盘1 盒包装270 PCS 图 2：统一方向线头朝上整齐排放入盘中， 图3：放入包装箱，每箱放置5层图4：封箱，用透明胶封箱 图 5：包装箱贴标签图 6：物料堆放，整齐整洁，标签往外方便寻找物料

FCC PART 15 SUBPART C 3 in 1 wireless charger MODEL No.: A151 FCC ID: 2A4WMABC-A151 REPORT NO.:NCT24032193XE-1 ISSUE DATE: Aug. 07, 2024 Prepared for DongGuanShi WeizhiChuang Technology Co., Ltd Room 801, Building 5, No.1, Fengjing Road, Daping, Tangxia Town, Dongguan City, Guangdong Province Prepared by Shenzhen NCT Testing Technology Co., Ltd. A101&2F B2, Fuqiao 6th Area, Xintian Community, Fuhai Street, Baoan District, Shenzhen, People’s Republic of China TEL: 400-8868-419 FAX: 86-755-27790922 Report No.: NCT24032193XE-1 Page 2 of 24 Hotline: 400-8868-419 Fax: 86-755-27790922 http://www.ncttesting.cn TABLE OF CONTENT Test Report Description Page 1. SUMMARY OF TEST RESULTS .............................................................................................................................. 5 2. GENERAL INFORMATION ...................................................................................................................................... 6 2.1. Description of Device (EUT) .............................................................................................................................. 6 2.2. Description of Support Units .............................................................................................................................. 6 2.3. Independent Operation Modes .......................................................................................................................... 7 2.4. Test Mode ........................................................................................................................................................... 7 2.5. Description of Test Facility ................................................................................................................................. 8 2.6. Measurement Uncertainty .................................................................................................................................. 9 3. MEASURING DEVICE AND TEST EQUIPMENT .................................................................................................. 10 4. 20DB BANDWIDTH ............................................................................................................................................... 12 4.1. Test Procedure ................................................................................................................................................. 12 4.2. Test Results...................................................................................................................................................... 12 5. POWER LINE CONDUCTED EMISSION MEASUREMENT ................................................................................. 14 5.1. Block Diagram of Test Setup ............................................................................................................................ 14 5.2. Limits ................................................................................................................................................................ 14 5.3. Test Procedure ................................................................................................................................................. 14 5.4. Measuring Results ........................................................................................................................................... 15 6. RADIATED EMISSION TEST ................................................................................................................................. 18 6.1. Measurement Procedure ................................................................................................................................. 18 6.2. Test SET-UP (Block Diagram of Configuration) ............................................................................................... 18 6.3. Radiated Emission Limit .................................................................................................................................. 19 6.4. Measurement Result ........................................................................................................................................ 21 7. TEST PHOTOGRAPHS AND EUT PHOTOGRAPHS ........................................................................................... 24 Report No.: NCT24032193XE-1 Page 3 of 24 Hotline: 400-8868-419 Fax: 86-755-27790922 http://www.ncttesting.cn TEST REPORT DESCRIPTION Applicant : DongGuanShi WeizhiChuang Technology Co., Ltd Address : Room 801, Building 5, No.1, Fengjing Road, Daping, Tangxia Town, Dongguan City, Guangdong Province Manufacturer : DongGuanShi WeizhiChuang Technology Co., Ltd Address : Room 801, Building 5, No.1, Fengjing Road, Daping, Tangxia Town, Dongguan City, Guangdong Province EUT : 3 in 1 wireless charger Model Name : A151 Trademark : UCOMX, QGeeM, RTOPS Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by Shenzhen NCT Testing Technology Co., Ltd.The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15C The test results of this report relate only to the tested sample identified in this report. Test Engineer: Keven Wu / Engineer Technical Manager: Henry Wang / Manager Report No.: NCT24032193XE-1 Page 4 of 24 Hotline: 400-8868-419 Fax: 86-755-27790922 http://www.ncttesting.cn Modified Information Version Report No. Revision Data Summary Ver.1.0 NCT24032193XE-1 Aug.07, 2024 Original Version Report No.: NCT24032193XE-1 Page 5 of 24 Hotline: 400-8868-419 Fax: 86-755-27790922 http://www.ncttesting.cn 1. SUMMARY OF TEST RESULTS Test Item Section in CFR 47 Result Antenna requirement 15.203 Pass AC Power Lin…

Text truncated - open the document above for the full version.

Setup Photo FCC ID: 2A4WMABC-A151
