Shenzhen HTT Technology Co., Ltd. TEST REPORT FCC PART 15.407 Report Reference No. .................... : FCC ID. ........................................... : HTT202503876F03 2A4WP-GMBP2100A1 Compiled by ( position+printed name+signature) . : File administrators Supervised by ( position+printed name+signature) . : Project Engineer Approved by ( position+printed name+signature) . : RF Manager Date of issue .................................... : May. 12, 2025 Testing Laboratory Name ............. : Shenzhen HTT Technology Co.,Ltd. Address ............................................ : 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao’an District, Shenzhen, Guangdong, China Applicant’s name ........................... : Shenzhen Speediance Living Technology Co., Ltd Address ............................................ : 19th Floor, Gemdale Viseen Tower A, No.16, Gaoxin 10th South Road, High-tech Zone, Yuehai Street, Nanshan District, Shenzhen, China. Test specification .......................... : Standard .......................................... : FCC Part 15.407: UNLICENSED NATIONAL INFORMATION INFRASTRUCTURE DEVICES Shenzhen HTT Technology Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HTT Technology Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HTT Technology Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Interactive Multi-Media DigitalFitness Equipment Trade Mark ....................................... : N/A Manufacturer .................................... : Shenzhen Speediance Living Technology Co., Ltd Model/Type reference ...................... : GMBP2100A1 Listed Models .................................. : GMBP2100A2, GMBP2100A3, GMBP2100A4, GMBP2100A5 Modulation Type .............................. : DSSS, OFDM Operation Frequency ....................... : From 5180MHz to 5320MHz, 5500MHz to 5700MHz, 5745MHz to 5825MHz Rating ............................................... : AC 100-230V Result ............................................... : PASS Report No.: HTT202503876F03 Page 2 of 30 T E S T R E P O R T Equipment under Test : Interactive Multi-Media DigitalFitness Equipment Model /Type : GMBP2100A1 Series Model No. GMBP2100A2, GMBP2100A3, GMBP2100A4, GMBP2100A5 Applicant : Shenzhen Speediance Living Technology Co., Ltd Address : 19th Floor, Gemdale Viseen Tower A, No.16, Gaoxin 10th South Road, High-tech Zone, Yuehai Street, Nanshan District, Shenzhen, China. Manufacturer : Shenzhen Speediance Living Technology Co., Ltd Address : 19th Floor, Gemdale Viseen Tower A, No.16, Gaoxin 10th South Road, High-tech Zone, Yuehai Street, Nanshan District, Shenzhen, China. Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: HTT202503876F03 Page 3 of 30 Contents 1. T E S T S T A N D A R D S .................................................................. 4 2. S U M M A R Y ............................................................................. 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Equipment Under Test 6 2.4. Short description of the Equipment under Test (EUT) 6 2.5. EUT operation mode 6 2.6. Block Diagram of Test Setup 8 2.7. Related Submittal(s) / Grant (s) 8 2.8. Modifications 8 3. T E S T E N V I R O N M E N T ............................................................... 9 3.1. Address of the test laboratory 9 3.2. Test Facility 9 3.3. Environmental conditions 9 3.4. Test Description 9 3.5. Statement of the measurement uncertainty 10 3.6. Equipments Used during the Test 11 4. T E S T C O N D I T I O N S A N D R E S U L T S ............................................ 12 4.1. AC Power Conducted Emission 12 4.2. Radiated Emission 15 4.3. For Conducted Band edge Measurement 22 4.4. Duty Cycle 23 4.5. Maximum Average Output Power 24 4.6. Power Spectral Density 25 4.7. 6dB Bandwidth 26 4.8. 26dB Bandwidth 27 4.9. Frequency Stability 28 4.10. Antenna Requirement 29 5. T E S T S E T U P P H O T O S O F T H E E U T .......................................... 30 6. E X T E R N A L A N D I N T E R N A L P H O T O S O F T H E E U T ....................... 30 Report No.: HTT202503876F03 Page 4 of 30 1. T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.407: UNLICENSED NATIONAL INFORMATION INFRASTRUCTURE DEVICES. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB 789033 D02: GUIDELINES FOR COMPLIANCE TESTING OF UNLICENSED NATIONAL INFORAMTION INFRASTRUCTURE (U-NII) DEVICES PART 15, SUBPART E Report No.: HTT202503876F03 Page 5 of 30 2. S U M M A R Y 2.1. General Remarks Date of receipt of test sample : Apr. 09, 2025 Testing commenced on : Apr. 09, 2025 Testing concluded on : May. 12, 2025 2.2. Product Description Product Name: Interactive Multi-Media DigitalFitness Equipment Model/Typereference: GMBP2100A1 Power supply: AC 100-230V testing sample ID： HTT202503876-1# (Engineer sample), HTT202503876-2# (Normal sample) WIFI WLAN Supported 802.11 a/n/ac Modulation Type IEEE 802.11a: OFDM(64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n HT20: OFDM (64QAM, 16QAM, QPSK,BPSK) IEEE 802.11n HT40: OFDM (64QAM, 16QAM, QPSK,BPSK) IEEE 802.11ac HT20: OFDM (64QAM, 16QAM, QPSK,BPSK) IEEE 802.11ac HT40: OFDM (64QAM, 16QAM, QPSK,BPSK) IEEE 802.11ac HT80: OFDM (64QAM, 16QAM, QPSK,BPSK) Operation frequency IEEE 802.11a:5180--5320MHz,5500-5700MHz,5745-5825MHz IEEE 802.11n HT20: 5180--5320MHz,5500-5700MHz,5745-5825MHz IEEE 802.11n HT40: 5190-5310MHz,5510-5670MHz,5755-5795MHz IEEE 802.11ac20: 5180--5320…
