2A525-AFF140Pet Smart Video Feeder

Jiangsu Zhongheng Pet Articles Joint-Stock Co., Ltd. Address: No. 1388 Century Avenue, Yandu District, Yancheng City, Jiangsu, P.R.China. Postal Code: 224014 SMARTO 4L/6L Pet Smart Video Feeder Operation Manual DESIGNED BY ZHONGHENG Please carefully read this Manual before use and keep it properly. FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Table of Contents Top Cover Sealed Food Bucket Food Shortage Reminder (built-in) UV Sterilizer (built-in) Fixing Knob of Food Bucket Food Outlet Microphone Hole Horn Hole Food Tray Food Shortage Reminder (built-in) UV Sterilizer (built-in) Fixing Knob of Food Bucket Camera Manual Feeding Button Product Introduction Main Components Product Introduction Manual Feeding 12 Main Components 01 Included Items 02 Removal of Top Cover 12 Instructions for Safe Use 03 Removal and Installation of Food Tray 13 Installation Instructions Desiccant Placement 14 Power-on 04 Insertion of Memory Card 14 Battery Installation 05 Statuses of Indicator Light 06 Removal and Installation of Food Bucket Operation Instructions Removal of Food Bucket 15 APP Download 07 Installation of Food Bucket 17 Network Configuration for Product 07 FAQ 19 Interface Navigation 08 Product Introduction Instructions for Safe Use This product is suitable for dried pet foods or freeze-dried foods with a diameter less than 25 mm and cannot contain any wet foods. Do not add any foreign objects other than pet foods into the food bucket; The product is neither allowed to immerse, soak, or rinse, nor be exposed to moisture, high temperature, or direct sunlight; It's recommended to clean its food delivery assembly every other month to avoid debris accumulation; The product applies to cats or medium- and small-sized dogs; Please use the product indoors and keep it away from fire; It's recommended to put the feeder in a corner or near a wall to prevent it from being toppled over by a pet; Please use the original adapter and power cord. While (un)plugging the adapter, do not directly pull the power cord; •The device only supports TF (MicroSD) cards in FAT32 format. Any MicroSD card in other formats, if inserted, will be automatically formatted by the device. Therefore, please back up your data from the MicroSD card beforehand; This product uses 3 No.5 (AA) batteries (alkaline ones recommended). If the feeder is not to be used in a long term, please remove the batteries to avoid electrolyte leakage; Do not remove and repair the device by yourself. For any fault or damage, please contact after sales in time; This product can be used by people above 12 years old. Children can only use it under the guidance of adults; If you need to go out, please check the batteries inside the battery compartment and ensure sufficient battery power (this product only supports alkaline batteries) Notes We will regularly carry out product improvements to provide better products; If the product illustration is slightly different from the physical product, the latter shall prevail; In this manual, a 4L bucket-shape product is taken as an example. Included Items Power Adapter ×1Power Cord ×1Insertion Pin×1Operation Manual ×1 Product Name SMARTO 4L/6L Smart Feeder with Camera Operating Power DC 5V 2A Product Model AFF140 Power Supply Battery 3 No.5 (AA) alkaline batteries Product Target Dogs and cats Applicable Pet Food Dried/freeze-dried foods (< 25 mm) Product Dimensions 4L - 217×362×387 mm 6L - 217×362×447 mm Communication Method WIFI 2.4GHz APP Support Android6.0/IOS8.0 and later Product Weight 4L - 2.0 kg 6L-2.28kg Storage Function MicroSD cards (16-512GB, Class10 and later memory cards supported) Product Material Environment-friendly ABS + PET Installation Instructions Although the product is equipped with an anti-slip mat and a suction disc at its bottom to prevent itself from being toppled over by pets, it's still recommended to put the feeder in a corner or near a wall. 1. Power-on Insert the power cord into the power port at the bottom, and wait for the device's circular light to turn on blue, which indicates that the device is powered on normally Installation Instructions 2. Battery Installation (the product can work without batteries) Users can choose whether to install batteries depending on their own needs. The batteries to be used are 3 No.5 (AA) batteries and sh…

Text truncated - open the document above for the full version.

Jiangsu Zhong Heng Pet Articles Joint-stock CO., LTD U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Baihetian Innovative Solutions FRN: 0033401605 Contact Name: Kenneth Young Street Address: 6837 Chase Rd City/Province/Zip: Dearborn, MI 48126 Telephone No: 313-395-3113 Email: [email protected] This letter is to confirm that we (“Baihetian Innovative Solutions) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: Nov 27, 2024 Signed by (Printed Name/Title): Kenneth Young/Manager The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: Jiangsu Zhong Heng Pet Articles Joint-stock CO., LTD Grantee Code: 2A525 FRN: 0032177487 Contact Name: Dongmei Yan Street Address: NO.1388 Century Avenue, Yandu District City/Province/Zip: Yancheng City, Jiangsu, China Telephone No: 860515-88463555 Email: [email protected] Applicant Signature: Date:2024-11-27 Signed by (Printed Name/Title): Dongmei Yan / Manager FCC ID: 2A525-AFF140 Nov 2024

Jiangsu Zhong Heng Pet Articles Joint-stock CO., LTD Covered Equipment Certification Attestation Letter 12/2/2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2A525-AFF140 Jiangsu Zhong Heng Pet Articles Joint-stock CO., LTD (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List , the applicant should include an explanation on why the equipment is not “covered” equipment. Jiangsu Zhong Heng Pet Articles Joint-stock CO., LTD (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates)as an entity producing “covered” equipment. Jiangsu Zhong Heng Pet Articles Joint-stock CO., LTD(“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Signed: Printed name: Dongmei Yan Title: Manager Company Name: Jiangsu Zhong Heng Pet Articles Joint-stock CO., LTD Date: 12/2/2024

Jiangsu Zhong Heng Pet Articles Joint-stock CO., LTD 2024-05-08 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint SHENZHEN TONGCE TESTING LAB / 2101 & 2201, Zhenchang Factory Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China (Name of Agent company name andaddress) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. Forinstanceswhereourauthorizedagentsignstheapplicationforcertificationonourbehalf,Iack nowledgethatallresponsibilityforcomplyingwiththetermsandconditionsforcertification,stillres ideswith Jiangsu Zhong Heng Pet Articles Joint-stock CO., LTD / NO.1388 Century Avenue, Yandu District, Yancheng City, Jiangsu, China (Applicant Nameandaddress) <Signature> Name: Dongmei Yan Title: Manager Applicant Company: Jiangsu Zhong Heng Pet Articles Joint-stock CO., LTD

Jiangsu Zhong Heng Pet Articles Joint-stock CO., LTD 2024-05-08 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2A525-AFF140 Product Name: Pet Smart Video Feeder Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name: Dongmei Yan Title: Manager Company: Jiangsu Zhong Heng Pet Articles Joint-stock CO., LTD

Page 1 of 4 Appendix C: Photographs of EUT Product: Pet Smart Video Feeder Model: AFF140 External Photos Page 2 of 4 Page 3 of 4 Page 4 of 4

LabelArtworkandLocation Model:AFF140 Label: Size:L*W=90*50mm Location

Page 1 of 13 Appendix C: Photographs of EUT Product: Pet Smart Video Feeder Model: AFF140 Internal Photos Page 2 of 13 Page 3 of 13 Page 4 of 13 Page 5 of 13 WIFI ANT Page 6 of 13 Page 7 of 13 Page 8 of 13 Page 9 of 13 Page 10 of 13 Page 11 of 13 Page 12 of 13 Page 13 of 13

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2A525-AFF140 Test Report No. ............... : TCT230921E032 Date of issue ................... : May 07, 2024 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory, Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Jiangsu Zhong Heng Pet Articles Joint-stock CO., LTD Address ........................... : NO.1388 Century Avenue, Yandu District, Yancheng City, Jiangsu, China Manufacturer's name ... : Jiangsu Zhong Heng Pet Articles Joint-stock CO., LTD Address ........................... : NO.1388 Century Avenue, Yandu District, Yancheng City, Jiangsu, China Standard(s) ..................... : FCC CFR Title 47 Part 1.1307 Product Name ................. : Pet Smart Video Feeder Trade Mark ...................... : N/A Model/Type reference..... : AFF140 Rating(s).......................... : Adapter Information: MODEL: HNDA050200U1 INPUT: AC 100-240V, 50/60Hz, 0.45A MAX OUTPUT: DC 5.0V, 2.0A DC 4.5V(3*AAA Battery) Date of receipt of test item ......................................... : Sep. 21, 2023 Date (s) of performance of test ................................... : Sep. 21, 2023 ~ May 07, 2024 Tested by (+signature) ... : Onnado YE Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT230921E032 Page 2 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 2. General Information ................................................................................. 4 2.1. Test environment and mode ................................................................................. 4 2.2. Description of Support Units ................................................................................ 4 3. Facilities and Accreditations .................................................................. 5 3.1. Facilities ................................................................................................................. 5 3.2. Location ................................................................................................................. 5 4. Test Results and Measurement Data ..................................................... 6 Report No.: TCT230921E032 Page 3 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : Pet Smart Video Feeder Model/Type reference........... : AFF140 Sample Number....................: TCT230921E031-0101 Operation Frequency ........... : 2412MHz~2462MHz (802.11b/802.11g/802.11n(HT20)) 2422MHz~2452MHz (802.11n(HT40)) Channel Separation ............. : 5MHz Number of Channel .............. : 11 for 802.11b/802.11g/802.11n(HT20) 7 for 802.11n(HT40) Modulation Technology ....... : 802.11b: Direct Sequence Spread Spectrum (DSSS) 802.11g/802.11n: Orthogonal Frequency Division Multiplexing(OFDM) Data speed ............................ : 802.11b: 1Mbps, 2Mbps, 5.5Mbps, 11Mbps 802.11g: 6Mbps, 9Mbps, 12Mbps, 18Mbps, 24Mbps, 36Mbps, 48Mbps, 54Mbps 802.11n: Up to 150Mbps Antenna Type ........................ : FPC Antenna Antenna Gain ........................ : 0.08dBi Rating(s)................................ : Adapter Information: MODEL: HNDA050200U1 INPUT: AC 100-240V, 50/60Hz, 0.45A MAX OUTPUT: DC 5.0V, 2.0A DC 4.5V(3*AAA Battery) Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list None. Report No.: TCT230921E032 Page 4 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. General Information 2.1. Test environment and mode Item Normal condition Temperature +25ºC Voltage AC 120V/60Hz Humidity 56% Atmospheric Pressure: 1008 mbar Test Mode: Transmitting mode: Keep the EUT in continuous transmitting by select channel 2.2. Description of Support Units The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Equipment Model No. Serial No. FCC ID Trade Name / / / / / Note: 1. All the equipment/cables were placed in the worst-case configuration to maximize the emission during the test. 2. Grounding was established in accordance with the manufacturer’s requirements and conditions for the intended use. 3. For conducted measurements (Output Power, 20dB Occupied Bandwidth, Carrier Frequencies Separation, Hopping Channel Number, Dwell Time, Spurious Emissions), the antenna of EUT is connected to the test equipment via temporary antenna connector, the antenna connector is soldered on the antenna port of EUT, and the temporary antenna connector is listed in the Test Instruments. Report No.: TCT230921E032 Page 5 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. Facilities and Accreditations 3.1. Facilities The test facility is recognized, ce…
