2A55L-RC522RFID Module RF IC Card

User manual Instructions for use: Take Arduino UNO microcontroller as an example 1. First upload the program in the data to the Arduino UNO microcontroller: 2. Wire the HW-126 module to the Arduino UNO microcontroller as shown below: Arduino UNO HW-126 D10 一 SDA D13 一 SCK D11 一 MOSI D12 __ MISO D5 一 RST GND 一 GND 3.3V 一 3.3V 3.3. Open the serial monitor and set the baud rate to 57600 to directly read the white card or blue alien Card data: Introduction to RFID Module The MF522-AN module adopts the Philips MFRC522 chip to design the card reading power Road, easy to use, low cost, suitable for equipment development, card reader development, etc. Users of advanced applications, those who need to design/produce RF card terminals Household. This module can be directly loaded into various card reader molds. module voltage It is 3.3V, and can directly communicate with the user through a few simple lines through the sPl interface. Any CPU motherboard is connected to communicate, which can ensure the stable and reliable operation of the module, Card reading distance is far. The device used internal antenna, the antenna gain is 0dBi FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Important Note: In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re‐evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. Radiation Exposure Statement: This module support RF(13.56MHz) which compliance with part 15.225 and apply for limit single module approval . The module is limited to OEM installation only. The OEM integrator is responsible for ensuring that the end-user has no manual instruction to remove or install module. OEM integrator shall equipped the antenna to compliance with antenna requirement part 15.203& 15.204 and must not be co-located or operating in conjunction with any other antenna or transmitters. And OEM host shall implement a Class II Permissive Change (C2PC) or a new FCC ID to demonstrate complied with FCC standard. The OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed. The final end product must be labelled in a visible area with the following: “Contains FCC ID:2A55L-RC522”

Shenzhenshi Saiweilakejiyouxiangongsi 1/1 Letter of Authorization Company: Shenzhenshi Saiweilakejiyouxiangongsi Address: Longhuaxinqu Guanlanjiedao Dahelu 99 Hao, Guanlanshangwudasha A Zuo 710 Shi, Shenzhen, Guangdong, 518000, China Product Name: RFID Module RF IC Card Model Number: RC522 FCC Identifier: 2A55L-RC522 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Huang Wei Date: 2022-04-02 Title: Manager Signature of applicant:

Shenzhenshi Saiweilakejiyouxiangongsi 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2022-04-01 Subject: Request for Confidentiality FCC ID: 2A55L-RC522 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up No ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Huang Wei Title: Manager

Shenzhenshi Saiweilakejiyouxiangongsi C5266091_X9_Ed.2 Modular Transmitter Approval Request Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Company name: Shenzhenshi Saiweilakejiyouxiangongsi FCC ID: 2A55L-RC522 Gentlemen, In accordance with 47CFR 15.212 Modular Transmitters and KDB 996369 D01 ‘Module Certification Guide v02’. FCC ID: 2A55L-RC522 has been examined against the following requirements. Items to be covered by Single modular transmitters. Requirement per 15.212 and KDB 996369 D01 ‘Modular Certification Guide v02 Explanation from Grantee(do not write yes/no, but explain why productcomplies/how it is achieved) 1. The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly No, The module there is no its own RF shield 2. The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal Buffered data inputs stage has been integrated in chip HW-126. 3. The module must contain power supply regulation on the module Module with power regulation and support for DC 3.3V input 4. The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per Sections 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b) The module meets the antenna requirements. 5. The module must demonstrate compliance in a stand- alone configuration The module has been tested in a stand alone configuration, see report for details 6. The module must be labelled with its permanently affixed FCC ID label, or use an electronic display (See KDB Publication 784748 about labelling requirements) The module has its own FCC ID number. See the label for details. 7. The module must comply with all specific rules applicable to the transmitter including all the conditions provided in the integration instructions by the grantee The module meets any specific rules or operational requirements applicable to the transmitter 8. The module must comply with RF exposure requirements The module complies with any applicable RF exposure requirements, as detailed in the instructions. C5266091_X9_Ed.2 Name: Huang Wei Date: 2022-4-02 Title:Manager Signature of applicant

Size:5*3mm M/N: RC522 FCC ID: 2A55L-RC522 Label location

ANT

Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220401012E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 19 TEST REPORT FCC ID: 2A55L-RC522 Applicant: Shenzhenshi Saiweilakejiyouxiangongsi Address: Longhuaxinqu Guanlanjiedao Dahelu 99 Hao, Guanlanshangwudasha A Zuo 710 Shi, Shenzhen, Guangdong, 518000, China Manufacturer: shenzhenshi shizhandeng maoyiyouxiangongsi Address: 310hao C zuo 601 longhuqu guanghujiedao luhushequ wuhedadao Shenzhen Guangdong china EUT: RFID Module RF IC Card Trade Mark: N/A Model Number: RC522 Date of Receipt: Mar. 25, 2022 Test Date: Mar. 25, 2022 - Mar. 31, 2022 Date of Report: Mar. 31, 2022 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC PART 15.225 ANSI C63.10:2013 Test Result: Pass Report Number: DL-20220401012E Prepared (Engineer): Lily Fu Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220401012E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 19 TABLE OF CONTENT Test Report Declaration Page 1. VERSION ................................................................................................................................................. 3 2. TEST SUMMARY ..................................................................................................................................... 3 3. GENERAL INFORMATION ..................................................................................................................... 4 4. TEST INSTRUMENT USED ..................................................................................................................... 6 5. CONDUCTED EMISSION TEST .............................................................................................................. 7 6. RADIATION EMISSION TEST ............................................................................................................... 11 7. BANDWIDTH TEST ............................................................................................................................... 17 8. SETUP PHOTOGRAPHS ...................................................................................................................... 19 9. EUT PHOTOGRAPHS ........................................................................................................................... 19 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220401012E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 19 1. VERSION Version No. Date Description 00 Mar. 31, 2022 Original 2. TEST SUMMARY EMC Emission Test Item Section in CFR 47 Result Remark AC Power Line Conducted Emission 15.207 PASS Radiated Spurious Emission 15.209, 15.225 PASS 20dB Bandwidth 15.225 15.215(c) PASS Frequency Tolerance 15.225(e) PASS Antenna requirement 15.203 PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report (2) Test Facility: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220401012E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 19 3. GENERAL INFORMATION 3.1 Description of Device (EUT) Product Name: RFID Module RF IC Card Model No.: RC522 Model Difference: N/A Hardware version: H1.0 Software version: S1.0 Operation Frequency: 13.56MHz Modulation type: ASK Antenna Type: Internal Antenna Antenna gain: 0dBi Power supply: Input: DC 3.3V 3.2 Tested System Details None. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220401012E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 19 3.3 Block Diagram of Test Set-up 3.4 Test Mode Description Mode1. Running Mode 3.5 Test Auxiliary Equipment Item Equipment Model/Type No. Series No. Note E-1 RFID Module RF IC Card RC522 N/A EUT E-2 Adapter HW-0330500E N/A Input: AC 100-240V 50/60Hz Output: DC 3.3V 0.5A Item Shielded Type Ferrite Core Length Note C1 No No 0.5m Mini USB Line 3.6 Test Uncertainty Conducted Emission Uncertainty (150KHz-30MHz) : ±2.56dB Radiated Emission Uncertainty (9KHz-1GHz) : ±3.24dB AC Mains C1 E-1 EUT E-2 Adapter Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220401012E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 6 of 19 4. TEST INSTRUMENT USED For Conducted Emission Test (843 Shielded Room) Equipment Manufacturer Model Serial Last Cal. Next Cal. 843 Shielded Room ChengYu 843 Room 843 Nov. 25, 2019 Nov. 24, 2022 EMI Receiver R&S ESR 101421 Dec. 07, 2021 Dec. 06, 2022 LISN R&S ENV216 102417 Dec. 07, 2021 Dec. 06, 2022 Clamp COM-POWER CLA-050 431071 Dec. 05, 2021 Dec. 04, 2022 3-Loop Antenna DAZE ZN30401 13021 Dec. 07, 2021 Dec. 06, 2022 ISN T8 Schwarzbeck NTFM 8158 101135 Dec. 07, 2021 Dec. 06, 2022 ISN T5 Schwarzbeck NTFM 8158 101136 Dec. 07, 2021 Dec. 06, 2022 843 Cable 1# ChengYu CE Cable 001 Dec. 07, 2021 Dec. 06, 2022 843 Cable 1# ChengYu CE Cable 002 Dec. 07, 2021 Dec. 06, 2022 For Radiated Emission Test (966 chamber) Equipment Manufacturer Model Serial Last Cal. Next Cal. 966 Chamber ChengYu 966 Room 966 Nov. 25, 2019 Nov. 24, 2022 Spectrum Analyzer Agilent E4408B MY50140780 Dec. 07, 2021 Dec. 06, 2022 EMI Receiver R&S ESRP7 101393 Dec. 07, 2021 Dec. 06, 2022 Amplifier Schwarzbeck BBV9743B 00153 Dec. 07, 2021 Dec. 06, 2022 Amplifier EMEC EM01G8GA 00270 Dec. 07, 2021 Dec. 06, 2022 Broadband Trilog A…

Text truncated - open the document above for the full version.

Radiated Measurement Photos Conducted Measurement Photos
