2A56E-NCA01Nooie Air Purifier

Nooie LLC

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Apr 17, 2023
Application Purpose: Original Equipment
Date of Application: Apr 17, 2023
Equipment Note: Nooie Air Purifier
Frequency Range: 2412.00000000 - 2462.00000000
Company: Nooie LLC
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

*RF warning for Mobile device: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Attestation Statements

(NooieLLC) (Applicantsignature (date)2023/4/3 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for(2A56E-NCA01) [Nooie LLC] (“the applicant”) certifies that the equipment for which authorization is sought is not“covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, ) (Applicantprintedname):JaniceLiu (APPLICANT’SCOMPANYLETTERHEAD) (Applicantsignature (date)2023/4/3 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for(2A56E-NCA01) [Nooie LLC] (“the applicant”) certifies that, as of the date of the filing of the application, the applicantis notidentified on the Covered List as an entity producing “covered” equipment. Sincerely, ) (Applicantprintedname):JaniceLiu

Attestation Statements

AttestationStatements Address:1603SMainSt,SuiteA,MilpitasCA95035 TelephoneNo:9139332197 Email: [email protected] (date)2023/4/3 TO:Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for(2A56E-NCA01) (Nooie LLC), the undersigned, hereby authorize(Nooie LLC)to act as our designated U.S. agent for service of process,(Nooie LLC)accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. (Nooie LLC)accepts the responsibility to act as designated U.S. agent for service of process. Applicant Information：Nooie LLC Company name:Nooie LLC Contact Name:Janice Liu m Signature [name] U.S. AgentInformationNooieLLC CompanyName:NooieLLC Address:1603SMainSt,SuiteA,MilpitasCA95035 FRN:0032193211 Contact Name:Janice Liu Telephone No:CertificationEngineer Email:[email protected] Signature [name]

Cover Letter(s)

NooieLLC (date)2023/4/3 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR(Product Name:Nooie Air Purifier/Model No: NCA01 F C C I D :2A56E-NCA01) Schematic ToWhomItMayConcern: Thisletterservesasanofficialrequestforconfidentialityundersections0.457and0.459 ofCFR47.Wehaverequestedthatthe s Blockdiagram Operationdescription requiredtobesubmittedwiththisapplicationbepermanentlywithheldfrompublic review. Thesematerialscontaintradesecretsandproprietaryinformationandarenot customarilyreleasedtothepublic.Thepublicdisclosureofthisinformationmightbe harmfultothecompanyandprovideunjustifiedbenefitstoour Pleasecontactmeifthereisanyinformationyoumayneed. Sincerely, Mustbesignedbytheapplicantcontactcitedastechnicalornon-technicalcontactonthe 731formprovidedtoEurofinsMETLabs,orbytheauthorizedagentifanappropriate authorizedagentletterhasbeenprovided.Letterssignedbytheapplicantshouldbe placedonapplicantletterhead <Signature> Name：JaniceLiu Title：manager Company：NooieLLC .

Cover Letter(s)

NooieLLC (Date)2023/4/3 EurofinsElectricalandElectronicTestingNA,Inc. 914WestPatapscoAvenue Baltimore,MD21230 RE:LETTEROFAGENTAUTHORIZATION ToWhomItMayConcern: We,theundersigned,herebyauthorize(BlueAsiaofTechnicalServices(Shenzhen) Co.,Ltd. ） toactonourbehalfinallmattersrelatingtoapplicationforequipmentauthorization, includingthesigningofalldocumentsrelatingtothesematters. Wealsoherebycertifythatnopartytotheapplicationauthorizedhereunderissubjecttothe denialofbenefits,includingFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseAct of1988,21U.S.C.853(a). Thisagreementexpiresoneyearfromthecurrentdate. Sincerely, Mustbesignedbytheapplicantcontactcitedastechnicalornon-technicalcontactonthe 731formprovidedtoEurofinsMETLabs,orbytheauthorizedagentifanappropriate authorizedagentletterhasbeenprovided.Letterssignedbytheapplicantshouldbe placedonapplicantletterhead. <Signature> Name：JaniceLiu Title：manager Company：NooieLLC

External Photos

ProductName: NooieAirPurifier

ID Label/Location Info

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference,and (2) this device must accept any interference received, including interference that may cause undesired operation

Internal Photos

ProductName: NooieAirPurifier

RF Exposure Info

SARevaluation ProductName: NooieAirPurifier FCCID: 2A56E-NCA01 TestStandard: KDB447498D04GeneralRFExposure Guidancev01 Accordingto447498D04InterimGeneralRFExposureGuidancev01 StandaloneSARtestexclusionconsiderations UnlessspecificallyrequiredbythepublishedRFexposureKDBprocedures,standalone1-ghead orbodyand10-gextremitySARevaluationforgeneralpopulationexposureconditions,by measurementornumericalsimulation,isnotrequiredwhenthecorrespondingSARExclusion Thresholdcondition,listedbelow,issatisfied. CalculatedResultandLimit(WORSECASEISASBELOW) BLE Directional antennaGain (Numeric) PeakOutput Power(dBm) PeakOutput Power(mW) Limit(mW/cm²) TestResult 2.54dBi(1.795)-0.944 0.805 (2402) 3060Compiles ERP=-0.944+2.54-2.15=0.880mW WIFI Directional antennaGain (Numeric) PeakOutput Power(dBm) PeakOutput Power(mW) Limit(mW/cm²) TestResult 2.54dBi(1.795)13.529 22.537 (802.11b2462) 3060Compiles ERP=13.529+2.54-2.15=24.655mW PeakOutputPowersum/3060 =1.054/3060+22.537/3060=0.007709<1 ERPsum/3060 =(1.153+24.655)/3060=0.008434<1

Test Report

AntennaSpecification Manufacture：TUYA ProductName：WBR3Antenna AntennaType：PCB TestDate：2021.05.20 Testedby：LongWang Approvedby：Licco Content 1.GeneralDescription.................................................................................1 2.TestConfigurations...................................................................................2 2.1TestEnvironment............................................................................2 2.2TestEquipment...............................................................................2 2.3TestPrinciple...................................................................................2 3.TestResults..............................................................................................3 3.1GainandEfficiency..........................................................................3 3.2RadiationPattern............................................................................4 4.AntennaDimensions................................................................................6 5.EUTPhoto................................................................................................6 6.TestSetupPhoto......................................................................................7 1 1.GeneralDescription ManufacturerHangzhouTuyaInformationTechnologyCo.,Ltd Address Room701,Building3,MoreCenter,No.87GuDunRoad, Hangzhou,Zhejiang,China TestLocation Room106,Building3,LetongSciencePark,No.500, QiuyiRoad,BinjiangDistrict,Hangzhou ProductNameWBR3Antenna Productmodel WBR3 AntennaType PCBAntenna TestItems Gain;Efficiency;RadiationPattern TestFrequency 2400-2500MHz TestStandard ANSI/IEEEStd149-1979 2 2.TestConfigurations 2.1TestEnvironment Temperature(°C)25 Humidity(%RH)60 AtmosphericPressure(kPa)100.5 2.2TestEquipment TestSystemTEM24Multi-probeMicrowaveChamber TestInstrumentAgilentE5071B 2.3TestPrinciple 3 3.TestResults 3.1GainandEfficiency Frequency(MHz)PeakGain(dBi)Efficiency(%) 2400 1.6252.29 2410 1.7152.17 2420 1.9353.14 2430 1.9854.16 2440 2.0057.62 2450 2.1759.64 2460 2.4561.55 2470 2.3860.64 2480 2.5462.86 2490 2.3059.85 2500 2.4960.41 4 3.2RadiationPattern Phi02D Phi902D 5 Theta902D 2480MHz3D 6 4.AntennaDimensions 5.EUTPhoto 7 6.TestSetupPhoto

Test Report

Page 1 of 59 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Add:BuildingC,No.107,ShihuanRoad,ShiyanSub-District,BaoanDistrict,Shenzhen,GuangdongProvince,China Tel:+86-755-23059481Email:[email protected] TESTREPORT ProductName: NooieAirPurifier BrandMark: Nooie ModelNo.: NCA01 ReportNumber: BLA-EMC-202303-A3302 FCCID: 2A56E-NCA01 DateofSampleReceipt: 2023/3/10 DateofTest DateofIssue TestStandard TestResult Preparedfor : 2023/3/10 to 2023/4/13 : 2023/4/13 : 47 CFR Part 15, Subpart C 15.247 :Pass : NooieLLC 1603SMainSt,SuiteA,MilpitasCA95035 Preparedby: BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. BuildingC,No.107,ShihuanRoad,ShiyanSub-District,BaoanDistrict, Shenzhen,GuangdongProvince,China TEL:+86-755-23059481 Compiledby:Reviewby: Approvedby:Date:2023/4/13 ReportNo.:BLA-EMC-202303-A3302 Page 2 of 59 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] REPORTREVISERECORD VersionNo.DateDescription 00Origina2023/4/13l ReportNo.:BLA-EMC-202303-A3302 Page 3 of 59 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] TABLEOFCONTENTS 1TESTSUMMARY........................................................................................................................................5 2GENERALINFORMATION.........................................................................................................................6 3GENERALDESCRIPTIONOFE.U.T..........................................................................................................6 4TESTENVIRONMENT................................................................................................................................7 5TESTMODE................................................................................................................................................7 6MEASUREMENTUNCERTAINTY..............................................................................................................7 7DESCRIPTIONOFSUPPORTUNIT..........................................................................................................8 8LABORATORYLOCATION.........................................................................................................................8 9TESTINSTRUMENTSLIST........................................................................................................................9 10CONDUCTEDPEAKOUTPUTPOWER...................................................................................................11 10.1LIMITS................................................................................................................................................................11 10.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................11 10.3TESTDATA...........................................................................................................................................................12 11MINIMUM6DBBANDWIDTH...................................................................................................................13 11.1LIMITS................................................................................................................................................................13 11.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................13 11.3TESTDATA...........................................................................................................................................................13 12ANTENNAREQUIREMENT......................................................................................................................14 12.1CONCLUSION.........................................................................................................................................................14 13CONDUCTEDEMISSIONSATACPOWERLINE(150KHZ-30MHZ).....................................................15 13.1LIMITS................................................................................................................................................................15 13.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................15 13.3PROCEDURE.......................................................................................................................................................15 13.4TESTDATA...........................................................................................................................................................17 14CONDUCTEDBANDEDGESMEASUREMENT.....................................................................................19 14.1LIMITS................................................................................................................................................................19 14.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................19 14.3TESTDATA...........................................................................................................................................................20 15RADIATEDSPURIOUSEMISSIONS........................................................................................................21 ReportNo.:BLA-EMC-202303-A3302 Page 4 of 59 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 15.1LIMITS................................................................................................................................................................21 15.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................…

Text truncated - open the document above for the full version.

Test Report

ReportNo.:BLA-EMC-202303-A3302 Page 31 of 59 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXhighchannel];[Polarity:Vertical] TestResult:Pass ReportNo.:BLA-EMC-202303-A3302 Page 32 of 59 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 16RADIATEDEMISSIONSWHICHFALLINTHERESTRICTEDBANDS TestStandard47CFRPart15,SubpartC15.247 TestMethodANSIC63.10(2013)Section6.10.5 TestMode(Pre-Scan)TX TestMode(FinalTest)TX TesterJozu Temperature25°C Humidity60% 16.1LIMITS Frequency(MHz) Field strength(microvolts/meter) Measurement distance(meters) 0.009-0.4902400/F(kHz)300 0.490-1.70524000/F(kHz)30 1.705-30.03030 30-881003 88-2161503 216-9602003 Above9605003 Remark:Theemissionlimitsshownintheabovetablearebasedonmeasurementsemployinga CISPRquasi-peakdetectorexceptforthefrequencybands9-90kHz,110-490kHzandabove1000 MHz.Radiatedemissionlimitsinthesethreebandsarebasedonmeasurementsemployingan averagedetector,thepeakfieldstrengthofanyemissionshallnotexceedthemaximumpermitted averagelimitsspecifiedabovebymorethan20dBunderanyconditionofmodulation. ReportNo.:BLA-EMC-202303-A3302 Page 33 of 59 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 16.2BLOCKDIAGRAMOFTESTSETUP 16.3PROCEDURE a.Forbelow1GHz,theEUTwasplacedonthetopofarotatingtable0.8metersabovethegroundata3 or10metersemi-anechoicchamber.Thetablewasrotated360degreestodeterminethepositionofthe highestradiation. b.Forabove1GHz,theEUTwasplacedonthetopofarotatingtable1.5metersabovethegroundata3 meterfully-anechoicchamber.Thetablewasrotated360degreestodeterminethepositionofthehighest radiation. c.TheEUTwasset3or10metersawayfromtheinterference-receivingantenna,whichwasmountedon thetopofavariable-heightantennatower. d.Theantennaheightisvariedfromonemetertofourmetersabovethegroundtodeterminethe maximumvalueofthefieldstrength.Bothhorizontalandverticalpolarizationsoftheantennaaresetto makethemeasurement. e.Foreachsuspectedemission,theEUTwasarrangedtoitsworstcaseandthentheantennawastuned toheightsfrom1meterto4meters(forthetestfrequencyofbelow30MHz,theantennawastunedto heights1meter)andtherotatabletablewasturnedfrom0degreesto360degreestofindthemaximum reading. f.Thetest-receiversystemwassettoPeakDetectFunctionandSpecifiedBandwidthwithMaximumHold Mode. g.IftheemissionleveloftheEUTinpeakmodewas10dBlowerthanthelimitspecified,thentesting couldbestoppedandthepeakvaluesoftheEUTwouldbereported.Otherwisetheemissionsthatdidnot have10dBmarginwouldbere-testedonebyoneusingpeak,quasi-peakoraveragemethodasspecified andthenreportedinadatasheet. ReportNo.:BLA-EMC-202303-A3302 Page 34 of 59 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] h.TesttheEUTinthelowestchannel,themiddlechannel,theHighestchannel. i.TheradiationmeasurementsareperformedinX,Y,ZaxispositioningforTransmittingmode,andfound theXaxispositioningwhichitistheworstcase. j.Repeataboveproceduresuntilallfrequenciesmeasuredwascomplete. Remark1:Level=ReadLevel+CableLoss+AntennaFactor-PreampFactor Remark2:Forfrequenciesabove1GHz,thefieldstrengthlimitsarebasedonaveragelimits.However, thepeakfieldstrengthofanyemissionshallnotexceedthemaximumpermittedaveragelimitsspecified abovebymorethan20dBunderanyconditionofmodulation.Fortheemissionswhosepeaklevelis lowerthantheaveragelimit,onlythepeakmeasurementisshowninthereport. ReportNo.:BLA-EMC-202303-A3302 Page 35 of 59 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 16.4TESTDATA [TestMode:TXlowchannel];[Polarity:Horizontal] TestResult:Pass ReportNo.:BLA-EMC-202303-A3302 Page 36 of 59 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXlowchannel];[Polarity:Vertical] TestResult:Pass ReportNo.:BLA-EMC-202303-A3302 Page 37 of 59 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXhighchannel];[Polarity:Horizontal] TestResult:Pass ReportNo.:BLA-EMC-202303-A3302 Page 38 of 59 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXhighchannel];[Polarity:Vertical] TestResult:Pass ReportNo.:BLA-EMC-202303-A3302 Page 39 of 59 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 17CONDUCTEDSPURIOUSEMISSIONS TestStandard47CFRPart15,SubpartC15.247 TestMethodANSIC63.10(2013)Section7.8.6&Section11.11 TestMode(Pre-Scan)TX TestMode(FinalTest)TX TesterJozu Temperature25°C Humidity60% 17.1LIMITS Limit: Inany100kHzbandwidthoutsidethefrequencybandinwhichthespread spectrumordigitallymodulatedintentionalradiatorisoperating,theradio frequencypowerthatisproducedbytheintentionalradiatorshallbeatleast20dB belowthatinthe100kHzbandwidthwithinthebandthatcontainsthehighest levelofthedesiredpower,basedoneitheranRFconductedoraradiated measurement,providedthetransmitterdemonstratescompliancewiththepeak conductedpowerlimits.Ifthetransmittercomplieswiththeconductedpower limitsbasedontheuseofRMSaveragingoveratimeinterval,aspermittedunder paragraph(b)(3)ofthissection,theattenuationrequiredunderthisparagraphshall be30dBinsteadof20dB.Attenuationbelowthegenerallimitsspecifiedin §15.209(a)isnotrequired.Inaddition,radiatedemissionswhichfallinthe restrictedbands,asdefinedin§15.205(a),mustalsocomplywiththeradiated emissionlimitsspecifiedin§15.209(a)(see§15.205(c)). 17.2BLOCKDIAGRAMOFTESTSETUP ReportNo.:BLA-EMC-202303-A3302 Page 40 of 59 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 17.3TESTDATA Pass:PleaseReferToAppendix:Appendix1ForDetails ReportNo.:BLA-EMC-202303-A3302 Page 41 of 59 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected]…

Text truncated - open the document above for the full version.

Test Report

Page 1 of 92 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Add:BuildingC,No.107,ShihuanRoad,ShiyanSub-District,BaoanDistrict,Shenzhen,GuangdongProvince,China Tel:+86-755-23059481Email:[email protected] TESTREPORT ProductName: NooieAirPurifier BrandMark: Nooie ModelNo.: NCA01 ReportNumber: BLA-EMC-202303-A3303 FCCID: 2A56E-NCA01 DateofSampleReceipt: 2023/3/10 DateofTest: 2023/3/10to2023/3/29 DateofIssue: 2023/3/29 TestStandard: 47CFRPart15,SubpartC15.247 TestResult:Pass Preparedfor: NooieLLC 1603SMainSt,SuiteA,MilpitasCA95035 Preparedby: BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. BuildingC,No.107,ShihuanRoad,ShiyanSub-District,BaoanDistrict, Shenzhen,GuangdongProvince,China TEL:+86-755-23059481 Compiledby:Reviewby: Approvedby:Date:2023/3/29 ReportNo.:BLA-EMC-202303-A3303 Page 2 of 92 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] REPORTREVISERECORD VersionNo.DateDescription 002023/3/29Original ReportNo.:BLA-EMC-202303-A3303 Page 3 of 92 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] TABLEOFCONTENTS 1TESTSUMMARY........................................................................................................................................5 2GENERALINFORMATION.........................................................................................................................6 3GENERALDESCRIPTIONOFE.U.T..........................................................................................................6 4TESTENVIRONMENT................................................................................................................................7 5TESTMODE................................................................................................................................................7 6MEASUREMENTUNCERTAINTY..............................................................................................................7 7DESCRIPTIONOFSUPPORTUNIT..........................................................................................................8 8LABORATORYLOCATION.........................................................................................................................8 9TESTINSTRUMENTSLIST........................................................................................................................9 10RADIATEDSPURIOUSEMISSIONS........................................................................................................11 10.1LIMITS................................................................................................................................................................11 10.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................12 10.3PROCEDURE.......................................................................................................................................................12 10.4TESTDATA...........................................................................................................................................................14 11ANTENNAREQUIREMENT......................................................................................................................23 11.1CONCLUSION.........................................................................................................................................................23 12RADIATEDEMISSIONSWHICHFALLINTHERESTRICTEDBANDS.................................................24 12.1LIMITS................................................................................................................................................................24 12.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................25 12.3PROCEDURE.......................................................................................................................................................25 12.4TESTDATA...........................................................................................................................................................27 13CONDUCTEDSPURIOUSEMISSIONS...................................................................................................40 13.1LIMITS................................................................................................................................................................40 13.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................40 13.3TESTDATA...........................................................................................................................................................41 14CONDUCTEDBANDEDGESMEASUREMENT.....................................................................................42 14.1LIMITS................................................................................................................................................................42 14.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................42 14.3TESTDATA...........................................................................................................................................................43 ReportNo.:BLA-EMC-202303-A3303 Page 4 of 92 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 15MINIMUM6DBBANDWIDTH...................................................................................................................44 15.1LIMITS...........................................................................................................................................................…

Text truncated - open the document above for the full version.

Test Report

ReportNo.:BLA-EMC-202303-A3303 Page 31 of 92 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXglowchannel];[Polarity:Horizontal] TestResult:Pass ReportNo.:BLA-EMC-202303-A3303 Page 32 of 92 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXglowchannel];[Polarity:Vertical] TestResult:Pass ReportNo.:BLA-EMC-202303-A3303 Page 33 of 92 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXghighchannel];[Polarity:Horizontal] TestResult:Pass ReportNo.:BLA-EMC-202303-A3303 Page 34 of 92 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXghighchannel];[Polarity:Vertical] TestResult:Pass ReportNo.:BLA-EMC-202303-A3303 Page 35 of 92 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXn20lowchannel];[Polarity:Horizontal] TestResult:Pass ReportNo.:BLA-EMC-202303-A3303 Page 36 of 92 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXn20lowchannel];[Polarity:Vertical] TestResult:Pass ReportNo.:BLA-EMC-202303-A3303 Page 37 of 92 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXn20highchannel];[Polarity:Horizontal] TestResult:Pass ReportNo.:BLA-EMC-202303-A3303 Page 38 of 92 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXn20highchannel];[Polarity:Vertical] TestResult:Pass ReportNo.:BLA-EMC-202303-A3303 Page 39 of 92 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] Remark: 1.FinalLevel=ReceiverReadlevel+Correctfactor 2.Correctfactor=AntennaFactor+CableLoss–PreamplifierFactor 3.Theemissionlevelsofotherfrequenciesareverylowerthanthelimitandnotshowintestreport. ReportNo.:BLA-EMC-202303-A3303 Page 40 of 92 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 13CONDUCTEDSPURIOUSEMISSIONS TestStandard47CFRPart15,SubpartC15.247 TestMethodANSIC63.10(2013)Section7.8.6&Section11.11 TestMode(Pre-Scan)TX TestMode(FinalTest)TX TesterJozu Temperature25°C Humidity60% 13.1LIMITS Limit: Inany100kHzbandwidthoutsidethefrequencybandinwhichthespread spectrumordigitallymodulatedintentionalradiatorisoperating,theradio frequencypowerthatisproducedbytheintentionalradiatorshallbeatleast20dB belowthatinthe100kHzbandwidthwithinthebandthatcontainsthehighest levelofthedesiredpower,basedoneitheranRFconductedoraradiated measurement,providedthetransmitterdemonstratescompliancewiththepeak conductedpowerlimits.Ifthetransmittercomplieswiththeconductedpower limitsbasedontheuseofRMSaveragingoveratimeinterval,aspermittedunder paragraph(b)(3)ofthissection,theattenuationrequiredunderthisparagraphshall be30dBinsteadof20dB.Attenuationbelowthegenerallimitsspecifiedin §15.209(a)isnotrequired.Inaddition,radiatedemissionswhichfallinthe restrictedbands,asdefinedin§15.205(a),mustalsocomplywiththeradiated emissionlimitsspecifiedin§15.209(a)(see§15.205(c)). 13.2BLOCKDIAGRAMOFTESTSETUP ReportNo.:BLA-EMC-202303-A3303 Page 41 of 92 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 13.3TESTDATA Pass:PleaseReferToAppendix:Appendix1ForDetails ReportNo.:BLA-EMC-202303-A3303 Page 42 of 92 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 14CONDUCTEDBANDEDGESMEASUREMENT TestStandard47CFRPart15,SubpartC15.247 TestMethodANSIC63.10(2013)Section7.8.8&Section11.13.3.2 TestMode(Pre-Scan)TX TestMode(FinalTest)TX TesterJozu Temperature25°C Humidity60% 14.1LIMITS Limit: Inany100kHzbandwidthoutsidethefrequencybandinwhichthespread spectrumordigitallymodulatedintentionalradiatorisoperating,theradio frequencypowerthatisproducedbytheintentionalradiatorshallbeatleast20dB belowthatinthe1…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Janice Liu(Certification Engineer)

[email protected]9139332197Fax: 0755-26509195

Test Firm

BlueAsia of Technical Services (Shenzhen)Blue Zheng

[email protected]+86 755-23059481-815

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15C	2.41 GHz - 2.46 GHz	22.54 mW

Confidentiality

Long Term

Grant Notes

Output Power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures.
