2A573-Z672 IN 1 MAGNETIC WIRELESS CHARGER

Descrip�on Cau�ons Product Features Parameters 1.Compa�ble for Iphone 12/13 Series magne�c wireless charging, QI standard mobile phone wireless charging, earphone wireless charging. 2.Support 15W wireless fast charging for phone, 3W wireless charging for earphone. 3.With fabric wrapping, appearance looks exquisite. 4.Mul�stage magne�c combina�on, strong magne�c power to keep phone steady. 5.Magne�c charging posi�on can be rotated 30°, you can adjust the phone placement angle. 6.Indicator: the blue light is always on in the standby state. 7.Support QC and PD adapter, advising to select suitable adapter to meet your mul�ple devices charging requirements. Opera�on Steps •Recommended for using product at environment temperature( -10°C to 45°C). •Do not disassemble charger without authoriza�on. •Please do not put the metal or magne�c goods (such as coin, bank card, key etc) on the charging area while charging. •Please keep the charger away from water or other liquid. •Try to avoid full-load work of the product, so as not to affect the charging efficiency of the product. 2.Place your device in the correct charging area to charge. Please select a suitable adapter to charge your mul�ple devices, the device may not be able to enter the fast charging mode or charging may be unstable due to insufficient adapter power. It is recommended to use PD 20W or above adapter when using this product for full load charging. 3.The indicator light is blue when the magne�c posi�on is in charging state, and the indicator light is red when the desktop posi�on is in charging state. 4.FOD detec�on: when there are metal or magne�c objects placed on the wireless charger, the green indicator will flash. (Note: the indicator light is s�ll blue when the mobile phone's magne�c posi�on in the FOD state.) 5.If your phone does not charge properly, please move your phone slightly to find the best charging posi�on for the wireless charging. Input : 9V 2.0A Or 12V3.0A Top: Magne�c wireless charging output power: 5W/7.5W/10W/15W Bo�om: Wireless charging output power: 5W/7.5W/10W/15W Headphone wireless charging output power: 3WMAX Product color : BlackWhite 3 / 70*110mm 2 IN 1 MAGNETIC WIRELESS CHARGING STAND User Manual 1.Connect product to adapter,blue indicator light keeps on. Rota�on axis FCC Cau�on Any Changes or modifica�ons not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Opera�on is subject to the following two condi�ons: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired opera�on. IMPORTANT NOTE —Increase the separa�on between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. FCC Radia�on Exposure Statement: This equipment complies with FCC radia�on exposure limits set forth for an uncontrolled environment .This equipment should be installed and operated with minimum distance 20cm between the radiator& your body. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protec�on against harmful interference in a residen�al installa�on. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruc�ons, may cause harmful interference to radio communica�ons. However, there is no guarantee that interference will not occur in a par�cular installa�on. If this equipment does cause harmful interference to radio or television recep�on, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna.

Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS1220513-20237E-RF Page 1 of 4 External Photos Z7 Z6 Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS1220513-20237E-RF Page 2 of 4 Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS1220513-20237E-RF Page 3 of 4 Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS1220513-20237E-RF Page 4 of 4

2 IN 1 MAGNETIC WIRELESS CHARGING STAND Model:Z7 Input Port: Type-C Input: 9V/2A or 12V/3A Magnetic Wireless Charging (phone): 15W (MAX) Desktop Wireless Charging (phone): 15W (MAX) Headphone Wireless Charging: 3W (MAX) FCC CE ROHS Made In ChinaFCC ID:2A573-Z67 2 IN 1 MAGNETIC WIRELESS CHARGING STAND Model:Z7 Input Port: Type-C Input: 9V/2A or 12V/3A Magnetic Wireless Charging (phone): 15W (MAX) Desktop Wireless Charging (phone): 15W (MAX) Headphone Wireless Charging: 3W (MAX) FCC CE ROHS Made In ChinaFCC ID:2A573-Z67

Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS1220513-20237E-RF Page 1 of 4 Internal photos Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS1220513-20237E-RF Page 2 of 4 Coil 1 Coil 2 Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS1220513-20237E-RF Page 3 of 4 Shenzhen Accurate Technology Co., Ltd. Project No.: SZNS1220513-20237E-RF Page 4 of 4

Shenzhen Accurate Technology Co., Ltd. Report No.: SZNS1220513-20237E-RF Version 43: 2021-11-09 Page 9 of 26 FCC- WPT FCC §1.1310, §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) Applicable Standard According to subpart §1.1310, systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Maximum Permissible Exposure (MPE) (§1.1310, §2.1091) (B) Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f²) 30 30–300 27.5 0.073 0.2 30 300–1500 / / f/1500 30 1500–100,000 / / 1.0 30 f = frequency in MHz; * = Plane-wave equivalent power density; According with KDB 680106 D01 RF Exposure Wireless Charging Apps v03r01 clause 3 c) According to KDB 680106 D01 RF Exposure Wireless Charging App v03r01 clause 5 b) Shenzhen Accurate Technology Co., Ltd. Report No.: SZNS1220513-20237E-RF Version 43: 2021-11-09 Page 10 of 26 FCC- WPT Block Diagram of Test Setup Note: 20 cm for Top test. Test Data Environmental Conditions Temperature: 23 C Relative Humidity: 51 % ATM Pressure: 101.1 kPa The testing was performed by Nick Fang on 2022-05-19. Test Mode: Wireless Charging (Worst case) H-Field Strength Frequency Range (kHz) Position A (A/m) Position B (A/m) Position C (A/m) Position D (A/m) Position E (A/m) 50% Limit (A/m) Limit (A/m) 110-205 0.371 0.369 0.384 0.389 0.404 0.815 1.63 15cm Shenzhen Accurate Technology Co., Ltd. Report No.: SZNS1220513-20237E-RF Version 43: 2021-11-09 Page 11 of 26 FCC- WPT E-Field Strength Frequency Range (kHz) Position A (V/m) Position B (V/m) Position C (V/m) Position D (V/m) Position E (V/m) 50% Limit (V/m) Limit (V/m) 110-205 4.732 4.726 4.747 4.751 5.243 307 614 Note: Test with 15cm distance from the center of the probe(s) to the edge of the device, 20cm from the center of the probe(s) to the top of the device. Result: Pass Considerations of compliance 680106 D01 RF Exposure Wireless Charging App v03r01 clause 5 b: (1) Power transfer frequency is less than 1 MHz. Yes, the operation frequency is 110-205 kHz. (2) Output power from each primary coil is less than or equal to 15 watts. Yes, the maximum output power of primary coil is 15watts. (3) The system may consist of more than one source primary coils, charging one or more clients. If more than one primary coil is present, the coil pairs may be powered on at the same time. The transfer system includes two coils, the coils pairs can be powered on at the same time. (4) Client device is placed directly in contact with the transmitter. Yes, client device is placed directly in contact with the transmitter (5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). Yes, mobile exposure conditions only (6) The aggregate H-field strengths anywhere at or beyond 15 cm surrounding the device, and 20 cm away from the surface from all coils that by design can simultaneously transmit, and while those coils are simultaneously energized, are demonstrated to be less than 50% of the applicable MPE limit. Yes, the test result for H and E-Field strength less than 50% of the MPE limit. 1. Wireless charging area which has two charging coils. 2. Note: The two wireless charging areas are independent. The coils and clients are able to detect and coupling only between individual pairs of coils. Coil 1 Coil2

Note: This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “★”. Shenzhen Accurate Technology Co., Ltd. is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with an asterisk ’*’. Customer model name, addresses, names, trademarks etc. are not considered data. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. Shenzhen Accurate Technology Co., Ltd. 1/F., Building A, Changyuan New Material Port, Science & Industry Park, Nanshan District, Shenzhen, Guangdong, P.R. China Tel: +86 755-26503290 Fax: +86 755-26503396 Web: www.atc-lab.com Version 43: 2021-11-09 Page 1 of 26 FCC- WPT TEST REPORT Applicant Name : Shenzhen Xiaojiu Technology Co., Ltd Address : 6 Floor, C Building, Huamingcheng High-Tech Park, Matian Street, Guangming District, Shenzhen , China Report Number : SZNS1220513-20237E-RF FCC ID: 2A573-Z67 Test Standard (s) FCC Part 15C Sample Description Product Type: 2 IN 1 MAGNETIC WIRELESS CHARGER Model No.: Z7 Multiple Model(s) No.: Z6 Date Received: 2022-05-13 Date of Test: 2022-05-18 to 2022-05-19 Report Date: 2022-05-20 Test Result: Pass* * In the configuration tested, the EUT complied with the standards above. Prepared and Checked By: Approved By: Black Ding Robert Li EMC Engineer EMC Engineer Shenzhen Accurate Technology Co., Ltd. Report No.: SZNS1220513-20237E-RF Version 43: 2021-11-09 Page 2 of 26 FCC- WPT TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 3 OBJECTIVE ................................................................................................................................................................... 3 TEST METHODOLOGY .................................................................................................................................................. 3 MEASUREMENT UNCERTAINTY .................................................................................................................................... 3 TEST FACILITY ............................................................................................................................................................. 4 SYSTEM TEST CONFIGURATION .......................................................................................................................... 5 JUSTIFICATION ............................................................................................................................................................. 5 EUT EXERCISE SOFTWARE .......................................................................................................................................... 5 LOCAL SUPPORT EQUIPMENT ....................................................................................................................................... 5 EXTERNAL I/O CABLE.................................................................................................................................................. 5 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 6 SUMMARY OF TEST RESULTS ............................................................................................................................... 7 TEST EQUIPMENT LIST ........................................................................................................................................... 8 FCC §1.1310, §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) ............................................................. 9 APPLICABLE STANDARD .............................................................................................................................................. 9 BLOCK DIAGRAM OF TEST SETUP .............................................................................................................................. 10 TEST DATA ................................................................................................................................................................ 10 FCC§15.203 – ANTENNA REQUIREMENT ........................................................................................................... 12 APPLICABLE STANDARD ............................................................................................................................................ 12 ANTENNA CONNECTED CONSTRUCTION .................................................................................................................... 12 FCC §15.207 – AC LINE CONDUCTED EMISSION ............................................................................................. 13 APPLICABLE STANDARD ............................................................................................................................................ 13 EUT SETUP ................................................................................................................................................................ 13 EMI TEST RECEIVER SETUP ....................................................................................................................................... 13 TEST PROCEDURE ...................................................................................................................................................... 13 CORRECTED FACTOR & MARGIN CALCULATION ...........…
