2A578-T33CAR FM TRANSMITTER

T33 Owner’s Manual Features: • Please read this manual carefully before using • Keep these instructions • Do not disassemble • Do not expose directly to sunlight or open flame • Pay attention to the road and do not operate this product while driving 2. Open the Bluetooth app on your phone, turn on the Bluetooth function, search for available devices, and connect to the Bluetooth receiver named "T33" 3.Turn on your Car Radio and check that it is FM mode. Tune to a vacant (unoccupied) frequency. 4.On your FM transmitter, press and hold multi-function button until the frequency display flashes. 5.When the display is flashing,press or button to exactly the same frequency as on your car radio. • Input 12-24V • Bluetooth V5.3 • Bluetooth hands free calling • Streaming music from smart phone to car audio system • FM transmitter frequency : 88.1-107.9 MHz via FM transmitter • USB-A5V/2.4A • USB-C1: PD65W • USB-C2: PD65W; 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3.25A • USB-C1+USB-C2 shared power: 15W(Max) • Support USB flash drive playing • Car battery voltage monitor Safety Instructions Introduction If you receive a call to your Smartphone whilst using the FM transmitter, it will switch to call mode automatically and your caller will be heard on your Car Stereo system. T33 Bluetooth FM Transmitter has one USB-A port, one USB-C1 port and one USB-C2 charging cable.(USB-A: 5V/2.4A, USB-C1: PD65W, USB-C2: PD65W, USB-C1+USB-C2 shared output: 5V/3A) Note: The manufacturer reserves the right to make changes to the design and/or specifications of the device without prior notice. FCC Warning 15.19 Labeling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 15.21 Information to user. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.105 Information to the user. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. FCC RF Radiation Exposure Statement: 1.This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 2.This equipment complies with RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. • DC Input: 12-24V • Power output: USB-C1: PD65W USB-C2: PD65W USB-C1 + USB-C2 shared output: 5V/3A • Bluetooth V5.3 • Effective Bluetooth distance: < 8m • Bluetooth frequency: 2.4GHz • FM transmitting distance: ≤5m • USB capacity support:≤64GB • Working temperature range: -20°C to 40°C • Storage temperature range: -40°C to 75°C Play music from your Smartphone After steps 1-5 above, you can play music from your smartphone through your car’s audio system. Play music from USB flash drive Plug USB flash drive into the USB port with izcon , the transmitter will recognize and start to play music. Hands-Free Call Charge Your Device Specifcations Play Music LED display USB-A: 5V/2.4A &USB flash drive Multi-function button USB-C1: PD65W Microphone Cable: 90cm USB-C2: PD65W Answer/End a call Reject an incoming callPress and hold Quickly press twice Press Previous Track / Volume - Play/Pause Switch play mode LED light control Previous Track / Volume + Press / Press and hold Press / Press and hold Press and hold for 5 sec Press 3 times. Press 1. Insert the device into the car cigarette lighter Get it Ready for Playing < Se�ng Bluetooth Wireless < Se�ng Bluetooth Wireless Now discoverable as “iPhone” DEVICES T33
