2A59J-DLSK162Handset

Changzhou Dengfeng Electronic Co., Ltd. TEL: +86-519-88966138 FAX: +86-519-88969328 Email: [email protected] DL-SK-162 Controller Instruction Manual Rev：A2 1 Technical Specifications: 1.1 Input Voltage：DC29V 2A（Power supply） 1.2 Q’ty of actuator controlled：2pcs 1.3 Button：8pcs. Knob switch：1pc 1.4 Control mode：with cable and control box 1.5 Ambient Temp：-15°C～+40°C 1.6 Relative Humidity：20%～75% 1.7 USB Output：5VDC/2A 1.8 USB TYPE-C Output：5VDC/2A 1.9 Wireless Charge output：9VDC,10W 2 Button function and Operation Instructions 1、1#：on/off switch 2、2#：USB-A Output，DC5V2A。 3、3#：TYPE-C Output，DC5V2A。 4、4#：Footrest open 5、5#：Footrest close 6、6#：Backrest open 7、7#：Backrest close 8、8#：Recline 9、9#：Home Button 10、10#：Child lock button，press for three seconds and indicator turns red, lock and no work for button 4# to 9#; Press three seconds again and indicator turns white to release function for button 4# to 9#. 11、Knob switch 11#： Heating and ventilation knob, when the knob is selected to middle position 12#， indicator lights off, turn off the heating and ventilation function, counterclockwise for ventilation and gradually increase the air Changzhou Dengfeng Electronic Co., Ltd. TEL: +86-519-88966138 FAX: +86-519-88969328 Email: [email protected] DL-SK-162 Controller Instruction Manual Rev：A2 volume, a total of 4 grades. Clockwise direction for heating, and gradually increases heating, a total of 4 grades. 13、13# plug，connect linear actuator 14、14# plug，connect control box 15、15# wireless charging 3 Warning 1) Metal objects cannot be placed on wireless charging 2) No heavy objects can be placed on the wireless charging 3) The mobile phone without wireless charging cannot be charged at the charging place. 4 FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Changzhou Dengfeng Electronic Co., Ltd. TEL: +86-519-88966138 FAX: +86-519-88969328 Email: [email protected] DL-SK-162 Controller Instruction Manual Rev：A2 FCC RF exposure statement: The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance between 20cm the radiator your body.
