2A5CTTYTJWUSH62SL1DH62S Series Smart Switch

正面 背面 规格：490*70mm 1 3 This user manual applies to: Wifi switch ZigBee switch Warning: Make sure power supply totally been cut off for the switch you are replacing. Installation 1.Remove your old switch from junction box 2.As shown in these diagrams below,insert wires into the corresponding terminal holes and fasten them. 3.Take off panel and fix switch with screws to junction box in the wall. For Dimmer switch Neutral switch Smart Switch Manual Dimmer switch N L Dimmerswitch CERTIFICATE：CE,ROHS INPUT：100-240V~50/60HZ OUTPUT：300W/gang Wireless protocoljIEEE：2.4GHz SIZE：70*120*41mm CERTIFICATE：CE,ROHS INPUT：100-240V~50/60HZ OUTPUT：500W/gang Wireless protocoljIEEE：2.4GHz SIZE：70*120*41mm N L 2 4 1.Download Smart Life APP from APPstore and register 2.Preparations before get started For WiFi switch A wifi router is required,the wifi switch only supports 2.4GHz WIFI network. For ZigBee switch A ZigBee gateway is required and this gateway should be successfully configured before adding a zigbee switch 3.Power up the switch,press and hold the button(for about 5 seconds) until the indicator blinking to enter pairing mode,then do the following steps for adding. Add switch to APP Non neutral switch L CERTIFICATE：CE,ROHS INPUT：100-240V~50/60HZ OUTPUT：150W/gang Wireless protocoljIEEE：2.4GHz SIZE：70*120*41mm N L1 Capacitor 6 57 For WiFi switch 1.Open Smart Life APP,tap the icon + on the top right in the homepage. 2.Tap Electrical--Switch(WI-FI), enter into Add Device 3.Choose your local wifi and input wifi password 4.Comfirm the indicator is blinking rapidly.---(Long press any switch button for about 5 seconds then indicator will blinking) 5.Wait for configuring successfully,then tap Cpmplete and edit name 1.Tap +>>Electrical>>Switch (ZigBee) into add device 2.Select ZigBee Gateway and follow the prompts 3.Wait for configuring successfully,then tap Complete For ZigBee switch 1 3 2 This user manual applies to: Wifi switch ZigBee switch Warning: Make sure power supply totally been cut off for the switch you are replacing. Installation 1.Remove your old switch from junction box 2.As shown in these diagrams below,insert wires into the corresponding terminal holes and fasten them. 3.Take off panel and fix switch with screws to junction box in the wall. For Dimmer switch For 1 gang switch 6 57 For WiFi switch 1.Open Smart Life APP,tap the icon + on the top right in the homepage. 2.Tap Electrical--Switch(WI-FI), enter into Add Device 3.Choose your local wifi and input wifi password 4.Comfirm the indicator is blinking rapidly.---(Long press any switch button for about 5 seconds then indicator will blinking) 5.Wait for configuring successfully,then tap Cpmplete and edit name 1.Tap +>>Electrical>>Switch (ZigBee) into add device 2.Select ZigBee Gateway and follow the prompts 3.Wait for configuring successfully,then tap Complete For ZigBee switch Smart Switch Manual Dimmer switch NL L1 GND 1 gang switch N L L1 GND 1 gang 2 way switch N L1 GND L L2 1 gang 2 way switch N L1 GND L2 4 1.Download Smart Life APP from APPstore and register 2.Preparations before get started For WiFi switch A wifi router is required,the wifi switch only supports 2.4GHz WIFI network. For ZigBee switch A ZigBee gateway is required and this gateway should be successfully configured before adding a zigbee switch 3.Power up the switch,press and hold the button(for about 5 seconds) until the indicator blinking to enter pairing mode,then do the following steps for adding. Add switch to APP For 1 gang 2 way switch Dimmerswitch Model：TY-TJ-WUSH62S-T1D CERTIFICATE：CE,ROHS INPUT：100-240V~50/60HZ OUTPUT：300W Wireless protocoljIEEE： 802.11 b/g/n,2.4GHz SIZE：70*120*41mm 1 switch ModelTY-TJ-WUSH62S-L1D CERTIFICATE：CE,ROHS INPUT：100-240V~50/60HZ OUTPUT：1000W/gang Wireless protocoljIEEE： 802.11 b/g/n,2.4GHz SIZE：70*120*41mm gang ： 1 Smart Switch Manual Smart Switch Manual H62S Series Smart Switch FCC Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. Radiation Exposure Statement To comply with FCC RF exposure compliance requirements, this grant is applicable to only mobile configurations. The antennas used for this transmitter must be installed to provide a separation di stance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.

Shenzhen Tianqiao Science & Technology Co.,Ltd Add: 1st floor, a1, Mingjun Industrial Park, Longrong Road, Dalang Street Community, Longhua New District, Shenzhen, China Date: 2022-4-16 FCC ID: 2A5CTTYTJWUSH62SL1D Dear Sir/Madam, We, Shenzhen Tianqiao Science & Technology Co.,Ltd Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: H62S Series Smart Switch Model no.: TY-TJ-WUSH62S-L1D, TY-TJ-WUSH62S-D1D, TY-TJ-WUSH62S-T1D Sincerely, Name/Title： Xun Zhu/Director Company: Shenzhen Tianqiao Science & Technology Co.,Ltd Address: 1st floor, a1, Mingjun Industrial Park, Longrong Road, Dalang Street Community, Longhua New District, Shenzhen, China Phone: 0755-21005501 Fax: 0755-21005501 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2022-4-16> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2A5CTTYTJWUSH62SL1D TY-TJ-WUSH62S-L1D For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Xun Zhu/Director Company: Shenzhen Tianqiao Science & Technology Co.,Ltd Address: 1st floor, a1, Mingjun Industrial Park, Longrong Road, Dalang Street Community, Longhua New District, Shenzhen, China Phone: 0755-21005501 Fax: 0755-21005501 E-Mail: [email protected]

Shenzhen Tianqiao Science & Technology Co.,Ltd 1st floor, a1, Mingjun Industrial Park, Longrong Road, Dalang Street Community, Longhua New District, Shenzhen, China Date: 2022-4-16 FCC ID: 2A5CTTYTJWUSH62SL1D Model Number: TY-TJ-WUSH62S-L1D To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, Shenzhen Tianqiao Science & Technology Co.,Ltd, declare that this EUT (FCC ID: 2A5CTTYTJWUSH62SL1D) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name/Title： Xun Zhu/Director Company: Shenzhen Tianqiao Science & Technology Co.,Ltd Address: 1st floor, a1, Mingjun Industrial Park, Longrong Road, Dalang Street Community, Longhua New District, Shenzhen, China Phone: 0755-21005501 Fax: 0755-21005501 E-Mail: [email protected]

Shenzhen Tianqiao Science & Technology Co.,Ltd 1st floor, a1, Mingjun Industrial Park, Longrong Road, Dalang Street Community, Longhua New District, Shenzhen, China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2022-4-16 To whom it may concern: We, Shenzhen Tianqiao Science & Technology Co.,Ltd the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2A5CTTYTJWUSH62SL1D including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Xun Zhu/Director Company: Shenzhen Tianqiao Science & Technology Co.,Ltd Address: 1st floor, a1, Mingjun Industrial Park, Longrong Road, Dalang Street Community, Longhua New District, Shenzhen, China Phone: 0755-21005501 Fax: 0755-21005501 E-Mail: [email protected]

Page 1 of 4 FCC ID: 2A5CTTYTJWUSH62SL1D Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity External Photos of the EUT Fig. 1 Fig. 2 Page 2 of 4 FCC ID: 2A5CTTYTJWUSH62SL1D Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 4 FCC ID: 2A5CTTYTJWUSH62SL1D Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Page 4 of 4 FCC ID: 2A5CTTYTJWUSH62SL1D Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7

Page 1 of 1 FCC ID: 2A5CTTYTJWUSH62SL1D Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity LABEL AND LOCATION (Size: L3.5cm x 3.0cm) Label Location H62S Series Smart Switch Model: TY-TJ-WUSH62S-L1D FCC ID: 2A5CTTYTJWUSH62SL1D

Page 1 of 3 FCC ID: 2A5CTTYTJWUSH62SL1D Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Internal Photos of the EUT Fig. 1 Fig. 2 Page 2 of 3 FCC ID: 2A5CTTYTJWUSH62SL1D Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 3 FCC ID: 2A5CTTYTJWUSH62SL1D Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Antenna

Page 1 of 4 FCC ID: 2A5CTTYTJWUSH62SL1D Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC RF Exposure Evaluation 1. Product Information FCC ID 2A5CTTYTJWUSH62SL1D Product name H62S Series Smart Switch Model number TY-TJ-WUSH62S-L1D Additional Model TY-TJ-WUSH62S-D1D, TY-TJ-WUSH62S-T1D Model Declaration PCB board, structure and internal of these model(s) are the same, So no additional models were tested Power supply Input: AC 110-220V, 50Hz Output: 10A max Hardware version / Software version / FCC Operation frequency 2412~2462 MHz Channel Number 11 Channels for 20MHz bandwidth (2412~2462MHz) 7 Channels for 40MHz bandwidth (2422~2452MHz) Modulation Type IEEE 802.11b: DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n: OFDM (64QAM, 16QAM,QPSK,BPSK) Antenna Type PCB Antenna Antenna Gain 0dBi(Max.) Exposure category General population/uncontrolled environment EUT Type Production Unit Device Type Mobile Devices Page 2 of 4 FCC ID: 2A5CTTYTJWUSH62SL1D Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2. Evaluation Method Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modelled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. 3. Limit 3. 1 Refer Evaluation Method ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB publication 447498 D01 General 1 RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices 3. 2 Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density Page 3 of 4 FCC ID: 2A5CTTYTJWUSH62SL1D Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 4. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 5. Antenna Information EUT can only use antennas certificated as follows provided by manufacturer; Internal Identification Antenna type and antenna number Operate frequency band Maximum antenna gain Note Antenna PCB Antenna 2400MHz-2500MHz 0dBi WIFI Antenna 6. Conducted Power <2.4G WIFI> Mode Channel Frequency(MHz) Max Conducted Power (dBm) IEEE 802.11b 1 2412 17.04 6 2437 17.09 11 2462 16.81 IEEE 802.11g 1 2412 17.12 6 2437 17.22 11 2462 16.6 IEEE 802.11n HT20 1 2412 17.11 6 2437 17.08 11 2462 16.71 IEEE 802.11n HT40 3 2422 17.23 6 2437 17.58 9 2452 16.05 Page 4 of 4 FCC ID: 2A5CTTYTJWUSH62SL1D Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 7. Manufacturing Tolerance <2.4G WIFI> 11B (Peak) C…

Text truncated - open the document above for the full version.

Page 1 of 55 FCC ID: 2A5CTTYTJWUSH62SL1D Report No.: LCS220228014AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix A RF Test Data for 2.4GWIFI (Conducted Measurement) Product Name: H62S Series Smart Switch Test Model: TY-TJ-WUSH62S-L1D Environmental Conditions Temperature: 23.5  C Relative Humidity: 52.2% ATM Pressure: 100.0 kPa Test Engineer: Kay Hu Supervised by: Li huan Page 2 of 55 FCC ID: 2A5CTTYTJWUSH62SL1D Report No.: LCS220228014AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.1 -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT b 2412 Ant1 9.593 0.5 Pass NVNT b 2437 Ant1 9.588 0.5 Pass NVNT b 2462 Ant1 9.621 0.5 Pass NVNT g 2412 Ant1 16.176 0.5 Pass NVNT g 2437 Ant1 16.043 0.5 Pass NVNT g 2462 Ant1 16.137 0.5 Pass NVNT n20 2412 Ant1 17.366 0.5 Pass NVNT n20 2437 Ant1 17.392 0.5 Pass NVNT n20 2462 Ant1 17.208 0.5 Pass NVNT n40 2422 Ant1 35.819 0.5 Pass NVNT n40 2437 Ant1 34.234 0.5 Pass NVNT n40 2452 Ant1 35.528 0.5 Pass Page 3 of 55 FCC ID: 2A5CTTYTJWUSH62SL1D Report No.: LCS220228014AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs -6dB Bandwidth NVNT b 2412MHz Ant1 -6dB Bandwidth NVNT b 2437MHz Ant1 Page 4 of 55 FCC ID: 2A5CTTYTJWUSH62SL1D Report No.: LCS220228014AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity -6dB Bandwidth NVNT b 2462MHz Ant1 -6dB Bandwidth NVNT g 2412MHz Ant1 Page 5 of 55 FCC ID: 2A5CTTYTJWUSH62SL1D Report No.: LCS220228014AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity -6dB Bandwidth NVNT g 2437MHz Ant1 -6dB Bandwidth NVNT g 2462MHz Ant1 Page 6 of 55 FCC ID: 2A5CTTYTJWUSH62SL1D Report No.: LCS220228014AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity -6dB Bandwidth NVNT n20 2412MHz Ant1 -6dB Bandwidth NVNT n20 2437MHz Ant1 Page 7 of 55 FCC ID: 2A5CTTYTJWUSH62SL1D Report No.: LCS220228014AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity -6dB Bandwidth NVNT n20 2462MHz Ant1 -6dB Bandwidth NVNT n40 2422MHz Ant1 Page 8 of 55 FCC ID: 2A5CTTYTJWUSH62SL1D Report No.: LCS220228014AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity -6dB Bandwidth NVNT n40 2437MHz Ant1 -6dB Bandwidth NVNT n40 2452MHz Ant1 Page 9 of 55 FCC ID: 2A5CTTYTJWUSH62SL1D Report No.: LCS220228014AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.2 Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Limit (dBm) Verdict NVNT b 2412 Ant1 17.04 30 Pass NVNT b 2437 Ant1 17.09 30 Pass NVNT b 2462 Ant1 16.81 30 Pass NVNT g 2412 Ant1 17.12 30 Pass NVNT g 2437 Ant1 17.22 30 Pass NVNT g 2462 Ant1 16.6 30 Pass NVNT n20 2412 Ant1 17.11 30 Pass NVNT n20 2437 Ant1 17.08 30 Pass NVNT n20 2462 Ant1 16.71 30 Pass NVNT n40 2422 Ant1 17.23 30 Pass NVNT n40 2437 Ant1 17.58 30 Pass NVNT n40 2452 Ant1 16.05 30 Pass Page 10 of 55 FCC ID: 2A5CTTYTJWUSH62SL1D Report No.: LCS220228014AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.3 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Conducted PSD (dBm/3kHz) Limit (dBm/3kHz) Verdict NVNT b 2412 Ant1 -13.06 8 Pass NVNT b 2437 Ant1 -12.92 8 Pass NVNT b 2462 Ant1 -13.29 8 Pass NVNT g 2412 Ant1 -14.56 8 Pass NVNT g 2437 Ant1 -14.41 8 Pass NVNT g 2462 Ant1 -14.72 8 Pass NVNT n20 2412 Ant1 -14.89 8 Pass NVNT n20 2437 Ant1 -14.65 8 Pass NVNT n20 2462 Ant1 -14.56 8 Pass NVNT n40 2422 Ant1 -16.91 8 Pass NVNT n40 2437 Ant1 -15.48 8 Pass NVNT n40 2452 Ant1 -17.27 8 Pass Page 11 of 55 FCC ID: 2A5CTTYTJWUSH62SL1D Report No.: LCS220228014AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji In…

Text truncated - open the document above for the full version.

Page 1 of 35 FCC ID: 2A5CTTYTJWUSH62SL1D Report No.: LCS220228014AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT For Shenzhen Tianqiao Science & Technology Co.,Ltd H62S Series Smart Switch Test Model: TY-TJ-WUSH62S-L1D Additional Model No.: Please Refer to Page 6 Prepared for : Shenzhen Tianqiao Science & Technology Co.,Ltd Address : 1st floor, a1, Mingjun Industrial Park, Longrong Road, Dalang Street Community, Longhua New District, Shenzhen, China Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel : (+86)755-82591330 Fax : (+86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : March 04, 2022 Number of tested samples : 2 Sample number : 220228014A-1, 220228014A-2 Serial number : Prototype Date of Test : March 04, 2022 ~ March 22, 2022 Date of Report : March 23, 2022 Page 2 of 35 FCC ID: 2A5CTTYTJWUSH62SL1D Report No.: LCS220228014AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT FCC CFR 47 PART 15 C(15.247) Report Reference No. ................. : LCS220228014AEA Date of Issue .................................. : March 23, 2022 Testing Laboratory Name ............ : Shenzhen LCS Compliance Testing Laboratory Ltd. Address .......................................... : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Testing Location/ Procedure .......... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name ......................... : Shenzhen Tianqiao Science & Technology Co.,Ltd Address .......................................... : 1st floor, a1, Mingjun Industrial Park, Longrong Road, Dalang Street Community, Longhua New District, Shenzhen, China Test Specification Standard ......................................... : FCC CFR 47 PART 15 C(15.247) Test Report Form No.................... : LCSEMC-1.0 TRF Originator ............................... : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF .................................... : Dated 2011-03 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Shenzhen LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. EUT Description. .......................... : H62S Series Smart Switch Trade Mark ..................................... : N/A Test Model ..................................... : TY-TJ-WUSH62S-L1D Ratings ........................................... : Input: AC 110-220V, 50Hz Output: 10A max Result ........................................... : Positive Compiled by: Supervised by: Approved by: Jin Wang/ Administrator Cary Luo/ Technique principal Gavin Liang/ Manager Page 3 of 35 FCC ID: 2A5CTTYTJWUSH62SL1D Report No.: LCS220228014AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC -- TEST REPORT EUT......................................... : H62S Series Smart Switch Test Model............................... : TY-TJ-WUSH62S-L1D Applicant............................... : Shenzhen Tianqiao Science & Technology Co.,Ltd Address.................................. : 1st floor, a1, Mingjun Industrial Park, Longrong Road, Dalang Street Community, Longhua New District, Shenzhen, China Telephone............................... : / Fax................................…
