2A5EQ-2605HS1Head-mounted triple-mode gaming headset

GAMING HEADSET User Manual Customize Your Style, Decorate the Side Covers CONTENTS QUICK START GUIDE PRODUCT LAYOUT SPECIFICATION PRODUCT STORAGE & BATTERY SAFETY FCC CAUTION ------------------1 -------------------3 ---------------------4 ------4 ----------------------5 1. Power On/Off QUICK START GUIDE 1 2. Button Functions Microphone Button ● Click: Mic on/off ● Double click: Switch sound effect mode ● Triple click: Switch connection mode ● Hold 3s: Clear BT pairing Power Button ● Hold 3s: Power on/off ● Click: Play/Pause/Answer/Hang up ● Hold 2s: Reject call ● Double click: Previous track ● Triple click: Next track Volume Wheel ● Scroll up: Volume up ● Scroll down: Volume down Microphone Switch Power Button Volume Button Long-press the Power Button for 3 seconds. 4. Charging 2 3. Connect Your Device Wired Mode ● Turn off the headset. ● Plug in the cable. ● Wired mode starts automatically. 3.5mm to Type-C cable 2.4G Mode ● Turn on the headset. ● Plug in the USB dongle. (Name: SS202) ● Pairing starts automatically. LED: Blue on receiver / White on headset “SS202” BT Mode ● Turn on the headset. ● Triple-press the Microphone Button. ● Search for "SS202" in your device's Bluetooth settings and tap to pair. Connect the USB Type-C cable, and the LED turns red during charging. The LED turns off when fully charged. Note: The headset can still be used while charging in 2.4G/BT mode. PRODUCT LAYOUT 3 Removable Decorative Cover 1 2 3 4 8 5 Headband Pad Ear Cup Ear Pad Microphone 6 7 Headband Microphone Switch Power Button Volume Button 1 2 3 4 8 5 6 7 Storage ● Store in a clean, dry place (–5°C to 35°C). ● For long-term storage, charge the headset every 3 months to protect battery life. Battery Safety ● Do not expose to fire, extreme heat, or liquids. ● Never disassemble, crush, or modify the battery. Custom Cover Care ● The decorative cover features a printed design. ● Clean only with a dry or slightly damp soft cloth. ● Do not use alcohol, solvents, or abrasive cleaners—they may damage the print. Rated Input Power Maximum Input Power Speaker Diameter Speaker Impedance Headphone Sensitivity Frequency Response Microphone Sensitivity Microphone Frequency Response Battery Capacity Headphone Lighting Effect Product Dimensions 32±10%Ω 30 mW 100 mW 50 mm 100±3 dB 1000 mAh RGB 20 Hz-20 KHz -40±3 dB 100~10 KHz 187*92*193 mm SPECIFICATION PRODUCT STORAGE & BATTERY SAFETY 4 Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ● Consult the dealer or an experienced radio/TV technician for help. * RF warning for Portable device: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC CAUTION 5

LTCNetworkingLimited CoveredEquipmentCertificationAttestationLetter 6/29/2026 NemkoNorthAmerica,Inc. 303RiverRoad Ottawa K1V1H2 Canada ATTN.:ReviewingEngineer FCCID:2A5EQ-2605HS1 LTCNetworkingLimited(“theapplicant”)certifiesthattheequipmentforwhich authorizationissoughtisnot“covered”equipmentprohibitedfromreceivingan equipmentauthorizationpursuanttosection2.903oftheFCCrules. Note:Iftheequipmentforwhichtheapplicantseeksauthorizationisproducedby anyoftheentitiesidentifiedonthecurrentCoveredList,theapplicantshould includeanexplanationonwhytheequipmentisnot“covered”equipment. LTCNetworkingLimited(“theapplicant”)certifiesthat,asofthedateofthefilingofthe application,theapplicantisnotidentifiedontheCoveredListasanentityproducing “covered”equipment. LTCNetworkingLimited(“theapplicant”)certifiesthattheequipmentforwhich authorizationissoughtdoesnotincludecybersecurityoranti-virussoftwareproducedor providedbyKasperskyLab,Inc.oranyofitssuccessorsandassignees,including equipmentwithintegratedKasperskyLab,Inc.(oranyofitssuccessorsandassignees) cybersecurityoranti-virussoftwarepursuanttoDA-24-886andKDB986446D01 CoveredEquipmentGuidancesectionB(2a). Signed: Printedname:HaroldLin Title:productmanager CompanyName:LTCNetworkingLimited Date:6/29/2026

LTCNetworkingLimited 6/29/2026 NemkoNorthAmerica,Inc. 303RiverRoad Ottawa,Ontario,Canada K1V1H2 REQUESTFORCONFIDENTIALITY-FCC FCCID:2A5EQ-2605HS1 PursuanttoSections0.457(d)(1)(ii)and0.459oftheCommission’sRulesandFCCGuidance document726920,weherebyrequestconfidentialtreatmentofinformationaccompanyingthis applicationasoutlinedbelow: PERMANENTLONG-TERMCONFIDENTIALITY: Schematics BlockDiagrams TheoryofOperation Theaboveinformationcontainstradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.Thepublicdisclosureofthisinformationmightbeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors.TheApplicantunderstandsthatpursuanttoRule 0.457(d)(1)(ii),disclosureofthisApplicationandallaccompanyingmaterialswillnotbemadebefore thedateoftheGrantforthisApplication. Sincerely, Signed: Printedname:HaroldLin Title:productmanager

FCCID:2A5EQ-2605HS1 FCCID:2A5EQ-2605HS1 FCCID:2A5EQ-2605HS1 FCCID:2A5EQ-2605HS1

LabelandLabelLocation

FCCID:2A5EQ-2605HS1 FCCID:2A5EQ-2605HS1 FCCID:2A5EQ-2605HS1 FCCID:2A5EQ-2605HS1

Page1of2 RFEXPOSUREEVALUATION FCCID:2A5EQ-2605HS1 ProductName:Head-mountedtriple-modegamingheadset ModelName:SS202 Specification:BT5.3BDR+EDR OperationFrequency:2402-2480MHz NumberofChannel:79channelsforBDR+EDR TypeofModulation:GFSK,Π/4-DQPSK,8DPSKForDSS Antennainstallation: AntennaGai Chip antenna n:2.5dBi RatedPowerSupply: Input:DC5V1A Battery: Li-ionBattery:523450 RatedVoltage:3.7V RatedCapacity:1000mAh HardwareVersion:V1.0 SoftwareVersion:V1 Page2of2 StandardRequirement Accordingto§15.247(i)and§1.1307b(1),systemsoperatingundertheprovisionsofthis sectionshallbeoperatedinamannerthatensuresthatthepublicisnotexposedtoradio frequencyenergylevelsinexcessoftheCommission’sguidelines.SeeKDB447498D01 GeneralRFExposureGuidancev06,section4.3.1. The1-gand10-gSARtestexclusionthresholdsfor100MHzto6GHzattestseparation distances≤50mmaredeterminedby: [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparationdistance, mm)]*[√f(GHz)]≤3.0for1-gSARand≤7.5for10-gSARextremitySAR,where f(GHz)istheRFchanneltransmitfrequencyinGHz PoweranddistanceareroundedtothenearestmWandmmbeforecalculation Theresultisroundedtoonedecimalplaceforcomparison. Thetestexclusionsareapplicableonlywhentheminimumtestseparationdistanceis≤ 50mmandfortransmissionfrequenciesbetween100MHzand6GHz.Whentheminimumtest separationdistanceis<5mm,adistanceof5mmisappliedtodetermineSARtestexclusion. RoutineSARevaluationreferstothatspecificallyrequiredby§2.1093,usingmeasurements orcomputersimulation.WhenroutineSARevaluationisnotrequired,portabletransmitters withoutputpowergreaterthantheapplicablelowthresholdrequireSARevaluationtoquality forTCBapproval. Channel (MHz) Maximum output power (dBm) Tuneup tolerance (dBm) MaxTune UpPower (mW) Distance (mm) Calculation results Limit Operating Mode 24804.37 4.37±1 3.44349951.08456633DH5 AccordingtoKDB447498,ThedeviceonlysupportBTfunction,andnosimultaneousSAR measurementisrequired. Signature SimonPu Manager Date:2026-06-28

ReportNo.:PTC26052217801E-FC01 Page 52 of 88 3DH1-Ant1-Hop-PASS DH3-Ant1-Hop-PASS ReportNo.:PTC26052217801E-FC01 Page 53 of 88 2DH3-Ant1-Hop-PASS 3DH3-Ant1-Hop-PASS ReportNo.:PTC26052217801E-FC01 Page 54 of 88 ReportNo.:PTC26052217801E-FC01 Page 55 of 88 13100kHzBandwidthofFrequencyBandEdgeRequirement 13.1TestStandardandLimit TestStandard FCCPart15CSection15.247(d) TestLimit inany100kHzbandwidthoutsidethefrequencybandsinwhichthe spreadspectrumintentionalradiatorinoperating,theradiofrequency powerthatisproducedbytheintentionalradiatorshallbeatleast20dB belowthatinthe100kHzbandwidthwithinthebandthatcontainsthe highestlevelofthedesiredpower,Inaddition,radiatedemissionswhich fallintherestrictedbands,asdefinedin§15.205(a),mustalsocomply withtheradiatedemissionlimitsspecifiedin15.209(a). 13.2TestSetup 13.3TestProcedure TheEUTmusthaveitshopping/Non-hoppingfunctionenabled.Usingthefollowingspectrum analyzersetting: 1.SettheRBW=100kHz. 2.SettheVBW=300kHz. 3.Sweeptime=autocouple. 4.Detectorfunction=peak. 5.Tracemode=maxhold. 6.Allowtracetofullystabilize. ReportNo.:PTC26052217801E-FC01 Page 56 of 88 13.4TestData TestModeAntennaChNameFrequency[MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5Ant1Low24022.11-39.61≤-17.9PASS DH5Ant1High24803.04-41.81≤-16.96PASS DH5Ant1LowHop_24021.02-41.62≤-18.98PASS DH5Ant1HighHop_24802.91-41.69≤-17.09PASS 2DH5Ant1Low24021.70-40.95≤-18.3PASS 2DH5Ant1High24803.02-42.11≤-16.98PASS 2DH5Ant1LowHop_2402-2.43-43.03≤-22.43PASS 2DH5Ant1HighHop_24802.09-41.93≤-17.91PASS 3DH5Ant1Low24022.05-38.69≤-17.95PASS 3DH5Ant1High24802.99-42.39≤-17.01PASS 3DH5Ant1LowHop_2402-0.75-42.57≤-20.75PASS 3DH5Ant1HighHop_24800.43-42.05≤-19.57PASS TestItem:BandedgeTestMode:CHLow~CHHigh TestVoltage:3.7VTemperature:24.5°C TestResult:PASSHumidity:55%RH ReportNo.:PTC26052217801E-FC01 Page 57 of 88 TestGraphs: DH5-Ant1-2402-PASS DH5-Ant1-2480-PASS DH5-Ant1-Hop_2402-PASS ReportNo.:PTC26052217801E-FC01 Page 58 of 88 DH5-Ant1-Hop_2480-PASS 2DH5-Ant1-2402-PASS ReportNo.:PTC26052217801E-FC01 Page 59 of 88 2DH5-Ant1-2480-PASS 2DH5-Ant1-Hop_2402-PASS ReportNo.:PTC26052217801E-FC01 Page 60 of 88 2DH5-Ant1-Hop_2480-PASS 3DH5-Ant1-2402-PASS ReportNo.:PTC26052217801E-FC01 Page 61 of 88 3DH5-Ant1-2480-PASS 3DH5-Ant1-Hop_2402-PASS ReportNo.:PTC26052217801E-FC01 Page 62 of 88 3DH5-Ant1-Hop_2480-PASS ReportNo.:PTC26052217801E-FC01 Page 63 of 88 ConductedEmissionMethod TestResult TestModeAntennaFrequency[MHz] FreqRange [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5Ant124020~Reference1.891.89---PASS DH5Ant1240230~10001.89-55.37≤-18.11PASS DH5Ant124021000~265001.89-35.57≤-18.11PASS DH5Ant124410~Reference2.702.70---PASS DH5Ant1244130~10002.70-54.95≤-17.3PASS DH5Ant124411000~265002.70-38.96≤-17.3PASS DH5Ant124800~Reference2.892.89---PASS DH5Ant1248030~10002.89-54.47≤-17.11PASS DH5Ant124801000~265002.89-40.05≤-17.11PASS 2DH5Ant124020~Reference1.861.86---PASS 2DH5Ant1240230~10001.86-54.22≤-18.14PASS 2DH5Ant124021000~265001.86-35.63≤-18.14PASS 2DH5Ant124410~Reference2.782.78---PASS 2DH5Ant1244130~10002.78-55.33≤-17.22PASS 2DH5Ant124411000~265002.78-38.97≤-17.22PASS 2DH5Ant124800~Reference2.962.96---PASS 2DH5Ant1248030~10002.96-54.77≤-17.04PASS 2DH5Ant124801000~265002.96-40.02≤-17.04PASS 3DH5Ant124020~Reference1.891.89---PASS 3DH5Ant1240230~10001.89-54.81≤-18.11PASS 3DH5Ant124021000~265001.89-35.51≤-18.11PASS 3DH5Ant124410~Reference2.642.64---PASS 3DH5Ant1244130~10002.64-54.8≤-17.36PASS 3DH5Ant124411000~265002.64-39.05≤-17.36PASS 3DH5Ant124800~Reference2.762.76---PASS 3DH5Ant1248030~10002.76-54.46≤-17.24PASS 3DH5Ant124801000~265002.76-39.79≤-17.24PASS ReportNo.:PTC26052217801E-FC01 Page 64 of 88 TestGraphs: DH5-Ant1-2402-0~Reference-PASS DH5-Ant1-2402-30~1000-PASS DH5-Ant1-2402-1000~26500-PASS ReportNo.:PTC26052217801E-FC01 Page 65 of 88 DH5-Ant1-2441-0~Reference-PASS DH5-Ant1-2441-30~1000-PASS ReportNo.:PTC26052217801E-FC01 Page 66 of 88 DH5-Ant1-2441-1000~26500-PASS DH5-Ant1-2480-0~Reference-PASS ReportNo.:PTC26052217801E-FC01 Page 67 of 88 DH5-Ant1-2480-30~1000-PASS DH5-Ant1-2480-1000~26500-PASS ReportNo.:PTC26052217801E-FC01 Page 68 of 88 2DH5-Ant1-2402-0~Reference-PASS 2DH5-Ant1-2402-30~1000-PASS ReportNo.:PTC26052217801E-FC01 Page 69 of 88 2DH5-Ant1-2402-1000~26500-PASS 2DH5-Ant1-2441-0~Reference-PASS ReportNo.:PTC26052217801E-FC01 Page 70 of 88 2DH5-Ant1-2441-30~1000-PASS 2DH5-Ant1-2441-1000~26500-PASS ReportNo.:PTC26052217801E-FC01 Page 71 of 88 2DH5-Ant1-2480-0~Reference-PASS 2DH5-Ant1-2480-30~1000-PASS ReportNo.:PTC26052217801E-FC01 Page 72 of 88 2DH5-Ant1-2480-1000~26500-PASS 3DH5-Ant1-2402-0~Reference-PASS ReportNo.:PTC26052217801E-FC01 Page 73 of 88 3DH5-Ant1-2402-30~1000-PASS 3DH5-Ant1-2402-1000~26500-PASS ReportNo.:PTC26052217801E-FC01 Page 74 of 88 3DH5-Ant1-2441-0~Reference-PASS 3DH5-Ant1-2441-30~1000-PASS ReportNo.:PTC26052217801E-FC01 Page 75 of 88 3DH5-Ant1-2441-1000~26500-PASS 3DH5-Ant1-2480-0~Reference-PASS ReportNo.:PTC26052217801E-FC01 Page 76 of 88 3DH5-Ant1-2480-30~1000-PASS 3DH5-Ant1-2480-1000~26500-PASS ReportNo.:PTC26052217801E-FC01 Page 77 of 88 ReportNo.:PTC26052217801E-FC01 Page 78 of 88 14AntennaRequirement 14.1TestStandardandRequirement TestStandard FCCPart15Section15.203/247(c) Requirement 1)15.203requirement: Anintentionalradiatorshallbedesignedtoensurethatnoantennaotherthan thatfurnishedbytheresponsiblepartyshallbeusedwiththedevice.The useofapermanentlyattachedantennaorofanantennathatusesaunique couplingtotheintentionalradiator,themanufacturermaydesigntheunitso thatabrokenantennacanbereplacedbytheuser,buttheuseofastandard antennajackorelectricalconnectorisprohibited. 2)15.247(c)(1)(i)requirement: Systemsoperatinginthe2400-2483.5MHzbandthatisusedexclusivelyfor fixed.Point-to-pointoperationsmayemploytransmittingantennaswith directionalgaingreaterthan6dBiprovidedthemaximumconductedoutput poweroftheintentionalradiatorisreducedby1dBforevery3dBthatthe directionalgainoftheantennaexceeds6dBi. 14.2 Antenna Connected Construction The antenna isChip antenna which permanently attached…

Text truncated - open the document above for the full version.

深圳市迎丰天线技术有限公司 SHEN ZHEN YINGFENG ANTENNA TECHNOLOYCO.,LTD Prepared by : harry Designed by : andy Checked by : andy Approved by：oliver TITLE：5.0 x2.0 x 0.6mm) WiFi/Bluetooth Ceramic Chip Antenna (YF500A) Engineering Specification DOCUMENT YF5020H1R2G4502 REV. NO. C PAGE 1 OF 10 5.0 x 2.0 x 0.6 (mm) WiFi/Bluetooth Ceramic Chip Antenna (YF500A) Engineering Specification 1. Product Number 5 4 3 2 1 2G4502R H1 5020 YF 1 2 3 4 5 Address: Room 412, Building 7, Phase II, Yung Valley, No. 2 Pingshan 1st Road, Taoyuan Street, Nanshan District, Shenzhen 深圳市迎丰天线技术有限公司 SHEN ZHEN YINGFENG ANTENNA TECHNOLOYCO.,LTD Prepared by : harry Designed by : andy Checked by : andy Approved by：oliver TITLE：5.0 x2.0 x 0.6mm) WiFi/Bluetooth Ceramic Chip Antenna (YF500A) Engineering Specification DOCUMENT YF5020H1R2G4502 REV. NO. C PAGE 2 OF 10 2. Features *Stable and reliable in performances *Low temperature coefficient of frequency *Low profile, compact size *RoHS compliance *SMT processes compatible 3. Applications *Bluetooth earphone systems *Hand-held devices when WiFi /Bluetooth functions are needed, e.g., Smart phone. *IEEE802.11 b/g/n *ZigBee *Wireless PCMCIA cards or USB dongle 4. Description Ying feng chip antenna series are specially designed for WiFi/Bluetooth applications. Based on yingfeng proprietary design and processes, this chip antenna has excellent stability and sensitivity to consistently provide high signal reception efficiency. 5. Electrical Specifications (40 x 40 mm 2 ground plane) 5-1. Electrical Table Characteristics Specifications Unit Outline Dimensions 5.0x2.0x0.6 mm Working Frequency 2400~2500 MHz VSWR 2 Max. Impedance 50  Polarization Linear Polarization Gain Peak 2 (typical) dBi Efficiency 75 (typical) % 5-2. Return Loss & VSWR Return Loss (S 11 ) Smith Chart(S 11 ) 深圳市迎丰天线技术有限公司 SHEN ZHEN YINGFENG ANTENNA TECHNOLOYCO.,LTD Prepared by : harry Designed by : andy Checked by : andy Approved by：oliver TITLE：5.0 x2.0 x 0.6mm) WiFi/Bluetooth Ceramic Chip Antenna (YF500A) Engineering Specification DOCUMENT YF5020H1R2G4502 REV. NO. C PAGE 3 OF 10 6 Outline Dimensions of Antenna & Evaluation Board (unit: mm) 6-1. Antenna Dimensions Configuration and Dimensions: 深圳市迎丰天线技术有限公司 SHEN ZHEN YINGFENG ANTENNA TECHNOLOYCO.,LTD Prepared by : harry Designed by : andy Checked by : andy Approved by：oliver TITLE：5.0 x2.0 x 0.6mm) WiFi/Bluetooth Ceramic Chip Antenna (YF500A) Engineering Specification DOCUMENT YF5020H1R2G4502 REV. NO. C PAGE 7 OF 10 7-2. 3D Efficiency Table Z X Y Y X X Y Z Z 深圳市迎丰天线技术有限公司 SHEN ZHEN YINGFENG ANTENNA TECHNOLOYCO.,LTD Prepared by : harry Designed by : andy Checked by : andy Approved by：oliver TITLE：5.0 x2.0 x 0.6mm) WiFi/Bluetooth Ceramic Chip Antenna (YF500A) Engineering Specification DOCUMENT YF5020H1R2G4502 REV. NO. C PAGE 8 OF 10 Frequency( MHz) 2400 2410 2420 2430 2442 2450 2460 2470 2480 2490 2500 Efficiency (dB) -1.4 -1.0 -0.9 -0.7 -0.7 -0.8 -0.9 -1.1 -1.2 -1.3 -1.4 Efficiency (%) 70.8 71.7 72.3 74.4 74.5 75.0 74.0 73.6 72.1 71.6 70.5 Gain (dBi) 1.9 2.1 2.3 2.4 2.5 2.5 2.4 2.3 2.2 2.1 1.8 深圳市迎丰天线技术有限公司 SHEN ZHEN YINGFENG ANTENNA TECHNOLOYCO.,LTD Prepared by : harry Designed by : andy Checked by : andy Approved by：oliver TITLE：5.0 x2.0 x 0.6mm) WiFi/Bluetooth Ceramic Chip Antenna (YF500A) Engineering Specification DOCUMENT YF5020H1R2G4502 REV. NO. C PAGE 9 OF 10 深圳市迎丰天线技术有限公司 SHEN ZHEN YINGFENG ANTENNA TECHNOLOYCO.,LTD Prepared by : harry Designed by : andy Checked by : andy Approved by：oliver TITLE：5.0 x2.0 x 0.6mm) WiFi/Bluetooth Ceramic Chip Antenna (YF500A) Engineering Specification DOCUMENT YF5020H1R2G4502 REV. NO. C PAGE 10 OF 10

ReportNo.:PTC26052217801E-FC01 Page 1 of 88 FCCTESTREPORT FCCID:2A5EQ-2605HS1 Product:Head-mountedtriple-modegamingheadset ModelName:SS202 Brand:LTC ReportNo.:PTC26052217801E-FC01 Preparedfor LTCNetworkingLimited FLAT/RM1205,12/FTaiSangBankBuilding130-132DESVoeuxRoadCentralHongKong Preparedby PreciseTesting&CertificationCo.,Ltd. Building1,No.6,TongxinRoad,DongchengStreet,Dongguan,Guangdong,China ReportNo.:PTC26052217801E-FC01 Page 2 of 88 1TESTRESULTCERTIFICATION Applicant’sname:LTCNetworkingLimited Address:FLAT/RM1205,12/FTaiSangBankBuilding130-132DESVoeux RoadCentralHongKong Manufacture'sname:GuangdongZeusInteractiveEntertainmentTechnologyCo.,Ltd. Address:No.240,LiuwuXinfengWestRoad,ShijieTown,DongguanCity, GuangdongProvince Productname:Head-mountedtriple-modegamingheadset Modelname:SS202 Standards:FCCCFR47Part15Section15.247 Testprocedure:ANSIC63.10-2020 TestDate: June03,2026toJune22,2026 DateofIssue: June28,2026 TestResult:Pass ThisdevicedescribedabovehasbeentestedbyPTC,andthetestresultsshowthatthe equipmentundertest(EUT)isincompliancewiththeFCCrequirements.Anditisapplicable onlytothetestedsampleidentifiedinthereport. Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofPTC,this documentmaybealteredorrevisedbyPTC,personalonly,andshallbenotedintherevision ofthedocument. TestEngineer: Jackzhou/Engineer TechnicalManager: SimonPu/Manager ReportNo.:PTC26052217801E-FC01 Page 3 of 88 Contents Page 1TESTRESULTCERTIFICATION...............................................................................................................................2 2TESTSUMMARY..........................................................................................................................................................5 3TESTFACILITY.............................................................................................................................................................5 4GENERALINFORMATION..........................................................................................................................................6 4.1GENERALDESCRIPTIONOFE.U.T.....................................................................................................................6 4.2TESTMODE.........................................................................................................................................................7 5EQUIPMENTDURINGTEST......................................................................................................................................9 5.1EQUIPMENTSLIST...............................................................................................................................................9 5.2MEASUREMENTUNCERTAINTY.........................................................................................................................11 5.3DESCRIPTIONOFSUPPORTUNITS...................................................................................................................12 6CONDUCTEDEMISSION..........................................................................................................................................13 6.1E.U.T.OPERATION............................................................................................................................................13 6.2EUTSETUP.......................................................................................................................................................13 6.3TESTSET-UP(BLOCKDIAGRAMOFCONFIGURATION).................................................................................14 6.4MEASUREMENTPROCEDURE:...........................................................................................................................14 6.5CONDUCTEDEMISSIONLIMIT...........................................................................................................................14 6.6MEASUREMENTRECEIVERPARAMETERS:.......................................................................................................15 6.7CONDUCTEDEMISSIONTESTRESULT.............................................................................................................15 7RADIATEDSPURIOUSEMISSIONS......................................................................................................................18 7.1EUTOPERATION...............................................................................................................................................18 7.2TESTSETUP......................................................................................................................................................19 7.3SPECTRUMANALYZERSETUP..........................................................................................................................20 7.4TESTPROCEDURE.............................................................................................................................................21 7.5SUMMARYOFTESTRESULTS...........................................................................................................................22 8MAXIMUMPEAKOUTPUTPOWERTEST............................................................................................................29 8.1TESTSTANDARDANDLIMIT..............................................................................................................................29 8.2TESTSETUP......................................................................................................................................................29 8.3TESTPROCEDURE.............................................................................................................................................29 8.4TESTDATA.........................................................................................................................................................30 ReportNo.:PTC26052217801E-FC01 Page 4 of 88 920DBOCCUPYBANDWIDTHTEST.............…
