2A5GJ-TD001F-10Foot Massager

User Manual 360°ALL DIRECTIONAL FOOT MASSAGER FOOT MASSAGER Safety Instructions Warranty Product Components Features and Use Diagram Setting Specifications Troubleshooting Maintenance Safety Instructions Important Safety Instructions 01) Be sure to read the user manual in a detailed way prior to use to ensure safety and proper use of the product 02) Make sure to use the product by following the instructions in this manual 03) After using or before cleaning the product. please disconnect to the power 04) Always cautiously use the heating function to avoid serious burn 05) Do not apply the product to too insensitive and over sensitive skin or to body parts of poor blood circulation 06) Never allow children or those of physical and mental disorders to use the heating function or improper operation that may be dangerous 07) To prevent fire,electric shock or injuries caused by overheating, never use it under a pillow or a blanket 08) Do not cover it during use so as to avoid malfunction or damage resulting from motor overheating 09) Children, those of physical and mental disorders and the disabled should be under guide when using the product 10) Please stop using it immediately if you feel uncomfortable 11) When the power cords or plugs are damaged,inappropriate operation is performed and the product has been dropped or damaged or dropped into water.do not use this product please contact the service center tor check and repair 12) Do not use spare parts that are not recommended by the manufacture 13) Do not insert or drop objects into any opening of the product 14) Please close all operation control before disconnecting the product to the power if you want to cut off the power 15) This product cannot be used for self-diagnosis or treatment and please visit professional medical care if in need of diagnosis or treatment Use Environment 01) Do not use the product in a wet or dusty environment in order to avoid product failure 02) Do not use this product at room temperature over 40 03) Do not use the product outdoor 04) Do not use the product next to an electric heater or scores or in direct sunlight Safety Instructions People Not recommended Using the Product 01) Please consult your doctor before using if you have the following situations 02) Receiving medical treatment or experiencing physical discomfort 03) Suffering from hypertension.heart disease. cerebral arterioscIerosis.and cerebral thrombosis 04) Suffering from cancer 05) Pregnant or in a period 06) Suffering from osteoporosis 07) Using a pacemaker or implantable medical devices 08) Suffering from acute diseases 09) Minors Buttons 01) Do not operate the button with wet hands 02) Keep the buttons from water or other liquid 03) Do not fall asleep when using the product 04) Do not use this product when you are drunk or feeling uncomfortable 05) Do not directly contact the massager pad with your hands, feet joints, knees chest, and abdomen 06) Do not use this product over thirty minutes in a row 07) Do not use if the product’s cloth cover has been damaged 08) Do not use the product one hour before and after eating so as to avoid adverse effects 09) Do not enable the heating function when the product is being used in a low room temperature It is recommended that you should gradually adjust the temperature to a normal range before enabling heating 10) If the product is used immediately after being transferred From a cold environment to a warm environment, the accumulation of water vapor inside the product may affect the normal operation of the product or even cause mechanical failure You are suggested Io put the product in normal room temperature for I hour before starting to use it after the transfer Warranty 01) Warranty is not transferable 02) Users can enjoy free warranty from the date of purchase during the warranty period(The surface is not covered under warranty) 03) The product warranty is valid for 12 months from the invoice date 04) If we write that supplier shall provide a warranty card 05) The purchasing date shall be based on the effective receipt or, invoice issued by the retailers 06) This warranty.shall not apply to leasing.trade.ecommerce.institutions and other non-buyer users 07) The following situations are not covered the warranty a) Destruction caused by human factors.including the non-normal using environment usage and storage that are not compliant to the instructions. and damage caused by improper use.etc b) Disassemble .repair and modification of the product without our authorization c) Damage caused by users poor transportation after Purchase d) Damage resulting from any other force majeure (such as flood, fire.lightning and earthquakes) Product Components Central Surface: Six independent buttons – controlling the product’s settings and functions Central Massager Pad:Scratching-Acupressure on the arches with heating Front Massager Pad:Roller Kneading-Acupressure on the front soles Rear Massager Pad:Push Kneading-Acupressure on the heels Interior airbag-Air pressure on the insteps Removable and washable fabric cover-cleaning Bottom:Cord Wrap-keeps things tidy Features and Use Diagram Pr oduct Features 01) Egg-shaped design.fashionable and beautiful.Lightweight and portable 02) A combination of a variety of function including scratching.roller kneading and push kneading acupressure, air pressure, and heating 03) Massager Pad that provides all-around massages and in -deep acupressure to clear the body’s meridians and foot reaction zones 04) Removable and washable cover, allowing you to keep clean at any moment 05) Cord wrap. bringing convenience to life Use Diagram Settings 1.Power: Turns on/off the machine 2.Mode: Switch between three massage modes (default mode 1) 3.Intensity: Controls the massage intensity,to your preference (9 IeveIs,defauIt intensity 5) 4.Time: Set massage time (05-30mins,default 15mins) 5.Heat: Press the button to control the heating independently (default on) 6.Vibration: U1 U2 two levels (default…

Text truncated - open the document above for the full version.

Zhejiang Todo Hardware Manufacture Co .,Ltd Agent Authorization Company: Zhejiang Todo Hardware Manufacture Co .,Ltd Ltd.Address: 31F Jinmao Building CBD center Yongkang city Zhejiang Province ,China Product Name: Foot Massager Model Number(s): TD001F-10, TD001F, TD001F-A TD001F-B TD001F-1,TD001F-1A TD001F-1B,TD001F-2, TD001F-3, TD001F-4, TD001F-5, TD001F-6, TD001F-7, TD001F-8, TD001F-9,TD001F-10, TD001F-11, TD001F-12, TD001F-13, TD001F- 14 ,TD001F-15 Product Description: Foot Massager We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2022-05-31 Name: Gong shasha Title: manager Company: Zhejiang Todo Hardware Manufacture Co .,Ltd

Zhejiang Todo Hardware Manufacture Co .,Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2022/05/31 Subject; Request for Confidentiality FCC ID: 2A5GJ-TD001F-10 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Gong shasha Title: manager

Zhejiang Todo Hardware Manufacture Co .,Ltd Model Difference Data：2022.05.31 Product description: Foot Massager Model name: TD001F-10, TD001F, TD001F-A TD001F-B TD001F-1,TD001F-1A TD001F-1B,TD001F-2, TD001F-3, TD001F-4, TD001F-5, TD001F-6, TD001F-7, TD001F-8, TD001F-9,TD001F-10, TD001F-11, TD001F-12, TD001F-13, TD001F- 14 ,TD001F-15 Trade Name: N/A FCC ID: 2A5GJ-TD001F-10 All the model are the same circuit, except model names . Regards Sincerely Client’s signature : Client’s name / title : Gong shasha（manager） Contact information / address：31F Jinmao Building CBD center Yongkang city Zhejiang Province ,China

External Photos

Model: TD001F-10 FCC ID: 2A5GJ-TD001F-10 Label Location

Internal Photos

Report No.: CTB2200509020RFX Ver. A.1 Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 / 19 EMC TEST REPORT Product Name Foot Massager Trade mark N/A Model No. TD001F-10, TD001F, TD001F-A TD001F-B TD001F-1,TD001F-1A TD001F-1B,TD001F-2, TD001F-3, TD001F-4, TD001F-5, TD001F-6, TD001F-7, TD001F-8, TD001F-9,TD001F-10, TD001F-11, TD001F-12, TD001F-13, TD001F-14 ,TD001F-15 FCC ID: 2A5GJ-TD001F-10 Report No. CTB2200509020RFX Prepared For: Zhejiang Todo Hardware Manufacture Co .,Ltd Address: 31F Jinmao Building CBD center Yongkang city Zhejiang Province ,China Manufacturer: Zhejiang Todo Hardware Manufacture Co .,Ltd Address: 31F Jinmao Building CBD center Yongkang city Zhejiang Province ,Chi na Prepared by Shenzhen CTB Testing Technology Co., Ltd. Floor 1&2, Building A, No. 26 of Xinhe Road, Xinqiao Street, Baoan D istrict, Shenzhen, China Date of Receipt Apr. 24, 2022 Date of Test(s) Apr. 24, 2022 to May. 11, 2022 Date of Issue May. 11, 2022 Test Standard(s) CFR47, FCC Part 15 Subpart B, ANSI C63.4: 2014 Test Result: Pass In the configuration tested, the EUT complied with the standards specified above. Compiled by: Reviewed by: Approved by: Zack Zhu Bin Mei Rita Xiao Note: The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report shall not be reproduced except in full, without prior written approval of CTB. This document may be altered or revised by CTB, personnel only, and shall be noted in the revision of the document. Report No.: CTB2200509020RFX Ver. A.1 Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 / 19 Table of Contents 1. Description of version ............................................................................................................................................. 3 2. Test summary........................................................................................................................................................... 3 3. Measurement uncertainty ...................................................................................................................................... 4 4. General information ................................................................................................................................................ 5 4.1. Description of EUT ................................................................................................................................... 6 4.2. Description of accessory device ............................................................................................................ 6 4.3. Test conditions .......................................................................................................................................... 6 4.4. Block diagram of EUT configuration ..................................................................................................... 6 5. List of Test and Measurement Instruments ......................................................................................................... 7 6. Conducted Emission ............................................................................................................................................... 8 6.1. Limit ............................................................................................................................................................ 8 6.2. Test setup .................................................................................................................................................. 8 6.3. EMI test receiver setup ........................................................................................................................... 8 6.4. Test procedure .......................................................................................................................................... 8 6.5. Test results ................................................................................................................................................ 9 7. Radiated emissions .............................................................................................................................................. 11 7.1. Limit .......................................................................................................................................................... 11 7.2. Test setup ................................................................................................................................................ 11 7.3. EMI test receiver setup and spectrum analyzer setup .................................................................... 12 7.4. Test procedure ........................................................................................................................................ 12 7.5. Corrected Amplitude & Margin Calculation........................................................................................ 12 7.6. Test results .............................................................................................................................................. 13 8. Photographs of test setup .................................................................................................................................... 15 9. Photographs of EUT ............................................................................................................................................. 16 Report No.: CTB2200509020RFX Ver. A.1 Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 3 / 19 1. Description of version Report No. Issue Date Description Approved CTB2200509020RFX May. 11, 2022 Original Valid 2. Test summary Report No.: CTB2200509020RFX Ver. A.1 Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 4 / 19 Test procedures according to the technical standards: Standard Test Item Test Result §15.107 Conducted Emission PASS §15.109 Radiated Emission PASS 3. Measurement uncertainty The reported uncertainty of measurement …

Text truncated - open the document above for the full version.

Radiated Emission Below 1G Conducted Emission
